Panasonic KX-PRW120 Bedienungsanleitung

Smartphone Connect Setup Guide

Premium Design Phone with Smartphone Connect

Model No. KX-PRW110

KX-PRW120

Wi-Fi

KX-PRW110

KX-PRW120

What is Smartphone Connect?

Smartphone Connect is a free app provided by Panasonic that turns your

smartphone into an extension of your phone system. You can use Smartphone

Connect to:

– make and receive landline calls with your smartphone

– copy data from your smartphone to your phone system

–and more!

Plus, you can even use your base unit to extend the range of your existing wireless

network (see page 6), perfect for larger homes.

How does it work?

Your smartphone and your phone system’s base unit communicate with each other

using your wireless router, allowing you to use phone system features over Wi-Fi.

Smartphone Connect Setup Overview

Everything you need to know to get started with Smartphone Connect is explained in this guide.

Configuring your base unit (page 2)

Downloading the Smartphone Connect app (page 4)

Starting the app for the first time (page 5)

Configuring your base unit

In this step you will use one of the handsets supplied with your phone system to configure the

base unit to connect to your wireless router. In most situations you should follow the instructions

explained in “Typical configuration (DHCP)”.

Note:

RBefore beginning, make sure your base unit and your wireless router are turned on and

functioning.

RRecommended wireless router standard: IEEE 802.11g or IEEE 802.11n

Typical configuration (DHCP)

1. Using one of the handsets supplied with your phone system,

press MMenuN (right soft key) and then press #523.

2. Press MDN or MCN to select “Search for Networks” and then

press MOKN.

RThe base unit displays a list of available wireless networks,

including the SSID (wireless network name), security setting,

and wireless signal strength.

Search for Networks

WPS (Easy Setup)

Connect

3. Select your wireless router’s SSID and then press MOKN.

Wi-Fi Networks

4. Confirm the SSID and then press MOKN.

Network Name

Smartphone Connect Setup Guide

5. Enter the password required to access the wireless network and

then press MOKN.

Password

6. Wait for the base unit to connect to your wireless router. When

“Connected to” and your wireless router’s SSID are

displayed, press M N to finish.

Wi-Fi Setup

Connected to

Simplified configuration (WPS, DHCP)

This procedure requires a wireless router that supports WPS. If your wireless router supports

WPS, make sure the feature is turned on, and locate its WPS button before beginning this

procedure. The WPS button is typically labelled “WPS” or has two curved arrows on it.

1. Using one of the handsets supplied with your phone system,

press MMenuN (right soft key) and then press #523.

2. Press MDN or MCN to select “WPS (Easy Setup)” and then

press MOKN.

Connect

Search for Networks

WPS (Easy Setup)

3. Press the WPS button on your wireless router and then press

MOKN on the handset.

Wi-Fi Setup

Press WPS button

on your router

4. Wait for the base unit to connect to your wireless router. When

“Connected to” and your wireless router’s SSID (wireless

network name) are displayed, press M N to finish.

Wi-Fi Setup

Connected to

Smartphone Connect Setup Guide

Downloading the Smartphone Connect app

After you have configured the base unit’s Wi-Fi and network settings, you are ready to download

the Smartphone Connect app. You can download the app directly from your smartphone

platform’s app download service by searching for “Panasonic Smartphone Connect”. You can

also find download information at the web page listed below.

Support page for this product on the Panasonic Global web site

www.panasonic.net/pcc/support/tel/air

For information about using the app, refer to the Smartphone Connect App Guide, which is

available for download from the support page.

Supported devices

RiPhone 4, iPhone 4S, iPhone 5, iPad, and iPad mini (iOS 5.0 or later)

RDevices running Android™ 4.0 or later

Functionality information

RThe app may not function properly depending on system environment, such as your

smartphone model, peripherals connected to your smartphone, and the apps installed on your

smartphone.

Smartphone Connect Setup Guide

Starting the app for the first time

After you have installed the Smartphone Connect app on your smartphone, you are ready to start

the app and register your smartphone to the base unit. Use your smartphone to perform this step.

1. Make sure that your smartphone’s Wi-Fi feature is enabled and

that your smartphone is connected to the same wireless network

as your base unit.

2. Start the Smartphone Connect app by tapping its icon (shown

here on the right).

3. When prompted to register your smartphone to the base unit, tap

[Start].

RIllustrations shown here depict the Android version of the app.

Confirm

Cancel Start

To begin registering this mobile

phone to the base unit, tap "Start".

4. Wait for the registration process to be end.

RThe app’s [Keypad] screen will be displayed.

RYou can confirm that your smartphone is connected to the

base unit.

iPhone/iPad

Check the information in the Notifications Centre.

Android

Check that is displayed in the status bar and notifications

panel.

Note:

RIn order to use most of the app’s features, your smartphone needs an active Wi-Fi connection.

If your smartphone’s Wi-Fi feature is disabled, or if it is configured to suspend (sleep) its Wi-Fi

connection to save power, you will not be able to make or answer calls.

Smartphone Connect Setup Guide

Configuring your base unit as a Wi-Fi range extender

(Wi-Fi repeater mode)

If you use your phone system in a large home, you can use the base unit’s built-in Wi-Fi repeater

mode feature to extend the range of your existing wireless network. This is useful if the wireless

signal of your wireless router does not cover all areas of your house.

Should I use Wi-Fi repeater mode?

Wi-Fi repeater mode is recommended for larger buildings, such as those shown below.

For smaller buildings, we recommend you do not use Wi-Fi repeater mode.

Wide, single-storey buildings Three-storey buildings

Note:

RDo not place the base unit and wireless router too close to each other.

If they are too close, using Wi-Fi repeater mode can cause the sound to cut out briefly during

landline calls.

– For a single-storey building, place the base unit and your wireless router in different rooms,

at least one room-width away from each other.

– For a three-storey building, place the base unit and wireless router on different floors.

RDo not use Wi-Fi repeater mode if you already have a Wi-Fi range extender.

If you already have a Wi-Fi range extender, using Wi-Fi repeater mode can cause network

problems such as not being able to access the Internet, and the sound may cut out briefly

during landline calls.

Smartphone Connect Setup Guide

Turning Wi-Fi repeater mode on

1. Using one of the handsets supplied with your phone system,

press MMenuN (right soft key) and then press #538.

2. Press MDN or MCN to select “On” and then press MOKN.

Repeater

Off

Important information

RA router is required to use Wi-Fi repeater mode.

If the router function of your wireless router is not enabled and if there is no other routing

device connected to your network, Wi-Fi repeater mode will not function.

RThe base unit does not have a router feature.

Wi-Fi repeater mode allows the base unit to function as a wireless access point. It does not

replace the functionality of a wireless router, and it does not have a router feature.

Open source software notice

RParts of this product use open source software supplied based on the relevant conditions of

the Free Software Foundation’s GPL and/or LGPL and other conditions. Please read all

licence information and copyright notices related to the open source software used by this

product. This information is available at the following web page:

www.panasonic.net/pcc/support/tel/air

At least three (3) years from delivery of this product, Panasonic System Networks Co., Ltd. will

give to any third party who contacts us at the contact information provided below, for a charge

of no more than the cost of physically distributing source code, a complete machine-readable

copy of the corresponding source code and the copyright notices covered under the GPL and

the LGPL. Please note that software licensed under the GPL and the LGPL is not under

warranty.

www.panasonic.net/pcc/support/tel/air

Software information

RThe End User License Agreement (EULA) for the Smartphone Connect app is available at the

following web page:

www.panasonic.net/pcc/support/tel/air

Smartphone Connect Setup Guide

Troubleshooting information

RIf you experience any trouble when performing the procedures found in this document, refer

to the network connection troubleshooting section of the Operating Instructions supplied

with your phone system.

RIf you experience any trouble when using the Smartphone Connect app, refer to the

troubleshooting section of the Smartphone Connect App Guide, which is available for

download from our web site.

Trademarks

RAndroid is a trademark of Google Inc.

RiPhone and iPad are trademarks of Apple Inc.

RWi-Fi® is a registered mark of the Wi-Fi Alliance.

RAll other trademarks identified herein are the property of their respective owners.

Other information

RDesign and specifications are subject to change without notice.

RThe illustrations in this document may vary slightly from the actual product.

RThe suffix is omitted from model numbers listed in this document.

RPlease refer to the base unit’s operating instructions for sales department and customer

support information.

1-62, 4-chome, Minoshima, Hakata-ku, Fukuoka 812-8531, Japan

*PNQX6094XA*

PNQX6094XA CC0513MG2063 (E)
