Panasonic PVDF2000 - MONITOR/DVD COMBO Bedienungsanleitung

Service Manual

TOP NEXT

ORDER NO. MKE0009600C1

B3, B6

TV/DVD/VCR Combination



PV-DF2000/PV-DF2700

Page

10/20/2008

http://tsn.pstc.panasonic.com/viewing/NA/PV

DF2000/SVC/s0000000000.html

distribution is a violation of law.

TOP

Page

10/20/2008

http://tsn.pstc.panasonic.com/viewing/NA/PV

DF2000/SVC/s0000000000.html

12.2.1 MECHANICAL REPLACEMENT

PARTS

TOP PREVIOUS NEXT

MECHANICAL REPLACEMENT PARTS

Ref. No. Part No. Part Name & Description Remarks

1VBSS0033 FULL ERASE HEAD 1

2VXKS0890 MOTOR BLOCK UNIT 1

3LSDB0045 TENSION ARM BOSS 1

4VXDS0212 CAPSTAN HOLDER UNIT 1

5LSMD0209 OPENER PIECE 1

8VVGS0009 MAIN CAM GEAR KIT 2

9LSDR0004 S REEL TABLE 1

10 LSDR0005 T REEL TABLE 1

11 VEGS0429 CYLINDER UNIT 1

OR VEGS0451

12 VEHS0583 AUDIO CONTROL/ERASE HEAD UNIT 1

14 LSDG0112 LIFT GEAR 1

16 VXDS0213 LOADING POST BASE-S UNIT 1

17 VXDS0214 LOADING POST BASE-T UNIT 1

18 VXLS1094 PINCH ARM UNIT 1

19 LSDG0110 INTERMEDIATE GEAR A 1

20 VXLS1101 P5 ARM UNIT 1

21 LSML0131 DRIVE RACK ARM 1

22 VXLS1103 TENSION CONTROL ARM UNIT 1

23 LSMX0129 OIL SEAL 1

27 VXLS1100 T BRAKE UNIT 1

29 VXLS1102 TENSION ARM UNIT 1

38 LSMB0221 CASSETTE DOOR SPRING 4 MKA

41 VXPS0389 CENTER CLUTCH UNIT 2

42 VMBS1151 CHANGING GEAR SPRING 2

43 LSDG0114 CHANGING GEAR 2

44 VXLS1091 IDLER ARM UNIT 2

45 VXPS0391 CAPSTAN ROTOR UNIT 2

46 LSMA0387 STOPPER ANGLE 2

47 LSMM0002 MAIN ROD 2

48 PICTURE TUBE UNIT

LXQVB01200F ( A ) 4 MKA

LXQVB01270F ( B ) 4 MKA

49 VXLS1099 S LOADING ARM UNIT 2

50 VXLS1098 T LOADING ARM UNIT 2

51 LSDG0116 REEL GEAR 2

52 LSDG0111 INTERMEDIATE GEAR B 2

53 LSMA0423 SUPPORT ANGLE 2

Page

10/20/2008

http://tsn.pstc.panasonic.com/viewing/NA/PV

DF2000/SVC/s1202010000.html

54 LSDV0007 CAPSTAN BELT SQUARE,RUBBER 2MM 2

57 LSSA0003 GROUNDING PLATE UNIT 1

60 VMFS0311 CUSHION 5

61 VXYS1347 CASSETTE UP ASS´Y 3,5

62 LSMA0352 TOP PLATE 3

64 LSMD0174 SIDE PLATE L 3

65 LSMD0173 SIDE PLATE R 3

66 LSMB0218 SUPPORT SPRING 3

67 LSML0096 OPENER LEVER 3

68 VXLS1111 DRIVE RACK UNIT 3

69 VXAS4423 HOLDER UNIT 3

70 VXLS1110 WIPER ARM UNIT 3

71 FRONT CABINET ASS´Y

LXQKY01200F ( A ) 4 MKA

LXQKY01270F ( B ) 4 MKA

72 LXQKF01270F VHS CASSETTE DOOR-LID UNIT 4 MKA

73 REAR COVER UNIT

LXQKV01200F ( A ) 4 MKA

LXQKV01270F ( B ) 4 MKA

84 LSGU0162 OPERATION BUTTON A 4 MKA

90 BADGE,ABS RESIN

TBM153022 ( A ) 4 MKA

TBM173052 ( B ) 4

91 TOP SHIELD PLATE ASS´Y

LXQUS01200FK

( A ) 5 MKA

LXQUS01270FK

( B ) 5 MKA

92 SPEAKER UNIT R

LXQAS01200F ( A ) 4 MKA

LXQAS01270F ( B ) 4 MKA

93 SPEAKER UNIT L

LXQAS02200F ( A ) 4 MKA

LXQAS02270F ( B ) 4 MKA

96 TMM7464-1 CLAMPER 5,6,7

100 VKFS2235 BATTERY COVER 8

102 LSMP0249 FRAME 5 MKA

104 LML69002A CLAMPER 5 MKA

106 HANDLE

LSKH0053 ( B ) 4 MKA

118 LPE64005A BAG,POLYETHYLENE 8 MKA

121 PACKING CASE,PAPER

LSPG0903 ( A ) 8 MKA

LSPG0902 ( B ) 8 MKA

122 LSQF0281 FAN BAG 8 MKA

123 INFRARED REMOTE CONTROL UNIT

LSSQ0246 ( A ) 8 MKA

LSSQ0245 ( B ) 8 MKA

125 TOP CUSHION RIGHT,STYROFOAM

Page

10/20/2008

http://tsn.pstc.panasonic.com/viewing/NA/PV

DF2000/SVC/s1202010000.html

LSPN0181 ( A ) 8 MKA

LSPN0177 ( B ) 8 MKA

126 TOP CUSHION LEFT,STYROFOAM

LSPN0180 ( A ) 8 MKA

LSPN0176 ( B ) 8 MKA

127 TMM6463-1 PURSE LOCK CLAMPER 4 MKA

131 BOTTOM CUSHION FRONT,STYROFOAM

LSPN0178 ( A ) 8 MKA

LSPN0174 ( B ) 8 MKA

132 BOTTOM CUSHION REAR,STYROFOAM

LSPN0179 ( A ) 8 MKA

LSPN0175 ( B ) 8 MKA

154 TMM5439-1 CLAMPER 5,7

168 VZFS0006 INSULATOR TIE,NYLON 5

200 LSGL0341 PANEL LIGHT 4 MKA

201 LSGU0163 OPERATION BUTTON B 4 MKA

202 LXQKF02270F DVD CASSETTE DOOR-LID UNIT 4 MKA

203 LSMB0170 DVD CASSETTE DOOR SPRING 4 MKA

204 LSMA0438 MOUNT PLATE,STEEL 5 MKA

208 TMK77708 CUSHION,RUBBER 4 MKA

209 VMFS0213 SHEET,NYLON-RAYON 4 MKA

215 LSQL0837 DOLBY DIGITAL CAUTION LABEL 4 MKA

230 LSKF0325 TRAY COVER 5 MKA

242 VXYS1403 DVD UNIT 5 MKA

244 TUX77809 CLAMPER 7 MKA

247 LSQL0840 CAUTION LABEL 5

261 VEKS5764 CONNECTOR CABLE W/PLUG,DC12V 5 MKA

262 VEKS5765 CONNECTOR CABLE W/PLUG,DC12V 5 MKA

263 VEKS5799 CONNECTOR CABLE W/PLUG,DC12V 5 MKA

264 VEKS5768 CONNECTOR CABLE W/PLUG,DC14V 5 MKA

265 VEKS5797 CONNECTOR CABLE W/PLUG,0V 5 MKA

266 VEKS5811 GROUNDING WIRE 5 MKA

268 LSMT0062 CUSHION,PLASTIC (early product) 5 MKA

401 VHDS0475 SCREW,STEEL 1

405 VHDS0496 SCREW W/WASHER,STEEL 5

410 VHDS0498 SCREW W/WASHER,STEEL 1

414 VHNS0070 MAIN CAM PUSH NUT,STEEL 2

422 XWGV2D5G WASHER,NYLON 2

424 XYC26+SF6J SCREW W/WASHER,STEEL 1

430 XTV26+6FFZJ TAPPING SCREW,STEEL 1

432 XTV3+8JR TAPPING SCREW,STEEL 5,7

443 XTV4+12A TAPPING SCREW,STEEL 4,7

445 SCREW W/WASHER,STEEL

LHT60002Y ( A ) 4 MKA

LHT60001Y ( B ) 4 MKA

446 XTV4+16A TAPPING SCREW,STEEL 4 MKA

449 VHDS0493 TAPPING SCREW,STEEL 5

Page

10/20/2008

http://tsn.pstc.panasonic.com/viewing/NA/PV

DF2000/SVC/s1202010000.html

450 VHDS0309 SCREW,STEEL 5

460 XTN4+12A TAPPING SCREW,STEEL 5

469 XSN3+6 SCREW,STEEL 5

470 XTV3+10G TAPPING SCREW,STEEL 4

471 XSN26+5 SCREW,STEEL 1

472 XTN26+5FJ TAPPING SCREW,STEEL 2

473 XYN26+C6 SCREW W/WASHER,STEEL 2

474 LSHD0056 TAPPING SCREW,STEEL 1

475 XTV26+5FJ TAPPING SCREW,STEEL 2

481 XTW4+Z15D TAPPING SCREW,STEEL 4 MKA

482 XNG3 NUT,STEEL 6

483 XYN3+F10S SCREW W/WASHER,STEEL 6,7

484 XTW3+10J TAPPING SCREW,STEEL 7

485 XYE3+EJ10 SCREW W/WASHER,STEEL 7

486 XYN3+F12S SCREW W/WASHER,STEEL 7

487 XYN3+J8 SCREW W/WASHER,STEEL 7

488 XYN3+F6S SCREW W/WASHER,STEEL 7

489 XYN3+F8S SCREW W/WASHER,STEEL 7

490 XQN2+B35 SCREW,STEEL 2

491 XYN2+J7 SCREW W/WASHER,STEEL 2

492 VHDS0274 TAPPING SCREW,STEEL 5

711 PNA4611M00HC

INFRARED RECEIVER UNIT 6 MKA

712 VMTS0035 CUSHION,RUBBER 6

713 VMAS1912 P.C.B. SUPPORT ANGLE 6,7

731(IC2505)

EZMPS300F12 MR HEAD 2

732(P2502)

LSJS0097 CONNECOR 12P 2

733 LSMA0384 BACK PLATE,STEEL 2

741 LSJA0349-FE AC CORD W/PLUG,125V 6 MKA

742 TJC6319 FUSE HOLDER 6

743 TUNER,UHF/VHF NR

ENG36701G ( A ) 6 MKA

TUNER 1,UHF/VHF NR

ENG36707G ( B ) 6 MKA

744 TUNER 2,UHF/VHF NR

ENG36708G ( B ) 6 MKA

745 CONNECTOR CABLE W/PLUG,DC 5V

VEKS5774 ( B ) 6 MKA

751 LML69001A ANODE LEAD CLAMPER 7 MKA

752 LSMA0444 HEAT SINK 7 MKA

753 LSSC0256 HEAT SINK 7 MKA

754 LSSC0438 HEAT SINK 7 MKA

755 TMM16480-1 CLAMPER 7

757 HEAT SINK

LSSC0409 ( A ) 7 MKA

LSSC0410 ( B ) 7 MKA

761 TUC15717 HEAT SINK 7 MKA

Page

10/20/2008

http://tsn.pstc.panasonic.com/viewing/NA/PV

DF2000/SVC/s1202010000.html

TOP

762 TUC76649-4 HEAT SINK 7

763 CONNECTOR CABLE W/PLUG,DC10KV

LXPJS01F2700 ( B ) 7 MKA

764 CONNECTOR CABLE W/PLUG,DC1.2KV

LXPJS02F2700 ( B ) 7 MKA

771 EYF52BC FUSE HOLDER 6

772 LSSC0408 HEAT SINK 6 MKA

773 VSCS1072 HEAT SINK 6 MKA

791 VEKS5773 CONNECTOR CABLE W/PLUG,DC 5V 5

792 VEKS5812 CONNECTOR CABLE W/PLUG,0V 5

E10 VEPS3091B MAIN C.B.A. 5,6 RTL MKA

E10 VEPS3091A MAIN C.B.A. 5,6 RTL MKA

E11 VEPS3090B TV PROCESS C.B.A. 6 RTL MKA

E11 VEPS3090A TV PROCESS C.B.A. 6 RTL MKA

E12 VEPS4036B AUDIO C.B.A. 6 RTL MKA

E12 VEPS4036A AUDIO C.B.A. 6 RTL MKA

E20 VEPS5035Z Hi-Fi AUDIO/VIDEO HEAD AMP C.B.A. 1 RTL MKA

E30 VEMS0331 CAPSTAN STATOR C.B.A. NR 2

E40 VEPS9005B TUNER MAIN C.B.A. 5,6 RTL MKA

E40 VEPS9005A TUNER MAIN C.B.A. 5,6 RTL MKA

E50 LRP61013B TV MAIN C.B.A. 5,7 RTL MKA

E50 LRP61013A TV MAIN C.B.A. 5,7 RTL MKA

E51 LRP63020A DEFLECTION C.B.A. 7 RTL MKA

E60 LRP63021B CRT C.B.A. 5,7 RTL MKA

E60 LRP63021A CRT C.B.A. 5,7 RTL MKA

E70 VEPS1020A POWER SUPPLY C.B.A. 5,6 RTL MKA

E80 VEPS8060A OPERATION C.B.A. 5 RTL MKA

E90 LSEP3025A DVD DECODER C.B.A. 5

Page

10/20/2008

http://tsn.pstc.panasonic.com/viewing/NA/PV

DF2000/SVC/s1202010000.html

12.3.1 PRINTED CIRCUIT BOARD

ASSEMBLY

TOP PREVIOUS NEXT

TOP

Ref. No.

Part No. Part Name & Description Remarks

E10 VEPS3091B

MAIN C.B.A. E.S.D. RTL MKA

( A )

E10 VEPS3091A

MAIN C.B.A. E.S.D. RTL MKA

( B )

E11 VEPS3090B

TV PROCESS C.B.A. E.S.D. RTL MKA

( A )

E11 VEPS3090A

TV PROCESS C.B.A. E.S.D. RTL MKA

( B )

E12 VEPS4036B

AUDIO C.B.A. E.S.D. RTL MKA

( A )

E12 VEPS4036A

AUDIO C.B.A. E.S.D. RTL MKA

( B )

E20 VEPS5035Z

Hi-Fi AUDIO/VIDEO HEAD AMP C.B.A.

RTL MKA

E30 VEMS0331

CAPSTAN STATOR C.B.A. NR

E40 VEPS9005B

TUNER MAIN C.B.A. RTL MKA

( A )

E40 VEPS9005A

TUNER MAIN C.B.A. RTL MKA

( B )

E50 LRP61013B

TV MAIN C.B.A. E.S.D. RTL MKA

( A )

E50 LRP61013A

TV MAIN C.B.A. E.S.D. RTL MKA

( B )

E51 LRP63020A

DEFLECTION C.B.A. RTL MKA

( B )

E60 LRP63021B

CRT C.B.A. RTL MKA

( A )

E60 LRP63021A

CRT C.B.A. RTL MKA

( B )

E70 VEPS1020A

POWER SUPPLY C.B.A. E.S.D. RTL MKA

E80 VEPS8060A

OPERATION C.B.A. RTL MKA

E90 LSEP3025A

DVD DECODER C.B.A. E.S.D.

Page

10/20/2008

http://tsn.pstc.panasonic.com/viewing/NA/PV

DF2000/SVC/s1203010000.html

12.3.2 MAIN C.B.A.

TOP PREVIOUS NEXT

INTEGRATED CIRCUITS

Ref. No.

Part No. Part Name & Description Remarks

IC1201

BA09T IC, LINEAR MKA

IC2601

AN3808K IC, LINEAR

IC3001

AN3479FBP-A IC, LINEAR

IC3101

NJM2235M-TE1 IC, LINEAR

IC3201

MN3885S IC, CCD E.S.D.

IC3202

TA8898AN IC, LINEAR

IC3301

LC8632165S53 IC, 8BIT MICROCONTROLLER

E.S.D. MKA

IC6001

MN101D02HDC IC, 8BIT MICROCONTROLLER

E.S.D. MKA

( A )

MN101D02HDB IC, 8BIT MICROCONTROLLER

E.S.D. MKA

( B )

IC6002

SG-PK01 REEL SENSOR

IC6003

SG-PK01 REEL SENSOR

IC6004

AT24C02A10PI IC, 2K EEP ROM E.S.D. MKA

OR KS24C021I IC, 2K EEP ROM E.S.D. MKA

OR M24C02-BN6

IC, 2K EEP ROM E.S.D. MKA

IC6005

M51957AL IC, LINEAR MKA

IC6501

D750066-330 IC, CMOS STANDARD LOGIC

E.S.D.

IC6601

TC74VHCT126F

IC, CMOS STANDARD LOGIC

E.S.D. MKA

IC7201

NJM2235M-TE1 IC, LINEAR

IC7211

NJM2235M-TE1 IC, LINEAR

IC7221

NJM2235M-TE1 IC, LINEAR

IC7231

NJM2234M-TE1 IC, LINEAR MKA

IC7241

NJM2235M-TE1 IC, LINEAR

( B )

IC7251

NJM2235M-TE1 IC, LINEAR

( B )

IC7261

NJM2235M-TE1 IC, LINEAR

( B )

TRANSISTORS

Ref. No.

Part No. Part Name & Description

Remarks

Q3001 2SA1037K146R

CHIP

OR 2SB709A CHIP

Q3002 2SC2412K1 CHIP

OR 2SD601A CHIP

Q3071 2SC2412K1 CHIP

OR 2SD601A CHIP

Q3202 DTC114EK CHIP

Page

10/20/2008

http://tsn.pstc.panasonic.com/viewing/NA/PV

DF2000/SVC/s1203020000.html

OR UN2211 CHIP

Q3203 DTC114EK CHIP

OR UN2211 CHIP

Q3310 2SC2412K1 CHIP

OR 2SD601A CHIP

Q3311 2SA1037K146R

CHIP

OR 2SB709A CHIP

Q3316 2SC2412K1 CHIP

OR 2SD601A CHIP

Q3601 2SC2412K1 CHIP

OR 2SD601A CHIP

( B )

Q3602 2SC2412K1 CHIP

OR 2SD601A CHIP

( B )

Q3603 2SC2412K1 CHIP

OR 2SD601A CHIP

( B )

Q3604 2SC2412K1 CHIP

OR 2SD601A CHIP

( B )

Q4001 2SA1037K146R

CHIP

OR 2SB709A CHIP

Q4002 2SD601(R,S) CHIP

Q4003 2SD601(R,S) CHIP

Q4101 2SC2412K1 CHIP

OR 2SD601A CHIP

Q4171 2SC2412K1 CHIP

OR 2SD601A CHIP

Q4173 DTC144EK CHIP

OR UN2213 CHIP

Q6001 2SA1037K146R

CHIP

OR 2SB709A CHIP

Q6002 2SC2412K1 CHIP

OR 2SD601A CHIP

Q6003 2SC2412K1 CHIP

OR 2SD601A CHIP

Q6004 2SA1037K146R

CHIP

OR 2SB709A CHIP

Q6005 2SA1037K146R

CHIP

OR 2SB709A CHIP

Q6006 2SC2412K1 CHIP

OR 2SD601A CHIP

Q6009 VEKS5707 PHOTO SENSOR UNIT

Q6010 VEKS5707 PHOTO SENSOR UNIT

Q7231 2SC2412K1 CHIP

OR 2SD601A CHIP

Page

10/20/2008

http://tsn.pstc.panasonic.com/viewing/NA/PV

DF2000/SVC/s1203020000.html

Andere Handbücher für PVDF2000 - MONITOR/DVD COMBO

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Panasonic Fernseher Handbücher

Panasonic

Panasonic CT-27SC13 Bedienungsanleitung

Panasonic

Panasonic TC-14B3R Bedienungsanleitung

Panasonic

Panasonic TX-55CX400E Bedienungsanleitung

Panasonic

Panasonic TX-32PS11P Bedienungsanleitung

Panasonic

Panasonic RX-28XDP1C Bedienungsanleitung

Panasonic

Panasonic TX-32PD30D Bedienungsanleitung

Panasonic

Panasonic TX-L42DT65B Montageanleitung

Panasonic

Panasonic TX-21FX20RSF-IRAN Bedienungsanleitung

Panasonic

Panasonic TX-55C320E Bedienungsanleitung

Panasonic

Panasonic VIERA TX-P42S10B Bedienungsanleitung

Panasonic

Panasonic TC-21S10R Bedienungsanleitung

Panasonic

Panasonic Viera TC-50PX34 Bedienungsanleitung

Panasonic

Panasonic QuintrixF TX-28PS1 Bedienungsanleitung

Panasonic

Panasonic TY-LA1500 Gebrauchs- und Pflegehandbuch

Panasonic

Panasonic TX-P42GT60B Bedienungsanleitung

Panasonic

Panasonic TR-1030P Bedienungsanleitung

Panasonic

Panasonic TC-29GA30R Bedienungsanleitung

Panasonic

Panasonic CT32D20B - 32" COLOR TV Bedienungsanleitung

Panasonic

Panasonic TCL47DT50X Bedienungsanleitung

Panasonic

Panasonic PT-50LC13 - 50" Rear Projection TV Bedienungsanleitung

Panasonic

Panasonic Viera TH-42PZ800E Bedienungsanleitung

Panasonic

Panasonic TC-21PM70R Bedienungsanleitung

Panasonic

Panasonic CT-2771S Bedienungsanleitung

Panasonic

Panasonic TX-28MD4P Bedienungsanleitung

Beliebte Fernseher Handbücher anderer Marken

Philips

Philips Colour Television Bedienungsanleitung

Toshiba

Toshiba 27A10 Bedienungsanleitung

Philips

Philips 42PF9630A/37 Bedienungsanleitung

Hitachi

Hitachi 32FX48B Bedienungsanleitung

DAEWOO ELECTRONICS

DAEWOO ELECTRONICS DTQ-14V1FC Bedienungsanleitung

Changhong Electric

Changhong Electric uhd55b6000is Bedienungsanleitung

Philips

Philips Matchline 21CE7551 Bedienungsanleitung

Toshiba

Toshiba 19A20 Bedienungsanleitung

Philips

Philips 25PT4523-16 Bedienungsanleitung

Sony

Sony XBR-100Z9D Bedienungsanleitung

Philips

Philips PR0930X3 Bedienungsanleitung

Philips

Philips Brilliance 231P4QPY Bedienungsanleitung

Samsung

Samsung 55S9 B Series Bedienungsanleitung

Philips

Philips 32HF9385D Fehlerbehebungshandbuch

Sharp

Sharp LC-40FI5012E Bedienungsanleitung

Loewe

Loewe Table Stand Reference 55 Bedienungsanleitung

Philips

Philips 32PFH5300 Bedienungsanleitung

Sylvania

Sylvania 6427FB Bedienungsanleitung
