Parabit Systems ACS-1E Handbuch

Parabit Systems Inc.

ACS-1E and ACS-1EUL

Installation and Service Manual

Release: Version 2.0

Effective Date: September 2018

Parabit Systems, Inc.

35 Debevoise Avenue

Roosevelt, NY 11575

NOTICE

or by any means without the written permission of the publisher.

ACS Enterprise Software User’s Guide

Table of Contents

Preface

Intended Audience ............................................................................................................................................1

Trademark Acknowledgments ..........................................................................................................................1

How to Use this Guide.........................................................................................................................................1

Conventions Used in this Guide.........................................................................................................................1

Navigating this Manual as a PDF.......................................................................................................................2

Contact Us ...........................................................................................................................................................2

Chapter 1 Overview and Pre-installation

System Overview .................................................................................................................................................3

Pre-installation Requirements.............................................................................................................................5

Chapter 2 Alerts

Alerts Overview....................................................................................................................................................7

Card Reader Alerts .............................................................................................................................................7

Sensor Device Alerts............................................................................................................................................8

Suspect Card Alerts (Optional)..........................................................................................................................8

Activating the Suspect Card function........................................................................................................8

Controller Box Tamper Alert ...............................................................................................................................8

Door Override Input Alert (Optional) ................................................................................................................9

Chapter 3 ACS-1E and ACS-1EUL Installation

Controller Box Installation.................................................................................................................................11

Secure Controller Location ........................................................................................................................11

Secure Power Source..................................................................................................................................11

200-240 VAC Power Locations.............................................................................................................12

Mounting the Controller Box and Routing Wires......................................................................................12

Additional Wiring Suggestions....................................................................................................................13

Mounting on Hollow Walls & controllers..............................................................................................13

Mounting on Solid Walls........................................................................................................................13

Card Reader Installation ..................................................................................................................................13

IMSR with SkimGardTM Technology ..........................................................................................................13

MMR and MMR-BT .......................................................................................................................................15

MMR Power Booster Module Installation (ACS-1E ONLY) .................................................................15

IMSR, MMR and MMR-BT Install Diagrams.................................................................................................17

Electrical Installation .........................................................................................................................................20

ACS-1E and ACS-1EUL Wiring.....................................................................................................................20

Wiring the Card Readers and Basic Input Devices ...........................................................................20

ACS-1E Card Reader and Input Device Wiring .................................................................................22

ACS-1EUL Card Reader and Input Device Wiring .............................................................................24

Wiring the Optional I/O Board Inputs..................................................................................................26

Table of Contents

Wiring the Door Control and Additional Outputs ..............................................................................26

System Wiring Diagrams ...................................................................................................................................29

ACS-1E Wiring Diagrams .............................................................................................................................30

ACS-1EUL Wiring Diagram ..........................................................................................................................33

Chapter 4 Post-Installation Checks and Testing

Post-Installation Checks....................................................................................................................................39

Default Settings............................................................................................................................................39

Preliminary Tools and Materials..................................................................................................................40

Preliminary Hardware Checks....................................................................................................................40

Preliminary Electrical Checks .....................................................................................................................41

Visual Inspection of the MMR Card Reader.............................................................................................42

Sticker Verification.......................................................................................................................................42

Post-Installation Testing .....................................................................................................................................42

ACS-1E Controller Tests ...............................................................................................................................43

ACS-1E Second Card Reader Board Tests ...............................................................................................45

ACS-1EUL Controller Tests ...........................................................................................................................46

ACS-1EUL Second Card Reader Board Tests ...........................................................................................48

Main Card Reader Tests .............................................................................................................................49

Additional Test Procedures for the MMR Card Reader ..........................................................................50

Additional Feature Tests .............................................................................................................................52

Troubleshooting .................................................................................................................................................53

ACS-1E and ACS-1EUL Install and Service Manual Ver 2 1

Intended Audience

This manual is for technicians trained to install and service Parabit Systems, Inc.ACS -1Eand

ACS-1EULaccess control systems.

Trademark Acknowledgments

ACS-1E, ACS Enterprise, AFH Service, AVA, AXSView Service, MMR, and SkimGard are registered trade-

marks of Parabit Systems Inc. or its subsidiaries in the United States and/or other countries.

Parabit Systems, Inc. and Parabit are trademarks of Parabit Systems Inc. or its subsidiaries in the United

States and/or other countries.

All other trademarks and trade names are the property of their respective owners.

How to Use this Guide

This guide provides concise, step-by-step instructions for set-up, configuration, and operation of the

ACS-1E and ACS-1EUL systems.

Conventions Used in this Guide

This guide contains the following conventions:

Convention Example

Screen names, dialog box names, tab names,

window names, field names, and menu names

appear in bold font.

Click the Customer box.

File names are italicized. AxsView.Transceiver.Installer.msi

Steps to be performed in order are numbered

and/or lettered.

1. Click Save and Close to save the information

before closing the dialog box, or click Can-

cel to close the dialog box without saving

the information.

2. From the Login screen, click Setup, and then

click Login.

Unordered steps are presented in bullets. • MicrosoftWindows7 or greater

• MicrosoftNet 3.5 and .Net 3.51

Preface

2ACS-1E and ACS-1EUL Install and Service Manual Ver 2

Warnings, Cautions, and Notes are used to draw immediate attention to matters of importance. The

following is a definition of their meanings:

WARNING: INDICATES A POTENTIALLY HAZARDOUS SITUATION THAT, IF NOT AVOIDED, COULD RESULT IN

SERIOUS INJURY.

CAUTION: Indicates a hazardous situation that, if not avoided, could result in data loss or product

damage.

Note: Indicates additional information.

Navigating this Manual as a PDF

This manual includes embedded hyperlinks for quick access to procedures and other sections when

viewing the manual as a PDF. Click on any section title or page reference to immediately display that

content. Here are some helpful keyboard shortcuts when using the Adobe Reader:

• To return to your previous location in the manual after following a hyperlink, press Alt+Left Arrow.

• To return to the hyperlink destination after returning to the previous location, press Alt+Right Arrow.

• To open a Search window, press Ctrl+Shift+F. Enter your search term in the text field and click

Search. Every instance of the search term that appears in the manual will display in the Search win-

dow. Click on any of the instances to jump directly to that section.

Parabit Systems, Inc.

35 Debevoise Avenue

Roosevelt, NY 11575

1 (888) 3-PARABIT

Checkboxes

• To select (enable) a checkbox setting, click

in the checkbox. The checkbox has a check

mark.

• To clear (disable) a checkbox setting, click

on the check mark in the checkbox. The

checkbox is empty.

Series of menu options to click Click Options > User Management > Add New

Convention Example

ACS-1E and ACS-1EUL Install and Service Manual Ver 2 3

Chapter 1

Overview and Pre-installation

1.1 System Overview .....................................................................................................................3

1.2 Pre-installation Requirements.................................................................................................5

1.1 System Overview

The Parabit ACS-1E and ACS-1EUL ATM / Building Access Control System provides secure entry to

branch and remote ATM lobby installations. It consists of the following components:

ACS-1E System

Optional Second

Card Reader Board

ACS-1E

Controller

Optional

4 Port

Input /

Output

Board

Optional Modem Board

Overview and Pre-installation System Overview

4ACS-1E and ACS-1EUL Install and Service Manual Ver 2

Card Readers

Controller Detail

IMSRwithSkimGardTM

Technology

MMR / MMR-BT MMR-C

ACS-1E ACS-1EUL

Pre-installation Requirements Overview and Pre-installation

ACS-1E and ACS-1EUL Install and Service Manual Ver 2 5

1.2 Pre-installation Requirements

The following requirements must be met prior to installation of a ACS-1E or ACS-1EUL system.

Power & Grounding

• One standard duplex 115-125 VAC 10 amp (or greater) wall outlet

• Earth grounding termination located within 5 feet of the ACS-1E or ACS-1EUL Controller

• Use of a Uninterruptible Power Supply (UPS) is highly recommended

PC & Software

• Laptop or other portable personal computer running MS Windows 7 (or later) operating system.

• ACS Enterprise software installed and running on the PC or laptop.

IP Connection

• One 10/100 MB Ethernet port connection terminated with an RJ45 jack installed within 5 feet of the

ACS-1E/ACS-1EUL Controller.

• All ACS-1E controllers leave the factory with a default IP address of 192.168.1.248, Port 2000 and

ACS-1EUL controllers with an address of 192.168.1.249, Port 2000.

•From a LAN Setting: The Ethernet port from a local network switch or hub must be active with

configured Port #2000 and a compatible IP address supplied prior to installation.

Note: A controller’s IP address and Port # can be reconfigured after installation. The IP address

also can be changed prior to installation using a Peer-to-Peer connection.

•From a Peer-to-Peer Setting: Connect to an ACS-1E or ACS-1EUL controller via a network cross-

over or Parabit-supplied serial cable between the PC or laptop and the controller network

socket.

Follow the steps below to connect via Parabit-supplied serial cable:

(1) Connect a USB to serial converter to the local PC.

(2) Open Device Manager of the local PC to determine the COM port assigned to the con-

verter.

(3) On the ACS Enterprise Main Menu, go to Setup > Dialup/Direct.

(4) In the COM Port list, select the COM port number to be assigned for the connection and

click Save.

(5) Connect the serial cable to the port of the local PC and to the 3-pin header (J4) on the

ACS Controller.

(6) On the Site Management screen, go to Connect > Direct Connect.

(7) To disconnect from an ACS Controller when finished, select Disconnect.

Modem Connection:

One analog “Tip & Ring” telephone line terminated with an RJ11C telephone jack installed within 5

feet of the ACS-1E or ACS-1EUL controller.

Overview and Pre-installation Pre-installation Requirements

6ACS-1E and ACS-1EUL Install and Service Manual Ver 2

This page intentionally left blank.
