Panasonic FV-08/11/15VQL4 Bedienungsanleitung

Service Manual

PEG0506014CE

Version:0701

SPECIFICATIONS

CONTENTS

1 Parts Identification

2 Wiring Diagram

3 Parts List

PAGE

1~8

10~13

Super Quiet Ventilating Fan/Light Combination

FV-08/11/15VQL4

Version A Version B

WARNING

This service information is designed for experienced repair technicians only and is not designed for use by

the general public. It does not contain warnings or cautions to advise non-technical individuals of potential

dangers in attempting to service a product. Products powered by electricity should be serviced or repaired

only by experienced professional technicians. Any attempt to service or repair the product or products dealt

with in this service information by anyone else could result in serious injury or death.

IMPORTANT SAFETY NOTICE

There are special components used in this equipment which are important for safety. These parts are

marked by in the Schematic Diagrams, Exploded Views and Replacement Parts List. It is essential

that these critical parts should by replaced with manufacturer s specified parts to prevent shock, fire

or other hazards. Do not modify the original design without permission of manufacture.

(North American Market)

WhisperLiteTM

FV-08VQL4 4 0.3 25 36 4 765 80 15.7 (7.1)

FV-11VQL4 4 1.0 35 36 4 890 110 15.7 (7.1)

FV-15VQL4 6 1.2 36 36 4 790 150 16.5 (7.5)

Model Air

direction VHz

Duct

diameter Noise Power consumption(W) Speed Air deliver

at 0.1"WG Weight

Fan

body

Lighting unit

(rpm) (cfm) Ib. (kg)

(inches) (sones) Fluorescent

lamp

Night

lamp

Exhaust 120 60

Sepcifications are based on HVI standard.

(2 PCS)

FV-08/11VQL4

(3PCS)

(27)

25 27

(26)

(4)

(14)

(24)

Details of Capacitor Box

(24)

(3PCS)

Details of Wiring Section

21 22B

(20)

(5 PCS)

(4 PCS)

31(4PCS)

(27)

Main Packing Materials

Fan body

32B

34B

36 38

35B

(36)

(23)

Details of Junction Box

Remark: Because of different structure, we divide this model into Version A & Version B.

In Version A, we also divide into Style A & Style B. The change points are mainly

refer to the installation method and the cord section, please pay attention to the

parts which circled with broken line, you can for

details.

refer to the following 3 pages

42B

Installation

Instruction

WARRANTY

Installation

Instruction

EnglishEnglishEnglish Spanish/French

54B

32AA 32AB

LR-03

LP-03

(22A)

Style A

(34A)

(35A) VLR-03

VLP-03

(22B)

Style B

(34B)

(35B)

Details of Connector Cord Details of Connector Cord

Details of Junction Box Details of Junction Box

FV-08/11VQL4

33 34B

36 38

35B

(36)

(23)

34A

36 38

35A

(36)

(23)

Parts For Version A

FV-08/11VQL4

Installation Attachment

VLR-03

VLP-03

(22B)

(34B)

(35B)

Details of Connector Cord

32B

Details of Junction Box

33 34B

36 38

35B

(36)

(23)

Parts For Version B

List For Parts Differentiation

Remarks: For your convenience, we list the differentiation parts above, when you need to

order these parts, please judge which version or style is adapt to your machine

first. Especially, if you need to order the Frame Assy. or Adapter Assy.,please

refer to the following 1 page for details.

Part name Style A of Version A Style B of Version A Version B

Cord 22A 22B 22B

Frame Assy. 25 25 25

Adapter Assy. 32AA 32AB 32B

Connector Plate 34A 34B 34B

Connector Assy. 1 35A 35B 35B

Accessory Set 42A 42A 42B

Installation Instruction 54A 54A 54B

FV-08/11VQL4

Attention:

For Version A For Version B

32B

Guide For Adapter Assy. Order

Change to

32AB

32AA

Notice: 1.In order to adapt the market demand, the Adapter Assy. has been upgraded to

Version B ,therefore, the Version A part will be provided no longer.

2.If this part in your machine belongs to Version B ,you can order the item 32B

(Part No.:FFV0000032S) directly.

3.If machine belongs to Version A ,you can order the item 32AA

( FFV0000020S ),or item 32AB( FFV0000045S) as usual, then

we will not only the Version B part ,but also provide a set of installation

parts to you, those installation parts will be offered free. However, to finish this

conversion, you need to re-adjust the installation method.

this part in your

Part No.: Part No.:

provide

For Version B

Guide For Frame Assy. Order

Differentiation point

Change to

For Version A

Suspension Bracket

Joist

Fixing Position

For Reference

Notice: The Frame Assy. has been upgraded to Version B, therefore, we can provide the

Version B part at present, If this part in your machine belongs to Version A, when

you receive the Version B part, in order to install successfully, you only need to

re-adjust the fixing position of the Suspension Bracket.

(27)

25 27

(26)

FV-15VQL4

(2 PCS)

(3PCS)

31(4PCS)

(27)

(4)

(14)

(24)

Details of Capacitor Box

(3PCS)

(5 PCS)

(3 PCS)

(24)

Details of Wiring Section

(20)

Main Packing Materials

Fan body

32B

33 34B

36 38

35B

(36)

(23)

Details of Junction Box

22B

42B

Installation

Instruction

WARRANTY

Installation

Instruction

EnglishEnglishEnglish Spanish/French

54B

Remark: Because of different structure, we divide this model into Version A & Version B.

In Version A, we also divide into Style A & Style B. The change points are mainly

refer to the installation method and the cord section, please pay attention to the

parts which circled with broken line, you can for

details.

refer to the following 3 pages

FV-15VQL4

32AA 32AB

LR-03

LP-03

(22A)

Style A

(34A)

(35A) VLR-03

VLP-03

(22B)

Style B

(34B)

(35B)

Details of Connector Cord Details of Connector Cord

Details of Junction Box Details of Junction Box

33 34B

36 38

35B

(36)

(23)

34A

36 38

35A

(36)

(23)

Parts For Version A

Installation Attachment

VLR-03

VLP-03

(22B)

(34B)

(35B)

Details of Connector Cord

32B

Details of Junction Box

33 34B

36 38

35B

(36)

(23)

Parts For Version B

FV-15VQL4

List For Parts Differentiation

Part name Style A of Version A Style B of Version A Version B

Cord 22A 22B 22B

Frame Assy. 25 25 25

Adapter Assy. 32AA 32AB 32B

Connector Plate 34A 34B 34B

Connector Assy. 1 35A 35B 35B

Accessory Set 42A 42A 42B

Installation Instruction 54A 54A 54B

Remarks: For your convenience, we list the differentiation parts above, when you need to

order these parts, please judge which version or style is adapt to your machine

first. Especially, if you need to order the Frame Assy. or Adapter Assy.,please

refer to the following 1 page for details.

FV-15VQL4

Attention:

For Version B

For Version A For Version B

32B

Guide For Frame Assy. Order

Differentiation point

Guide For Adapter Assy. Order

Change to

For Version A

Change to

32AB

Suspension Bracket

Joist

Fixing Position

32AA

Notice: 1.In order to adapt the market demand, the Adapter Assy. has been upgraded to

Version B ,therefore, the Version A part will be provided no longer.

2.If this part in your machine belongs to Version B ,you can order the item 32B

(Part No.:FFV0000033S) directly.

3.If machine belongs to Version A ,you can order the item 32AA

( FFV0000021S ),or item 32AB( FFV0000046S) as usual, then

we will not only the Version B part ,but also provide a set of installation

parts to you, those installation parts will be offered free. However, to finish this

conversion, you need to re-adjust the installation method.

this part in your

Part No.: Part No.:

provide

For Reference

Notice: The Frame Assy. has been upgraded to Version B, therefore, we can provide the

Version B part at present, If this part in your machine belongs to Version A, when

you receive the Version B part, in order to install successfully, you only need to

re-adjust the fixing position of the Suspension Bracket.

FV-08/11/15VQL4

Motor

Fan body

Red

White

Green

Capacitor

Electronic

Ballast

Lighting unit

Fluorescent

lamp

Earth ground

Night lamp

Junction box

Power supply

AC120V 60Hz

Black

Earth ground

White

Black

Current Fuse

Power supply

AC120V 60Hz

Green

Black

White

Moteur
