VPC-HD22
VPC-HD22 Product Specification & Operational Manual
1. Scope of Application
This is to describe VPC-HD22, an assembly unit for camera modules. All specifications contained herein are
subject to change without prior notice. Reproduction in whole or in part is prohibited.
2. Handling Precautions
The assembly unit must not be used for any nuclear equipments or aerospace equipments
with which mechanical failure or malfunction could result in serious bodily injury or loss of
human life. Our warranty does not apply to damages or defects caused by irregular and/or
abnormal use of the product..
Please observe all warnings and cautions stated below.
Our warranty does not apply to damages or malfunctions caused by neglecting these
precautions.
Do not use or store the assembly unit in the dusty or humid places.
.
Do not apply excessive force or static electricity that could damage the assembly unit.
Do not shoot direct images that are extremely bright (e.g., light source, sun, etc).
Follow the instructions in Chapter 7, “External Connector Pin Assignment” for connecting
the camera module. Improper connection may cause damages not only to the camera
module but also to the connected devices. t
Confirm the mutual ground potential carefully and then connect the camera module to
monitors or computers. AC leaks from the connected devices may cause damages or
destroy the camera module.
Do not apply excessive voltage. (Use only the specified voltage.) Unstable or improper
power supply voltage may cause damages or malfunction of the camera assembly.
VPC-HD22 is an assembly unit for camera modules. It is designed based on the premise of
embedded in a camera. Therefore, the appropriate heat dissipation needs to be considered
when embedding the board unit. Operating the assembly unit without appropriate heat dissipation
considered may cause damages or malfunction.
