1 INTRODUCTION
1.1 General
The Patol 5000 Series of equipment is specifically designed for the protection of
establishments and systems where a movement of materials with a potential fire hazard is
a routine occurrence.
The 5000 Series system employs enhanced Infra-red monitoring technology that enables
the detection of fire initiating materials, whilst they are being transported, and before they
have reached a flame condition.
The system has many applications within industries such as Power Generation, Coal
Mining, Process Plant, Road Transportation and Rail Networks and has been specifically
designed to both meet the rigors of these environments and to provide the reliability
required.
The equipment monitors for fire and fire potential of materials in transit. The system can
detect anomalies where combustion has not yet been reached, but where there is sufficient
energy for a fire initiation upon destination arrival.
A typical example is in the coal feed systems on power stations where coal on the ‘out field
stack’ may very well smoulder with little adverse effect for long periods of time. However, if
imported to the power station it may have devastating effects on conveyor systems, holding
hoppers, blending plants etc.
♦ Detection of hazards at temperatures below flame point including both embers and
buried hot spots.
♦ Air purged system for Dusty environments with air pressure monitoring.
♦ Eight high integrity detectors for maximum reliability
♦ Multi-facet lensing provides wide uniform coverage superior to some ember/spark
detectors.
♦ Coincidence- Double Knock - option for unit detectors as standard.
♦ Timed auto reset / coincidence analyser circuit.
♦ Tuned response - solar blind.
♦ Special configurations and application specific calibration options.
♦ Specifically designed for high EMC compliance
1.2 Principles
The principle of operation is that
temperature dependant black body
emissions occur for all materials.
These emissions range through the
infra red spectrum to visible light.
Both the wavelength and level of
peak energy emission are related to
temperature.
The Series 5000 detectors are
designed to detect the changes in
these emissions that occur when a
hot body enters the field of view of
the detector.
By the use of both optical filtering and electronic analysis of the various parameters the
system is blind to visible light from the sun or local luminaires, whilst being able to detect
relatively low temperature material moving through the field of view.
123456789
200 C
320 C
SOLAR
o
o
10
Typical Black Body Energy Emissions
5000 RESPONSE FILTER
WAVELENGTH (Micrometres) Fig. 1
