Panasonic ET-MDNDP10C Bedienungsanleitung
Thank you for purchasing this Panasonic product.
■Before using this product, please read these “Operating Instructions” and
the “Operating Instructions” of the projector carefully and save the manuals
for future use.
■Before using this product, be sure to read “Read this rst!” (xpage 3).
DPQX1381ZA/X1
Printed in China
Interface Board for DisplayPort 2 input
Commercial Use
Operating Instructions
ENGLISH
Model No. ET-MDNDP10C
ET-MDNDP10C_DPQX1381ZA_E.indb 1 2019/03/15 9:53:10
2 - ENGLISH
Contents
Contents
Read this rst! 3
Precautions for use 5
Supported projector 5
About the handling of the product 5
Disposal 5
Accessories 6
Part names and functions 6
Installing the Interface Board 7
Before installing or removing the Interface Board 7
How to install the Interface Board 8
How to remove the Interface Board 9
Specications 10
rTrademarks
fDisplayPort™ is a trademark owned by the Video Electronics Standards
Association (VESA®) in the United States and other countries.
ET-MDNDP10C_DPQX1381ZA_E.indb 2 2019/03/15 9:53:10
ENGLISH - 3
Read this rst!
Read this rst!
WARNING:
Do not spill water on this product or allow this product to get wet.
Doing so may cause re, electric shock, or malfunction due to short circuit
or overheating.
fDo not place a container with liquid close to this product.
fConsult your dealer when liquid such as water is spilled on this
product.
Do not place the supplied screws in a location that a child can reach.
Accidentally swallowing them can cause a physical harm.
fSeek a medical advice immediately if a child might have swallowed a
screw.
Do not disassemble or modify.
Doing so may cause electric shock or re. It may also cause a malfunction.
CAUTION:
Do not place this product in a location with excessive humidity or
dust, or in a location exposed to oil smoke or steam.
Doing so may cause re or electric shock.
Do not place this product in extremely hot location.
Doing so may deteriorate the part, or may cause re.
fDo not install or store in a location with direct sunlight or close to the
heating device, etc.
Turn o the power and disconnect the power plug from the outlet
when installing or removing this product to/from the projector.
Failure to do so may cause electric shock.
ET-MDNDP10C_DPQX1381ZA_E.indb 3 2019/03/15 9:53:10
4 - ENGLISH
Read this rst!
Name and quantity of hazardous substances contained in the
product
Parts Hazardous substances
Pb Hg Cd Cr VI PBB PBDE
Printed circuit boards
(PCB)
Accessories
This table is prepared in accordance with the provisions of SJ/T 11364.
: The amount of hazardous substances included in all homogeneous
materials for the relevant part does not exceed the limit specied in GB/T
26572.
: The amount of hazardous substances included in all homogeneous
materials for the relevant part exceeds the limit specied in GB/T 26572.
ET-MDNDP10C_DPQX1381ZA_E.indb 4 2019/03/15 9:53:10
Precautions for use
ENGLISH - 5
Precautions for use
This product is an interface board with two DisplayPort inputs for use
installed in a Panasonic projector.
Supported projector
PT-SRQ22KC
(As of April 2019)
Note
fProducts other than the above may also be supported. Refer to the operating instructions for
your projector or the Panasonic website (http://prosystem.panasonic.cn/projector/download.
html).
fIf the main version of the rmware of the PT-SRQ22KC is less than 3.00, this interface board
cannot be used. For details, contact your dealer.
About the handling of the product
rDo not touch the connector section of the Interface Board
directly with your hands.
The component may be damaged by the static electricity. To prevent the
static electricity damage, remove the static electricity in your body by
touching the surrounding metal, etc. beforehand.
Disposal
To dispose of the product, ask your local authorities or dealer for correct
methods of disposal.
ET-MDNDP10C_DPQX1381ZA_E.indb 5 2019/03/15 9:53:10
Precautions for use
6 - ENGLISH
Accessories
Make sure that the following accessories are provided with your product.
Numbers enclosed in < > show the number of accessories.
Screw <4>
(XSB3+8FN)
Attention
fAppropriately discard the packaging material after unpacking the product.
fFor missing accessories, consult your dealer.
fStore small parts in an appropriate manner, and keep them away from small children.
Note
fThe supplied screws are spare. Use them when a screw to x the slot cover of the projector
is lost.
fThe model numbers of accessories are subject to change without prior notice.
Part names and functions
3 31 2
1 <DisplayPort 输入 1> terminal
(when it is installed in <SLOT 1> of
the projector),
<DisplayPort 输入 3> terminal
(when it is installed in <SLOT 2> of
the projector)
This is a terminal to input DisplayPort
signals.
2 <DisplayPort 输入 2> terminal
(when it is installed in <SLOT 1> of
the projector),
<DisplayPort 输入 4> terminal
(when it is installed in <SLOT 2> of
the projector)
This is a terminal to input DisplayPort
signals.
3 Handle
ET-MDNDP10C_DPQX1381ZA_E.indb 6 2019/03/15 9:53:10
Installing the Interface Board
ENGLISH - 7
Installing the Interface Board
It is recommended to ask a qualied technician to install or remove the
Interface Board to a projector. A malfunction may occur due to static
electricity. Consult your dealer.
Before installing or removing the Interface Board
fAlways turn o the power of the projector before installing or removing the
Interface Board.
gMake sure to follow the procedure described in the Operating
Instructions of your projector when turning o the power.
fDo not touch the connector section of the Interface Board directly with your
hands.
gThe component may be damaged by the static electricity.
fTo prevent the static electricity damage, remove the static electricity in your
body by touching the surrounding metal, etc. beforehand.
fTake care not to get injured when installing or removing the Interface
Board.
gHands may be injured by the opening of the blank slot of the projector or
the edge of the bracket of the Interface Board.
fWhen installing the Interface Board to the slot, insert it into the connector
straight and slowly.
gIt may not operate or cause malfunction if it is not correctly installed.
ET-MDNDP10C_DPQX1381ZA_E.indb 7 2019/03/15 9:53:10
Installing the Interface Board
8 - ENGLISH
How to install the Interface Board
Screws (4 locations) Screws (4 locations)Salient
Slot cover Guide groove
Fig. 1 Fig. 2 Fig. 3
1) Remove the slot cover. (Fig. 1)
fRemove the four screws xing the slot cover of the projector by
rotating counterclockwise with a Phillips screwdriver. The removed
screws are used to x the Interface Board.
fWhen removing the fourth screw, hold the slot cover with your hand so
it will not fall.
fTo replace from other Interface Board, remove the Interface Board
following the procedure in “How to remove the Interface Board”
(xpage 9).
2) Install the Interface Board to the projector. (Fig. 2)
fInsert the guide groove of the Interface Board aligned to the salient of
the slot. Insert the bracket rmly all the way in.
3) Fix the Interface Board. (Fig. 3)
fTighten and x with the four screws removed in Step 1).
Attention
fThe removed slot cover is required when the unnecessary Interface Board is removed. Store
it so it can be attached in the future.
ET-MDNDP10C_DPQX1381ZA_E.indb 8 2019/03/15 9:53:10
Installing the Interface Board
ENGLISH - 9
How to remove the Interface Board
Fig. 1
Handle
1) Remove the Interface Board. (Fig. 1)
fRemove the four screws xing the Interface Board by rotating
counterclockwise with a Phillips screwdriver. The removed screws are
used to x the slot cover.
fHold the handle of the Interface Board and remove it slowly.
2) Attach the slot cover.
fAttach the stored slot cover to the blank slot, and tighten and x with
the four screws removed in Step 1).
Attention
fAlways attach the slot cover on the blank slot.
fStore the removed Interface Board inside an antistatic bag.
ET-MDNDP10C_DPQX1381ZA_E.indb 9 2019/03/15 9:53:11
Specications
10 - ENGLISH
Specications
Compatible slot SLOT NX specication
Connection terminals
DisplayPort 2 lines
HDCP2.2 compatible, SST(Single-stream Transport) mode
compatible
Supported
signals
Resolution Moving image signal: 480/60p to 4 096 x 2 160/60p
Still image signal: 640 x 480 to 3 840 x 2 400 (non-interlace)
Dot clock
frequency 25 MHz to 594 MHz
Dimensions
Width 151 mm (5-15/16")
Height 38.5 mm (1-17/32")
Depth 142 mm (5-19/32")
Weight 380 ] (13.4 ozs.)
Note
f“SLOT NX” is a name of the slot unique to Panasonic supporting the signal input for the 4K
image.
fThe video signal that can actually display will vary depending on the projector that the
Interface Board is installed. For details, refer to the Operating Instructions of your projector.
ET-MDNDP10C_DPQX1381ZA_E.indb 10 2019/03/15 9:53:11
