Oster TSSTTVCG01 Bedienungsanleitung

User Manual

Countertop Oven

Manual de InstrucctionesHorno para

Mostrador

P.N. 147408

Visit us at www.oster.com

MODEL/MODELO

TSSTTVCG01

English-2

IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety precautions should always

be followed, including the following:

READ AND SAVE THESE

INSTRUCTIONS

• READALLINSTRUCTIONS,PRODUCTLABELSANDWARNINGSBEFOREUSINGTHE

COUNTERTOPOVEN.

• 

Donottouchhotsurfaces.Alwaysuseovenmittswhenhandlinghotmaterialsandallow

metalpartstocoolbeforecleaning.Allowtheunittocoolthoroughlybeforeputtingin

ortakingoffparts.Alwaysusetheovenhandleswhenmovingtheunit.

• Whentheunitisnotinuseandbeforecleaning,unplugthecountertopovenfromthe

walloutlet.Note:Makesuretheovenisturnedoffbeforeunplugging.

• Toprotectagainstriskofelectricalshock,donotimmersetheapplianceinwateror

anyotherliquids.

• Closesupervisionisalwaysnecessarywhenthisoranyapplianceisused

nearchildren.Thisapplianceisnotforusebychildren.

• Donotoperatethisoranyappliancewithafrayedordamagedcordorplugorafterthe

appliancemalfunctionsorisdroppedorhasbeendamagedinanymanner.Returnthe

countertopoventothenearestAuthorizedSunbeamApplianceServiceCenter

forexamination,repairorelectricalormechanicaladjustment.

• Donotuseattachmentsnotrecommendedbythemanufacturer;theymaycausefire,

electricshockorpersonalinjury.

• Donotuseoutdoorsorforcommercialpurposes.

• Donotusethisapplianceforotherthanitsintendeduse.

• Donotletthecorddangleovertheedgeofatabletoporcountertop

ortouchhotsurfaces.

• Donotplacetheappliancenearahotgasorelectricburnerorinaheatedoven.

• Extremecautionshouldbeusedwhenusingcontainersconstructedofmaterialother

thanmetalorglass.

• Afiremayoccurifthecountertopoveniscoveredortouchingflammablematerials,

includingcurtains,draperies,walls,etc.,wheninoperation.Donotstoreanyitemson

topoftheappliancewheninoperation.

English-3

• Whenusingcountertopoven,pulltheunitoutaminimumof6inchesawayfromthe

wallorothercords.

• Donotstoreanymaterials,otherthanmanufacturer’srecommendedaccessories,

inthisunitwhennotinuse.

• Donotplaceanyflammablematerialsinoven,suchaspaper,cardboard,

plasticoranymaterialsthatmaycatchfireormelt.

• Donotcovertheoventraywithmetalfoil.Thiswillcauseoverheatingoftheappliance.

• Oversizedfoodsormetalutensilsmustnotbeinsertedintheapplianceastheymay

createafireorriskofelectricalshock.

• Donotcleanwithmetalscouringpads.Piecescanbreakoffthepad

andtouchelectricalpartsinvolvingariskofelectricalshock.

• Useextremecautionwhenremovingpanordisposingofhotgreaseorotherhot

liquids.

• Toturnthisapplianceoff,returnallcontrolstothe“OFF”positionandremovecord

fromoutlet.

This Unit Is for Household Use Only

Short Power Supply Cord Instructions

Ashortpower-supplycordisprovidedtoreducetheriskresultingfrombecoming

entangledinortrippingoveralongercord.Anextensioncordmaybeusedifcare

isexercisedinitsuse.Ifanextensioncordisused,theelectricalratingofthecord

mustbeatleastasgreatastheelectricalratingoftheappliance.Theextensioncord

shouldbearrangedsothatitwillnotdrapeoverthecountertoportabletopwhereit

canbepulledonbychildrenortrippedoverunintentionally.

For Products Purchased in the United States and Canada Only

Toreducetheriskofelectricalshock,thisappliancehasapolarizedplug(one blade

is wider than the other).Thisplugfitsapolarizedoutletonlyoneway;iftheplug

doesnotfitfullyintotheoutlet,reversetheplug.Ifitstilldoesnotfit,contacta

qualifiedelectrician. Do not attempt to defeatthissafetyfeature.

SAVE THESE INSTRUCTIONS

English-4

Learning about Your Countertop oven

1. ToastezeTM Control Knob – Turn the knob to select how dark you would like

your food toasted; 1 is lightest, 7 is darkest. (See Figure 1)

2. Function Selector Knob – Select cooking function by turning knob to desired

setting. (See Figure 2)

3. Temperature Control Knob – Adjust the dial thermostat to the desired

temperature. (See Figure 3)

4. Timer Control Knob with Bell Signal – Set cooking time up to 60 minutes.

Will automatically turn the oven OFF at the end of the cooking time. (See

Figure 4)

5. Removable Crumb Tray – For crumb or fallen food particles collection. Pulls

out for easy cleaning.

6. Removable Wire/Broil Rack – Use for all your broiling and grilling needs. See

“Positioning Rack” section.

7. Tempered Glass Door – For front viewing of food.

6 7

Figure 2Figure 1 Figure 3 Figure 4

English-5

8. Two Rack Positions

9. Baking Pan & Cookie sheet in one – Use for all your baking needs.

10. Easy Clean Interior Walls – Allows fast clean up.

preparing to use Your Countertop oven for the first time

NOTE: During initial start up you may detect a slight smell and/or smoke.

Turn the temperature to max and let run for approximately 5 minutes.

If you are using your Countertop oven for the first time, please be sure to:

• Remove any stickers from the surface of the oven.

• Open oven door and remove all printed documents and paper from

inside the Countertop Oven.

• Clean the rack and pan with hot water, a small amount of dishwashing

liquid and a non-abrasive cleaning pad.

• DO NOT IMMERSE THE BODY OF THE UNIT IN WATER.

• Dry the unit thoroughly before using.

• Select a location for the Countertop Oven. The location should be in

an open area on a flat counter where the plug will reach an outlet.

• Plug the Countertop Oven into a 120 Volt AC electrical outlet.

WARNING: When Countertop Oven is in use or cooling down, please be

sure there is a 6-inch clearance between the Countertop Oven and any other

surface including cords. Be sure the cord is not resting against the back of the

Countertop Oven.

English-6

to use the toastezetm funCtion (see fig. 5)

We simplified toasting for more precise, consistent

results with less hassle. To use this function, simply

select your ideal shade from light to dark with no

timing guesswork. Next time, select the same shade

for perfect toasting results.

Step 1. Place food on Wire Rack.

Step 2. Close glass door completely.

Step 3. Turn the Function dial to Toast.

Step 4. Select the desired darkness setting by

turning the Toasteze™ Control Knob to the

desired toast shade.

Step 5. When toasting is complete, a bell will

sound. Open door completely and remove

food. For best toasting results, position the

rack in the upper position. **

NOTE: If the function selector knob is not on

Toast, the Toasteze™ Control Knob will

not turn the unit ON (heating elements).

Special Note: For best toasting results, position the

rack in the upper rack guide.

to use the turbo ConveCtion heat

funCtion (see fig. 6)

The Turbo Convection Heat Function turns on

a built in fan that circulates hot air in the oven

chamber cooking your food faster and more evenly.

Preheat oven 5-7 minutes at desired temperature

with oven rack in place.

Step 1. Place baking pan with food inside on

wire rack.

Step 2. Close glass door completely.

Step 3. Turn the Function dial to Turbo.

Step 4. Turn the Temperature dial to desired setting.

Step 5. Turn the Timer to desired cook time.*

Step 6. When baking is complete, open door

completely and remove food.**

Figure 5

Figure 6

English-7

Figure 7

faQs about turbo ConveCtion heat

What is Turbo Convection Heat?

Answer: In your Countertop Oven there is a built in

fan that circulates the hot air in the oven chamber

cooking your food faster and more evenly.

How do I adjust the time for Turbo Convection?

Answer: On average, the Turbo function will

shorten the cooking time by 30% but it varies by

food. It is suggested to go with a shorter cooking

time to start with and then add time if it is needed.

What are the best foods to use with Turbo?

Answer: While a shorter cook time is often

desirable, bake goods in particular benefit from

Turbo cooking as the circulating air keeps oven

temperature consistent throughout.

to use the bake funCtion (see fig. 7)

Step 1. Place baking pan with food inside on

wire rack.

Step 2. Close glass door completely.

Step 3. Turn the Function dial to Bake.

Step 4. Turn the Temperature dial to desired setting.

Step 5. Turn the Timer to desired cook time.*

Step 6. When baking is complete, open door

completely and remove food.**

English-8

to use the Warm funCtion (see fig. 8)

Step 1. Place baking pan with food inside on

wire rack.

Step 2. Close glass door completely.

Step 3. Turn the Function dial to Warm.

Step 4. Turn the Temperature dial to 200º F.

Step 5. Turn the Timer to desired warming time.*

Step 6. When Warming is complete, open door

completely and remove food.**

to use the broiL funCtion (see fig. 9)

Adjustable Broil allows the oven to broil at any

temperature. Great for melting cheese at 150º F

or cooking fish at 400º F. Adjust as needed.

Step 1. Place food on broil rack or on baking pan

if needed.

Step 2. Close glass door leaving approximately

a 3-inch opening at the top of the

Countertop Oven.

Step 3. Turn the Function dial to Broil.

Step 4. Turn the Temperature dial to desired

temperature.

Step 5. Turn the Timer to desired cook time.*

Step 6. When Broiling is complete, open door

completely and remove food.**

* Special note: If cook time is less than 20 minutes,

you must turn Timer past the 20

minute mark to engage the timer

then back to desired time.

** WARNING: Cooked food and metal rack can be

very hot, handle with care. Do not

leave Countertop Oven unattended.

Figure 9

Figure 8

English-9

NOTE: For Turbo, Warm, Bake and Broil: If the Function Selector Knob is

on Toast the Timer Control Knob will not turn the unit ON (heating

elements).

positioning raCk

• To accommodate a wide variety of foods the oven has two rack positions.

The rack can be inserted in the oven in the upper or lower rack guides. The

rack will fit into either of the rack guides inside of the Countertop Oven.

(See Figure Below)

• Before removing the rack allow the unit to cool.

• To remove the rack, open the oven door and pull the rack towards the front

of the oven. The rack will slide on the rack guides on the inside of the oven.

PLEASE NOTE: the oven rack may tilt downward causing food to shift when

the rack is pulled out, proceed with caution.

• Positioning of the oven rack will depend on the size of the food and

desired browning. Move the rack to the lower rack position to prevent top

browning and move the rack to the upper rack position to prevent bottom

burning.

• For best toasting results, position the rack in the upper rack guide.

raCk guide

options

English-10

positioning pan

• To accommodate a wide variety of foods the oven has two pan positions.

The pan can be placed on top of the rack or inserted into the guide rails

below the rack. (See Figure Below)

• Before removing the pan allow the unit to cool.

• Positioning of the oven pan will depend on the desired cooking method.

For baking, place the pan on top of the rack. For grilling or broiling, insert

the pan into the guide rails below the rack and place the food on top of the

rack.

for

baking

for

griLLing or

broiLing

CLeaning Your Countertop oven

DO NOT IMMERSE IN LIQUIDS.

Step 1. Turn all knobs to “OFF” position and remove plug from electrical

outlet. Allow to cool.

Step 2. Wipe unit down with damp cloth. DO NOT IMMERSE IN WATER.

Make sure to only use mild, soapy water. Abrasive cleaners, scrubbing

brushes and chemical cleaners will damage the coating on this unit.

Step 3. Remove crumb tray by pulling out of Countertop Oven.

Step 4. Shake off crumbs from crumb tray. Cleaning the crumb tray often will

avoid any accumulations.

Step 5. Remove wire rack and clean with damp cloth or place in top rack of

dishwasher.

storing Your Countertop oven

Allow the appliance to cool completely before storing. If storing the

Countertop Oven for long periods of time make certain that the Countertop

Oven is clean and free of food particles. Store the Countertop Oven in a dry

location such as on a table or countertop or cupboard shelf. Other than the

recommended cleaning, no further user maintenance should be necessary.

Inhaltsverzeichnis

Sprachen:

Andere Oster Ofen Handbücher

Oster

Oster TSSTTVMNDG Bedienungsanleitung

Oster

Oster TSSTTVSKBT Bedienungsanleitung

Oster

Oster TSSTTVRB04 Bedienungsanleitung

Oster

Oster TSSTTVFDXL2 Bedienungsanleitung

Oster

Oster 6235 Bedienungsanleitung

Oster

Oster 4831 Bedienungsanleitung

Oster

Oster TSSTTVDG01 Montageanleitung

Oster

Oster CKSTRS18-NP Bedienungsanleitung

Oster

Oster TSSTTVMNDG Bedienungsanleitung

Oster

Oster 4-Slice Toaster Oven Bedienungsanleitung

Oster

Oster TSSTTVFDDG Bedienungsanleitung

Oster

Oster TSSTTVMAF1 Bedienungsanleitung

Oster

Oster CKSTRS18-BSB Bedienungsanleitung

Oster

Oster TSSTTVLS25NS Bedienungsanleitung

Oster

Oster TSSTTVCG04 Bedienungsanleitung

Oster

Oster TSSTTV7052 Bedienungsanleitung

Oster

Oster 6204 Bedienungsanleitung

Oster

Oster TSSTTVXLDG-003 Bedienungsanleitung

Oster

Oster TSSTTVXXLL-049 Bedienungsanleitung

Oster

Oster TSSTTVSK01 Bedienungsanleitung

Oster

Oster TSSTTVCF01 Bedienungsanleitung

Oster

Oster TSSTTVCG04 Bedienungsanleitung

Oster

Oster TSSTTV10LTR Bedienungsanleitung

Oster

Oster TSSTTV7118 Bedienungsanleitung

Beliebte Ofen Handbücher anderer Marken

Bosch

Bosch HVA531NS0 Bedienungsanleitung

Electrolux

Electrolux EOF6P46X Bedienungsanleitung

NEFF

NEFF B44S32 5GB Series Bedienungsanleitung

Combi

Combi BLODGETT BC142GDS Bedienungsanleitung

AEG

AEG COMPETENCE 311704300 Bedienungsanleitung

Falcon

Falcon DOMINATOR PLUS G3106 Series Benutzerhandbuch

Rational

Rational SCC WE 61G Bedienungsanleitung

Smeg

Smeg DOSPA38X Installations- und Betriebshandbuch

Electrolux

Electrolux air-o-convect 20 GN 2/1 Bedienungsanleitung

Miele

Miele HR 1954-2 Bedienungsanleitung

KHIND

KHIND OT50 Bedienungsanleitung

Henny Penny

Henny Penny Smoker Box Bedienungsanleitung

Lang

Lang ECOD-AP Bedienungsanleitung

AEG

AEG BEK455310M Bedienungsanleitung

Frigidaire

Frigidaire FNGE90JGR Bedienungsanleitung

Hotpoint

Hotpoint FE9 S831 JSH IX Bedienungsanleitung

GE Advantium SCB2000 Bedienungsanleitung

AEG

AEG DE401301DM Bedienungsanleitung
