Oton Geek N8 Bedienungsanleitung

User Manual

8CH Touch Screen NDI Switcher With Built-in Camera Control

Model -Oton Geek N8

Introduction

Thank you very much for using our portable broadcast platform products!please read the manual

carefully before using this product.

This manual describes in detail the functions, installation and operation of the portable broadcast

station general principles or methods.

This series of portable broadcast station is a high performance, multi - function product of live

broadcast switching station.

This manual is applicable to portable broadcast station series products.

Warnings and Precautions

1. Read all of these warnings and save them for later reference.

2. Follow all warnings and instructions marked on this unit.

3. Unplug this unit from the wall outlet before cleaning. Do not use liquid or aerosol cleaners. Use a

damp cloth for cleaning.

4. Do not use this unit in or near water.

5. Do not place this unit on an unstable cart, stand, or table. The unit may fall, causing serious

damage.

6. Slots and openings on the cabinet top, back, and bottom are provided for ventilation. To ensure

safe and reliable operation of this unit, and to protect it from overheating, do not block or cover these

openings. Do not place this unit on a bed, sofa, rug, or similar surface, as the ventilation openings on

the bottom of the cabinet will be blocked. This unit should never be placed near or over a heat register

or radiator. This unit should not be placed in a built-in installation unless proper ventilation is provided.

7. This product should only be operated from the type of power source indicated on the marking

label of the AC adapter. If you are not sure of the type of power available, consult our local dealer or

your local power company.

8. Do not allow anything to rest on the power cord. Do not locate this unit where the power cord will

be walked on, rolled over, or otherwise stressed.

9. If an extension cord must be used with this unit, make sure that the total of the ampere ratings

on the products plugged into the extension cord do not exceed the extension cord rating.

10. Make sure that the total amperes of all the units that are plugged into a single wall outlet do not

exceed 15 amperes.

11. Never push objects of any kind into this unit through the cabinet ventilation slots, as they may

touch dangerous voltage points or short out parts that could result in risk of fire or electric shock.

Never spill liquid of any kind onto or into this unit.

12. Except as specifically explained elsewhere in this manual, do not attempt to service this product

yourself. Opening or removing covers that are marked “Do Not Remove” may expose you to dangerous

voltage points or other risks, and will void your warranty. Refer all service issues to qualified service

personnel.

13. Unplug this product from the wall outlet and refer to qualified service personnel under the

following conditions:

a. When the power cord is damaged or frayed;

b. When liquid has spilled into the unit;

c. When the product has been exposed to rain or water;d. When the product does not operate

normally under normal operating conditions. Adjust only those controls that are covered by the

operating instructions in this manual; improper adjustment of other controls may result in damage to

the unit and may often require extensive work by a qualified technician to restore the unit to normal

operation;

e. When the product has been dropped or the cabinet has been damaged;

f. When the product exhibits a distinct change in performance, indicating a need for service.

Warranty Terms

For products purchased through resellers and distributors, please refer to the return policy of the

merchant from whom it was initially purchased; any products eligible for return or replacement

through the original merchant should be submitted through them. We will only accept direct return of a

product for replacement, under the stated warranty service after the original return time frame of

place of purchase has expired.

Standard Warranty

Oton equipment is guaranteed against any manufacturing defects for one year for limited parts

and labor from the date of purchase.

Oton equipment is guaranteed against any manufacturing defects for one year for limited parts

and labor from the date of purchase.

The original purchase invoice or other documentary evidence should be supplied at the time of

any request for repair under warranty.

The product warranty period beings on the purchase date. If the purchase date is unknown, the

product warranty period begins on the thirtieth day after shipment from Oton office.

Warranty only valid in the country or region of purchase.

Shipping expenses are at Oton for any delivery claim - you get a defective piece at box just

opened.

What Is Not Covered

It is important to note that our warranty is not an unconditional guarantee for the duration of the

Program. Any replaced parts become the property of manufacturer. The Program does not apply to the

software component of a product or a product which has been damaged due to accident, misuse,

abuse, improper installation, usage not in accordance with product specifications and instructions,

natural or personal disaster, or unauthorized alterations, repairs or modifications.

The Program Does Not Cover Any Events Such As:

A. Any damages unrelated to manufacturing defects

B. Any unsuitable environment or use of the product, as determined by manufacturer

C. Any product which has been modified without official permission from manufacturer, or on which

the serial number or warranty sticker has been defaced, modified, or removed Damage, deterioration or

malfunction resulting from:

* Accident, abuse, misuse, neglect, fire, water, lightning, or other acts of god, commercial or

industrial use, unauthorized product modification or failure to follow instructions included with the

product

* Third party products using manufacturer components will not be covered by warranty.

* Any shipment damages (claims MUST be made with the carrier)

* Unauthorized repairs to the product will void the warranty

Manufacturer reserves the right to refuse to service any product which has been altered, modified or

repaired by any non-authorized personnel

Visit https://otontechnology.com/warranty/ or scan below QR code to register 2-year warranty for your

Oton switcher.

Table of Content

Introduction................................................................................................................................................................... 2

Warnings and Precautions..........................................................................................................................................2

Warranty Terms.............................................................................................................................................................3

Standard Warranty............................................................................................................................................... 3

What Is Not Covered............................................................................................................................................ 3

Register for 2-year Warranty............................................................................................................................. 4

Table of Content........................................................................................................................................................... 5

Overview........................................................................................................................................................................ 6

Control Surface.....................................................................................................................................................6

Rear Panel..............................................................................................................................................................6

Key Features..................................................................................................................................................................7

Technical Specification............................................................................................................................................... 7

Getting Started............................................................................................................................................................10

Using Multi-view.................................................................................................................................................10

Connecting NDI|HX Sources..............................................................................................................................11

Connecting HDMI Sources................................................................................................................................ 12

Importing Local Media........................................................................................................................................12

Importing RTSP/RTMP Video............................................................................................................................12

Removing Channel Video..................................................................................................................................14

Tally Indication.................................................................................................................................................... 14

Connection Diagram.......................................................................................................................................... 15

Switching Your Production.......................................................................................................................................16

Using Transition Effects.................................................................................................................................... 16

Using PinP............................................................................................................................................................16

Adding Logo......................................................................................................................................................... 17

Adding Titles........................................................................................................................................................18

On-Board PTZ Camera Control................................................................................................................................ 19

Controlling Audio........................................................................................................................................................ 21

Audio Mixing........................................................................................................................................................ 21

Adjust Volume.....................................................................................................................................................22

Audio Sync.......................................................................................................................................................... 22

Live Streaming via Ethernet.....................................................................................................................................22

Video Recording and Playback................................................................................................................................24

System Settings......................................................................................................................................................... 25

Overview

The Geek N8 combines a live switcher, H.264 video encoder, PTZ camera controller, video recorder and

audio mixer in one unit. Live production for live musical performances, lectures, presentations and church

service can now be done easily by one operator, instead of the multiple operators that are usually required.

It is also compliant with the NDI|HX standards, enabling connection and control of the remote camera to be

performed through the same LAN cable with power provided* for smooth remote shooting. RTMP

(Real-Time Messaging Protocol) is also supported. Footage can be directly uploaded to various streaming

services such as YouTube Live.

Control Surface

Geek N8’s control surface features a traditional video mixer’s program and preview row configuration, with

CUT and AUTO buttons. It also features audio volume control and camera control including 4D Joystick PTZ

control, focus, exposure, iris, gain and white balance control for up to 8 cameras. Plus, it support recording,

live streaming control as well.

Rear Panel

The rear panel provides connections to a wide range of A/V equipment. Connecting NDI|HX equipment

using the LAN port. Keyboard, mouse and external USB disk can be connected to the USB2.0/3.0

connectors at left, while HDMI camera or computers and a monitor for viewing Program video are supported

by HDMI port. Connect audio sources like microphones or audio mixers to the 6.35mm or R/L audio inputs.

The tally allows to view camera status while sys port is for internal usage only.

Key Features

8 channel inputs from NDI|HX, HDMI , USB local video or online decoding video

Built-in 10.1 inch multiview screen

Touch screen or mouse & keyboard control for configuration

HDMI out for viewing program video on big screen

Exciting transition effects including wipe, mix, fade,PinP etc

Support add logo overlay

Built-in title templates for smooth stream workflow

1 pair 6.35mm audio + 1 pair R/L audio in

1 pair R/L audio + 1x3.5mm audio out for audio monitoring

Individual audio channel control on volume, audio mixing (on/off/AFV),including analog audio

Support audio delay for program video between 0-500ms

Multi-stream to 2 service platforms at the same time via RTMP protocol

Record program video to USB drive directly

Support live playback of recorded videos

Support digital clock for time Synchronization

Support Tally indication for camera status

Built-in camera control for pan, tilt, zoom, location preset, focus, exposure, gain, white balance etc

Technical Specification

Connections

Video Source

NDI®|HX, HDMI V1.4 Type-A, USB local video, RTSP online video

Video Output

HDMI V1.4 Type-A

Audio Source

1 pair 6.35mm audio + 1 pair R/L audio

Audio Output

1 pair R/L audio + 1x3.5mm audio

Screen

10.1 inch

USB 2.0 Port

Mouse & Keyboard, load local video, video recording

USB 3.0 Port

Mouse & Keyboard, load local video, video recording

Ethernet

10/100/1000Mb/s, NDI Connection, live stream, video decoding, NMS,

camera control

Tally

DB-9 pin

Video Standard

HD Video Resolution

720p30, 1080p 25/30/50/60

Built-in Screen Res.

1920x1080

Multiview Video Format

16:10

Program Out

1080p 60

HD Video Sampling

4:2:2 YUV

Color Accuracy

10 bit

Color Space

Rec 709

Computer HDMI In

1280x720p 50/59.94/60, 1920x1080p 25/29.97/30/50/59.94/60

USB Video Format

MP4

USB Still Format

PNG,JPG

Online Video Protocol

RTSP, NDI®|HX, Onvif，HLS,FLV

Online Video Address Preset

Audio Standard

Audio Mixing

8 Channel in total

Analog Audio In

Unbalanced stereo audio

Audio Control

Volume, audio on/off/AFV/gain

PGM Audio Delay

0-500ms adjustable

Audio Sampling

48kHz

Audio Format

AAC

Switching

Cut direct switching and Auto transition switching

Effects

Wipe, Fade, Mix etc

PinP Layout

Transition Rate

0.2-1s

Logo & Title

Logo Format

PNG,JPG

Logo Size

Less than 1MB

Logo Preset

Title Modes

Fixed/rolling title

Title Templates

4 default + 1

Title Preset

Live Streaming

Encoding

H.264

Protocol

RTMP

Bit Rate

High Bit Rate - 512/768kbps, 1/1.5/2 Mbps

Low Bit Rate - 3/5/8/12/16 Mbps

Resolution

High Bit Rate - 960x540, 1280x720,1920x1080

Low Bit Rate - 640x360, 736x416, 960x540

Frame Rate

High Bit Rate - 30/60 Fps

Low Bit Rate - 25/30 Fps

Stream Address Preset

Multistream

2 platforms at the same time

Audio Sampling

48kHz

Audio Bit Rate

80/96/128 Kbps

Video Recording

Recording Format

MP4

Resolution

1920×1080, 1280×960, 960×540, 736×416, 640×360

Recording Bit Rate

512KB, 768KB, 1MB, 2MB, 3MB, 5MB, 8MB, 12MB, 16MB, 20MB

USB Drive Format

FAT32, NTFS, exFAT

Camera Control

Controlling Camera

8 Max

Port

Ethernet

Protocol

NDI®|HX, VISCA

Pan & Tilt

4D Joystick- up, down, left, right

Zoom

Tele-Wide

Focus

Auto/Manual

Exposure

Auto/Manual

Iris

Manual

White Balance

Auto/Manual/Gain/Red Gain/Blue Gain

White Balance

Manual

Camera Location Preset

Power Requirement

Voltage

12V

Current

Power Consumption

36W Max

Environment

Working Temperature

-20℃~40℃(-4°F–104°F)

Storage Temperature

-20℃~40℃(-4°F–104°F)

Working Humidity

0%-90% no condensing

Storage Humidity

0%-90% no condensing

Dimension

Product Dimension

42x25.8x12cm / 16.54x10.16.4.72 inch

Package Dimension

47.5x32x14.5cm / 18.7x12.6x5.7 inch

Product N.W.

1.25kgs / 2.75lbs

Product G.W.

2.04kgs / 4.5lbs

System

Language

Simplified Chinese, Traditional Chinese, English

Upgrade

USB Drive

Warranty

1 year standard warranty for limited labor and parts

Package Content

Main Unit x1

HDMI Cable x1

Power Adapter x1

User Manual x1

Warranty Card x1

Getting Started

The switcher might seem intimidating with all the connectors and buttons, however the unit is actually very

easy to set up and use. Each feature serves a specific function and it won’t take long to get familiar with it

and know exactly what each feature does.This section of the manual will show you how to get started with

your switcher.

Plug in power using the supplied power adapter.

Connect your video sources to the inputs of video switcher - see tips below

Connect your monitor to the HDMI outputs of N8 via HDMI Cable for viewing program video

Connect your microphone/audio mixer to the 6.35mm or R/L audio inputs.

Connect amplifier to the R/L audio out or headphone to the 3.5mm port on the left upper corner of

Panel for audio monitoring

Connect mouse and keyboard to USB2.0/3.0 port of N8 if you want to use mouse and keyboard

control.

Turn on the power rocker switch at the rear of N8. At this point, the LED display will illuminate. (If this

does not happen, check your connections and retry)

Using Multi-view

The multiview is a powerful feature that lets you monitor the 8 inputs, together with the program and

preview outputs as a group of views on one screen. The multi-view also displays the media player,

streaming status, disk recording status, audio levels, logo, subtitle and other dynamics indicators.This

feature provides a comprehensive overview so you will always know exactly what is happening with your

broadcast!

Initially, as you have not yet configured inputs or added content, the Multi-view screen looks a bit barren.

Take a quick look around, but then let’s continue to configure your devices.

Inhaltsverzeichnis

Andere Oton Schalten Handbücher

Oton

Oton Geek S08 Series Bedienungsanleitung

Beliebte Schalten Handbücher anderer Marken

URC

URC Total Control MFS-8 Bedienungsanleitung

Azbil

Azbil HPQ-D11 Bedienungsanleitung

Sony

Sony DFS-900M Bedienungsanleitung

SICK

SICK i17S Bedienungsanleitung

F&F

F&F SZR-277 Bedienungsanleitung

Shure

Shure UAMS/BK Bedienungsanleitung

Dräger

Dräger X-zone Switch Off Bedienungsanleitung

Asco

Asco Joucomatic 349 Series Bedienungsanleitung

BT Mini Hub Bedienungsanleitung

D-Link

D-Link DES-1226G Bedienungsanleitung

Johnson Controls

Johnson Controls FS80-C Bedienungsanleitung

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Bedienungsanleitung

MicroNet

MicroNet SP1200A Bedienungsanleitung

Ruijie

Ruijie RG-PF2920 Series Installations- und Betriebsanleitung

Altinex

Altinex DA1914SX Bedienungsanleitung

MiLAN

MiLAN MIL-SM2401M Bedienungsanleitung

RJM

RJM MASTERMIND PBC/6X Bedienungsanleitung

Atlas

Atlas MMK-KVM8 Bedienungsanleitung
