Panasonic BB-GT1500C Bedienungsanleitung

PQQW15680YA DM0507SY1067

Routine care

LTo clean the product, use a dry soft cloth. The outer surface of the product can

be scratched by wiping or rubbing with a hard cloth.

Setting up

Base unit

Handset CHARGE 7 HOURS

Confirm the

charge indicator

is on.

Model shown is BB-GT1500.

“Click”

TEL LAN

Noise filter

To single-line

telephone jack

(RJ11C)

AC adaptor

Telephone line cord

Ethernet cable

Router

Cable or

DSL modem

Internet

(120 V AC, 60 Hz)

Use only the included Panasonic AC adaptor PQLV203.

Hook

Press

plug firmly.

“Click”

ABE

Model No. BB-GT1500C

BB-GT1502C

BB-GT1540C

Quick Guide

BB-GT15xxC_QG(e).fm Page 1 Thursday, June 14, 2007 3:34 PM

– 2 –

Setting up

Note:

LIf “Please read joip Terms of Use. Agree?” is not displayed in step 2,

press {IP}.

LWhen the STATUS indicator on the base unit does not light in green even if you

wait for a few minutes, see “STATUS indicator” (page 6).

Viewing the Atext messages

1{MENU}i{#}{3}{6}{0}

2{V}/{^}: Select the desired item. i{OK}

3{OFF}

For product assistance, visit www.globarange.com

For Aassistance, visit www.joip.com

joip

Model shown is BB-GT1500.

Amber Green

[

Please read joip

Agree?

YES NO

joip:#1001060429

To use the AIP line, read the Terms of Use for the Aservices on the

included leaflet or at www.joip.com

Wait for a Atext message for the Awebsite password (www.joip.com).

To view the message, see below.

Press {YES}.

2Wait until the STATUS

indicator turns green.

3Confirm your A

number.

Charger*1

(120 V AC, 60 Hz)

*1 BB-GT1502

Use only the included Panasonic AC adaptor

PQLV208.

Confirm the

charge indicator

is on.

BB-GT15xxC_QG(e).fm Page 2 Thursday, June 14, 2007 3:34 PM

– 3 –

Operating tips

{}: shows button names.

Using the joystick

The handset joystick can be used to navigate

through menus and to select items shown on the

display, by pushing it up {^}, down {V}, left {<}, or

right {>}.

Adjusting audio volume

Push the joystick up {^} or down {V} repeatedly

while talking.

Handset soft keys

The handset features 2 soft keys and a joystick. By

pressing a soft key, or by pressing the center of the

joystick, you can select the feature shown directly

above it on the display.

{SELECT}, {SAVE}, {OK}, and additional other

functions are assigned to soft keys. Pay attention to

soft keys to find functions you need during handset

operation.

Middle soft key

The joystick can be used to select the center soft

key icon, by pressing down on the center of the

joystick.

Change language (Handset) (default: English)

Display language

1{OFF}i{MENU}i{#}{1}{1}{0}

2{V}/{^}: Select the desired setting. iPress down the center of the joystick to

save. i{OFF}

Voice guidance language (BB-GT1540)

{MENU}i{#}{1}{1}{2}i{V}/{^}: Select the desired setting. i{SAVE}i

{OFF}

For product assistance, visit www.globarange.com

For Aassistance, visit www.joip.com

BB-GT15xxC_QG(e).fm Page 3 Thursday, June 14, 2007 3:34 PM

– 4 –

Date and time (Handset)

1{MENU}i{#}{1}{0}{1}

2Enter the current month, date, and year by selecting 2 digits for each.

3Enter the current hour and minute (12-hour clock format) by selecting 2 digits for

each.

4{AM/PM}: Select “AM” or “PM”. i{SAVE}i{OFF}

Basic operation (Handset)

Making calls 1Dial the phone number.

2To make a landline call, press {TEL}.

To make a Ainternet call, press {IP}.

Note:

LTo call a Panasonic GLOBARANGE phone, dial the

Anumber consisting of the pound key (#)

followed by 10 digits.

Answering calls To answer the landline call, press {TALK}, {TEL}or

{s}.

To answer the Ainternet call, press {TALK}, {IP}

or {s}.

Adjusting the receiver/

speaker volume

Push the joystick up {^} or down {V} while talking.

Viewing the caller list and

calling back

{CID}i{V}/{^}: Select the desired item. i

{TEL}/{IP}

Ringer volume 1{MENU}i{#}{1}{6}{0}{1}(IP line)/

{#}{1}{6}{0}{2}(landline)

2{^}/{V}: Select the desired volume. i{SAVE}

BB-GT1540 Basic operation (Base unit)

Making calls 1To make a landline call, press {TEL}.

To make a Ainternet call, press {IP}.

2Dial the phone number, and then speak into the

MIC.

Note:

LTo call a Panasonic GLOBARANGE phone, dial the

Anumber consisting of the pound key (#)

followed by 10 digits.

Answering calls To answer the landline call, press {TEL}or {s}.

To answer the Ainternet call, press {IP}or {s}.

BB-GT15xxC_QG(e).fm Page 4 Thursday, June 14, 2007 3:34 PM

– 5 –

Adjusting the speaker

volume

Press {^} or {V} repeatedly while talking.

Ringer volume 1Press {IP/TEL}repeatedly until the display shows

the desired line (nor m).

2Press {^} or {V} repeatedly to select the desired

volume.

LTo turn the ringer off, press and hold {V} until the

unit beeps.

BB-GT1540 Answering system (Base unit)

Auto answer on 1Press {IP/TEL}repeatedly until the display

shows the desired line(s) (nand/or m).

2Press {ANSWER ON}.

Auto answer off Press {ANSWER ON}.

Recording your greeting

message (max. 2 minutes)

1Press {IP/TEL}repeatedly until the display

shows the desired line(s) (nand/or m).

2{GREETING REC}

3Within 10 seconds, press {GREETING REC}

again.

4Speak clearly about 20 cm (8 inches) away from

the MIC.

5To stop recording, press {STOP}.

Listening to new messages When {6}flashes on the center of navigator key,

press {6}.

Erasing a message Press {ERASE}during playback.

Using the answering system

remotely

1Dial your phone number from a touch tone

phone.

2After the greeting message starts, enter your

remote code. (Default remote code is “111”.)

LThe unit plays back new messages.

LAfter playing back new messages, the voice

guidance starts.

3Follow the voice guidance as necessary.

For product assistance, visit www.globarange.com

For Aassistance, visit www.joip.com

BB-GT1540 Basic operation (Base unit)

BB-GT15xxC_QG(e).fm Page 5 Thursday, June 14, 2007 3:34 PM

– 6 –

For further information, refer to the STATUS indicator section in the Operating

Instructions.

Quick troubleshooting

STATUS indicator

Status Cause/solution

Colour Light pattern

Green On LReady to make/receive Ainternet calls.

Flashing LDownloading data, please wait.

Red On LOn for about 3 seconds during initial startup. (Normal)

Flashing LThe base unit is registering a handset. Please wait.

Flashing

rapidly

LThe base unit is paging handsets. (BB-GT1500/BB-

GT1502)

Amber On LThe base unit’s IP address may conflict with the IP

addresses of other devices on your local network if you

have set the static IP address. We recommend using

the automatic setup (default):

1. {MENU}i{#}{5}{0}{0}

2. {V}{^}: “On” i{SAVE}i{OFF}

Flashing LThe base unit is registering with the Aservice.

Please wait.

LIf the STATUS indicator continues flashing:

– If you have set the static address, we recommend

using the automatic setup (default):

1. {MENU}i{#}{5}{0}{0}

2. {V}{^}: “On” i{SAVE}i{OFF}

– Many installation issues can be resolved by resetting

all the equipment. First, shut down your modem,

router, base unit, and computer. Then turn the

devices back on one at a time in this order: modem,

router, base unit, computer.

– If you cannot access Internet Web pages using your

computer, check to see if your Internet service

provider is having connection issues in your area.

– For more troubleshooting help, visit www.joip.com or

contact the Aservice provider.

OFF —LAinternet calls are not available. Check the

following:

– The base unit’s AC adaptor is connected.

– Set up for Ause (page 2).

– The Ethernet cable is connected.

– Your network devices (hub, router, etc.) are turned

on. Check the LEDs for the link status of the devices.

BB-GT15xxC_QG(e).fm Page 6 Thursday, June 14, 2007 3:34 PM

– 7 –

For other questions, please refer to the Operating Instructions.

Frequently asked questions

Question Cause/solution

The unit does not work. LMake sure the battery is installed correctly and

fully charged.

LUnplug the base unit’s AC adaptor to reset the

unit. Reconnect the adaptor and try again.

LThe handset has not been registered to the base

unit. Register the handset as explained later in

this guide.

I cannot hear a dial tone for

the IP line.

LConfirm the Ethernet cable is properly connected.

LYou have not agreed to the Terms of Use for the

Aservices. To use the AIP line, you need to

agree to it using the handset.

LIf you cannot make or receive internet calls or if

you are experiencing any other issues with your

VoIP telephone service provided by deltathree,

Inc., visit www.joip.com

I cannot hear a dial tone for

the landline.

LConfirm the telephone line cord is properly

connected.

LDisconnect the unit from the telephone line and

connect a known working telephone. If the

working telephone operates properly, contact

Panasonic service personnel to have the unit

repaired. If the working telephone does not

operate properly, contact your landline service

provider.

How can I increase handset

volume level?

LPush the joystick up repeatedly while talking.

The VM indicator on the

base unit flashes.

Example: BB-GT1540

LYou have new voice mail messages received by

your landline service provider and/or A. For

further information, refer to the Voice Mail section

in the Operating Instructions.

BB-GT1540: The message

indicator on the base unit

flashes.

LYou have new messages received from the

landline and/or AIP line by the unit’s

answering system. For further information, refer

to the answering system section in the Operating

Instructions.

For product assistance, visit www.globarange.com

For Aassistance, visit www.joip.com

BB-GT15xxC_QG(e).fm Page 7 Thursday, June 14, 2007 3:34 PM

– 8 –

Quick troubleshooting

Place the handset on the base unit, then

check if the charge indicator is on.

LModel shown is BB-GT1500.

The charge indicator is OFF.

The charge indicator

is ON.

Unplug the AC adaptor of the base unit and remove the

battery from the handset, then plug in the AC adaptor and

insert the battery into the handset again. Try re-registration

as explained later in this guide.

Lift the handset, then try again.

If handset still shows the same

message, try re-registration as

explained later in this guide.

Re-registration failed.

Your telephone may need service.

“No link to base. Move closer to base, try again.”

Handset shows:

Unplug and then plug AC

adaptor properly to both the

base unit and AC outlet.

BB-GT15xxC_QG(e).fm Page 8 Thursday, June 14, 2007 3:34 PM

– 9 –

Registering a handset to base unit

The included handset and base unit are preregistered. If for some reason the

handset is not registered to the base unit, register the handset.

For product assistance, visit www.globarange.com

For Aassistance, visit www.joip.com

Handset

Press {MENU}, then press {#}{1}{3}{0}.

Handset

Press {OK

Base unit

BB-GT1500/BB-GT1502

Press and hold {HANDSET LOCATOR}

until the STATUS indicator flashes in red.

LComplete next step within 90 seconds.

BB-GT1540

Press and hold {LOCATOR/INTERCOM}

until the registration tone sounds and the

STATUS indicator flashes in red.

LComplete next step within 90 seconds.

{LOCATOR/INTERCOM}

{HANDSET LOCATOR}

{MENU}

Press LOCATOR

on base for 4sec

Then press

FRANÇ.

{OK

}

BB-GT15xxC_QG(e).fm Page 9 Thursday, June 14, 2007 3:34 PM

IMPORTANT!

If your product is not working

properly. . .

For your phone’s functions or features, please contact

Panasonic.

FOR PRODUCT OPERATION ASSISTANCE, please

contact:

Our Customer Care Centre:

Telephone #: (905) 624-5505

1-800 #: 1-800-561-5505

Fax #: (905) 238-2360

Email link: “Contact Us” on www.panasonic.ca

FOR PRODUCT REPAIRS, please locate your nearest

Authorized Servicentre at www.panasonic.ca :

Link : “Servicentres™ locator” under “Customer support”

Acustomer support

Ais the VoIP service provided by deltathree, Inc. for this

phone. If you cannot make or receive internet calls or if you

are experiencing any other issues with your VoIP telephone

services, please contact Acustomer support:

LVisit www.joip.com or send an email to

support@joip.com

LCall *JOIP (*5647) from your GLOBARANGE phone

using the IP line.

LCall 1-888-654-JOIP (1-888-654-5647) using the landline.

BB-GT15xxC_QG(e).fm Page 10 Thursday, June 14, 2007 3:34 PM

Andere Handbücher für BB-GT1500C

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Panasonic Telefon Handbücher

Panasonic

Panasonic KX-TGF320E Bedienungsanleitung

Panasonic

Panasonic KX-UT248 Bedienungsanleitung

Panasonic

Panasonic KX-NCP500 Bedienungsanleitung

Panasonic

Panasonic KX-AT7730 Bedienungsanleitung

Panasonic

Panasonic KX-TD1232NL Bedienungsanleitung

Panasonic

Panasonic KX-TS500LX1B Bedienungsanleitung

Panasonic

Panasonic VB-9411ADSUK Bedienungsanleitung

Panasonic

Panasonic SUNCO DT546 Einrichtungshandbuch

Panasonic

Panasonic KXTD7690 - BTS 2.4 GHZ WIRELESS Bedienungsanleitung

Panasonic

Panasonic KX-T7636 Bedienungsanleitung

Panasonic

Panasonic KX-T7668 Bedienungsanleitung

Panasonic

Panasonic EASA-PHONE KX-T123250 Bedienungsanleitung

Panasonic

Panasonic DBS 576 Bedienungsanleitung

Panasonic

Panasonic KX-TS840MX Bedienungsanleitung

Panasonic

Panasonic KX-TPA73 Bedienungsanleitung

Panasonic

Panasonic KX-TG2352W - 2.4 GHz DSS Expandable Cordless Phone... Bedienungs- und Montageanleitung

Panasonic

Panasonic EASA-PHONE KX-T123230D Bedienungsanleitung

Panasonic

Panasonic KX-T7710 Bedienungsanleitung

Panasonic

Panasonic KX-TG2480S Bedienungsanleitung

Panasonic

Panasonic 4LINE KX-TGWA40 Bedienungsanleitung

Panasonic

Panasonic KX-TCD725AXM Bedienungsanleitung

Panasonic

Panasonic HYBRID IP-PBX KX-TDA100 Bedienungsanleitung

Panasonic

Panasonic KX-TD1232AL Montage- und Bedienungsanleitung

Panasonic

Panasonic KX-T7020E Bedienungsanleitung

Beliebte Telefon Handbücher anderer Marken

GE 2-9480 Bedienungsanleitung

Geemarc

Geemarc PHOTOPHONE 155 Bedienungsanleitung

D-Link

D-Link DWR-720/PW Bedienungsanleitung

Interquartz

Interquartz Gemini IQ333 Bedienungsanleitung

SSS Siedle

SSS Siedle HT 840-0 Bedienungsanleitung

Motorola

Motorola TITANIUM Bedienungsanleitung

LG H870DS Bedienungsanleitung

Samsung

Samsung GT-I9500 Bedienungsanleitung

AT&T

AT&T Trimline 205 Bedienungsanleitung

Selta

Selta zenyth 600 Bedienungsanleitung

Doro

Doro AFTI 20 Bedienungsanleitung

UNIQCELL

UNIQCELL A1 Bedienungsanleitung

Jabra

Jabra SP5050 - Bluetooth hands-free Speakerphone Bedienungsanleitung

BT Decor 425 Bedienungsanleitung

NEC

NEC SV8500 Bedienungsanleitung

Teledex

Teledex PEARL Bedienungsanleitung

Ericsson

Ericsson Dialog 3213 Bedienungsanleitung

Yealink

Yealink VP530 Bedienungsanleitung
