Panasonic KX-UT670 Handbuch
Panasonic KX-UT670
Admin Guide
Schmooze Com Inc.
Panasonic
KX-UT670
Phone Contacts Network Camera Browser Calendar Screen lock now
Jan 26 10:21 AM4704 UT670
Menu Home Back
Volume Enter
SP-Phone
MutePhone
How To Find IP Address & MAC Address
Quick Steps
1.Press the “Menu” button.
2.Press the “Settings” button.
3.Scroll down and press the “About Phone” option.
© Copyright Schmooze Com, 2012
4. Select the “Status” option.
5. The IP address and MAC address will be displayed.
How To Set the Configuration Server
Quick Steps
1. Log into the Web Admin GUI of the phone.
2. Select the “Maintenance” tab at the top right.
3. Next select “Provisioning Maintenance”.
4. You can now specify the provisioning server information. In our example we are using
tftp://10.10.0.1/Config{MAC}.cfg
How To Factory Default
Quick Steps
1.Log into the Web Admin GUI of the phone
2. Next select the “Maintenance” tab at the top right.
3. Now select “Reset to Defaults” on the left navigation menu.
4. Finally click the “OK” button to complete the reset.
Menu Home Back
Volume Enter
SP-Phone
MutePhone
Browser Calculator Calendar Clock Contacts
Email Gallery Music Network Camera Phone
Settings
Menu Home Back
Volume Enter
SP-Phone
MutePhone
4706 UT670
Menu Home Back
Volume Enter
SP-Phone
MutePhone
4706 UT670
Search
Language & keyboard
Accessibility
Date & Time
Network Camera
About phone
Administration
Settings
How To Find IP Address & MAC Address
Quick Steps
1.Press the “Menu” button.
2.Press the “Settings” button.
3.Scroll down and press the “About Phone” option.
4. Select the “Status” option.
5. The IP address and MAC address will be displayed.
© Copyright Schmooze Com, 2012
How To Set the Configuration Server
Quick Steps
1. Log into the Web Admin GUI of the phone.
2. Select the “Maintenance” tab at the top right.
3. Next select “Provisioning Maintenance”.
4. You can now specify the provisioning server information. In our example we are using
tftp://10.10.0.1/Config{MAC}.cfg
How To Factory Default
Quick Steps
1.Log into the Web Admin GUI of the phone
2. Next select the “Maintenance” tab at the top right.
3. Now select “Reset to Defaults” on the left navigation menu.
4. Finally click the “OK” button to complete the reset.
Menu Home Back
Volume Enter
SP-Phone
MutePhone
4706 UT670
Status
Legal information
Model number
OS Version
Kernel version
Firmware version
Network, Service state, etc.
KX-UT670
2.2
2.6.32.9
01.072
About phone
Menu Home Back
Volume Enter
SP-Phone
MutePhone
4706 UT670
Status
Legal information
Model number
OS Version
Kernel version
Firmware version
Network, Service state, etc.
KX-UT670
2.2
2.6.32.9
01.072
About phone
Status
Network OK ( 10.4.0.152 )
Phone service OK 4704
MAC address 00:00:00:00:00:00
OK
How To Find IP Address & MAC Address
Quick Steps
1.Press the “Menu” button.
2.Press the “Settings” button.
3.Scroll down and press the “About Phone” option.
4. Select the “Status” option.
5. The IP address and MAC address will be displayed.
How To Set the Configuration Server
Quick Steps
1. Log into the Web Admin GUI of the phone.
2. Select the “Maintenance” tab at the top right.
3. Next select “Provisioning Maintenance”.
4. You can now specify the provisioning server information. In our example we are using
tftp://10.10.0.1/Config{MAC}.cfg
© Copyright Schmooze Com, 2012
How To Factory Default
Quick Steps
1.Log into the Web Admin GUI of the phone
2. Next select the “Maintenance” tab at the top right.
3. Now select “Reset to Defaults” on the left navigation menu.
4. Finally click the “OK” button to complete the reset.
KX-UT670 Status Network System VoIP Telephone Maintenance
Web Port Close
Status
Version Information
Network Status
VoIP Status
Version Information
Version Information
Model KX-UT670
OS Version 2.2
Firmware Version 01.072
Web Port Close
Maintenance
Firmware Maintenance
Provisioning Maintenance
Reset to Defaults
Restart
Firmware Maintenance
Firmware Maintenance
Enable Firmware Update Yes No
Firmware File URL http://10.10.0.1:2004/panasonic/2/UT670.bin
Save Cancel
KX-UT670 Status Network System VoIP Telephone Maintenance
Web Port Close
Maintenance
Firmware Maintenance
Provisioning Maintenance
Reset to Defaults
Restart
Provisioning Maintenance
Provisioning Maintenance
Enable Provisioning Yes No
Standard File URL http://10.10.0.1:2004/Config{MAC}.cfg
Product File URL
Master File URL
Cyclic Auto Resync Yes No
Resync Interval 10080 minute(s) [1-40320]
Header Value for
Resync Event check-sync
Save Cancel
KX-UT670 Status Network System VoIP Telephone Maintenance
How To Find IP Address & MAC Address
Quick Steps
1.Press the “Menu” button.
2.Press the “Settings” button.
3.Scroll down and press the “About Phone” option.
4. Select the “Status” option.
5. The IP address and MAC address will be displayed.
How To Set the Configuration Server
Quick Steps
1. Log into the Web Admin GUI of the phone.
2. Select the “Maintenance” tab at the top right.
3. Next select “Provisioning Maintenance”.
4. You can now specify the provisioning server information. In our example we are using
tftp://10.10.0.1/Config{MAC}.cfg
How To Factory Default
Quick Steps
1.Log into the Web Admin GUI of the phone
2. Next select the “Maintenance” tab at the top right.
3. Now select “Reset to Defaults” on the left navigation menu.
4. Finally click the “OK” button to complete the reset.
© Copyright Schmooze Com, 2012
KX-UT670 Status Network System VoIP Telephone Maintenance
Web Port Close
Status
Version Information
Network Status
VoIP Status
Version Information
Version Information
Model KX-UT670
OS Version 2.2
Firmware Version 01.072
Web Port Close
Maintenance
Firmware Maintenance
Provisioning Maintenance
Reset to Defaults
Restart
Firmware Maintenance
Firmware Maintenance
Enable Firmware Update Yes No
Firmware File URL http://10.10.0.1:2004/panasonic/2/UT670.bin
Save Cancel
KX-UT670 Status Network System VoIP Telephone Maintenance
Web Port Close
Maintenance
Firmware Maintenance
Provisioning Maintenance
Reset to Defaults
Restart
Reset to Defaults
Reset Web Data
KX-UT670 Status Network System VoIP Telephone Maintenance
The Web data for this unit will be reset to it’s default values when you click [Reset Web Settings].
Reset Web Settings
VOICE MAIL
LINE 1
LINE 2
LINE 3
LINE 4
Schmooze Com Inc.
http://schmoozecom.com
(920) 886-8130
