OSEE T5+ Bedienungsanleitung

ON CAMERA Monitor

User Manual

Product Information

Model:

T5+ ON CAMERA Monitor

Version:

V010000

Release Date:

October 24th, 2022

Company

OSEE TECHNOLOGY LTD.

Contact Information

OSEE TECHNOLOGY LTD.

Address:

No.22 Building, No.68 zone, Beiqing Road, Haidian

District, Beijing, China

Post Code:

100094

Tel:

(+86) 010-62434168

Fax:

(+86) 010-62434169

Web:

http://www.osee-dig.com/

E-mail:

[email protected]

About this manual

Important

The following symbols are used in this manual:

The further information or know-how for described subjects above

which helps user to understand them better.

The safety matters or operations that user must pay attention to when

using this product.

Contents

The user manual applies to the following device types:

T5 PLUS

The images and descriptions of T5+ are adopted as examples in the

following document.

Before reading the manual, please confirm the device type.

Contents

Contents.....................................................................................................I

Chapter 1 Overview..................................................................................1

Chapter 2 Safety.......................................................................................3

Chapter 3 Unpack and Installation.........................................................7

Chapter 4 Features.................................................................................13

4.1 Parts and Functions....................................................................13

4.2 Buttons and Functions...............................................................14

4.3 Operations ...................................................................................15

4.4 Power On .....................................................................................18

4.5 ZOOM&PAN..................................................................................19

4.6 Supported Signal Format...........................................................22

Chapter 5 Monitor Settings...................................................................25

5.1 Menu Operations.........................................................................26

5.2 Monitor Menu...............................................................................27

5.2.1 INPUT.......................................................................................27

5.2.2 Controls....................................................................................28

5.2.3 Camera Profile .........................................................................32

5.2.4 System .....................................................................................39

Chapter 6 Scenes and Tools.................................................................43

6.1 Scenes Tools Settings................................................................43

6.1.1 Frame Tools.............................................................................45

6.1.2 Expose Tools............................................................................49

6.1.3 Focus Tools..............................................................................58

6.1.4 Look Tools................................................................................60

6.1.5 Analysis Tools..........................................................................65

6.1.6 Meter Tools ..............................................................................68

6.2 Tools Operations.........................................................................69

6.2.1 Add a Scene.............................................................................69

6.2.2 Delete a Scene.........................................................................70

6.2.3 Add a Tool................................................................................71

6.2.4 Load/Close Tool Bar ................................................................74

6.2.5 Turn ON/OFF a Tool................................................................75

6.2.6 Tool Settings ............................................................................76

6.2.7 Delete a Tool............................................................................78

Chapter 7 Specifications.......................................................................81

7.1 Product detailed information.....................................................81

7.2 Dimensions..................................................................................83

Overview

Chapter 1 Overview

T5+ is a high-performance UHD HDMI On Camera Monitor to monitor

professional 4K HDMI for outdoor photography.

The unit is designed in a high impact plastic frame, and the professional

screen glass at full resolution of 1920x1080 with 450nit brightness makes

T5+ capable of reproducing a natural color. In addition, the monitor has

excellent assistant functionalities, versatile build-in color profiles and easy

to use.

Figure 1-1 A Diagram of T5+

Features

Support 4K HDMI input

Support output to external cameras, such as SONY, Panasonic,

Canon etc.

Support high qualified waveform, vector scope, histogram and

audio meter

Support multiple assistants: zebra, focus assist, exposure assist,

peaking adjust

Overview

Provide a five directions joystick as a navigation tool to scroll

between scenes pages and set features

Support SONY NP-F and Canon LP-E6 series batteries

Provide optional dummy battery adaptors to output battery DC

power to cameras

Functionality

Provide versatile build-in color profiles, supporting the general

profiles for ARRI, BMD, Canon, DCI, EBU, FUJI, NIKON,

Panasonic, RED and SONY, etc. And you can upload custom 3D

LUTs through SD card and apply to on Camera monitor

Support Anamorphic Desqueeze functionality in multiple modes:

1.33X, 1.4X, 1.5X, 1.6X, 1.8X, 1.9X, 2X

Support Image ZOOM functionality to double(2X) or

quadruple(4X) the image, and to pan the image in every

direction

Safety

Chapter 2 Safety

FCC Caution:

Any Changes or modifications not expressly approved by the party

responsible for compliance could void the user's authority to operate the

equipment.

This device complies with part 15 of the FCC Rules.

Operation is subject to the following two conditions: (1) This device may

not cause harmful interference, and (2) this device must accept any

interference received, including interference that may cause undesired

operation.

Note: This equipment has been tested and found to comply with the limits

for a Class B digital device, pursuant to part 15 of the FCC Rules. These

limits are designed to provide reasonable protection against harmful

interference in a residential installation. This equipment generates uses

and can radiate radio frequency energy and, if not installed and used in

accordance with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not

occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by

turning the equipment off and on, the user is encouraged to try to correct

the interference by one or more of the following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and receiver.

Connect the equipment into an outlet on a circuit different from that to

which the receiver is connected.

Consult the dealer or an experienced radio/TV technician for help.

Warnings:

Read, keep and follow all of these instructions for your safety. Heed all

Safety

warnings.

Device

Install in accordance with the manufacturer's instructions.

Do not touch the screen with sharp, metallic or abrasive objects.

Do not make the freeze picture displaying on the screen time too

long, otherwise, it will leave the afterimage on the screen.

If the brightness is adjusted to the minimum, then it might be

hard to see the display screen.

Clean only with dry cloth.

Do not block any ventilation openings. Leave enough space

around the unit for ventilation.

Do not expose to strong electrical or magnetic fields.

To reduce the risk of fire or electric shock, do not expose the unit

to rain or moisture.

If the product needs replacement parts, make sure that the

service person use replacement parts specified by the

manufacture, or those with the same characteristics and

performance as the original parts. Use of unauthorized parts can

result in fire, electric shock and/or other damage.

The panel used in this produce is made of glass. Therefore, it

can break when it is dropped or applied with impact. Be careful

not to be injured by broken glass pieces.

Refer all servicing to qualified service personnel.

Specifications are subject to change without notice.

Do not use attachments or accessories not recommended by the

manufacture. Use of inadequate attachments may result in
