Panasonic CS-VA75KE Bedienungsanleitung

1 Features 2

2 Functions 3

3 Product Specifications 6

4 Dimensions 12

5 Refrigeration Cycle Diagram 14

6 Block Diagram 16

7 Wiring Diagram 17

8 Operation Details 20

9 Operating Instructions 36

10 Installation And Servicing Air Conditioner Using R410A 60

11 Installation Instructions 71

12 2-way, 3-way Valve 80

and distribution is a violation of law.

CS-VA75KE CU-VA75KE

CS-VA95KE CU-VA95KE

CS-VA125KE CU-VA125KE

13 Servicing Information 87

14 Troubleshooting Guide 90

15 Technical Data 92

16 Exploded View 97

17 Replacement Parts List 98

18 Exploded View 99

19 Replacement Parts List 100

20 Exploded View 101

21 Replacement Parts List 102

22 Electronic Parts List 103

23 Electronic Circuit Diagram 104

Room Air Conditioner

CONTENTS

Page Page

Order No: MAC0010055C2

• Environmental Friendly

− R410A, which does not contain chlorine, is used as its

refrigerant, so there is no danger of damage to the

ozone layer in Stratosphere.

• High Efficiency

• Compact Design

• Comfort Environment

− 8 hours of sleep mode operation

− Air filter with function to reduce dust and smoke

− Wider range of horizontal discharge air

• Auto Restart

− Random auto restart after power failure for safety restart

operation

• Removable and Washable Front Panel

• Remote Control Self-illuminating Button

• Catechin Air Purifying Filter

− Trap dust, tabacco smoke and tiny particles

− Prevent the growth of bacteria and viruses trapped

• Deodorizing Air Purifying Filter

− Remove unpleasant odors from the air

• Quality Improvement

− Gas leakage protection

− Prevent compressor reverse cycle

− 2-stage OLP to protect compressor

− Noise prevention during soft dry operation.

• Service Improvement

− Easy fan motor replacement procedure

• Operation Improvement

− Economy mode to reduce electrical power consumption

− Powerful mode to reach the desired room temperature

quickly

• Long Installation Piping

− CS/CU-VA75KE, CS/CU-VA95KE, long piping up to 10

meter

− CS/CU-VA125KE, long piping up to 15 meter

1 Features

CS-VA75KE CU-VA75KE / CS-VA95KE CU-VA95KE / CS-VA125KE CU-VA125KE

2 Functions

Remote Control

Operation OFF / ON

OFF / ON IRoom Temperature Setting

TEMP.

Operation Mode Selection

•AUTO Automatic Operation Mode

•HEAT Heating Operation Mode

•COOL Cooling Operation Mode

•DRY Soft Dry Operation Mode

MODE

TIMER Time / Timer Setting

• Hours and minutes setting.

Clock Setting

• Current time setting.

Sleep Mode Operation OFF / ON

SLEEP

Indoor Fan Speed Selection

FAN SPEED

•h j k Low Speed

•h j k Medium Speed

lll

•h j k High Speed

lllll

•AUTOFAN Automatic Fan Speed

Airflow Direction Control

• 24-hour, OFF / ON Real Timer Setting.

ON-TIMER

OFF-TIMER Timer Operation Selection

SET

CANCEL Timer Operation Set / Cancel

• ON Timer and OFF Timer setting and

cancellation.

CLOCK

AIR SWING

•AUTO Automatic Airflow Direction

Control

•MANUAL Airflow Direction Manual

Control

Powerful Mode Operation OFF/ON

POWERFUL

Economy Mode Operation OFF/ON

ECONOMY

• Temperature Setting (16°C to 30°C)

• Automatic Operation

Operation with 2°C higher than

standard temperature.

Operation with standard

temperature.

Operation with 2°C lower than

standard temperature.

8 HI

9 Lo

Self illuminating

button

CS-VA75KE CU-VA75KE / CS-VA95KE CU-VA95KE / CS-VA125KE CU-VA125KE

Indoor Unit

Sleep Mode Auto Control

•Indoor Fan operates at Low speed.

•Operation stops after 8 hours.

•Automatic air swing and manual adjusted

by remote control for vertical airflow.

•

Manually adjusted by hand for horizontal airflow.

Airflow Direction Control

Automatic Operation Button

•Press for < 5s to operate Automatic

operation mode.

(Used when the remote control cannot be used.)

•Press continuosly for 5s or < 10s to

operate Test Run/Pump down. “Beep”

sound will be heard at the 5th second.

(Used when test running or servicing.)

•Press continuosly for 10s and above to

omit or resume the remote control signal

receiving sound. “Beep, beep”sound will

be heard at the 10th second.

AUTO

OFF / ON

Operation Indication Lamps (LED)

•POWER (Green) ........Lights up in operation,

blinks in Automatic

Operation Mode

judging.

•SLEEP (Orange)........Lights up in Sleep

Mode Operation.

•TIMER (Orange) .......Lights up in Timer

Setting.

•POWERFUL (Orange)..Lights up in Powerful

Mode Operation.

•ECONOMY (Green) .....Lights up in Economy

Mode Operation.

Operation Mode

•Heating, Cooling, Soft Dry and

Automatic Mode.

Powerful Operation

•Reaches the desired room temperature

quickly.

Time Delay Safety Control

•

Restarting is inhibited for appro. 3 minutes.

Starting Current Control

Economy Operation

•To reduce electrical power consumption.

7 Minutes Time Save Control

•Cooling Operation only.

Random Auto Restart Control

•Operation is restarted randomly after

power failure at previous setting mode.

Anti-Freezing Control

•Anti-Freezing control for indoor heat

exchanger. (Cooling and Soft Dry)

Anti Cold Draft Control

•

The indoor fan operates at SSLo when the

indoor heat exchanger temperature is low.

Hot-Start Control

•At Heating Operation the indoor fan will

operate at Lo speed when indoor heat

exchanger temperature reaches 30°C.

Indoor Fan Speed Control

•High, Medium and Low.

•Automatic Fan Speed Mode

–Heating: Fan speed varies from Me

;Lo in accordance with

indoor heat exchanger.

–Cooling : Fan rotates at Hi and Me

speed. Deodorizing control

is available.

–Soft Dry: Fan rotates at Lo speed.

Deodorizing control

is available.

30 Minutes Time Save Control

•Heating Operation only.

CS-VA75KE CU-VA75KE / CS-VA95KE CU-VA95KE / CS-VA125KE CU-VA125KE

Outdoor Unit

•To protect compressor from reverse

rotation when there is a instantaneous

power failure.

60 Secs. Forced Operation Control

•Once the compressor is activated, it

does not stop within the first 60 secs.

However, it stops immediately with

remote control stop signal.

Overload Protector

•2-Stage OLP to protect the compressor.

Overload Protector will trip when

–Temperature of compressor increases

to 120°C.

–High temperature or high current flows

to compressor.

(Refer circuit diagram for OLP

characteristic)

Compressor Reverse Rotation

Protection Control

Outdoor Fan Operation Control

•Inner protector.

CU-VA75KE / CU-VA95KE CU-VA125KE

4-Way Valve Control

•When the unit is switched to “OFF”

during Heating Operation, 4-way valve

stays at Heating position for 5 minutes.

Overload Protection Control

•Outdoor fan stops when indoor heat

exchanger temperature rises to 51°C

and above, and restarts when the indoor

heat exchanger temperature drops to

49°C and below.

•Compressor stop when indoor heat

exchanger temperature reaches 65°C or

above. (Heating Operation Only)

Deice Control

•To prevent frosting at outdoor heat

exchanger. (Only for Heating Operation)

•

Temperature of outdoor heat exchanger

is sensed by TRS (Thermal Reed Switch).

TRS OFF temperature 4°C.

TRS ON temperature -3°C.

Compressor Protection Control

•If the outdoor fan motor is not running

after compressor starts for 50 secs.,

compressor will stop. (Cooling and Soft

Dry Operation only).

CS-VA75KE CU-VA75KE / CS-VA95KE CU-VA95KE / CS-VA125KE CU-VA125KE

3 Product Specifications

Unit CS-VA75KE CU-VA75KE

Cooling Capacity kW

kcal/h 2.20

1,890

Heating Capacity kW

kcal/h 2.40

2,060

Moisture Removal l/h

Pint/h 1.4

3.0

Power Source Phase

Cycle

Single

230

Airflow Method OUTLET

INTAKE

SIDE VIEW TOP VIEW

Air Volume Indoor Air (Lo) m3/min (cfm) Cooling; 5.9 (210) —

Heating; 6.2 (220)

Indoor Air (Me) m3/min (cfm) Cooling; 6.2 (220) —

Heating; 7.5 (270)

Indoor Air (Hi) m3/min (cfm) Cooling; 7.5 (270) —

Heating; 8.4 (300)

Indoor Air (SHi) m3/min (cfm) Cooling; 8.4 (300) —

Heating; 8.4 (300)

dB (A) Cooling; High 34, Low 26 Cooling; High 46

Heating; High 36, Low 26 Heating; High 48

Noise Level

Power level dB Cooling; High 47 Cooling; High 61

Heating; High 49 Heating; High 63

Electrical Data Input WCooling; 640

Heating; 590

Running Current ACooling; 3.1

Heating; 2.9

EER W/W (kcal/hw) Cooling; 3.44 (2.95)

COP W/W (kcal/hw) Heating; 4.07 (3.49)

Starting Current A13.0

Piping Connection Port

(Flare piping) inch

inch G ; Half Union 3/8”

L ; Half Union 1/4”G ; 3-way valve 3/8”

L ; 2-way valve 1/4”

Pipe Size

(Flare piping) inch

inch G ; (gas side) 3/8”

L ; (liquid side) 1/4”G ; (gas side) 3/8”

L ; (liquid side) 1/4”

Drain

Hose Inner diameter mm 12 —

Length m0.7 —

CS-VA75KE CU-VA75KE / CS-VA95KE CU-VA95KE / CS-VA125KE CU-VA125KE

Power Cord Length

Number of core-wire m2.0

3 (1.0 mm2)—

—

Dimensions Height inch (mm) 10 - 31/32 (279) 18 - 29/32 (480)

Width inch (mm) 31 - 15/32 (799) 30 - 23/32 (780)

Depth inch (mm) 7 - 27/32 (199) 9 - 21/32 (245)

Net Weight lb (kg) 20 (9.0) 71 (32.0)

Compressor Type —Rotary (1 cylinder)

rolling piston type

Motor Type —Induction (2-poles)

Rate Output W—550

Air Circulation Type Cross-flow Fan Propeller Fan

Material AS + Glass Fiber 30% AES + Glass Fiber 12%

Motor Type Induction (4-poles) Induction (6-poles)

Input W20.6 65.8

Rate Output W10 20

Fan Speed Low rpm Cooling; 820 —

Heating; 855

Medium rpm Cooling; 855 —

Heating; 1,040

High rpm Cooling; 1,040 —

Heating; 1,160

SuperHigh rpm Cooling; 1,160 —

Heating; 1,160

Heat Exchanger Description Evaporator Condenser

Tube material Copper Copper

Fin material Aluminium (Pre Coat) Aluminium (Pre Coat)

Fin Type Slit Fin Louver Fin

Row / Stage (Plate fin configuration, forced draft)

2×14 1×18

FPI 18 19

Size (W × H × L) mm 614 × 294 × 25.4 856 × 457.2 × 22

Refrigerant Control Device —Capillary Tube

Refrigeration Oil (c.c) —RB68A (300)

Refrigerant (R410A) g (oz) —880 (31.1)

Thermostat Electronic Control —

Protection Device —Overload Protector

Capillary Tube Length mm —C (× 2); 970, C-H; 310 H; 610

Flow Rate l/min —C (× 2); 5.0, C-H; 11.3 H; 6.5

Inner Diameter mm —C (× 2); 1.2, C-H; 1.3 H; 1.2

Air Filter Material

Style (c.c) P.P.

Honeycomb —

Capacity Control Capillary Tube

Compressor Capacitor µF, VAC —15 µF, 440VAC

Fan Motor Capacitor µF, VAC 1.0 µF, 400VAC 1.2 µF, 400VAC

• Specifications are subject to change without notice for further improvement.

CS-VA75KE CU-VA75KE / CS-VA95KE CU-VA95KE / CS-VA125KE CU-VA125KE

Unit CS-VA95KE CU-VA95KE

Cooling Capacity kW

kcal/h 2.85

2,450

Heating Capacity kW

kcal/h 3.40

2,920

Moisture Removal l/h

Pint/h 1.7

3.6

Power Source Phase

Cycle

Single

230

Airflow Method OUTLET

INTAKE

SIDE VIEW TOP VIEW

Air Volume Indoor Air (Lo) m3/min (cfm) Cooling; 6.1 (220) —

Heating; 6.1 (220)

Indoor Air (Me) m3/min (cfm) Cooling; 7.5 (270) —

Heating; 7.5 (270)

Indoor Air (Hi) m3/min (cfm) Cooling; 8.9 (310) —

Heating; 9.5 (340)

Indoor Air (SHi) m3/min (cfm) Cooling; 9.5 (340) —

Heating; 9.5 (340)

dB (A) Cooling; High 38, Low 26 Cooling; High 48

Heating; High 38, Low 26 Heating; High 48

Noise Level

Power level (dB) Cooling; High 51 Cooling; High 63

Heating; High 51 Heating; High 63

Electrical Data Input WCooling; 950

Heating; 860

Running Current ACooling; 4.3

Heating; 3.9

EER W/W (kcal/hw) Cooling; 3.00 (2.58)

COP W/W (kcal/hw) Heating; 3.95 (3.40)

Starting Current A20.0

Piping Connection Port

(Flare piping) inch

inch G ; Half Union 3/8”

L ; Half Union 1/4”G ; 3-way valve 3/8”

L ; 2-way valve 1/4”

Pipe Size

(Flare piping) inch

inch G ; (gas side) 3/8”

L ; (liquid side) 1/4”G ; (gas side) 3/8”

L ; (liquid side) 1/4”

Drain

Hose Inner diameter mm 12 —

Length m0.7 —

Power Cord Length

Number of core-wire m2.0

3 (1.0 mm2)—

—

CS-VA75KE CU-VA75KE / CS-VA95KE CU-VA95KE / CS-VA125KE CU-VA125KE

Dimensions Height inch (mm) 10 - 31/32 (279) 18 - 29/32 (480)

Width inch (mm) 31 - 15/32 (799) 30 - 23/32 (780)

Depth inch (mm) 7 - 27/32 (199) 9 - 21/32 (245)

Net Weight lb (kg) 20 (9.0) 73 (33.0)

Compressor Type —Rotary (1 cylinder)

rolling piston type

Motor Type —Induction (2-poles)

Rate Output W—750

Air Circulation Type Cross-flow Fan Propeller Fan

Material AS + Glass Fiber 30% AES + Glass Fiber 12%

Motor Type Induction (4-poles) Induction (6-poles)

Input W26.9 65.8

Rate Output W13 20

Fan Speed Low rpm Cooling; 830 —

Heating; 830

Medium rpm Cooling; 1,030 —

Heating; 1,030

High rpm Cooling; 1,215 —

Heating; 1,300

SuperHigh rpm Cooling; 1,300 —

Heating; 1,300

Heat Exchanger Description Evaporator Condenser

Tube material Copper Copper

Fin material Aluminium (Pre Coat) Aluminium (Pre Coat)

Fin Type Slit Fin Louver Fin

Row / Stage (Plate fin configuration, forced draft)

2×14 1×18

FPI 18 19

Size (W ×H×L) mm 614 ×294 ×25.4 856 ×457.2 ×22

Refrigerant Control Device —Capillary Tube

Refrigeration Oil (c.c) —RB68A (350)

Refrigerant (R410A) g (oz) —870 (30.7)

Thermostat Electronic Control —

Protection Device —Overload Protector

Capillary Tube Length mm —C(×2); 970, C-H; 590 H; 590

Flow Rate l/min —C(×2); 5.0, C-H; 17.5 H; 8.2

Inner Diameter mm —C(×2); 1.2, C-H; 1.7 H; 1.3

Air Filter Material

Style (c.c) P.P.

Honeycomb —

Capacity Control Capillary Tube

Compressor Capacitor µF, VAC —25 µF, 370VAC

Fan Motor Capacitor µF, VAC 1.5 µF, 400VAC 1.2 µF, 400VAC

• Specifications are subject to change without notice for further improvement.

CS-VA75KE CU-VA75KE / CS-VA95KE CU-VA95KE / CS-VA125KE CU-VA125KE

Unit CS-VA125KE CU-VA125KE

Cooling Capacity kW

kcal/h 3.65

3,140

Heating Capacity kW

kcal/h 4.20

3,610

Moisture Removal l/h

Pint/h 2.1

4.4

Power Source Phase

Cycle

Single

230

Airflow Method OUTLET

INTAKE

SIDE VIEW TOP VIEW

Air Volume Indoor Air (Lo) m3/min (cfm) Cooling; 6.4 (230) —

Heating; 6.4 (230)

Indoor Air (Me) m3/min (cfm) Cooling; 8.0 (280) —

Heating; 8.0 (280)

Indoor Air (Hi) m3/min (cfm) Cooling; 9.0 (320) —

Heating; 9.6 (340)

Indoor Air (SHi) m3/min (cfm) Cooling; 9.6 (340) —

Heating; 9.6 (340)

dB (A) Cooling; High 39, Low 29 Cooling; High 49

Heating; High 39, Low 29 Heating; High 49

Noise Level

Power level (dB) Cooling; High 52 Cooling; High 64

Heating; High 52 Heating; High 64

Electrical Data Input kW Cooling; 1.24

Heating; 1.17

Running Current ACooling; 5.6

Heating; 5.3

EER W/W (kcal/hw) Cooling; 2.94 (2.53)

COP W/W (kcal/hw) Heating; 3.59 (3.09)

Starting Current A25.0

Piping Connection Port

(Flare piping) inch

inch G ; Half Union 1/2”

L ; Half Union 1/4”G ; 3-way valve 1/2”

L ; 2-way valve 1/4”

Pipe Size

(Flare piping) inch

inch G ; (gas side) 1/2”

L ; (liquid side) 1/4”G ; (gas side) 1/2”

L ; (liquid side) 1/4”

Drain

Hose Inner diameter mm 12 —

Length m0.7 —

Power Cord Length

Number of core-wire m2.0

3 (1.0 mm2)—

—

CS-VA75KE CU-VA75KE / CS-VA95KE CU-VA95KE / CS-VA125KE CU-VA125KE

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Panasonic Klimaanlage Handbücher

Panasonic

Panasonic CS-E9CKP Bedienungsanleitung

Panasonic

Panasonic CS-E24LKES Bedienungsanleitung

Panasonic

Panasonic CS-K24PKF Bedienungsanleitung

Panasonic

Panasonic CSC9BKP - SPLIT A/C SYSTEM Bedienungsanleitung

Panasonic

Panasonic CS-HE9NKD Bedienungsanleitung

Panasonic

Panasonic S-15MF3E5AN Bedienungsanleitung

Panasonic

Panasonic CS-C181KE Bedienungsanleitung

Panasonic

Panasonic S-22KA1E5 Bedienungsanleitung

Panasonic

Panasonic CSS12JKUW - SPLIT A/C INDOOR Bedienungsanleitung

Panasonic

Panasonic CW-C120MU Bedienungsanleitung

Panasonic

Panasonic CS-MKS9NB4U Installations- und Benutzerhandbuch

Panasonic

Panasonic CS-WPU24WKH-8M Bedienungsanleitung

Panasonic

Panasonic CS-E15DTEW Bedienungsanleitung

Panasonic

Panasonic CS-PC12MKF Bedienungsanleitung

Panasonic

Panasonic CS-E24MKES Bedienungsanleitung

Panasonic

Panasonic CS-E10JD3EA Bedienungsanleitung

Panasonic

Panasonic CS-20PM1HPK Bedienungsanleitung

Panasonic

Panasonic CS-MKE18NKU Bedienungsanleitung

Panasonic

Panasonic S-3650PU3E Bedienungsanleitung

Panasonic

Panasonic CS-A7HKD Bedienungsanleitung

Panasonic

Panasonic CS-YE18NKV-6 Bedienungsanleitung

Panasonic

Panasonic S-15MK2E5A Bedienungsanleitung

Panasonic

Panasonic cs-pa7dkd Bedienungsanleitung

Panasonic

Panasonic WH-ADC0309H3E5 Betriebsanleitung

Beliebte Klimaanlage Handbücher anderer Marken

Spheros

Spheros CC 355 Bedienungsanleitung

Bosch

Bosch Climate 5000 SCI 24 CAS/ OU- OUE Bedienungsanleitung

nedis

nedis ACMB1WT7 Bedienungsanleitung

Samsung

Samsung AR KV Series Leitfaden

Daikin

Daikin FCFV50A Bedienungsanleitung

Fujitsu

Fujitsu Inverter ASBA30JFC Bedienungsanleitung

Toshiba

Toshiba RAS-M10SMUV-E Bedienungsanleitung

Daikin

Daikin FXLQ20MAVE Bedienungsanleitung

Hitachi

Hitachi RAS-E24CAK Bedienungsanleitung

CIAT

CIAT Magister 2 Series Leitfaden

Bestron

Bestron AAC6000 Bedienungsanleitung

Hisense

Hisense 7K Technisches Handbuch

Frigidaire

Frigidaire FFRE0533S1E0 Bedienungsanleitung

Samsung

Samsung AS09HM3N Bedienungsanleitung

Frigidaire

Frigidaire CRA073PU11 Betriebsanleitung

Soleus Air

Soleus Air GB-PAC-08E4 Bedienungsanleitung

McQuay

McQuay MCK020A Bedienungsanleitung

Webasto

Webasto Frigo Top 25 DS Bedienungsanleitung
