Packard Bell LC700 Bedienungsanleitung

ENGLISH...........................................................2

FRANÇAIS........................................................13

DEUTSCH..........................................................24

ESPAÑOL..........................................................35

NEDERLANDS ................................................46

ITALIANO .........................................................57

monitor_guide_6908470000.qxd 27/05/03 15:55 Page 1

ENGLISH

LC700 17" CR

LC700 17" CRT

COLOUR

OLOUR M

MONITOR

ONITOR

USER’SGUIDE

CONTENTS

1. Introduction ...........................................................................3

2. Safety Information .................................................................3

3. Installing the monitor ............................................................4

4. Adjusting the picture .............................................................6

5. Display power management ..................................................9

6. Troubleshooting......................................................................10

7. Specifications .........................................................................12

monitor_guide_6908470000.qxd 27/05/03 15:55 Page 2

ENGLISH

1. INTRODUCTION

This manual contains instructions for installing and operating the LC700 Monitor.

LC700 Monitor features:

• 17” diagonal (16” viewable) 0.236 mm horizontal dot pitch CDT

• Supports high screen refresh rates and full scan flicker-free picture quality

• Includes On Screen Display menus for user control

• 100-240V AC input voltage

• VESA DPMS (Display Power Management Signalling)

• VESA DDC1/2B compatibility

2. SAFETY INFORMATION

When you set up and use your display unit, follow the safety instructions below.

Do not use the display unit in humid environments like bathrooms, damp cellars,

swimming pools, etc.

This equipment must be connected to an earthed outlet close to the display unit

and accessible in case you need to disconnect the display.

Never insert objects into the openings on the outside of the device as you can

come into contact with live electrical components. This can cause fire or give

strong electrical shocks.

Slots in the cabinet are provided for ventilation. Do not block the ventilation slots

in the display unit cabinet.

Do not under any circumstances open the display unit cabinet.

Cleaning and Maintenance

• To avoid risk of electric shock, do not disassemble the display unit cabinet.The unit is not

user-serviceable. Remember to unplug the display unit from thepower outlet before cleaning.

• Do not use alcohol (methyl, ethyl or isopropyl) or any strong solvent. Do notuse thinner

or benzene, abrasive cleaners or compressed air.

• Do not wipe the screen with a cloth or sponge that could scratch the surface.

• To clean your antistatic screen, use water and a special micro fibre screencleaning tissue

used in optical lens cleaning, or lightly dampen a soft, cleancloth with water or a mild

detergent.

• To clean display unit cabinet, use a cloth lightly dampened with a milddetergent.

• For transportation of the monitor, the swivel base must be removed.

monitor_guide_6908470000.qxd 27/05/03 15:55 Page 3

ENGLISH

3. INSTALLING THE MONITOR

3-1. Packing List

The following items should be found in the packaging.

A: Attached signal cable

B: Tilt and swivel stand

C: Compact disk*

D: Power cord

*Optional

3-2. Connecting the swivel and tilt base

• Place the base against the bottom of the monitor so that the base connecters are aligned

with the corresponding slots.

• Push the base towards the front of the monitor until the latch locks into position.

3-3. Selecting a suitable location

• 30cm from other electrical or heat-emitting equipment and allow at least 10cm on each

side for ventilation.

• Place the monitor in a position where no light shines directly onto or is reflected on the

screen.

• To reduce eyestrain, avoid installing the display unit against a bright background such as

a window.

• Position the monitor so that the top of the screen is no higher than eye level.

• Position the monitor directly in front of you at a comfortable reading distance (45 to

90cm approx).

monitor_guide_6908470000.qxd 27/05/03 15:55 Page 4

ENGLISH

3-4. Connecting the monitor

Before you start cabling your monitor, check that the power is off on all units. To avoid any

possibility of electric shock, always connect your equipment to properly earthed outlets.

1. Insert the 15-pin signal cable connector to the VGA connection on your computer and

screw it down.

2. Plug the display unit’s power cable first to the back of the display unit.

3. Then plug the power cable to a 100V - 240V earthed electrical outlet or to the system unit,

if it has an outlet for the display power cable.

4. Turn on the display unit using the Power switch and check that the power LED is on. If

not, repeat steps 2, 3 and 4 or refer to the Troubleshooting section of this guide.

5. Turn on the power to the computer. The picture will appear within about 15 seconds.

Adjust the picture to obtain optimum picture quality. See the section Adjusting the picture

in this guide for more information.

Power LED Power Switch

3-5. Setting the refresh rate

Follow the instructions below to set your refresh rate in Windows 98/ME/XP/2000.

1. Go to the configuration window (Start-Settings-Configuration window).

2. Double click on the “Display” icon.

monitor_guide_6908470000.qxd 27/05/03 15:56 Page 5

ENGLISH

3. Click on the “Settings” tab.

4. Click on the “Advanced” button.

5. Click on “Adapter” and select 85Hz from the list.

6. Click on “Apply” to accept the selected value.

The recommended setting is a resolution of 1024x768 and a refresh rate of 85Hz.

Preset Timing Table

* Recommended primary mode.

4. ADJUSTING THE PICTURE

You can adjust the screen display by using the buttons located below the screen.

4-1. Using the On Screen Display

1. Push the MENU button to open the OSD. The resolution and frequency are displayed at

the top of the menu box for your information.

No. Resolution Horizontal

Frequency Refresh Rate

1720 x 400 31.5 KHz 70 Hz

2640 x 480 43.3 KHz 85 Hz

3640 x 480 50.6 KHz 100 Hz

4800 x 600 46.9 KHz 75 Hz

5800 x 600* 53.7 KHz 85 Hz

6800 x 600 63.9 KHz 100 Hz

71024 x 768 60.0 KHz 75 Hz

81024 x 768* 68.7 KHz 85 Hz

monitor_guide_6908470000.qxd 27/05/03 15:56 Page 6

ENGLISH

2. Push the or button to choose the item you want to adjust. The selected item is

highlighted.

3. Push the SELECT button to adjust the highlighted item.

4. Use the or button to adjust the selection.

5. Push the MENU button to return to the previous menu if you are in a submenu.

6. The display unit automatically saves the new settings in 1 second after your last adjust-

ments and the menu disappears. You can also push the MENU button to make the menu

disappear.

4-2. Direct access buttons

BRIGHTNESS

Use the button to select the brightness adjustment.

Adjust with the or button.

CONTRAST

Use the button to select the contrast adjustment.

Adjust with the or button.

4-3. OSD Adjustments

The OSD adjustments available are listed below.

H. SIZE

Adjusts the horizontal size of the entire screen image.

H. POSITION

Adjusts the horizontal position of the entire screen image.

V. SIZE

Adjusts the vertical size of the entire screen image

V. POSITION

Adjusts the vertical position of the entire screen image.

PINCUSHION

If the vertical sides of the picture curve in or bulge out, you can correct the pin-

cushion distortion by using this adjustment.

TRAPEZOID

If the picture is wider at the top or at the bottom, you can correct the trapezoid dis-

tortion by using this adjustment.

PARALLEL

If the sides of the screen image are tilted, you can correct the parallel distortion by

using this adjustment.

monitor_guide_6908470000.qxd 27/05/03 15:56 Page 7

ENGLISH

PIN BALANCE

If the sides of the picture are bowed to the right or to the left, you can correct the

pincushion balance by using this adjustment.

V. MOIRE

Clears vertical moire if a series of concentric circles or arcs appear on your screen.

H. MOIRE

Clears horizontal moire if a series of concentric circles or arcs appear on your

screen.

Moire is an interference pattern that makes the screen seem to have faint lines. A

picture that is rasterised or consists of (small) repeating figures is sensitive to moire

interference. Strong colours are also liable to intensify moire.

The moire pattern on the screen does not affect the printout of the image.

TOP CORNER

If the top corner sides of the picture curve in or bulge out, you can correct the top

corner distortion by using this adjustment.

BOTTOM CORNER

If the bottom corner sides of the picture curve in or bulge out, you can correct the

bottom corner distortion by using this adjustment.

H. LINEARITY

If either left or right side of the picture is out of proportion to the other, you can

correct horizontal linearity by using this adjustment.

V. LINEARITY

If top and bottom side of the picture is out of proportion to the centre area, you can

correct vertical linearity by using this adjustment.

LANGUAGE

You can select the language in which adjustment menus are displayed.

The following languages are available: English, French, German, Italian, Spanish,

Swedish, Finnish, Danish, Portuguese and Dutch.

ROTATION

If the entire screen image is tilted, you can correct the distortion by using this

adjustment.

OSD H. POSITION

Adjusts the OSD menu’s horizontal position on the screen.

OSD V. POSITION

Adjusts the OSD menu’s vertical position on the screen.

monitor_guide_6908470000.qxd 27/05/03 15:56 Page 8

ENGLISH

COLOR CONTROL

Colour temperature affects the tint of the image.

With lower colour temperatures the image turns

reddish and with higher temperatures bluish.

There are three colour settings available: 9300K,

6500K or USER. With the USER setting you can

set individual values for red, green and blue.

RECALL

If you operate your display unit in a factory preset mode, this function deletes

adjustments you made for size, position and shape, and restores the properties,

which have been set in the factory. If you operate your display unit in a user mode,

this function has no effect except that the contrast will be reset to the maximum

value and the brightness to the cut-off level.

INFORMATION

Information shows horizontal and vertical sync polarity of current timing set.

DEGAUSS

External magnetic fields may cause distortion or discoloration in the picture.

Demagnetising takes place automatically when the display unit is switched on, and

the unit normally maintains faultless colour purity during operation. If you have til-

ted, swivelled or moved the display unit, you can perform a demagnetisation.

During this process the picture is distorted for a few seconds. After demagnetising,

the colour impurities have disappeared if caused by stray magnetic fields. Do not

use the degauss feature more than once every half hour.

CONTRAST

Adjusts the contrast of the screen.

BRIGHTNESS

Adjusts the brightness of the screen.

5. DISPLAY POWER MANAGEMENT

If the power management function of your computer is enabled, your monitor turns on and

off automatically. You can control power management features from your computer.

Reducing power Consumption

Your computer may have power management features that enable the computer or monitor

to enter a power saving mode when the system is idle. You can reactivate the system by pres-

sing any key or moving the mouse.

monitor_guide_6908470000.qxd 27/05/03 15:56 Page 9

ENGLISH

The power button does not disconnect the display unit from the mains. The only

way to isolate the display unit completely from the mains supply is to unplug the

mains cable.

6. TROUBLESHOOTING

If your monitor does not function properly, you may be able to solve the problem by reading

the following.

Mode LED Power

Consumption

Stage 1 (Normal) Green 70 W (Typ.)

Stage 2 Orange ≤5 W

Power Switch off Not illuminated ≤1 W

Unplugged Not illuminated 0W

monitor_guide_6908470000.qxd 27/05/03 15:56 Page 10

Inhaltsverzeichnis

Sprachen:

Andere Packard Bell Monitor Handbücher

Packard Bell

Packard Bell Maestro 240DML Bedienungsanleitung

Packard Bell

Packard Bell airFrame M28000 Bedienungsanleitung

Packard Bell

Packard Bell Maestro Series Bedienungsanleitung

Packard Bell

Packard Bell VISEO 230WS Bedienungsanleitung

Packard Bell

Packard Bell CT500P Bedienungsanleitung

Packard Bell

Packard Bell A526 Bedienungsanleitung

Packard Bell

Packard Bell Viseo 200T Bedienungsanleitung

Packard Bell

Packard Bell airFrame M27200 Bedienungsanleitung

Packard Bell

Packard Bell Maestro20 Series Bedienungsanleitung

Packard Bell

Packard Bell Viseo203DX Bedienungsanleitung

Packard Bell

Packard Bell VISEO 220DX Bedienungsanleitung

Packard Bell

Packard Bell Viseo223DX Bedienungsanleitung

Packard Bell

Packard Bell MAESTRO 191W Bedienerhandbuch

Packard Bell

Packard Bell LCD Monitor Bedienungsanleitung

Packard Bell

Packard Bell A927 Bedienungsanleitung

Packard Bell

Packard Bell A520 Bedienungsanleitung

Packard Bell

Packard Bell Maestro 230 LED HD Bedienungsanleitung

Packard Bell

Packard Bell VISEO 240DX Bedienungsanleitung

Packard Bell

Packard Bell Viseo 200Ws Bedienungsanleitung

Packard Bell

Packard Bell Viseo243D Bedienungsanleitung

Beliebte Monitor Handbücher anderer Marken

Linear Acoustic

Linear Acoustic LQ-1000 Bedienungsanleitung

AOC

AOC I2579V Bedienungsanleitung

Gateway

Gateway FPD1520 Bedienungsanleitung

Furuno

Furuno Mu 120c Bedienungsanleitung

Asus

Asus VB171D - 17" LCD Monitor Bedienungsanleitung

Dell

Dell S2230MX Gebrauchsanweisung

Philips

Philips 107C64 Bedienungsanleitung

Dell

Dell S2409WFP Bedienungsanleitung

EverFocus

EverFocus EN-7517E Bedienungsanleitung

Panasonic

Panasonic TH152UX1 - 152" PLASMA TV Bedienungsanleitung

Dell

Dell Precision 7680 Bedienungsanleitung

LG 50PM1M - - 50" Plasma Panel Bedienungsanleitung

Bosch

Bosch DDU 9 Bedienungsanleitung

Acer

Acer A231HL Bedienungsanleitung

Philips

Philips 86BDL4152T Bedienungsanleitung

NEC

NEC AccuSync LCD5V Bedienungsanleitung

Emay

Emay SleepO2 Bedienungsanleitung

IBM

IBM 6360 Montageanleitung
