Upgrade Manual for KX-HGT100 from Ver1.XX to Ver2.04

The necessary one

1. HGT100 that does upgrade

2. PC

3. firmware(IPPAPL_02_04_20090515.img)

Connection

1. LAN port of HGT100 and PC is connected with the same hub.

HGT100 and PC's connected charts

Setting

1. IPaddress of PC is set to 192.168.0.100.

2. HGT100 turns on the power supply while pushing MUTE and OK at the same time.

figure of HGT100

HUB

HGT100

PC

LAN port

OK button

MUTE button

Procedure

1. The setting of the network of HGT100 is confirmed.

The Network setting (STATIC/DHCP) is confirmed pushing [INFO], [ ], [ ].

IP address is confirmed continuously pushing [ ].

When the Network setting is STATIC, Subnet mask and Default gateway is confirmed

pushing [ ] in addition.

2. Connection PC and HGT100

Internet Explorer is started up with PC, and IPaddress of HGT100 is input to the

address.

If the screen of Authorization is displayed, the following values are input.

User name:KX-HGT100

Password:kx-hgt100

login display of HGT100

KX-HGT100

kx-hgt100

3. Saving of configuration

"Configuration File" is selected from a left menu.

And, "Save Configuration File" is clicked.

Cfg.txt is saved to an arbitrary directory.

Configuration File display of HGT100

1. click 2. click

4. Firmware upgrade

"Upgrade Firmware" is selected from a left menu.

File (IPPAPL_02_04_20090515.img) for the update is selected clicking "Browse...".

"Upgrade Firmware" is clicked.

If "Successfully completed" is displayed, the power supply of HGT100 is turned off.

Upgrade Firmware display of HGT100

1. click

3. click

2. select firmware file

5. HGT100 is made a factory default setting.

The power supply is turned on while pushing [PROGRAM], [OK], and [MUTE] at the

same time.

It is confirmed to become "Not configured Web setting" screen.

figure of HGT100

OK button

MUTE button

PROGRAM button

6. Connection PC and HGT100

Internet Explorer is started up with PC, and IPaddress of HGT100 is input to the

address(192.168.0.241).

If the screen of Authorization is displayed, the following values are input.

User name:KX-HGT100

Password:kx-hgt100

login display of HGT100

KX-HGT100

kx-hgt100

7. The Network setting of HGT100 is returned to the value before.

"LAN Connection" is selected from a left menu.

It makes it to the value in which the network setting is confirmed by step 1.

LAN Connection display of HGT100

1. click

2. setting the value

8. Configuration of HGT100 is returned to the value before.

"Configuration File" is selected from a left menu.

Cfg.txt saved by step 3 is selected clicking “browse...” of Load Configuration File.

"Load Configuration File" is clicked.

configuration file display of HGT100

If "Successfully completed" is displayed, "Restart" is clicked.

"Restart now" is clicked when becoming "Restart" screen.

NOTE:

Caller ID list, Redial list and Speed dial are erased.

If you have not set “Basic setting” of KX-HGT100, execute steps 2, 4, and 5.

1. click 3. click

2. select the cfg.txt
