Printed in Malaysia PQQW13512ZA DA1104PM0

Please read the operating instructions for further details.

Connections

Base unit

Charger unit (KX-TG5422 and KX-TG5423)

Note:

LBase unit: Use only the included Panasonic AC adaptor PQLV1.

LCharger unit: Use only the included Panasonic AC adaptor KX-TCA1.

LMake sure that the AC adaptor and telephone line cords are plugged into the unit

properly.

LThe AC adaptor must remain connected at all times. (It is normal for the adaptor to feel

warm during use.)

Fasten the AC adaptor cord.

Hook

AC adaptor

Raise the antennas.

Telephone line cord

To single-line telephone jack (RJ11C)

To power outlet (120 V AC, 60 Hz)

AC adaptor

To power outlet (120 V AC, 60 Hz)

Model No. KX-TG5421

Model No. KX-TG5422

Model No. KX-TG5423

Quick Guide

TG5421_5422_5423_QG(e).fm Page 1 Tuesday, November 16, 2004 2:29 PM

–2 –

Battery installation

1Insert the battery (1), and press it down

until it snaps into the compartment (2).

2Close the handset cover.

Battery charge

Place the handset on the base unit or charger for 6 hours before initial use.

Base unit Charger unit (KX-TG5422 and

KX-TG5423)

Navigator key Soft keys

The handset navigator key can be used to

navigate through menus and to select

items shown on the display, by pressing

{^}, {V}, {<}, or {>}.

The handset features 2 soft keys. By

pressing a soft key, you can select the

function displayed directly above it.

CHARGE indicator

CHARGE

indicator

Rcvd Phone

calls book

TG5421_5422_5423_QG(e).fm Page 2 Tuesday, November 16, 2004 2:29 PM

–3 –

Basic operation

Feature Operation

To make a call Press {C}, then dial the phone number.

To turn on the speakerphone Press {s}.

To hang up Press {OFF}.

To adjust the receiver or speaker

volume

While using the receiver or speaker, press {V} or {^}

repeatedly.

To redial the last number dialed Press {C}, then press {REDIAL}.

To make a call using the redial

list

Press {REDIAL}. Scroll to the desired number by

pressing {V} or {^}. Then, press {C}.

To answer a call Press {C}.

To put an outside call on hold KX-TG5421:

Press {HOLD}during an outside call.

KX-TG5422 and KX-TG5423:

Press {HOLD}2 times during an outside call.

Voice Mail service

Voice Mail is an automatic answering service offered by your telephone company. If you

subscribe to this service, your telephone company’s Voice Mail system can answer calls

for you when you are unavailable to answer the phone or when your line is busy.

Messages are recorded by the telephone company, not your telephone.

Storing the Voice Mail (VM)

access number

Listening to Voice Mail

messages

Once you have stored your Voice Mail

access number, you can dial it

automatically by pressing {VM}.

1Press {MENU}{0}{7}{1}.

2Enter your access number (max. 32

digits).

3Press {Save}, then press {OFF}.

The unit will let you know that you have

new Voice Mail messages in the following

ways:

–“Voice Mail” will be displayed on the

handset.

– The message indicator on the handset

will flash slowly if message alert feature

is turned on (page 5).

1Press {C} or {s}, then press {VM}

within 15 seconds.

2Follow the pre-recorded instructions.

3Press {OFF}when finished.

TG5421_5422_5423_QG(e).fm Page 3 Tuesday, November 16, 2004 2:29 PM

–4 –

Phonebook

Adding items to the phonebook

1Press {Phonebook}.

2Press {Add}.

Example:

3Enter the name (max. 16 characters).

4Press {Next}.

5Enter the phone number (max. 32

digits).

6Press {Next}.

Example:

7Press {Save}.

LTo add other items, repeat from step

8Press {OFF}.

Calling someone in the phonebook

1Press {Phonebook}.

2Press {V} or {^} repeatedly to display the desired item.

LTo exit the phonebook, press {OFF}.

3Press {C} or {s}.

Caller list

Viewing the caller list and calling back

1Press {V} or {^} to enter the caller list.

2Press {V} to search from the most

recent call, or press {^} to search

from the oldest call.

LThe caller’s name and phone

number are displayed alternately.

Example:

LTo exit the caller list, press {OFF}.

3Press {C} or {s}.

Displayed symbols

LIf the same caller calls more than once,

it will be displayed with the number

(“×2” to “×9”). Only the date and time

of the most recent call will be stored.

LA Qis displayed next to items which

have already been viewed or

answered on this handset.

Rcvd Phone

calls book

Phonebook

7 items

Add Search

Enter name

Back Next

Enter phone no.

Tom

555-765-4321

Edit Save

SMITH,JACK

3:10P JUN.29

1-555-333-4444

3:10P JUN.29

TG5421_5422_5423_QG(e).fm Page 4 Tuesday, November 16, 2004 2:29 PM

–5 –

Programming via direct commands

You can program most features using “direct commands”—special codes that take you

directly to the feature you wish to program and allow you to select the desired setting.

There is no need to scroll through the unit’s menus.

1Press {MENU}.

2Enter the desired feature code (shown below).

3Enter the desired setting code (shown below).

4Press {Save}.

5Press {OFF}to exit programming mode.

Direct commands chart

Feature Feature code Setting code

Ringer volume {1}{1} {1}: Low {2}: Medium

{3}: High {0}: Off

Ringer tone {1}{2} {1}–{3}: Tone pattern 1–3

{4}–{7}: Melody pattern 1–4

Voice enhancer {5} {1}: On {0}: Off

LCD contrast {0}{1} {1}–{6}: Level 1–6

Auto talk {0}{3} {1}: On {0}: Off

Set dial mode {0}{5}{1} {1}: Pulse {2}: Tone

Change language {0}{8} {1}: English {2}: Spanish

Message alert {0}{#} {1}: On {0}: Off

Important information about subscription services

In order to use Caller ID, Call Waiting, Call Waiting Caller ID (CWID), or Voice Mail,

you must first contact your telephone company and subscribe to the desired

service.

LFor more information, contact your telephone company.

If the Call Waiting Caller ID (CWID) feature does not function:

LYou may need to contact your telephone company to activate this specific service, even

if you already subscribed to both Caller ID and Call Waiting with Caller ID services

(CWID).

TG5421_5422_5423_QG(e).fm Page 5 Tuesday, November 16, 2004 2:29 PM

1Read this Quick Guide or Operating

Instructions

2Visit our website:

http://www.panasonic.com/

consumersupport

3Contact us via the web at:

http://www.panasonic.com/contactinfo

4Call us at: 1-800-211-PANA (7262)

To order a replacement batteries,

1-800-332-5368

http://www.panasonic.com/batterystore

IMPORTANT!

If your product is not

working properly. . .
