Connections

Base unit

Connect the AC adaptor to the unit by pressing the plug firmly.

Fasten the cord by hooking it.

Connect the AC adaptor to the power outlet.

Connect the telephone line cord to the unit, then to the single-line telephone jack (RJ11C) until you hear a click.

A DSL/ADSL filter (not supplied) is required if you have a DSL/ADSL service.

Note:

Use only the supplied Panasonic AC adaptor PNLV226.

Charger

Connect the AC adaptor to the power outlet.

Model No. KX-TGH262C/KX-TGH263C

Quick Guide

TGH26xC_QG(en).fm Page 1 Wednesday, December 25, 2013 9:21 AM

Battery installation/Battery charging

Charge for about 7 hours.

Note:

LUSE ONLY rechargeable Ni-MH batteries AAA (R03) size

().

LDo NOT use Alkaline/Manganese/Ni-Cd batteries.

LConfirm correct polarities (S, T).

LFollow the directions on the display to set up the unit.

LConfirm “Charging”is displayed

()

Operating tips

Soft keys

By pressing a soft key, you can select the feature

shown directly above it on the display. Pay attention

to the display to see what functions the soft keys are

assigned during operation.

Navigator key

−{^}, {V}, {<}, or {>}: Scroll through various lists

and items.

−v(Volume: {^} or {V}): Adjust the receiver or

speaker volume while talking.

−{<}k: View the phonebook entry.

−{>}REDIAL: View the redial list.

−{V} CID (CalI Display): View the caller list.

{V}

{^}

{<}{>}

TGH26xC_QG(en).fm Page 2 Wednesday, December 25, 2013 9:21 AM

Date and time (Handset)

1{MENU}(right soft key) (1)1

2Enter the current month, date, and year. s{OK}

3Enter the current hour and minute (12-hour clock format).

4*: Select “AM”or “PM”. s{SAVE}s{OFF}

Recording your greeting message for the answering system

for the landline (Handset)

If you use a pre-recorded greeting message, you do not need to record your own greeting

message.

1{MENU}(right soft key) (3)2s{r}: “Yes”s{SELECT}

2After a beep sounds, hold the handset about 20 cm (8 inches) away and speak clearly into

the microphone (2 minutes max.).

3Press {STOP}to stop recording. s{OFF}

Link to cell

You can connect your base unit and cellular phone using Bluetooth®wireless technology, so that

you can make or answer cellular calls using your phone system. For more details, please visit our

Web site: http://www.panasonic.ca/link2cell

LLocate your cellular phone near the base unit. If the cellular phone is too close to the base unit

during a cellular call, you may hear noise. For best performance, we recommend placing the

cellular phone between 0.6 m to 3 m (2 feet to 10 feet) away from the base unit.

1Cell line

2Cell phone service providers

Trademarks

LThe Bluetooth®word mark and logos are registered trademarks owned by Bluetooth SIG, Inc.,

and any use of such marks by Panasonic Corporation is under licence.

LAll other trademarks identified herein are the property of their respective owners.

TGH26xC_QG(en).fm Page 3 Wednesday, December 25, 2013 9:21 AM

Pairing a Bluetooth cellular phone

1Handset:

For CELL 1: {MENU}(right soft key) (6241

For CELL 2: {MENU}(right soft key) (6242

LAfter the corresponding CELL indicator on the base unit starts flashing, the rest of the

procedure must be completed within 5 minutes.

2Your cellular phone:

While the corresponding CELL indicator is flashing, follow the instructions of your cellular

phone to enter the pairing mode.

LDepending on your cellular phone, it may ask you to enter the Bluetooth PIN (default:

“0000”). If your cellular phone shows PassKey confirmation on its display, follow the

directions to proceed.

3Handset:

Wait until a long beep sounds.

LIt may take more than 10 seconds to complete pairing.

LWhen the corresponding CELL indicator lights up, the cellular phone is connected to the

base unit. You are ready to make cellular calls.

4{OFF}

Note:

LMake sure that your cellular phone is set to connect to this product automatically. Refer to your

cellular phone’s operating instructions.

Base unit: CELL indicators

Status Meaning

On A cellular phone is connected. Ready to make/receive cellular

calls.

Flashing −The cellular line is in use.

−Phonebook entries are being copied from a cellular phone.

−The base unit is searching for the paired cellular phone.

−The base unit is pairing a cellular phone.

−A cellular call is put on hold.

Flashing rapidly A cellular call is being received.

Light off −A cellular phone is not paired to the base unit.

−A cellular phone is not connected to the base unit.

Handset: Link to cell display items

A cellular line is in use.*1

LWhen flashing: The cellular call is put on hold.

LWhen flashing rapidly: A cellular call is being received.

*1 Corresponding cellular line(s) is(are) indicated next to the item.

A cellular phone is connected.*1 Ready to make/receive cellular calls.

LWhen turned off: A cellular phone is not connected to the base unit.

*1 Corresponding cellular line(s) is(are) indicated next to the item.

uv −A cellular call is being done on that line.

−The cellular line is selected for the setting.

Link to cell

TGH26xC_QG(en).fm Page 4 Wednesday, December 25, 2013 9:21 AM

Connecting/disconnecting the cellular phone

Auto connection to the Bluetooth devices (cellular phones or headset)

The unit connects to the Bluetooth devices at regular intervals if the connection is lost. To change

the interval (default: “1 min”), see the operating instructions.

LWhen 3 Bluetooth devices (2 cellular phones and 1 headset) are paired to the base unit, only

2 Bluetooth devices can be used with the unit at the same time, and the base unit loses its

connection from other Bluetooth devices. To automatically resume the connection to Bluetooth

devices, leave the auto connection on.

Connecting/disconnecting the cellular phone manually

If you will not be using the paired cellular phone’s link to cell feature temporarily (for example, you

do not want the unit to ring when your cellular line receives a call), you can disconnect your

cellular phone from the base unit. If you want to use it again, reconnect the cellular phone to the

base unit.

LEven if a paired cellular phone was disconnected from the base unit, if it is brought within the

base unit’s range during the auto connection interval, it may automatically connect to the base

unit.

LA disconnected cellular phone is not unpaired from the base unit, so pairing it to the base unit

again is unnecessary.

1To connect/disconnect:

For CELL 1: {MENU}(right soft key) (6251 (A long beep sounds.)

For CELL 2: {MENU}(right soft key) (6252 (A long beep sounds.)

2{OFF}

Cellular line only mode (If you do not use the landline) (Handset)

If you do not use the landline, set the cellular line only mode to use this unit more conveniently.

LIf you turn on the “Cell line only mode”, disconnect the telephone line cord from the base

unit. Otherwise the “Cell line only mode”cannot be activated.

1{MENU}(right soft key) (157

2To turn on:

{r}: “On”s{SELECT}s{r}: “Yes”s{SELECT}

To turn off:

{r}: “Off”s{SELECT}

Link to cell

TGH26xC_QG(en).fm Page 5 Wednesday, December 25, 2013 9:21 AM

Basic operations

Making/Answering calls (Handset)

Making cellular calls 1Dial the phone number. s{CELL}

LWhen the cellular line only mode is set, you can also press

{C}/{s} instead of {CELL}.

LWhen only 1 cellular phone is paired, the unit starts dialing.

2When 2 cellular phones are paired:

{r}: Select the desired cellular phone. s{SELECT}

Making landline calls Dial the phone number. s{C}/{s}

Answering calls {C}/{s}/{w}

To hang up {OFF}

To adjust the receiver/

speaker volume

Press {^} or {V} repeatedly while talking.

Making a call using the

redial list

1{>}REDIAL s{r}: Select the desired entry.

2To make a cellular call:

When only 1 cellular phone is paired: {CELL}

When 2 cellular phones are paired:

{CELL}s{r}: Select the desired cellular phone. s

{SELECT}

To make a landline call:

{C}

To adjust the ringer volume

(cellular line/landline)

Press {^} or {V} repeatedly to select the desired volume while

ringing.

TGH26xC_QG(en).fm Page 6 Wednesday, December 25, 2013 9:21 AM

Phonebook (Handset)

Adding entries 1{<}

s{MENU}

2{r}: “Add new entry”s{SELECT}

3{r}: “(Name)”s{SELECT}

4Enter the party’s name (16 characters max.). s{OK}

5{r}: Select the desired phone number location. s

{SELECT}

6Enter the party’s phone number (24 digits max.). s{OK}

7{r}: Select the desired label. s{SELECT}

LTo store 2 or 3 phone numbers, repeat steps 5-7.

8{r}: Select the current setting of the group. s{SELECT}

9{r}: Select the desired group. s{SELECT}

10{r}: “<Save>”s{SELECT}s{OFF}

Making calls 1{<}

s{r}: Select the desired entry.

2To make a cellular call:

When only 1 cellular phone is paired: {CELL}s{r}: Select

the desired phone number. s{CALL}

When 2 cellular phones are paired:

{CELL}s{r}: Select the desired phone number. s

{CALL}s{r}: Select the desired cellular phone. s

{SELECT}

To make a landline call:

{C} s{r}: Select the desired phone number. s{C}

Answering system for the landline (Base unit)

Answering on/off Press {ANSWER ON/OFF}to turn on/off the answering system.

Listening to messages {P}(PLAY)

Answering system for the landline (Handset)

Listening to messages To listen to new messages:

{PLAY}or {MENU}(right soft key) (323

To listen to all messages:

{MENU}(right soft key) (324

Basic operations

TGH26xC_QG(en).fm Page 7 Wednesday, December 25, 2013 9:21 AM

Using Bluetooth devices

Copying phonebook entries from a Bluetooth cellular phone (phonebook transfer)

You can copy phonebook entries from the paired cellular phones or other cellular phones (not

paired) to the unit’s phonebook.

1Handset: {MENU}(right soft key) (618

2Handset:

To copy from paired cellular phones:

{r}: Select the desired cellular phone. s{SELECT}

LCopied items are stored to the group (“Cell 1”or “Cell 2”) which the cellular phone is

paired to.

To copy from other cellular phones (not paired):

{r}: “Other cell”s{SELECT}s{r}: Select the group you want to copy to. s

{SELECT}

3When “Use the cell to transfer phone book”is displayed: Go to step 4.

When “Select mode”menu is displayed:

{r}: Select “Auto”or “Manual”. s{SELECT}

“Auto”: Download all entries from the cellular phone automatically. Go to step 5.

“Manual”: Copy entries you selected.

L“Select mode”menu is displayed only when the cellular phone supports PBAP (Phone

Book Access Profile) for Bluetooth connection.

4Cellular phone:

Follow the instructions of your cellular phone to copy phonebook entries.

LFor other cellular phones (not paired), you need to search for and select the base unit. The

Bluetooth PIN (default: “0000”) may be required. If your cellular phone shows PassKey

confirmation on its display, follow the directions to proceed.

LThe entries being copied are displayed on the handset.

5Handset:

Wait until “Completed”is displayed. s{OFF}

TGH26xC_QG(en).fm Page 8 Wednesday, December 25, 2013 9:21 AM

Using a Bluetooth wireless headset (optional) for landline calls

By pairing a Bluetooth headset to the base unit, you can have a hands-free conversation wirelessly

for landline calls.

LOnly 2 Bluetooth devices can be used with the unit at the same time (for example, 2 cellular

lines, or the headset and 1 cellular line).

Pairing a headset to the base unit

1Your headset:

Set your headset to pairing mode.

LRefer to your headset operating instructions.

2Handset:

{MENU}(right soft key) (621

1Pair using the handset.

2Paring

3If your headset PIN is “0000”, go to step 4.

If your headset PIN is other than “0000”, press {CLEAR}, then enter your headset PIN.

LTypically, default PIN is “0000”. Refer to the headset operating instructions.

4Press {OK}, then wait until a long beep sounds. s{OFF}

LWhen the HEADSET indicator on the base unit lights up, you are ready to use the headset.

Operating a Bluetooth wireless headset using a landline

Refer to your headset operating instructions for headset operations.

NAnswering landline calls with your headset

To answer a landline call, turn on your headset referring to your headset operating instructions.

When you finish talking, turn off your headset referring to your headset operating instructions.

LIf you cannot hang up the call using your headset, press {P}(STOP) on the base unit.

NSwitching between the base unit and your headset

You can switch between the base unit and your headset while listening to messages recorded

on the base unit answering system.

LYou can only switch from the base unit to your headset.

To switch to your headset:

Turn on the headset referring to your headset operating instructions.

Using Bluetooth devices

TGH26xC_QG(en).fm Page 9 Wednesday, December 25, 2013 9:21 AM

Frequently asked questions

Question Cause/solution

Why is _displayed? LThe handset is too far from the base unit. Move closer.

LThe base unit’s AC adaptor is not properly connected. Reconnect

AC adaptor to the base unit.

LThe handset is not registered to the base unit. Register it.

1Handset: {MENU}(right soft key) (13)

2Base unit: Press and hold {LOCATOR}for about 5 seconds.

3Handset: Press {OK}, then wait until a long beep sounds.

Why am I unable to pair a

cellular phone to the base

unit?

Depending on the compatibility of the cellular phone, you may not be

able to

pair

it to the base unit. For more information, please visit

http://www.panasonic.ca/link2cell

LConfirm that the Bluetooth feature of your cellular phone is turned

on. You may need to turn this feature on depending on your

cellular phone.

How can I increase the

handset volume level?

LPress the navigator key {^} repeatedly while talking.

Why is the conversation

noisy or cutting off?

LTry to relocate the base unit so that distance to the handset is

minimized.

LIf the same problem occurs even if the handset is next to the base

unit, contact an authorized service centre.

Can I add another

accessory handset to my

base unit?

LYes, you can add up to 6 handsets (including the handset(s) sold

with your base unit) to a single base unit.

Can I keep the batteries

charging all the time?

LYou can leave the handset on the base unit or charger anytime.

This will not harm the batteries.

How can I answer a Call

Waiting call (2nd call)?

LPress {CALL WAIT}when you hear the Call Waiting tone.

TGH26xC_QG(en).fm Page 10 Wednesday, December 25, 2013 9:21 AM

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Sprachen:

Andere Panasonic Telefon Handbücher

Panasonic

Panasonic KXT2395 - PHONE/ANSWER MACHINE Bedienungsanleitung

Panasonic

Panasonic KX-UT670 Handbuch

Panasonic

Panasonic KX-TC1701B - 900 MHz Cordless Phone Bedienungsanleitung

Panasonic

Panasonic KX-TDA30 Bedienungsanleitung

Panasonic

Panasonic KX-TC1851B - 900 MHz DSS Cordless Phone Bedienungsanleitung

Panasonic

Panasonic KX-T7735 - 3 Line Backlit Display... Bedienungsanleitung

Panasonic

Panasonic KX-TA824 Betriebsanleitung

Panasonic

Panasonic KX-TC1481B Bedienungsanleitung

Panasonic

Panasonic KX-TG2352W - 2.4 GHz DSS Expandable Cordless Phone... Bedienungs- und Montageanleitung

Panasonic

Panasonic HYBRID IP-PBX KX-TDA100 Bedienungsanleitung

Panasonic

Panasonic KX-T7335 Bedienungsanleitung

Panasonic

Panasonic CPC-EX Bedienungsanleitung

Panasonic

Panasonic KX-TDA15 Bedienungsanleitung

Panasonic

Panasonic KX-TS500HG Bedienungsanleitung

Panasonic

Panasonic KX-UT670 Bedienungsanleitung

Panasonic

Panasonic KX-TGP600 Bedienungsanleitung

Panasonic

Panasonic KX-A114EX/E Bedienungsanleitung

Panasonic

Panasonic KX-HGT100 Kurzanleitung

Panasonic

Panasonic KX-TDA30 Bedienungsanleitung

Panasonic

Panasonic KX-DT 333 Series Bedienungsanleitung

Panasonic

Panasonic KX-T7735 Bedienungsanleitung

Panasonic

Panasonic KX-TA824 Bedienungsanleitung

Panasonic

Panasonic DBS 576HD Bedienungsanleitung

Panasonic

Panasonic KX-TGD590C Bedienungsanleitung

Beliebte Telefon Handbücher anderer Marken

GE 2-9480 Bedienungsanleitung

Geemarc

Geemarc PHOTOPHONE 155 Bedienungsanleitung

D-Link

D-Link DWR-720/PW Bedienungsanleitung

Interquartz

Interquartz Gemini IQ333 Bedienungsanleitung

SSS Siedle

SSS Siedle HT 840-0 Bedienungsanleitung

Motorola

Motorola TITANIUM Bedienungsanleitung

LG H870DS Bedienungsanleitung

Samsung

Samsung GT-I9500 Bedienungsanleitung

AT&T

AT&T Trimline 205 Bedienungsanleitung

Selta

Selta zenyth 600 Bedienungsanleitung

Doro

Doro AFTI 20 Bedienungsanleitung

UNIQCELL

UNIQCELL A1 Bedienungsanleitung

Jabra

Jabra SP5050 - Bluetooth hands-free Speakerphone Bedienungsanleitung

BT Decor 425 Bedienungsanleitung

NEC

NEC SV8500 Bedienungsanleitung

Teledex

Teledex PEARL Bedienungsanleitung

Ericsson

Ericsson Dialog 3213 Bedienungsanleitung

Yealink

Yealink VP530 Bedienungsanleitung
