Orro Simple Multiway Bedienungsanleitung
Standard Switch Orro Switch
This installation guide is to be used only if
you are installing 1 Orro Switch where the
light(s) is controlled by 2 switches.
Simple Multiway Installation Guide
2
Need Help?
We're ready to assist you.
Installation FAQ:
General support:
Urgent issues:
Support hours:
getorro.com/setupfaq
(747) 253 0608
Weekdays 7am-7pm (PST)
Weekends 10am-6pm (PST)
1
Before We Start
3
Check Compatibility
7
Prepare for Install
11
Identify Wires
16
Install Orro
23
Set Up Orro
Troubleshooting
33
41
2
Before We Start
3
Installing Orro is a straightforward process but requires
handling high voltage wiring. Please be careful.
Hire a professional if you are not comfortable with the
installation or if you do not have the proper tools available.
Start the install during daylight or have a flashlight ready.
Switch installation requires your lights to be o.
Your rst time installing Orro may take up to 45 min.
You’ll get faster after each installation.
Be Safe
45
min
4
What’s in the Box
4x Wire Connectors 2x Mounting Screws
2x Plate Screws
6x Wire Labels
1x Orro Switch1x Faceplate & Mount 4x Extension Wires
5
Tools Needed
Power tools are not recommended.
Phillips
Screwdriver
Flathead
Screwdriver
Pliers
(recommended)
6
Check Compatibility
7
Maximum Load
Calculate the Total Load of your current light setup:
Identify your bulb type:
LED CFL Incandescent Halogen
Number of bulbs
controlled by switch
Wattage of
single bulb
x
[ [] ] =Total Load
LED MagLowV
CFL Incandescent
*360W max load if switch
is located in a wall box
with more than one switch
(multi-gang box)
ElecLowV
Halogen Fluorescent
150WMax Load
Bulb Type
300W 500W* 5A
Total Load must be less than Max Load (based on bulb type):
Example: [ 4 LED bulbs ] x [ 10 watts ] = 40 watts total load
Common bulb types:
(often plastic)
(often glass)
1
2
3
8
120V/60 Hz power is standard in residential homes in USA and Canada.
Orro does not rely on WiFi to make lighting decisions. However, the
switch must be connected to WiFi for setup, enabling certain features,
and getting updates.
120V/60 Hz Power Required
WiFi Required for Setup
