Parkside 89587 Bedienungsanleitung

POWER ENGRAVING TOOL PGG 15 A1

POWER ENGRAVING TOOL

Operation and Safety Notes

Translation of original operation manual

URZĄDZENIE DO GRAWEROWANIA

Wskazówki dotyczące obsługi i bezpieczeństwa

Tłumaczenie oryginalnej instrukcji obsługi

GRAVÍROZÓ KÉSZÜLÉK

Kezelési és biztonsági utalások

Az originál használati utasítás fordítása

GRAVIERGERÄT

Bedienungs- und Sicherheitshinweise

Originalbetriebsanleitung

APARAT ZA GRAVIRANJE

Navodila za upravljanje in varnostna opozorila

Prevod originalnega navodila za uporabo

GRAVÍROVAČKA

Pokyny pre obsluhu a bezpečnostné pokyny

Preklad originálneho návodu na obsluhu

IAN 89587

GB Operation and Safety Notes Page 5

PL Wskazówki dotyczące obsługi i bezpieczeństwa Strona 19

HU Kezelési és biztonsági utalások Oldal 35

SI Navodila za upravljanje in varnostna opozorila Stran 51

SK Pokyny pre obsluhu a bezpečnostné pokyny Strana 67

DE/AT/CH Bedienungs- und Sicherheitshinweise Seite 81

Before reading, unfold the page containing the illustrations and familiarise yourself with all

functions of the device.

Przed przeczytaniem proszę rozłożyć stronę z ilustracjami, a następnie proszę zapoznać się z

wszystkimi funkcjami urządzenia.

Olvasás előtt kattintson az ábrát tartalmazó oldalra és végezetül ismerje meg a készülék

mindegyik funkcióját.

Pred branjem odprite stran s slikami in se nato seznanite z vsemi funkcijami naprave.

Pred čítaním si odklopte stranu s obrázkami a potom sa oboznámte so všetkými funkciami prístroja.

Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und machen Sie sich anschließend

mit allen Funktionen des Gerätes vertraut.

1 2 3

5GB

Table of contents

Introduction

Proper use................................................................................ Page 6

Features and equipment......................................................... Page 6

Included items ......................................................................... Page 7

Technical details...................................................................... Page 7

General safety advice for electrical

power tools....................................................................... Page 8

1. Workplace safety............................................................... Page 9

2. Electrical safety................................................................... Page 9

3. Personal safety.................................................................... Page 10

4. Careful handling and use of electrical power tools......... Page 11

5. Service................................................................................. Page 12

Operation

Switching on/ off .................................................................... Page 13

Setting the cutting depth......................................................... Page 13

Changing the engraving point ............................................... Page 14

Advice on use.......................................................................... Page 14

Cleaning ............................................................................... Page 15

Service................................................................................... Page 15

Warranty............................................................................. Page 15

Disposal................................................................................ Page 17

Manufacturer’s Declaration of

Conformity/Manufacturer................................... Page 17

6 GB

Introduction Introduction

Power engraving tool PGG 15 A1

Introduction

We congratulate you on the purchase of your new device. You have

chosen a high quality product. The instructions for use are part of the

product. They contain important information concerning safety, use

and disposal. Before using the product, please familiarise yourself with

all of the safety information and instructions for use. Only use the unit

as described and for the speciﬁed applications. If you pass the product

on to anyone else, please ensure that you also pass on all the docu-

mentation with it.

Proper use

This product is intended for engraving or decorating materials such

as metal, plastic, glass, ceramic, wood, leather and stone. Any other

use or modiﬁcation to the drill/grinder shall be considered as improper

use and could give rise to considerable dangers. The manufacturer will

not accept liability for loss or damage arising from improper use. Not

intended for commercial use.

Features and equipment

1ON/ OFF switch

2Stroke rate rotary controller

3Hanging eye

4Mains lead

7GB

Introduction Introduction

5Engraving point

6Engraving point holder

7Engraving stencils

Included items

1 Power engraving tool PGG 15 A1

2 Engraving stencils

1 Operating instructions

Technical details

Rated voltage: 230V∼ 50Hz

Mode of operation: intermittent operation: S3 20%

Note: A duty cycle (in %) deﬁnes explicitly the maximum continuous

duration of use and the subsequent rest period. In this case the tool

requires a cooling phase of eight minutes after an operating period of

two minutes, for example.

Rated current: 0.15A

Stroke rate: 6000min-1

Noise and vibration data:

Measured values for noise are determined in accordance with

EN 60745. The A-weighted noise level of the electrical power tool

are typically:

Sound pressure level: 74.4dB(A)

Sound power level: 85.4dB(A)

Uncertainty K: 3dB

8 GB

General safety advice for electrical power toolsIntroduction/General safety advice for electrical power tools

Wear ear protection!

Evaluated acceleration, typical:

Hand/ arm vibration: 1.582m/s2

Uncertainty K = 1.5m/ s2

The vibration level speciﬁed in these instructions was

measured in accordance with an EN 60745 standardised measurement

process and can be used to compare equipment. The vibration emission

value speciﬁed can also serve as a preliminary assessment of the ex-

posure.

The vibration level will change according to the application of the elec-

trical tool an in some cases may exceed the value speciﬁed in these in-

structions. Regularly using the electric tool in such a way may make it

easy to underestimate the vibration.

Note: If you wish to make an accurate assessment of the vibration

loads experienced during a particular period of working, you should

also take into account the intervening periods of time when the device

is switched oﬀ or is running but is not actually in use. This can result in

a much lower vibration load over the whole of the period of working.

General safety advice for

electrical power tools

Read all the safety advice and

instructions! Failure to observe the safety advice and in-

structions may result in electric shock, ﬁre and/or serious

injury.

9GB

General safety advice for electrical power toolsIntroduction/General safety advice for electrical power tools

Keep all the safety advice and instructions in a safe place

for future reference!

The term “electrical tool” used in the safety advice refers to electrical

tools powered by mains electricity (by means of a mains lead) and elec-

trical tools powered by rechargeable batteries (without a mains lead).

1. Workplace safety

a) Keep your working area clean and well lit. Untidy or

poorly lit working areas can lead to accidents.

b) Do not work with the device in potentially explosive

environments in which there are inflammable liquids,

gases or dusts. Electrical power tools create sparks, which can

ignite dusts or fumes.

c) Keep children and other people away while you are

operating the electrical tool. Distractions can cause you to

lose control of the device.

2. Electrical safety

he mains plug on the device must match the mains

socket. The plug must not be modified in any way.

Do not use an adapter plug with devices fitted with

a protective earth. Unmodiﬁed plugs and matching sockets

reduce the risk of electric shock.

b) Avoid touching earthed surfaces such as pipes, radia-

tors, ovens and refrigerators with any part of your

body. There is an increased risk of electric shock if your body is

earthed

10 GB

General safety advice for electrical power toolsGeneral safety advice for electrical power tools

c) Keep the device away from rain or moisture. Water en-

tering an electrical device increases the risk of electric shock.

d) Do not use the mains lead for any purpose for which

it was not intended, e.g. to carry the device, to hang

up the device or to pull the mains plug out of the mains

socket. Keep the mains lead away from heat, oil, sharp

edges or moving parts of the device. Damaged or tangled

mains leads increase the risk of electric shock.

e) When working outdoors with an electrical power tool

always use extension cables that are also approved

for use outdoors. The use of an extension cable suitable for

outdoor use reduces the risk of electric shock.

f) Use a residual current device (RCD) for protection if

operating the electrical power tool in a moist environ-

ment is unavoidable. The use of an RCD reduces the risk of

electric shock.

3. Personal safety

a) Remain alert at all times, watch what you are doing

and always proceed with caution. Do not use the de-

vice if you are tired or under the influence of

drugs,

alcohol or medication. One mo

ment of carelessness when using

the device can lead to serious injury.

b) Wear personal protective equipment and always wear

safety glasses. The wearing of personal protective equipment

such as dust masks, non-slip safety shoes, safety helmets or ear

protectors, appropriate to the type of electrical power tool used

and work undertaken, reduces the risk of injury.

c) Avoid unintentional operation of the device. Check

that the electrical power tool is switched off before y
