This manual contains very important safety warnings and information.

Read and save these instructions for future reference.

INTRODUCTION

Congratulations on your purchase of a new 8”

Whirl vane axial fan from Pearson Industries. It

is our goal to provide you with the highest quality

air mover. The Whirl is durable and will provide

years of trouble free service when you follow the

recommendations included in this manual.

Please read this manual before operating the

unit. If you do not understand any portion of this

manual, please contact Buhin or an authorized

dealer for additional assistance and guidance

before operating the fan.

SAFETY INFORMATION

DO NOT operate the 8” Whirl fan without rst

reading this owner’s Manual and understand-

ing the fans operation.

Pearson has endeavored to design and make

the best ventilation equipment possible. How-

ever, the possibility exists that the fan can be

subjected to applications for which it was not

designed. This misuse can lead to serious in-

jury or death. Refer to current OSHA job safe-

ty and health rules and regulations pertaining

to the construction industry. Pay particular at-

tention to the rules governing Permit-Required

Conned Spaces for General Industry 29 CFR

1910.

This fan is designed and made for air ventila-

tion only. It is not designed to move/transport

any sort of liquid or semi-liquid material.

Do not operate the fan in any explosive or

ammable atmosphere. Neither the mo-

tor nor the fan is designed to work in such

environments. Serious property damage,

injury or death may result if used in an ex-

plosive or ammable environment.

Keep the unit grounded with a three pronged

grounding plug and a grounded electrical out-

let. Do not use an ungrounded extension cord

or an ungrounded adapter.

GETTING STARTED

1) Read this owner’s manual to familiarize your-

self with all warnings and precautions.

2) Inspect the fan to conrm that it’s in its original

factory conguration. If it is not, contact Buhin or

an authorized Buhin representative.

3) Always use your legs to lift the fan to help

prevent back injury.

4) The fan should not be operated by a minor.

Use caution when operating this fan around chil-

dren.

5) Inspect the fan on a regular basis for signs of

any damage and lose or worn parts. Inspect all

accessories as well.

6) Understand how to turn the fan off in an emer-

gency. Turn it off by pushing the ON/OFF switch

which is located on the side of the unit or unplug

it at the power source.

7) The fan uses a NEMA 5-15P plug and is de-

signed to work ONLY from a grounded, 115 volt

nominal AC, 60Hz, single phase power source.

This power source should utilize a NEMA 5-15R

receptacle. Use a ground fault circuit interrupter

(GFCI) to further protect against electrical shock

hazards caused by ground faults.

Always use caution before entering a con-

ned space area. Test all conned space

air with gas detection equipment that is

appropriate for the job. Assume that a

conned space is contaminated until it is

proven otherwise.

DANGER!

GENERAL SAFETY INFORMATION

1) Do not operate any fan with a damaged cord

or plug. Discard fan or return to an authorized

service facility for examination and/or repair.

2) Do not run cord under carpeting. Do not cover

cord with throw rugs, runners, or similar cover-

ings. Do not route cord under furniture or appli-

ances. Arrange cord away from trafc area and

where it will not be tripped over.

3) Do not block the air intake grill.

4) Do not put any object in the air intake grill.

5) Do not place the fan in standing water be-

cause of extreme shock hazard.

6) Do not operate the fan outside when it is rain-

ing. Only store the fan indoors.

7) Do not discharge ammable solvents or

chemicals through the fan air intake grill.

8) Do not use the Fan in areas where amma-

ble or combustible liquids, gases, vapors, dust,

bers, or lings may be present.

9) This fan is not toy.

8) A properly grounded outlet should only be

used with this fan.

9) Unplug the fan from the power supply before

servicing and when not in use.

10) Do not handle the fan with wet hands. Do not

pull or carry the fan by its cord, do not use cord

as a handle, do not close a door on the cord, and

do not pull cord around sharp edges or corners.

Keep cord away from heated surfaces. Do not

unplug the fan by pulling on cord, grasp the plug

and not the cord.

11) Do not place hair, loose clothing, ngers,

and any parts of the body near the air intake grill.

12) Do not allow water inside the motor. Un-

plug the fan and let it dry thoroughly before

using again, if the motor becomes wet.

13) Do not remove ground from the power

cord. Removing it may result in electrical

shock or electrocution. Removing the ground

will void the warranty.

14) Inspect the fan if it has been dropped, left

outdoors, or dropped into water, etc.. Thor-

oughly inspect it prior to use.

15) Do not install ducting when the fan is in

operation.

DO NOT USE THE FAN IF THE INLET AND

OUTLET GRILLS ARE NOT INSTALLED.

If the Fan is not working or if you have a

question about its safe operation, do not

operate it.

Contact a Pearson Industries Authorized Ser-

vice Center, or the factory direct at (847) 963-

9633 or www.pearsonind.com.

DANGER!

MAINTENANCE

DANGER!

Shut off the fan and unplug it before conduct-

ing any service or inspection . Accidental elec-

trocution or shock may occur if the fan is not

disconnected from a power supply. Conrm

that the fan blade has stopped rotating before

removing the grills and handling the fan blade.

1) Check for any loose or broken fasteners

or components. Replace, repair or tighten as

needed with only factory approved parts.

2) Clean the fan blade of any debris. A build

up of debris such as paint, cement dust, dirt,

etc can unbalance the fan blade and damage

the unit.

OPERATION

1) When unpacking the fan, inspect it for any

damage that may have occurred during ship-

ping.

2) Read this manual before connecting and

operating the fan.

3) Determine if your job is considered hazard-

ous. The working environment may contain

explosive gases or dust in explosive amounts.

4) The outlet to be used must be grounded.

5) Make sure that both grills on the fan are

not obstructed in anyway that may restrict the

airow. Do not operate the fan at anytime if

the grills are not installed.

6) The fan is marked with an arrow on either

side. This is the direction of airow.

7) Never stand in front of the fan in the di-

rection of airow. Serious injury or death may

occur from being struck with debris that are

sucked into the fan and discharged at a high

speed.

8) Install duct when the fan is turned off and

unplugged.

9) Do not place the fan next to an obstruction

such as a wall as this will decrease airow.

10) Keep in mind that using duct will decrease

the airow rate.

11) Always test the atmosphere for explosive

gases prior to turning on the fan. Be sure to

continually retest the atmosphere.

TROUBLESHOOTING

PROBLEM CAUSE SOLUTION

Unit does not run 1. Switch is not on.

2. No power at outlet.

3. Switch is broken.

4. Loose wiring.

1. Turn on switch.

2. Check circuit breaker for power to

outlet.

3. Replace Switch.

4. Check wiring, tighten as needed.

Unit runs briey,

then shuts off on

overload.

1. Duct length is to long.

2. One or both grills are exhausted.

3. Motor bearing are failing or have

failed.

4. Internal motor wiring is faulty.

1. Shorten duct length.

2. Clear grills.

3. Replace motor

4. Replace motor

Unit vibrates exces-

sively when oper-

ating.

1. The fan blade is damaged.

2. There is dirt build up on the fan blade.

3. The motor shaft is bent because of a

severe jolt.

1. Replace fan blade.

2. Clean fan blade.

3. Replace motor. If necessary,

replace fan blade.

Unit makes a

scraping sound

while running.

1. A severe jolt has deformed the hous-

ing.

2. A sever jolt has dislodged the mo-

tor from the housing and/or the motor

mount vanes.

1. Replace the housing or the entire

unit if necessary.

2. Replace the motor if necessary.

Replace the motor mount vanes if

necessary.

Fan does not run,

but motor makes

noise.

1. A severe jolt has deformed the hous-

ing causing interference with the fan

blade.

2. The capacitor has failed or the ca-

pacitor wire is broken.

1. Repair or replace the housing as

necessary.

2. Repair or replace the capacitor as

necessary.

For parts and service contact a Pearson Industries Authorized Service Center, or the

factory direct at (847) 963-9633 or www.pearsonind.com.

DANGER!

ALL THE SERVICE PROCEDURES BELOW SHOULD BE CONDUCTED WITH THE UNIT

TURNED OFF AND UNPLUGGED!

8” WHIRL EXPLODED VIEW

MOTOR SPECIFICATIONS

WHIRL

Voltage 115V AC~

Phase Single

Frequency 50/60 Hz

Electric Motor 1/3 H.P.

Current (amps) 2.2

R.P.M. 3450

Max. S.P. .8"

AIR FLOW

RATES CFM M3/Min.

Free Air 615 18

DIMENSIONS

Size 8" diameter (203 mm)

Weight 16 lbs. (7 Kg)

Height 15" (381 mm)

Length 14" (356 mm)

Width 10" (254 mm)

ITEM PART # QTY DESCRIPTION

1 1 Duct Ring Screw

1 Well Nut

2 BCV3002 1Duct Ring/Grill

5 BCV3004 1Fan Blade Assembly

7BCV3010 1Motor (110V 50/60 Hz)

8 1

1Rubber Grommet

1PVC for motor wire

9 BCV3001 1 Vane

10 1Rivet for Rubber Foot

11 1Rubber Foot

12 BCV3005 1Shell w/4 Color Mold-In

13 1Rivets

14 BCV3003 1Capacitor

15 1Ring Terminal

1Quick connect male

1Quick connect female

1Star Lock Washer

1Hex nut

1Nylon Lock Nut

17 BCV3008 110" Switch Plate w/Gasket

18 1 Switch Plate Bolt

19 1Cord strain relief

20 1Switch and cover

22 1 Power cord

5420 Newport Drive STE 56

Rolling Meadows, IL 60008

Phone: (847) 963-9633

Fax: (847) 963-9733

Toll Free 888-364-9836

5420 Newport Dr. Suite 56

PEARSON INDUSTRIES LIMITED WARRANTY

The original purchaser of a new Peasron Industries fan is entitled to a limited warranty subject to the

terms and conditions set forth herein. Peasrosn’s limited warranty is for the replacement or repair

of any part that proves to be defective in workmanship or materials for a period of two (2) years from

the date of purchase by the original purchaser. During these two years, Pearson will provide all parts

necessary to correct any defects free of charge. This limited warranty is not transferable and is only

available for the original purchaser.

The limited warranty is only for the repair or replacement of parts found to be defective upon Pearson’s

examination. This limited warranty will be null and void unless the assembled unit is returned, freight

pre-paid, together with a letter describing the problem to Pearson or an authorized Pearson dealer,

This warranty is limited to ninety (90) days for labor from the date of the purchase. Thereafter, any labor

costs incurred will be charged to the customer at the current hourly rate.

This limited warranty is null and void if the product has been used in an improper manner, disassem-

bled, altered or not maintained properly. Furthermore, this limited warranty is null and void if fan has

been subjected to unauthorized repairs, corrosive chemicals, improper voltage, re, ood, abnormal

wear or any causes beyond Pearson’s control.

This limited warranty is null and void if the serial number has been removed, obliterated, or defaced.

Pearson Industries reserves the right to make changes to the fan design, materials or specications as

necessary and without prior notice. Pearson shall not be obliged to make any changes or modications

to any product previously manufactured.

Please provide the serial number of the fan and call Pearson to receive a return authorization number.

Replacements parts cannot be provided unless Pearson has the proper information from the customer.

To obtain replacement parts pursuant to this limited warranty, you must write to Pearson or call (888)

364-9836 to receive an authorization number.

VER. 1/12/15

Inhaltsverzeichnis

Andere Pearson Gebläse Handbücher

Pearson

Pearson WHIRL GEN-2 Bedienungsanleitung

Beliebte Gebläse Handbücher anderer Marken

Weed Eater

Weed Eater VS2000BV Bedienungsanleitung

KRAUSMANN

KRAUSMANN U37020-00 Bedienungsanleitung

Bosch

Bosch ALB 36 LI Bedienungsanleitung

Cub Cadet

Cub Cadet HB425 Bedienungsanleitung

GreenWorks Pro

GreenWorks Pro BLB482 Bedienungsanleitung

ARIETE

ARIETE 2768 Bedienungsanleitung

NuTone

NuTone 331H Bedienungsanleitung

GÜDE

GÜDE GLB 200 18 Li-Ion Bedienungsanleitung

I.VA.CO.

I.VA.CO. SC Series Betriebsanleitung

DeWalt

DeWalt DCE100 Bedienungsanleitung

Becker

Becker SV 7.330 Bedienungsanleitung

Metabo

Metabo AG 18 Pro Bedienungsanleitung

Desa

Desa GA3650TB Bedienungsanleitung

Echo

Echo Power Blower PB-230LN Bedienungsanleitung

Echo

Echo PB-413H Bedienungsanleitung

Black & Decker

Black & Decker BV3100 Bedienungsanleitung

Ryobi

Ryobi RY08570 Bedienungsanleitung

Haaga

Haaga 355 Bedienungsanleitung
