Pantech Jetpack MHS291L Bedienungsanleitung
User Guide
5U000748C0A REV.00
Guía del Usuario
4G LTE
Mobile Hotspot - MHS291L
4G LTE
Mobile Hotspot - MHS291L
User Manual
Thank you for purchasing the Verizon
Jetpack® 4G LTE Mobile Hotspot
MHS291L. The MHS291L is a Global
ReadyTM wireless device that provides
high-speed wireless communication
and easily connects at high speeds to
the internet, your corporate intranet,
and your email while you’re away
from the office or out of the country.
The MHS291L is simple to use.
2 Table of Contents
Table of Contents
Table of Contents
Getting Started 5
System Requirements........................................................................................ 5
Components ........................................................................................................ 6
Display Icons ......................................................................................................... 8
Using Your Jetpack 9
About Broadband Networks ........................................................................... 9
Removing/Attaching the Back Cover.........................................................11
Installing/Removing the 4G LTE SIM Card................................................12
Installing/Removing the Battery..................................................................13
Power Management.........................................................................................17
Connecting to Your Jetpack .........................................................................18
Tethering Your Jetpack ......................................................................................19
Table of Contents 3
Jetpack User Interface
Settings 23
Wi-Fi Name/Password......................................................................................23
Connected Devices...........................................................................................23
Messages..............................................................................................................24
Network Settings...............................................................................................24
Wi-Fi Settings ......................................................................................................24
Software Update................................................................................................27
About Jetpack.....................................................................................................28
Web User Interface
Start the Jetpack’s Web User Interface 30
My Jetpack Home..............................................................................................31
Data Usage...........................................................................................................32
Connected Devices...........................................................................................33
Jetpack Settings 34
Jetpack ..................................................................................................................34
Wi-Fi........................................................................................................................38
Advanced .............................................................................................................40
Messages 49
4 Table of Contents
About Jetpack 50
Internet Status....................................................................................................50
Jetpack Info .........................................................................................................51
Diagnostics ..........................................................................................................52
Statistic & Logs ...................................................................................................53
Help and Support..............................................................................................54
Troubleshooting 55
Windows XP(SP3) ..............................................................................................55
Windows Vista(SP2) ..........................................................................................56
Windows 7 / Vista(SP2) ....................................................................................56
Windows 7 ...........................................................................................................58
Glossary 59
Safety and Warranty 63
Regulatory Notices ...........................................................................................63
Warnings and Cautions...................................................................................63
Product Handling ..............................................................................................65
Caring for Your Device.....................................................................................65
Safety Information for Mobile Hotspot .....................................................66
Safety Information for FCC RF Exposure ...................................................71
SAR Information.................................................................................................72
FCC Compliance Information........................................................................74
12-Month Limited Warranty ..........................................................................75
Getting Started 5
Getting Started
System Requirements
• Wi-Fi: Compatible with all major operating systems
• USB tethering: Compatible with Windows 8 (32-bit/64-bit),
Windows 7 (32-bit/64-bit), Windows Vista SP2 (32-bit/64-bit),
Windows XP SP3 32-bit
• Works with the latest versions of browsers, including
Android™, Chrome™, Firefox®, Internet Explorer®, Safari™,
Mobile Safari™, and Konqueror.
Note
USB Tethering is not compatible with Mac OS.
To use Wi-Fi mode, your computer or connected device needs Wi-Fi
capability.
Note
• When multiple users are connected to the MHS291L, all of
their data usage will be combined and applied to the data
plan associated with this jetpack.
• USB 3.0 is not supported for tethering mode.
6 Getting Started
Components
3
4
3
21
Number Description
1Red Lighting Effect - Illuminates when the display
is on.
2
Home Screen - Provides connection and battery
status, network signal strength, roaming status, and
the number of users connected with Wi-Fi.
3Scroll Up/Down( / ) - Scrolls up or down through
the available menu options.
4OK Button( ) - Press to select a menu option.
Getting Started 7
65 6
7
Number Description
5Power Button( ) - Press and hold to turn the
Jetpack on and off.
6
External Antenna Adapter Port( ) - Connects to
an external antenna (sold separately) for improved
signal reception under certain conditions.
7Micro USB Port - Connects to the included USB cable
for charging or tethering.
8 Getting Started
Display Icons
The icons on the LCD screen indicate the status of the Jetpack.
Connected Devices
Activity Indicator
Network Signal
Strength
Mobile
Network & Roaming
Messages
Battery
Menu
Display Icon Description
Network signal strength indicator.
Indicates data is being transferred between the
Verizon Wireless network and the Jetpack.
Indicates the number of connected devices.
When available connections are filled, MAX is
displayed.
Indicates the number of unread SMS messages.
If no unread messages, this icon does not appear.
Battery charge indicator.
Indicates the current network connection and
roaming status.
Access to Jetpack settings and Data Usage.
Using Your Jetpack 9
Using Your Jetpack
About Broadband Networks
4G LTE
With Verizon 4G LTE, you can get the broadband-like speed you
require to work efficiently outside the home or office. You can
connect to the Internet, access your corporate intranet, check your
email and download attachments at speeds that are up to 10 times
faster than 3G*.
4G LTE Mobile Broadband*
• Download: typical download speeds of 5-12 Mbps.
• Upload: typical upload speeds of 2-5 Mbps.
3G Mobile Broadband with EVDO Rev. A**
• Download: typical download speeds of 600 kbps–1.4 Mbps
with bursts up to 3.1 Mbps.
• Upload: typical upload speeds of 500-800 kbps with bursts up to
1.8 Mbps.
