Parrot ANAFI USA Bedienungsanleitung

ANAFI USA

General Checks

Preflight Checks

Inflight Checks

Battery Information

Super Quick Start Guide

ANAFI USA x Skycontroller

USA

Flight Checks:

BY DRONIVO GMBH

MCPKG01417A

Dronivo GmbH

Giulinistraße 2;

Gebäude S07;

67065 Ludwigshafen

Germany

Bitte Bild ändern,

das ist keine Parrot

Anafi USA

General Checks:

1. Gimbal protection - Remove

2. Arms - Deploy

3. Arms - Check general condition and absence

of cracks

4. Propeller blades - Check general condition

and absence of cracks

5. Propeller blades - check tightening

6. Gimbal - Check if it is free on both axes

7. Camera lenses - Cleanse

8. SD Card - Check presence

9. Vertical camera and ultrasonar -

Check/cleanse

10. Battery - Insert

11. Drone - Power on

12. Remote control - Power on

13. Stylus - Check/cleanse

14. Wi-Fi link - Check

15. Battery levels (drone and remote control) -

Check full charge

16. SD Card - Format/Encrypt

17. Magnetometer - Calibrate

18. Main camera streaming - Check

19. Zoom camera streaming - Check

20. IR camera streaming - Check then back to

Visible

21. Gimbal stabilization - Check

22. Hand launch - Activate/deactivate as

required by mission

23. Map - Charge

24. Security settings - Check

25. Flight Preset - Check

26. LED Settings - Check

27. Network settings - Select Manual / set a 5

Hz channel / revert to Auto

28. Take-off - Proceed

29. Flight stability - Check

30. Joystick and triggers control - Check

31. Landing - Proceed

32. Drone - Power off

33. Remote control - Power off

Preflight Checks:

1. Remove control - Power on

2. Arms - Deploy

3. Drone battery level - Check

4. Drone - Power on

5. Propeller blades - Check

6. Gimbal stabilization - Check

7. Wi-Fi link - Check

8. Obstacles in flight zone - Check

9. Line of sight - Estimate

10. Take-off - Proceed

11. Streaming - Check

12. RTH* settings - Check/modify

as required by mission

13. GPS - Check

14. Auto recording - Check/modify

as required by mission

Inflight Checks:

Battery Information

When a battery is not plugged to a power

source, its 4 lEDs indicate its charge level

after a short press on the power button:

1 flashing LED: 0-20%

1 1 LED: 21-40%

2 LEDs: 41-60%

3 LEDs: 61-80%

4 LEDs: 81 -100%

NOTE 1: ANAFI USA batteries can be

charged with any USB-C cable.

NOTE 2: ANAFI USA batteries

hibernate after 10 days without use. In

hibernation mode, batteries discharge

to 65% charge, their LEDs do not turn

on, and they cannot power the drone.

Thanks to hibernation mode, batteries

last longer without losing their power.

To get a battery out of the hibernation

mode, plig it to a power source.

Signal strength1.

GPS2.

Height3.

Drone battery level4.

Remote control battery level5.

Video recording6.

Obstacles7.

Line of sight8.

RTH* path9.

*RTH - Return to Home: by default, the drone flies back to its Home point (take-off point or 1st GPS fix), but the function is fully customazible through FreeFlight 6.

*LED - Light Emitting Diode

When a battery is plugged to a power

source, its 4 LEDs* indicate its charge

level:

1 LED - 0-24%

2 LED - 25-49%

3 LED - 50-74%

4 LED - 75-100%

Sieht mehr nach einer Anafi Thermal aus

GPS fehlt
