Palm AT&T Treo 680 Merkblatt

Read This First

READ THIS FIRST

ENGLISH

Check the contents of the box

Palm®Tr e o ™680

smartphone

AC charger & adapter(s)

(if required)

USB sync cable

Rechargeable battery

SIM card

(not included

with all models)

Printed materialHeadset

CD (includes desktop

sync software &

bonus smartphone

software)

READ THIS FIRST

OVERVIEW

Overview Insert the SIM card

1Remove the battery door.

2If the battery is installed, remove it.

3Slide the SIM tray out of the slot.

Indicator

light

Calendar

5-way navigator

and Center button

Earpiece

Send

Phone

Side

button

Volume

Power/End

Messaging

Applications

Press battery

door release

READ THIS FIRST

INSERT THE BATTERY 3

ENGLISH

4Insert the notched end of the SIM card

into the SIM tray, and then press the

other end of the card into place.

5Slide the SIM tray back into the slot.

Insert the battery

1Insert the battery into the compartment.

2Slide the battery door onto the back of

the smartphone until it clicks into place.

Notch

Align

battery

contacts

with

smartphone

contacts

READ THIS FIRST

COMPLETE SETUP

Complete setup

1Select the language you want to use.

2Follow the onscreen instructions.

3(Optional) When the setup is complete,

press Applications and select

Quick Tour .

Make a call

1Press Phone . (If prompted, press

Center to turn off Keyguard.)

2Use the number keys to enter the

phone number.

3Press Send to make the call.

4To end the call, press Power/

End .

TIP

Ask your wireless service provider if their

network supports automatic date, time, and

time zone settings. If not, use the manual

settings.

Center

Phone

Number

keys

READ THIS FIRST

INSTALL THE SOFTWARE 5

ENGLISH

Install the software

1Close all programs on your computer.

2Insert the Palm Software Installation CD

into your computer’s CD drive.

3 Mac only: Double-click the CD icon on

the desktop, and then double-click the

PalmSoftware.pkg icon.

4Select the same language you selected

on your smartphone.

5Follow the onscreen instructions.

Sync and charge your

smartphone

When Install asks you to sync, do this:

1If necessary, attach the appropriate

adapter to the AC charger.

2Connect the AC charger to a wall outlet

and to the bottom of your smartphone.

3Connect the USB sync cable to a USB

port on your computer and to the

bottom of your smartphone.

4Press the sync button.

TIP

Charge your smartphone until the indicator

light turns solid green.

Sync cable Sync button

READ THIS FIRST

WHERE’S MY MANUAL?

Where’s my manual?

On your computer

User Guide

Hundreds of pages of illustrated info,

steps, and tips.

Windows: Start>All Programs>Palm

Mac: In the Documentation folder on the

Palm Software Installation CD.

In the box

Quick Reference Guide

Printed introduction to the basics.

On your smartphone

User Guide

Hundreds of pages of illustrated info,

steps, and tips. Press Applications

and select My Treo .

Quick Tour

An intro to common smartphone features.

Press Applications and select

Quick Tour .

On the web

Downloads, troubleshooting, and support.

www.palm.com/treo680gsm

www.palm.com/treo680gsm-support

NOTE For questions about your mobile

account, contact your wireless service

provider.

Intellectual property notices

and other intellectual property notices are set forth on page ii within

Your Palm Treo 680 Smartphone User Guide installed on the user’s

computer.

The TREO trademark is used by Palm in Sweden and Denmark with

the express consent of Pfizer and its affiliated companies. The

products marketed and/or sold by Palm under the TREO trademark

are in no way affiliated with Pfizer or its business.

Swedish: Varumärket Treo används av Palm i Sverige och Danmark

med uttryckligt tillstånd från Pfizer och dess dotterbolag. De

produkter som marknadsförs och/eller säljs av Palm under varumärket

Treo ska på inget sätt alls kopplas samman med Pfizer eller dess

verksamhet.

Danish: Treo-varemærket anvendes af Palm i Danmark og Svirge med

udtrykkelig tilladelse fra Pfizer og Pfizers associerede selskaber. De

produkter, der markedsføres og/eller sælges af Palm under

Treo-varemærket, er på ingen måde tilknyttet Pfizer eller Pfizers

virksomhed.

Disclaimer and limitation of liability

Palm, Inc. assumes no responsibility for any damage or loss resulting

from the use of this manual. Palm, Inc. assumes no responsibility for

any loss or claims by third parties that may arise through the use of

this product. Palm, Inc. assumes no responsibility for any damage or

loss caused by deletion of data as a result of malfunction, dead

battery, or repairs of this product.

PN: 406-10751-00

v. 1.0

Palm, Inc.

950 W. Maude Ave.

Sunnyvale, CA 94085-2801

United States of America

PN: 406-10750-00

v. 1.0
