Pantech PC-1000N Bedienungsanleitung
1
PC-1000N
Untitled-1 1 2004.11.5 8:2:2 PM
2
Welcome to Pantech PC-1000N
Welcome to the wireless mobile
communication network with this
tri-band mobile phone, PC-1000N.
We, Pantech, are pleased to
introduce this brand new portable
handset.
Our product always keeps you
connected to the network.
Thank you for choosing Pantech
PC-1000N.
The user manual explains in detail how
it works and what unique features are
available.
Some of the contents in this User Manual could vary from your
phone.
It may differ depending on the S/W version and the network
provider you subscribed to.
Untitled-1 2 2004.11.5 8:2:5 PM
3
Display
H 28.032 mm x 35.04 mm display for ” LCD
H True TFT colour display
H Supports up to 262,000 colours within 128 x 160 pixels
H 8 lines for text in basic mode with 16-pixel font
H Three Soft keys with four-way scroll including selection
function
(OK key)
H List and grid menu
Melody
Yamaha poly sound
Dynamic 3D stereo sound
Camera
Integrated VGA Camera.
H Resolution up to 640 x 480 (330,000 pixels)
H
Phone display used as a viewfinder
H
Standard, wide (portrait) modes on external viewfinder
H
Photo album in Picture Album
H
Photo Gallery for image storing and editing
Dimension & Weight
H
Weight: g
H
Dimensions: mm x mm x mm
Characteristic Specification of PC-1000N
Untitled-1 3 2004.11.5 8:2:5 PM
4
Power Management (Performance)
Operating Frequency
H
H
Characteristic Specification of PC-1000N
Battery Type
Standard
(Li-ion)
850 mAh 200 Hours 5 Hours
Capacity Talk Time
Standby Time
Untitled-1 4 2004.11.5 8:2:5 PM
5
Views of Pantech PC-1000N
Earpiece
LCD
Cancel/Back
Text Clear/
Edit exit key
4-way Menu
Navigation
Special Menu
Short key
Left Softkey
Wap Access
key
Dial key
Call Accept
Right Softkey
Alphanumeric
Key
Microphone
Power On/Off
Menu exit key
Select/Menu
Confirm key
Untitled-1 5 2004.11.5 8:2:6 PM
6
Views of Pantech PC-1000N
Camera Access
Key
Volume Up/Down
Menu Scroll
Earjack
Camera
Untitled-1 6 2004.11.5 8:2:7 PM
7
Quick & Easy
Quick & Easy
Keys Functions
SOFT KEYS : (Menu Key) Press to access the menu or
function displayed on bottom line of the display.
(Left Key) Press to access a phonebook.
NAVIGATION KEY :
In Idle Mode : Press up to access Messaging, down
to access Recent Calls, right for Do More and left for
Settings.
Inside the menu : Within a menu, use to scroll through
menu options, or to select a function displayed on the
bottom line of the screen.
OK KEY
In Idle Mode : Press to access the menu.
Inside the menu : Press it in to make your selection.
In Camera Mode, Take Picture as Camera Key.
BACK KEY
While viewing menus, press to go back to the previoius
menu.
While entering characters with the keypad, press once to
clear one character at a time.
INTERNET KEY
From standby mode, use for quick access to the
'Wireless Web' menu.
SEND KEY
Press to place or receive a call.
Press and hold to redial last outgoing call.
Untitled-1 7 2004.11.5 8:2:8 PM
8
Keys Functions
to
When entering text, press to shift between upper
and lower case.
While in standby mode, press and hold to quickly
activate/de-activate Vibration Mode.
When entering text, press to place spaces between
characters.
While in standby mode, press and hold to enter key
guard mode.
In edit screen :
Cycle through candidate words matched when T9
word mode Insert '0' when alphabet mode.
From standby mode, use for quick access to the
'Camera' menu and use to take pictures.
Adjusts earpiece volume while making a call, and
moves the cursor upward in the menu.
Controls the key tone volume in the standby mode
if the handset flip is opened, and moves the cursor
upward in the menu.
Press and hold to turn the phone on or off.
While in a call, press to end the call.
while viewing any screen, press to return to stanby
Quickly connects to the voice mail server if pressed
longer in the standby mode.
Use to enter characters or numbers.
Also used to access different menu options.
Quick & Easy
Untitled-1 8 2004.11.5 8:2:9 PM
9
Quick & Easy
Keys Functions
Adjusts earpiece volume while making a call, and
moves the cursor downward in the menu.
Controls the key tone volume in the standby mode
if the handset flipis opened, and moves the cursor
downward in the menu.
Untitled-1 9 2004.11.5 8:2:9 PM
10
Using a handset while driving is prohibited.
With regards to the regulation about prohibition of handset
usage while driving, please check relevant laws and
regulation and comply with them
H Use of your cellular while you are driving may disturb your
concentration on driving and consequently incur accidents.
Please turn it off as far as possible.
H Should you use your handset in an emergency, please make use
of the hands free built in your car or pull over your car in a safe
place for a while for your utmost safety.
H The electronic wave energy emitting from your handset may
affect the electronic device built in your car. Please pay attention
to this characteristic.
Cellular Use Restriction Area
Make sure to turn your handset off in the handset usage
restricted area.
Using a Handset in the Explosive or Dangerous Area is
not Allowed Please turn your handset off in the area with
explosive or dangerous materials (such as gas, gas station,
or chemical goods) and abide by any instruction or signal.
Never try to detach your cellular battery from the handset in
such areas, either.
Boarding Airplane
H Please turn your handset off when you are on the airplane. The
electronic wave from your handset may affect the electronic
navigation device in your airplane.
Safety Precautions
Untitled-1 10 2004.11.5 8:2:9 PM
