OWIM HG00073A Bedienungsanleitung

IAN 279818
TEMPERATURSTATION
Bedienungs- und Sicherheitshinweise
TEMPERATURSTATION
Bruksanvisning och säkerhetsanvisningar
LÄMPÖMITTARI
Käyttö- ja turvallisuusohjeet
TEMPERATURE STATION
Operation and Safety Notes
TEMPERATURE STATION
STACJA METEO
Wskazówki dotyczące obsługi i bezpieczeństwa
METEOROLOGINĖ STOTELĖ
Nurodymai dėl valdymo ir saugumo

GB Operation and
Safety Notes Page 5
FI Käyttö- ja turvallisuusohjeet Sivu 26
SE Bruksanvisning och
säkerhetsanvisningar Sidan 47
PL Wskazówki dotyczące
obsługi i bezpieczeństwa Strona 67
LT Nurodymai dėl valdymo
ir saugumo Puslapis 91
DE/AT / CH Bedienungs- und
Sicherheitshinweise Seite 113

A
10
13
12
17
25
11
B
28 27
14 9
2
5
15
8
16
241923 22 20 21
26
1
3467 18

D30
C
29
31
33 32

5GB
Introduction.....................................................Page 6
Proper use ..........................................................Page 6
Description of parts and features......................Page 6
Technical data....................................................Page 8
Safety..................................................................Page 9
General safety information................................Page 9
Safety instructions for batteries .........................Page 10
Before initial use..........................................Page 11
General information ..........................................Page 11
Preparing to use the outdoor sensor.................Page 12
Preparing the temperature station
for use.................................................................Page 12
Temperature station ...........................................Page 15
External sensor...................................................Page 15
Setting the language/time zone/
time/date manually ..........................................Page 15
Displaying summer time.....................................Page 17
Calling up the time zone ...................................Page 17
Setting the alarm time........................................Page 18
Calling up the alarm times ................................Page 18
Switching the alarm on/off ..............................Page 18
Using the snooze button....................................Page 19
Displaying temperature .....................................Page 20
Calling up the minimum/maximum
values..................................................................Page 20
Displaying temperature trends..........................Page 21
Battery state display ..........................................Page 21
Replacing the batteries......................................Page 21
Troubleshooting...........................................Page 21
Cleaning and maintenance...................Page 23
Disposal .............................................................Page 23
Declaration of conformity.....................Page 24
Warranty ..........................................................Page 25

6 GB
Temperature station
Introduction
We congratulate you on the purchase of your
new product. You have chosen a high quality
product. The instructions for use are part of the
product. They contain important information
concerning safety, use and disposal. Before
using the product, please familiarise yourself
with all of the safety information and instruc-
tions for use. Only use the unit as described
and for the specified applications. If you pass
the product on to anyone else, please ensure
that you also pass on all the documentation
with it.
Proper use
The temperature station displays the indoor
and outdoor temperatures in Celsius (°C) or
Fahrenheit (°F) and their maximum and mini-
mum values. The temperature station also
displays the time in 12/24-hour clock modes
and the date. In addition, the temperature sta-
tion has two alarm functions. The device is not
intended for commercial use.
Description of parts
and features
LC display
1Temperature trend (outdoor temperature)
2Outdoor temperature
3symbol (outdoor sensor)

7GB
4MAX-/MIN display for indoor
temperature
5Temperature trend (indoor temperature)
6Indoor temperature
7symbol (temperature station)
8Time
9ZZsymbol (snooze function)
10 Seconds display
11 symbol
12 Day of the week display
13 Date display (day/month)
14 DST display (summer time)
15 / symbol (Alarm 1/Alarm 2)
16 2nd time zone (ZONE)
17 MAX-/MIN display (outdoor temperature)
18 Radio signal
Temperature station
19 ZZ/REGISTER button (snooze function/
REGISTER)
20 SELECT button
21 SET/RESET button
22 ALARM button
23 CLOCK button
24 Hanging slot
25 Battery compartment
26 Stand
27 Screw (ø 3mm)
28 Dowel (ø 7.7mm)
Outdoor sensor
29 Control LED
30 Hanging slot

8 GB
31 Battery compartment
32 Screw (ø 3mm)
33 Dowel (ø 7.7mm)
Technical data
Temperature station:
Temperature
measurement range: 0–+50°C
+32–+122°F
Note: If the temperature is ≤0°C (32°F),
the LC display shows “LL.L”. If the temperature
is ≥50°C (122°F), the LC display shows
“HH.H”.
Temperature interval: 0.1°C
Radio signal: DCF
Batteries: 2 x AA 1.
5V
(included)
Outdoor sensor:
Temperature
measurement range: –20°C–+60°C
–4°F–+140°F
Note: If the temperature is ≤–20°C
(–4°F), the LC display shows “LL.L”. If the
temperature is ≥60°C (140°F), the LC dis-
play shows “HH.H”.
HF transmission signal: 433 MHz
HF transmission range: max. 30 metres
(in open area)
Batteries: 2 x AA 1.
5V
(included)
Protection class: IPX4

9GB
Safety
YOU SHOULD STORE ALL SAFETY INFOR-
MATION AND INSTRUCTIONS IN A SAFE
PLACE IN CASE YOU NEED TO REFER TO
THEM AGAIN IN THE FUTURE!
General safety
information
This appliance can be used by children
aged from 8 years and above and per-
sons with reduced physical, sensory or
mental capabilities or lack of experience
and knowledge if they have been given
supervision or instruction concerning use
of the appliance in a safe way and under-
stand the hazards involved. Children shall
not play with the appliance. Cleaning and
user maintenance shall not be made by
children without supervision.
Do not expose the device to an extremely
high electromagnetic field. This may im-
pair the correct functioning of the device.
Please note that the guarantee does not
cover damage caused by incorrect han-
dling, non-compliance with the operating
instructions or interference with the device
by unauthorised individuals.

10 GB
Safety instructions
for batteries
DANGER TO LIFE!
Batteries can be swallowed, which may
represent a danger to life. If a battery
has been swallowed, medical help is
required immediately.
Remove the batteries from the device if
they are not going to be used for a pro-
longed period.
CAUTION! DANGER OF
EXPLOSION! Never recharge
batteries which are not
rechargeable.
When inserting the batteries, ensure the
correct polarity! This is shown in the bat-
tery compartments.
Remove spent batteries immediately from
the device. There is an increased danger
of leaks!
Keep batteries away from children do not
throw the batteries in the fire, short-circuit
them or take them apart.
Always replace all the batteries at once.
Use batteries of the same type only. Oth-
erwise there is a risk of an explosion.
If the batteries have leaked inside your
device, you should remove them immedi-
ately in order to prevent damage to the
device!
Avoid contact with the skin, eyes and mu-
cous membranes. Any parts of the body
