Panasonic CS-HE9DKE Bedienungsanleitung

1 Features 2

2 Functions 3

2.1. Remote Control 3

2.2. Indoor Unit 4

2.3. Outdoor unit 5

3 Product Specifications 6

4 Dimensions 10

4.1. Indoor Unit / Remote Control 10

4.2. Outdoor Unit 11

5 Refrigeration Cycle Diagram 12

6 Block Diagram 13

7 Wiring Diagram 14

7.1. Indoor Unit 14

rights reserved. Unauthorized copying and

distribution is a violation of law.

CS-HE9DKE CU-HE9DKE

CS-HE12DKE CU-HE12DKE

7.2. Outdoor Unit 15

8 Electronic Circuit Diagram 16

8.1. Indoor Unit / Remote Controller 16

8.2. Outdoor Unit 18

9 Operation Details 20

9.1. Basic Function 20

9.2. Indoor Power Relay Control 21

9.3. Room Temperature Control (Compressor Control) 22

9.4. Airflow Direction Control 23

9.5. Quiet operation (Cooling Mode / Cooling area of Dry

Mode) 26

9.6. Indoor Fan Control 28

9.7. Powerful Operation 30

Air Conditioner

CONTENTS

Page Page

Order No. RAC0504012C2

9.8. Automatic Operation 31

9.9. Sleep Timer Operation 32

9.10. Timer Operation 32

9.11. Auto Restart Control 32

9.12. Ionizer Operation 33

9.13. Oxygen Enrich Operation 34

9.14. Deice Control <Heating> 36

9.15. Protection Control 37

10 Operating Instructions 39

11 Installation Instructions 45

11.1. Safety Precautions 45

11.2. Indoor Unit 48

11.3. Outdoor Unit 52

12 Installation and Servicing Air Conditioner Using R410A 55

12.1. Outline 55

•

• •

• Product

−

− −

− Telecommunication Support.

−

− −

− Air Swing to adjust vertical or horizontal airflow louver.

−

− −

− Four modes of operation selection.

−

− −

− Air filter with function to reduce dust and smoke.

−

− −

− Supersonic air purifying device (Super Alleru-buster)

operation.

−

− −

− Remote control unit holder.

−

− −

− Remote control self-illuminating button.

−

− −

− Ionizer control to provide fresh air effect by generating

negative ion.

−

− −

− Powerful mode to achieve setting temperature quickly

room.

−

− −

− Quiet mode to provide quiet operation (Lo: -3dB).

−

− −

− Oxygen mode to supply oxygen enrich air to indoor

room.

−

− −

− 24-hour real-timer setting.

−

− −

− Long installation piping up to 15 meters.

−

− −

− Guard net provided in Outdoor unit

•

• •

• Quality Improvement

−

− −

− Random auto restart after power failure for safety restart

operation.

−

− −

− Blue Coated Condenser for high resistance to corrosion.

•

• •

• Serviceability

−

− −

− Removable and washable front panel.

−

− −

− Breakdown self diagnosis function.

•

• •

• Environmental Protection

−

− −

− Non-ozone depletion substances refrigerant (R410A).

12.2. Tools For Installing/Servicing Refrigerant Piping 56

12.3. Refrigerant Piping Work 60

12.4. Installation, Transferring, Servicing 63

13 Servicing Information 67

13.1. About Lead Solder (PbF) 67

13.2. Troubleshooting 68

13.3. Disassembly of Parts 72

14 Technical Data 81

14.1. Operation Characteristics 81

14.2. Sensible Capacity Chart 83

15 Exploded View and Replacement Parts List 84

15.1. Exploded View (Indoor Unit) 84

15.2. Replacement Parts List (Indoor Unit) 85

15.3. Exploded View (Outdoor Unit) 86

15.4. Replacement Parts List (Outdoor Unit) 87

1 Features

CS-HE9DKE CU-HE9DKE / CS-HE12DKE CU-HE12DKE

2 Functions

2.1. Remote Control

CS-HE9DKE CU-HE9DKE / CS-HE12DKE CU-HE12DKE

2.2. Indoor Unit

CS-HE9DKE CU-HE9DKE / CS-HE12DKE CU-HE12DKE

2.3. Outdoor unit

CS-HE9DKE CU-HE9DKE / CS-HE12DKE CU-HE12DKE

3 Product Specifications

Unit CS-HE9DKE CU-HE9DKE

Cooling Capacity kW

kcal/h

BTU/h

2.60 (0.60 - 3.00)

2,240 (520 - 2,580)

8,870 (2,050 - 10,200)

Heating Capacity kW

kcal/h

BTU/h

3.60 (0.60 - 6.50)

3,100 (520 - 5,590)

12,300 (2,050 - 22,080)

Moisture Removal l/h

Pint/h

1.5

(3.2)

Power Source Phase

Cycle

Single

230/240

Airflow Method OUTLET

INTAKE

SIDE VIEW TOP VIEW

Air Volume Indoor Air (Lo) m3/min (cfm) Cooling; 5.2 (180) —

Heating; 6.3 (220)

Indoor Air (Me) m3/min (cfm) Cooling; 7.9 (280) —

Heating; 8.8 (310)

Indoor Air (Hi) m3/min (cfm) Cooling; 10.5 (370) Cooling; 23.8 (840)

Heating; 11.5 (410) Heating; 23.1 (820)

dB (A) Cooling; High 39, Low 26 Cooling; 46

Heating; High 40, Low 27 Heating; 47

Noise Level

Power level dB Cooling; High 50 Cooling; High 59

Heating; High 51 Heating; High 60

Electrical Data Input W Cooling; 510 (120 - 700)

Heating; 690 (115 - 1,720)

Running Current ACooling; 2.6

Heating; 3.5

EER W/W (kcal/hw), BTU/hw Cooling; 5.10 (4.39), 17.4

COP W/W (kcal/hw), BTU/hw Heating; 5.22 (4.49), 17.8

Starting Current A 3.6

Piping Connection Port

(Flare piping)

inch

G ; Half Union 3/8”

L ; Half Union 1/4”

G ; 3-way valve 3/8”

L ; 2-way valve 1/4”

Pipe Size

(Flare piping)

inch

G (gas side) ; 3/8”

L (liquid side) ; 1/4”

G (gas side) ; 3/8”

L (liquid side) ; 1/4”

CS-HE9DKE CU-HE9DKE / CS-HE12DKE CU-HE12DKE

Unit CS-HE9DKE CU-HE9DKE

Drain

Hose

Inner diameter mm 16 —

Length m 0.65 —

Power Cord Length

Number of core-wire

1.8 m

3-core wires × 1.0 mm2

—

Dimensions Height inch (mm) 11 - 23/32 (298) 21 - 1/4 (540)

Width inch (mm) 34 - 8/32 (870) 30 - 23/32 (780)

Depth inch (mm) 7 - 27/32 (199) 11 - 3/8 (289)

Net Weight lb (kg) 24 (11) 79 (36)

Compressor Type — Involute scroll

Motor Type —Brushless (4-poles)

Rated Output W — 750

Air Circulation Type Cross-flow Fan Propeller Fan

Material AS + Glass Fiber 20% P.P

Motor Type Transistor (8-poles) Induction (8-poles)

Input W — —

Rate Output W 30 40

Fan Speed Lo (Cool/Heat) rpm 660 / 750 —

Me (Cool/Heat) rpm 880 / 950 —

Hi (Cool/Heat) rpm 1,090 / 1,150 790 / 770

Heat Exchanger Description Evaporator Condenser

Tube material Copper Copper

Fin material Aluminium (Pre Coat) Aluminium (Blue Coated)

Fin Type Slit Fin Corrugated Fin

Row / Stage (Plate fin configuration, forced draft)

3/16 2/24

FPI 20 16.5

Size (W × H × L) mm 671 × 322.6 × 30.9 816.9 × 504 × 36.4

Refrigerant Control Device — Capillary Tube

Refrigeration Oil (c.c) — RB68A (400)

Refrigerant (R410A) g (oz) — 1, 190 (42.0)

Thermostat Electronic Control Electronic Control

Protection Device Electronic Control Electronic Control

Air Filter Material

Style

P.P.

Honeycomb

—

•

• •

• Specifications are subject to change without notice for further improvement.

CS-HE9DKE CU-HE9DKE / CS-HE12DKE CU-HE12DKE

Unit CS-HE12DKE CU-HE12DKE

Cooling Capacity kW

kcal/h

BTU/h

3.50 (0.60 - 4.00)

3,010 (520 - 3,440)

11,900 (2,050 - 13,600)

Heating Capacity kW

kcal/h

BTU/h

4.80 (0.60 - 7.70)

4,130 (520 - 6,620)

16,400 (2,050 - 26,100)

Moisture Removal l/h

Pint/h

2.0

(4.2)

Power Source Phase

Cycle

Single

230/240

Airflow Method OUTLET

INTAKE

SIDE VIEW TOP VIEW

Air Volume Indoor Air (Lo) m3/min (cfm) Cooling; 6.2 (220) —

Heating; 7.8 (280)

Indoor Air (Me) m3/min (cfm) Cooling; 8.4 (300) —

Heating; 10.0 (350)

Indoor Air (Hi) m3/min (cfm) Cooling; 11.3 (400) Cooling; 23.8 (840)

Heating; 12.5 (440) Heating; 23.8 (840)

dB (A) Cooling; High 42, Low 29 Cooling; 48

Heating; High 42, Low 33 Heating; 50

Noise Level

Power level dB Cooling; High 53 Cooling; High 61

Heating; High 53 Heating; High 63

Electrical Data Input W Cooling; 850 (120 - 1,050)

Heating; 1,040 (115 - 2,280)

Running Current ACooling; 4.2

Heating; 5.0

EER W/W (kcal/hw), BTU/hw Cooling; 4.12 (3.54), 14.0

COP W/W (kcal/hw), BTU/hw Heating; 4.62 (3.97), 15.8

Starting Current A 5

Piping Connection Port

(Flare piping)

inch

G ; Half Union 1/2”

L ; Half Union 1/4”

G ; 3-way valve 1/2”

L ; 2-way valve 1/4”

Pipe Size

(Flare piping)

inch

G (gas side) ; 1/2”

L (liquid side) ; 1/4”

G (gas side) ; 1/2”

L (liquid side) ; 1/4”

Drain

Hose

Inner diameter mm 16 —

Length m 0.65 —

Power Cord Length

Number of core-wire

1.8 m

3-core wires × 1.5 mm2

—

CS-HE9DKE CU-HE9DKE / CS-HE12DKE CU-HE12DKE

Unit CS-HE12DKE CU-HE12DKE

Dimensions Height inch (mm) 11 - 23/32 (298) 21 - 1/4 (540)

Width inch (mm) 34 - 8/32 (870) 30 - 23/32 (780)

Depth inch (mm) 7 - 27/32 (199) 11 - 3/8 (289)

Net Weight lb (kg) 24 (11) 82 (37)

Compressor Type — Involute scroll

Motor Type —Brushless (4-poles)

Rated Output W — 1,100

Air Circulation Type Cross-flow Fan Propeller Fan

Material AS + Glass Fiber 20% P.P

Motor Type Transistor (8-poles) Induction (8-poles)

Input W — —

Rate Output W 30 40

Fan Speed Lo (Cool/Heat) rpm 740 / 870 —

Me (Cool/Heat) rpm 920 / 1,050 —

Hi (Cool/Heat) rpm 1,110 / 1,230 790 / 790

Heat Exchanger Description Evaporator Condenser

Tube material Copper Copper

Fin material Aluminium (Pre Coat) Aluminium (Blue Coated)

Fin Type Slit Fin Corrugated Fin

Row / Stage (Plate fin configuration, forced draft)

3/16 2/24

FPI 20 16.5

Size (W × H × L) mm 671 × 322.6 × 30.9 671 × 322.6 × 30.9

Refrigerant Control Device — Capillary Tube

Refrigeration Oil (c.c) — RB68A (400)

Refrigerant (R410A) g (oz) — 1,160 (40.9)

Thermostat Electronic Control Electronic Control

Protection Device Electronic Control Electronic Control

Air Filter Material

Style

P.P.

Honeycomb

—

•

• •

• Specifications are subject to change without notice for further improvement.

CS-HE9DKE CU-HE9DKE / CS-HE12DKE CU-HE12DKE

4 Dimensions

4.1. Indoor Unit / Remote Control

CS-HE9DKE CU-HE9DKE / CS-HE12DKE CU-HE12DKE

Andere Handbücher für CS-HE9DKE

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Panasonic Klimaanlage Handbücher

Panasonic

Panasonic CW-XC60YU Bedienungsanleitung

Panasonic

Panasonic PZ2 Series Bedienungsanleitung

Panasonic

Panasonic S-22MZ1H4A Bedienungsanleitung

Panasonic

Panasonic CS-C7MKP-7 Bedienungsanleitung

Panasonic

Panasonic CS-S9NKUA Bedienungsanleitung

Panasonic

Panasonic CW-A121VR Bedienungsanleitung

Panasonic

Panasonic CSC9BKP - SPLIT A/C SYSTEM Bedienungsanleitung

Panasonic

Panasonic CS-Z20XKEW Bedienungsanleitung

Panasonic

Panasonic CS-PA7KKD Bedienungsanleitung

Panasonic

Panasonic CS-E7NKR Bedienungsanleitung

Panasonic

Panasonic CS-A7GKD Bedienungsanleitung

Panasonic

Panasonic CS-XZ7SKEW Bedienungsanleitung

Panasonic

Panasonic S-22MU2E5A Bedienungsanleitung

Panasonic

Panasonic OCU-CR1000VF8 Betriebsanleitung

Panasonic

Panasonic CW-XC100HU Bedienungsanleitung

Panasonic

Panasonic CS-MKE24NKU Installations- und Benutzerhandbuch

Panasonic

Panasonic CS-A24BD2P Bedienungsanleitung

Panasonic

Panasonic CU-KS30NKUA Bedienungsanleitung

Panasonic

Panasonic CS-W7NKD Bedienungsanleitung

Panasonic

Panasonic CS-RZ9YKA Bedienungsanleitung

Panasonic

Panasonic CS-YE9MKX Bedienungsanleitung

Panasonic

Panasonic CS-C9KKV Bedienungsanleitung

Panasonic

Panasonic S-140MH1H5 Bedienungsanleitung

Panasonic

Panasonic CS-HE9NKE Bedienungsanleitung

Beliebte Klimaanlage Handbücher anderer Marken

Spheros

Spheros CC 355 Bedienungsanleitung

Bosch

Bosch Climate 5000 SCI 24 CAS/ OU- OUE Bedienungsanleitung

nedis

nedis ACMB1WT7 Bedienungsanleitung

Samsung

Samsung AR KV Series Leitfaden

Daikin

Daikin FCFV50A Bedienungsanleitung

Fujitsu

Fujitsu Inverter ASBA30JFC Bedienungsanleitung

Toshiba

Toshiba RAS-M10SMUV-E Bedienungsanleitung

Daikin

Daikin FXLQ20MAVE Bedienungsanleitung

Hitachi

Hitachi RAS-E24CAK Bedienungsanleitung

CIAT

CIAT Magister 2 Series Leitfaden

Bestron

Bestron AAC6000 Bedienungsanleitung

Hisense

Hisense 7K Technisches Handbuch

Frigidaire

Frigidaire FFRE0533S1E0 Bedienungsanleitung

Samsung

Samsung AS09HM3N Bedienungsanleitung

Frigidaire

Frigidaire CRA073PU11 Betriebsanleitung

Soleus Air

Soleus Air GB-PAC-08E4 Bedienungsanleitung

McQuay

McQuay MCK020A Bedienungsanleitung

Webasto

Webasto Frigo Top 25 DS Bedienungsanleitung
