Panasonic CS-VE9NKE Bedienungsanleitung

F568728

ENGLISH

Before operating the unit, read these operating

instructions thoroughly and keep them for future

reference.

FRANÇAIS

Avant d’utiliser l’appareil, lisez ce mode d’emploi

dans son intégralité et conservez-le pour toute

référence ultérieure.

ESPAÑOL

Antes de utilizar la unidad, sírvase leer

atentamente estas instrucciones de

funcionamiento y conservarlas como futuro

elemento de consulta.

DEUTSCH

Bevor Sie das Gerät in Betrieb nehmen, lesen

Sie bitte diese Bedienungsanleitung aufmerksam

durch und bewahren Sie sie für die künftige

Verwendung auf.

ITALIANO

Prima di utilizzare l’unità si prega di leggere

attentamente le istruzioni e di conservare questo

opuscolo per potervi fare riferimento in futuro.

NEDERLANDS

Lees voor u het apparaat gebruikt deze

gebruiksinstructies grondig en bewaar ze voor

toekomstig gebruik.

QUICK GUIDE

GUIDE RAPIDE

GUÍA RÁPIDA

KURZANLEITUNG

GUIDA RAPIDA

SNELLE GIDS

Operating Instructions

Air Conditioner

Model No.

Indoor Unit Outdoor Unit

CS-VE9NKE CU-VE9NKE

CS-VE12NKE CU-VE12NKE

POWER NANOE-G TIMER +8/10°C

F568728_YB0512-1062.indb 1F568728_YB0512-1062.indb 1 6/11/2012 9:43:19 AM6/11/2012 9:43:19 AM

ENGLISH

TABLE OF CONTENTS

NOTICE: When the outdoor temperature is out of the above

temperature range, the heating capacity will drop signiﬁcantly and

outdoor unit might stop for protection control.

OPERATION CONDITION

Use this air conditioner under the following temperature range

Temperature (°C) Indoor Outdoor

*DBT *WBT *DBT *WBT

COOLING Max. 32 23 43 26

Min. 16 11 -10 -

HEATING Max. 30 - 24 18

Min. 16 - -20 -

+8/10°C

HEAT Max. 10 - - -

Min. 8 - -20 -

* DBT: Dry bulb temperature * WBT: Wet bulb temperature

SAFETY PRECAUTIONS 4~5

REMOTE CONTROL 6~9

INDOOR UNIT 10~11

TROUBLESHOOTING 12

INFORMATION 13

QUICK GUIDE BACK COVER

NOTE : The illustrations in this manual are for explanation purposes only and may differ from the actual unit.They are

subjected to change without notice for future improvement.

FRANÇAIS

TABLE DES MATIÈRES

ATTENTION: Si la température extérieure sort de la plage de températures

ci-dessus, la capacité thermique chutera de façon importante et il se peut que

l’unité extérieure s’arrête pour le contrôle de protection.

CONDITION D’UTILISATION

Utilisez ce climatiseur en respectant la plage de températures suivante

Température (°C) Unité intérieure Unité extérieure

*DBT *WBT *DBT *WBT

REFROIDIS-

SEMENT Max. 32 23 43 26

Min. 16 11 -10 -

CHAUFFAGE Max. 30 - 24 18

Min. 16 - -20 -

+8/10°C

DE CHAUFFAGE Max. 10 - - -

Min. 8 - -20 -

* DBT: Température sèche * WBT: Température humide

CONSIGNES DE SÉCURITÉ

14~15

TÉLÉCOMMANDE 16~19

UNITÉ INTÉRIEURE 20~21

DÉPANNAGE 22

INFORMATIONS 23

GUIDE RAPIDE

DOS DE COUVERTURE

REMARQUE : Les illustrations de ce mode d’emploi sont fournies à titre d’exemple uniquement et peuvent présenter des différences

par rapport à l’appareil proprement dit. Celui-ci peut être modiﬁé sans préavis à des ﬁns d’amélioration.

ESPAÑOL

CONTENIDO

AVISO: Cuando la temperatura exterior esté fuera del intervalo de temperatura

superior, la capacidad del equipo disminuirá signiﬁcativamente y la unidad

exterior podría pararse como protección.

CONDICIONES DE FUNCIONAMIENTO

Utilice este aparato de aire acondicionado dentro del siguiente intervalo

de temperaturas

Temperatura (°C) Interior Exterior

*DBT *WBT *DBT *WBT

ENFRIAMIENTO

Máx. 32 23 43 26

Mín. 16 11 -10 -

CALENTAMIENTO

Máx. 30 - 24 18

Mín. 16 - -20 -

+8/10°C

CALOR Máx. 10 - - -

Mín. 8 - -20 -

* DBT: Temperatura en seco * WBT: Temperatura en húmedo

PRECAUCIONES DE

SEGURIDAD 24~25

MANDO A DISTANCIA 26~29

UNIDAD INTERIOR 30~31

LOCALIZACIÓN DE AVERÍAS

INFORMACIÓN 33

GUÍA RÁPIDA

CUBIERTA TRASERA

NOTA : Las ilustraciones de este manual sirven únicamente para describir las explicaciones y pueden no coincidir exactamente con las

del aparato suministrado. Están sujetas a cambios sin previo aviso con el ﬁn de mejorar el producto.

Nous vous remercions d’avoir porté votre choix sur un climatiseur Panasonic

Thank you for purchasing Panasonic Air Conditioner

Muchas gracias por elegir una unidad de aire acondicionado Panasonic

F568728_YB0512-1062.indb 2F568728_YB0512-1062.indb 2 6/11/2012 9:43:23 AM6/11/2012 9:43:23 AM

DEUTSCH

INHALT

BETRIEBSBEREICHE

Verwenden Sie dieses Klimagerät in folgenden Temperaturbereichen

Temperatur (°C) Innen Außen

*TK *FK *TK *FK

KÜHLEN Max. 32 23 43 26

Min. 16 11 -10 -

HEIZEN Max. 30 - 24 18

Min. 16 - -20 -

+8/10°C

HEIZBETRIEB Max. 10 - - -

Min. 8 - -20 -

* TK: Trockenkugeltemperatur * FK: Feuchtkugeltemperatur

HINWEIS: Wenn sich dieAußentemperatur außerhalb des oben genannten

Bereiches beﬁndet, fällt die Heizleistung erheblich ab, und dasAußengerät kann

durch Schutzmaßnahmen abgeschaltet werden.

SICHERHEITSHINWEISE

34~35

FERNBEDIENUNG 36~39

INNENGERÄT 40~41

STÖRUNGSSUCHE 42

INFORMATIONEN 43

KURZANLEITUNG

RÜCKSEITE

HINWEIS : DieAbbildungen in diesem Handbuch dienen nur Erläuterungszwecken und können sich von dem tatsächlichen Gerät

unterscheiden. Sie können durch künftige Verbesserungen am Gerät ohne vorherigeAnkündigung geändert werden.

ITALIANO

INDICE

CAVVISO: Quando la temperatura esterna non è ricompresa tra la gamma delle

temperature di cui sopra, la capacità di riscaldare diminuirà sensibilmente e

l’unità esterna può arrestarsi seguendo un comando di sicurezza.

CONDIZIONI OPERATIVE

Questo condizionatore può essere utilizzato con temperature rientranti nel

seguente intervallo

Temperatura (°C) Interna Esterna

*DBT *WBT *DBT *WBT

RAFFREDDAMENTO

Max. 32 23 43 26

Min. 16 11 -10 -

RISCALDAMENTO

Max. 30 - 24 18

Min. 16 - -20 -

+8/10°C

RISCALDAMENTO

Max. 10 - - -

Min. 8 - -20 -

*DBT: Temperatura con bulbosecco * WBT: Temperaturacon bulbo bagnato

PRECAUZIONI PER LA

SICUREZZA 44~45

TELECOMANDO 46~49

UNITÀ INTERNA 50~51

SOLUZIONE DEI PROBLEMI

INFORMAZIONI 53

GUIDA RAPIDA

COPERCHIO POSTERIORE

NOTA : le illustrazioni contenute in questo manuale sono riportate esclusivamente a scopo esplicativo e potrebbero differire

dall’apparecchio vero e proprio. I contenuti del presente manuale sono soggetti a modiﬁca senza preavviso e verranno aggiornati

in base alle innovazioni future.

NEDERLANDS

INHOUDSOPGAVE

OPMERKING: Wanneer de buitentemperatuur buiten het hierboven vermelde

temperatuurbereik ligt, zal de verwarmingscapaciteit aanzienlijk afnemen

en zal de buiten-unit door een beveiligingsvoorziening misschien niet meer

functioneren.

GEBRUIKSOMSTANDIGHEDEN

Gebruik deze airconditioner binnen het volgende temperatuurbereik

Temperatuur (°C) Binnen Buiten

*DBT *WBT *DBT *WBT

KOELEN Max. 32 23 43 26

Min. 16 11 -10 -

VERWARMEN Max. 30 - 24 18

Min. 16 - -20 -

+8/10°C

VERWARM Max. 10 - - -

Min. 8 - -20 -

* DBT: Droge bolttemperatuur * WBT: Natte bolttemperatuur

VEILIGHEIDSMAATREGELEN

54~55

AFSTANDSBEDIENING56~59

BINNENUNIT 60~61

PROBLEMEN OPLOSSEN 62

INFORMATIE 63

SNELLE GIDS

ACHTERKLEP

OPMERKING : De afbeeldingen in deze handleiding zijn alleen bedoeld als toelichting en kunnen afwijken van het daadwerkelijke

uiterlijk van het apparaat. Deze handleiding kan zonder voorafgaande kennisgeving worden gewijzigd ter verbetering.

Wir danken Ihnen für den Kauf Ihres Panasonic-Klimageräts

Grazie per aver acquistato un climatizzatore Panasonic

Hartelijk dank voor de aanschaf van de Panasonicairconditioner

F568728_YB0512-1062.indb 3F568728_YB0512-1062.indb 3 6/11/2012 9:43:24 AM6/11/2012 9:43:24 AM

SAFETY PRECAUTIONS

To prevent personal injury, injury to others, or property

damage, please comply with the following.

Incorrect operation due to failure to follow instructions below

may cause harm or damage, the seriousness of which is

classiﬁed as below:

WARNING

This sign warns of death or serious injury.

CAUTION

This sign warns of injury or damage to property.

The instructions to be followed are classiﬁed by the following

symbols:

This symbol denotes an action that is PROHIBITED.

These symbols denote an actions that is

COMPULSORY.

WARNING

INDOOR UNITAND OUTDOOR UNIT

This appliance is not intended for use by

persons (including children) with reduced

physical, sensory or mental capabilities, or lack

of experience and knowledge, unless they have

been given supervision or instruction concerning

use of the appliance by a person responsible for

their safety. Children should be supervised to

ensure that they do not play with the appliance.

Please consult authorized dealer or specialist to

clean the internal parts, repair, install, remove

and reinstall the unit. Improper installation and

handling will cause leakage, electric shock or

ﬁre.

Conﬁrm to authorized dealer or specialist on

usage of speciﬁed refrigerant type. Using of

refrigerant other than the speciﬁed type may

cause product damage, burst and injury etc.

Do not install the unit in a potentially explosive

or ﬂammable atmosphere. Failure to do so could

result in ﬁre.

Do not insert your ﬁngers or other

objects into the air conditioner indoor

or outdoor unit, rotating parts may

cause injury.

Do not touch the outdoor unit during lightning, it

may cause electric shock.

Do not expose yourself directly to cold air for a

long period to avoid excess cooling.

Do not sit or step on the unit, you may

fall down accidentally.

REMOTE CONTROL

Do not allow infants and small children to play

with the remote control to prevent them from

accidentally swallowing the batteries.

POWER SUPPLY

Do not use a modiﬁed cord,

joint cord, extension cord or

unspeciﬁed cord to prevent

overheating and ﬁre.

To prevent overheating, ﬁre or electric shock:

• Do not share the same power outlet with other

equipment.

• Do not operate with wet hands.

• Do not over bend the power supply cord.

• Do not operate or stop the unit by inserting or

pulling out the power plug.

Air Inlet

Air Outlet

Air Inlet

Remote

Control

Power

Supply

Indoor

Unit

Outdoor

Unit

F568728_YB0512-1062.indb 4F568728_YB0512-1062.indb 4 6/11/2012 9:43:24 AM6/11/2012 9:43:24 AM

ENGLISH

CAUTION

INDOOR UNITAND OUTDOOR UNIT

Do not wash the indoor unit with water, benzene,

thinner or scouring powder to avoid damage or

corrosion at the unit.

Do not use for preservation of precise

equipment, food, animals, plants, artwork

or other objects. This may cause quality

deterioration, etc.

Do not use any combustible equipment in front of

the airﬂow outlet to avoid ﬁre propagation.

Do not expose plants or pet directly to airﬂow to

avoid injury, etc.

Do not touch the sharp aluminium ﬁn,

sharp parts may cause injury.

Do not switch ON the indoor unit when waxing

the ﬂoor.After waxing, aerate the room properly

before operating the unit.

Do not install the unit in oily and smoky areas to

prevent damage to the unit.

Do not dismantle the unit for cleaning purpose to

avoid injury.

Do not step onto an unstable bench when

cleaning the unit to avoid injury.

Do not place a vase or water container on the

unit. Water may enter the unit and degrade the

insulation. This may cause an electric shock.

Do not open window or door for long time during

COOL/DRY mode operation.

Ensure drainage pipe is connected properly and

keep drainage outlet clear of gutters, containers

or does not immersed in water to prevent water

leakage.

After a long period of use or use with any

combustible equipment, aerate the room

regularly.

After a long period of use, make sure the

installation rack does not deteriorate to prevent

the unit from falling down.

REMOTE CONTROL

Do not use rechargeable (Ni-Cd) batteries.

It may damage the remote control.

To prevent malfunction or damage of the remote

control:

• Remove the batteries if the unit is not going to

be used for a long period of time.

• New batteries of the same type must be

inserted following the polarity stated.

POWER SUPPLY

Do not pull the cord to disconnect the plug to

prevent electric shock.

WARNING

POWER SUPPLY

If the supply cord is damage, it must be replaced

by the manufacturer, its service agent or similarly

qualiﬁed persons in order to avoid a hazard.

It is strongly recommended to be installed

with Earth Leakage Circuit Breaker (ELCB)

or Residual Current Device (RCD) to prevent

electric shock or ﬁre.

To prevent overheating, ﬁre or electric shock:

• Insert the power plug properly.

• Dust on the power plug should be periodically

wiped with a dry cloth.

Stop using the product if any abnormality/failure

occurs and disconnect the power plug or turn off

the power switch and breaker.

(Risk of smoke/ﬁre/electric shock)

Examples of abnormality/failure

• The ELCB trips frequently.

• Burning smell is observed.

• Abnormal noise or vibration of the unit is

observed.

• Water leaks from the indoor unit.

• Power cord or plug becomes abnormally hot.

• Fan speed cannot be controlled.

• The unit stops running immediately even if it is

switched on for operation.

• The fan does not stop even if the operation is

stopped.

Contact your local dealer immediately for

maintenance/repair.

This equipment must be earthed to prevent

electrical shock or ﬁre.

Prevent electric shock by switching off the power

supply and unplug when:

- Before cleaning or servicing.

- Extended non-use.

-Abnormally strong lightning activity.

F568728_YB0512-1062.indb 5F568728_YB0512-1062.indb 5 6/11/2012 9:43:25 AM6/11/2012 9:43:25 AM

NOTES

Remote

Control display

Maximum distance: 7m

Human activity sensor

REMOTE CONTROL

Movable panel

Indicator

(Blue) (Orange) (Green)(Green)

POWER NANOE-G TIMER +8/10°C

(Green)

Press the remote control’s button

1TO SELECT OPERATION MODE POWER

AUTO mode - For your convenience

•

During operation mode selection the power indicator blinks.

• Unit selects operation mode every 30 minutes according to

temperature setting, outdoor and room temperature.

HEAT mode - To enjoy warm air

• Unit takes a while to warm up. The power indicator blinks during this

operation.

• This air conditioner removes frost automatically by two types of

operation.

• Unit removes ice formed on outdoor unit by methods below.

• Deice with heating operation (HEAT CHARGE Operation).

Unit has a heat absorbing device which accumulates heat

generated by outdoor unit while performing the heating operation

to remove ice formed on outdoor unit for maximum 6 minutes.

During this operation, the discharge temperature and fan speed

may be lowered when outdoor temperature is low, or the room is

not warmed up sufﬁciently, or set temperature is high.

• Deice without heating operation

Unit stops heating operation to remove large amount of ice

formed on outdoor unit for maximum 12 minutes.

During this operation, the power indicator blinks and the vertical

airﬂow direction louver is left open.

The heating operation resumes once this operation is completed.

COOL mode - To enjoy cool air

• Use curtains to screen off sunlight and outdoor heat to reduce power

consumption during cool mode.

DRY mode - To dehumidify the environment

• Unit operates at low fan speed to give a gentle cooling operation.

MOVABLE PANEL

• Opens for air intake when operation starts, and closes when operation

stops. During this time, do not hold it as it may cause malfunction or

breakdown.

F568728_YB0512-1062.indb 6F568728_YB0512-1062.indb 6 6/11/2012 9:43:26 AM6/11/2012 9:43:26 AM

ENGLISH

NOTES

, , , ,

• Can be activated in all modes and can be cancelled by

pressing the respective button again. • Cannot be selected at the same time.

• operation can be activated independently.

2TO SET TEMPERATURE

• Selection range : 16°C ~ 30°C.

• Operating the unit within the recommended temperature

could induce energy saving.

HEAT mode : 20°C ~ 24°C.

COOLmode : 26°C ~ 28°C.

DRYmode : 1°C ~ 2°C lower than room temperature.

3TO TURN OFF THE UNIT

4TO SELECT FAN SPEED

FAN

PEED

AUTO

• ForAUTO, the indoor fan speed is automatically adjusted

according to the operation mode.

5TOADJUST AIRFLOW DIRECTION

AIR SWING

AUTO

• Keeps the room ventilated.

• In COOL/DRYmode, ifAUTO is set, the louver swing

left/right and up/down automatically.

• In HEAT mode, ifAUTO is set, the horizontal louver ﬁx at

predetermined position. The vertical louver swing left/right

after the temperature rises.

• In POWERFULmode, ifAUTO is set, the vertical louvers

ﬁx at center position of the room according to installation

location setting.

6TO REACH TEMPERATURE QUICKLY

• The temperature setting and the Fan speed automatically

adjusted for higher performance, and will adjust for

adequate operation once the temperature is reached.

• Press the button again or turn OFF the unit to stop this

operation.

7TO ENJOY QUIET OPERATION

• This operation reduces airﬂow noises.

8TO CHANGE SETTINGACCORDING TO LIVING

ENVIRONMENT

• Complete below procedures to change the settings.

• 3 options are available in MENU.

CENTER BRIGHTNESS CONTRAST

• Select preference setting.

• Indoor unit installation location

CENTER LEFT RIGHT

• Indoor unit indicator brightness

BRIGHTER

LED

DIMMER

LED

ECONAVI

OFF

• Remote control LCD contrast

CONTRAST

3456 712

• Press SET to conﬁrm the setting.

F568728_YB0512-1062.indb 7F568728_YB0512-1062.indb 7 6/11/2012 9:43:27 AM6/11/2012 9:43:27 AM

REMOTE CONTROL

NOTES

, , , , ,

• Can be activated in all modes and can be cancelled by

pressing the respective button again. • Cannot be selected at the same time.

• operation can be activated independently.

9TO MONITOR HUMAN PRESENCE & ACTIVITY,

SUNLIGHT FOR ENERGY SAVING & COMFORT

ECONAVI

To optimize energy

saving

• When the operation is activated, the unit will start to

initialize for approximately 1 minute.

• After initialization, the human activity sensor will start

to detect the level of heat source & movement, the unit

adjusts the temperature and airﬂow to keep you comfort

consistently.

+1°C

Fan Speed

COLD/DRY Mode

Set Temperature +1°C

Low High Normal None

Fan Speed -2°C

-2°C

HEAT Mode

Set Temperature

Heat Source & Movement

• The human activity sensor will also scan for area of heat

source and movement in a room.

• The unit will determine the heat source & movement

hotspot, and automatically adjust horizontal airﬂow

direction louver either ﬁx at predetermined position.

Detection area (top view)

160º

• When manualAIR SWING or FAN SPEED is

selected, the ECONAVI operation will be cancel.

• The human activity sensor may not detect moving objects

further than 5m away or beyond detection angle.

• The human activity sensor sensitivity is inﬂuenced by

indoor unit location, movement speed, temperature range,

etc.

• The human activity sensor may:

- Mistakenly detects an object with heat source &

movement similar to human, such as pets, etc. as

human being.

- Mistakenly detects as non-heat source & movement if

a person stays motionless for certain period of time.

• The sunlight sensor detects sunlight intensity coming

through windows and differentiates between sunny

and cloudy/night to further optimize energy saving by

adjusting the temperature.

Ambient condition SunnyCloudy/

Night SunnyCloudy/

Night

COOL/DRY Mode

Set Temperature

HEAT Mode

Set Temperature -1°C -1°C

+1~2°C

ECONAVI is activated while it is cloudy / night

ECONAVI is activated while it is sunn

• In a room without window or with thick curtain, the

sunlight sensor will judge as cloudy/night.

• When sunlight sensor judge as cloudy/night, the indoor

unit indicator will automatically dim.

F568728_YB0512-1062.indb 8F568728_YB0512-1062.indb 8 6/11/2012 9:43:29 AM6/11/2012 9:43:29 AM

ENGLISH

10 TO MONITOR HUMAN PRESENCE & ACTIVITY

• The human activity sensor will scan for the heat source

and movement in the room.

• The unit will determine the heat source & movement

hotspot, and automatically adjust horizontal airﬂow

direction louver ﬁx at predetermined position.

• When manualAIR SWING or FAN SPEED is

selected,AUTO COMFORToperation will be cancel.

11 TO PURIFY THE AIR NANOE-G

• Removes/deactivates harmful micro-organisms such as

viruses, bacteria, etc.

• nanoe-G starts automatically when the unit switched on.

12 TO USE MAINTENANCE HEATING

+ 8/10°C

• Maintain indoor temperature at +8/10ºC. Fan switches to

high fan speed automatically.

• This operation overwrite the operation mode and could be

cancelled by pressingAUTO, HEAT, COOLor DRYmode.

• Deice operation at outdoor unit will result in

sudden cold air from indoor unit. Eliminate

cold air with heat mode.

10°C

8°C

13 INFO

• Press during HEAT orAUTO mode to retrieve level of heat

stored in heat absorbing device; HEAT CHARGE level 1

(min.) to 4 (max.). “--” will be displayed during COOL, DRY

or NANOE-G mode.

• Press to retrieve error code when the unit stops and the

timer indicator blinks.

If the signal transmission is failed, (PRESSAGAIN).

14 TO TURN OFF THE UNITAFTER ASLEEP

0.5

SLEEP 1 2 3 5 7 9hr Cancel

• When used together with the timer, sleep operation has a

priority.

15 PRESS TO RESTORE THE INDOOR UNIT

SETTING

• To restore the remote control’s default setting, remove the

batteries.

NOTES

16 TO SET THE TIMER

• 2 sets of ON and OFF timers are available to turn ON or

OFF the unit at different preset time.

• Complete below procedures to set each timer:

Cancel

TIMER

Select ON or OFF timer Set the

time Conﬁrm

• Example of application at living room:

Morning: ON at 07:00 (Wake up)

OFF

at 08:00 (Out for work)

Evening: ON at 17:00 (Back home)

OFF

at 22:00 (Sleep)

• To cancel ON or OFF timer, press or to

select respective or then press .

• If timer is cancelled manually or due to power failure,

you can restore the timer again by pressing or

to select respective or then press .

• Upcoming timer will be displayed and will be activated

in sequence.

• When ON Timer is set, the unit may start earlier (up to 15

minutes at COOLmode, up to 40 minutes at HEAT mode)

before the actual set time in order to achieve the desired

temperature on time.

• Timer operation is based on the clock set in the remote

control and repeats daily once set. For clock setting,

please refer to Remote Control Preparation on the back

cover.

F568728_YB0512-1062.indb 9F568728_YB0512-1062.indb 9 6/11/2012 9:43:31 AM6/11/2012 9:43:31 AM

POWER NANOE-G TIMER +8/10°C

INDOOR UNIT

CLEANING INSTRUCTIONS

HINT

• Do not use benzene, thinner or scouring powder.

• Use only soap ( pH7) or neutral household detergent.

• Do not use water hotter than 40°C.

• To ensure optimal performance of the unit, cleaning

maintenance has to be carried out at regular intervals.

Dirty unit may cause malfunction and you may see error

code “H99”. Please consult authorized dealer.

6HUMAN ACTIVITY SENSOR

• Do not hit or violently press the sensor or

poke it with a sharp object. This can lead

to damage and malfunction.

• Do not place large objects near the

sensor and keep away heating units

or humidiﬁers from the sensor’s

detection area. This may lead to sensor

malfunction.

11 nanoe-G GENERATOR

• Do not touch during operation.

1INDOOR UNIT

• Wipe the unit gently with a soft, dry cloth.

2FRONT PANEL WITH MOVABLE PANEL

Remove Front Panel

• Raise and pull to remove the front panel.

• Wash gently and dry.

Close Front Panel

•

Press down both ends of the front panel to close it securely.

•

Do not remove the movable panel from front panel.

3REMOTE CONTROL RECEIVER

4SUNLIGHT SENSOR

5ALUMINIUM FIN

6HUMAN ACTIVITY SENSOR

7HORIZONTALAIRFLOW DIRECTION LOUVER

• Do not adjust by hand.

8VERTICALAIRFLOW DIRECTION LOUVER

• Do not adjust by hand.

•Switch off the power supply and unplug before cleaning.

•Do not touch the aluminium ﬁn, sharp parts may cause injury.

F568728_YB0512-1062.indb 10F568728_YB0512-1062.indb 10 6/11/2012 9:43:33 AM6/11/2012 9:43:33 AM

Andere Handbücher für CS-VE9NKE

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Sprachen:

Andere Panasonic Klimaanlage Handbücher

Panasonic

Panasonic CW-C100MU Bedienungsanleitung

Panasonic

Panasonic CS-W50BTP Bedienungsanleitung

Panasonic

Panasonic KIT-UZ25-VKE Bedienungsanleitung

Panasonic

Panasonic CS-YZ9WKH-8 Bedienungsanleitung

Panasonic

Panasonic CS-Z25YKEA Bedienungsanleitung

Panasonic

Panasonic CS-A18EKH Bedienungsanleitung

Panasonic

Panasonic S-22MU1E5 Bedienungsanleitung

Panasonic

Panasonic U-20GES3E5 Bedienungsanleitung

Panasonic

Panasonic CS-W18NKD Bedienungsanleitung

Panasonic

Panasonic Urban Multi Series Bedienungsanleitung

Panasonic

Panasonic CS-E9PKEA Bedienungsanleitung

Panasonic

Panasonic CS-A182KR Bedienungsanleitung

Panasonic

Panasonic CS-MKS7NKU Installations- und Benutzerhandbuch

Panasonic

Panasonic CS-C28JKV Bedienungsanleitung

Panasonic

Panasonic CS-CZ25WKE Bedienungsanleitung

Panasonic

Panasonic CS-RU18UKYRN Series Bedienungsanleitung

Panasonic

Panasonic ACXF55-32920 Bedienungsanleitung

Panasonic

Panasonic CS-V28EKE CU-V28EKE Bedienungsanleitung

Panasonic

Panasonic CS-RE18NKE Bedienungsanleitung

Panasonic

Panasonic S-22MF2E5 Bedienungsanleitung

Panasonic

Panasonic CS-RE9PKV-7 Bedienungsanleitung

Panasonic

Panasonic CS-Z25UB4RAW Bedienungsanleitung

Panasonic

Panasonic CS-KE18NKU Bedienungsanleitung

Panasonic

Panasonic CS-PW18MKD Bedienungsanleitung

Beliebte Klimaanlage Handbücher anderer Marken

Spheros

Spheros CC 355 Bedienungsanleitung

Bosch

Bosch Climate 5000 SCI 24 CAS/ OU- OUE Bedienungsanleitung

nedis

nedis ACMB1WT7 Bedienungsanleitung

Samsung

Samsung AR KV Series Leitfaden

Daikin

Daikin FCFV50A Bedienungsanleitung

Fujitsu

Fujitsu Inverter ASBA30JFC Bedienungsanleitung

Toshiba

Toshiba RAS-M10SMUV-E Bedienungsanleitung

Daikin

Daikin FXLQ20MAVE Bedienungsanleitung

Hitachi

Hitachi RAS-E24CAK Bedienungsanleitung

CIAT

CIAT Magister 2 Series Leitfaden

Bestron

Bestron AAC6000 Bedienungsanleitung

Hisense

Hisense 7K Technisches Handbuch

Frigidaire

Frigidaire FFRE0533S1E0 Bedienungsanleitung

Samsung

Samsung AS09HM3N Bedienungsanleitung

Frigidaire

Frigidaire CRA073PU11 Betriebsanleitung

Soleus Air

Soleus Air GB-PAC-08E4 Bedienungsanleitung

McQuay

McQuay MCK020A Bedienungsanleitung

Webasto

Webasto Frigo Top 25 DS Bedienungsanleitung
