Overland Vehicle Systems Pop-up Bedienungsanleitung
Pop-up
Changing Room
assembly instrucons
PLEASE READ THIS INSTRUCTION BEFORE ASSEMBLY
POP-UP CHANGING ROOM
SET-UP & CARE INSTRUCTIONS
Full Kit: 26019910
ASSEMBLY
1. Lay changing room at on oor with center poinng upward. Then bring arms
out ll the top is formed.
Unlocked
2. Pull hub together
make sure that it locks.
Locked
POP-UP CHANGING ROOM
SET-UP & CARE INSTRUCTIONS
Full Kit: 26019910
3. Tie loop under hub.
5. Clip fabric to tent frame.4. Expand telescoping legs and click to secure.
PRESS HERE PULL UP
POP-UP CHANGING ROOM
SET-UP & CARE INSTRUCTIONS
Full Kit: 26019910
7. Set up Solar Shower by rst aaching the hose to the
shower spigot with provided zip e, then trim as needed.
6. Use provided stakes, then secure the shower with guide ropes.
POP-UP CHANGING ROOM
SET-UP & CARE INSTRUCTIONS
Full Kit: 26019910
8. Secure nozzle so that water does not pour
out when lling with water.
9. Twist nozzle to adjust water ow when in use. 10. Undo cap and ll with water, then secure.
11. Feed nozzle and tube into the
hole of the shower bag.
12. Clip Solar shower bag in to secure.
POP-UP CHANGING ROOM
SET-UP & CARE INSTRUCTIONS
Full Kit: 26019910
13. Clip in and secure shower bag using the 4 clips on the roof of the shower.
TAKE DOWN
1. Unhook the shower bag, drain any remaining water and store in carrying bag.
POP-UP CHANGING ROOM
SET-UP & CARE INSTRUCTIONS
Full Kit: 26019910
2. Remove stakes and guide ropes. Unclip tent fabric and collapse the telescoping legs.
PRESS HERE
PULL
DOWN
3. Unfasten loop under hub. 4. Unlock hub.
Unlocked
POP-UP CHANGING ROOM
SET-UP & CARE INSTRUCTIONS
Full Kit: 26019910
5. Lay fabric corners inward to the center pole.
1. Fold all corners inward
2. Lay fabric at
3. Fold fabric over
4. Store in bag
1. 2. 3.
HOW TO FOLD UP
POP-UP CHANGING ROOM
SET-UP & CARE INSTRUCTIONS
Full Kit: 26019910
DO YOU NEED OUR HELP?
CUSTOMER SUPPORT 833-226-4863
SALES@OVERLANDVEHICLESYSTEMS.COM
WANT TO SHOW US YOUR RIG?
CHECK OUT OUR SOCIAL!
@overlandvehiclesystems
PARTS AND ACCESSORIES:
A- SHOWER STAKE X12
B- DRAWSTRING BAG X1
C- SOLAR SHOWER X1
D- SHOWER BAG X1
E- ZIP TIE X1
F- NYLON STRAPS X2
G- GUIDE ROPES X4
H- TRANSPORT BAG X1
E F G
H
A B C D
+ In a moving vehicle, always store the Pop-Up Changing room inside its traveling bag on
the oor of the vehicle, either behind the 1st row of seats or behind the 2nd row of seats.
