Peavey TLS-5X Bedienungsanleitung

FFrreeqquueennccyy rraannggee ((--1100 ddBB,, hhaallff

ssppaaccee))::

46 Hz to 1 kHz

FFrreeqquueennccyy rreessppoonnssee ((++//-- 33ddBB,,

hhaallff ssppaaccee))::

66 Hz to 17 kHz

SSeennssiittiivviittyy ((11ww//11mm))::

98 dB

PPoowweerr rraattiinngg ((pprrooggrraamm))::

500 Watts

PPeeaakk ppoowweerr ccaappaacciittyy ((ppeeaakk))::

1000 Watts

MMaaxxiimmuumm SSPPLL::

1 7 dB

TTrraannssdduucceerr ccoommpplliimmeenntt::

Sheffield®Pro 1500+™15"

premium woofer, 14XT™1.4"

titanium diaphragm dynamic

compression driver on a 90˚ x

40˚ coverage constant

directivity horn

DDrriivveerr pprrootteeccttiioonn::

Sound Guard™IV for the

compression driver provides

long- and medium-term

overload and overdrive

protection

NNoommiinnaall ccoovveerraaggee ppaatttteerrnn::

90˚ x 40˚

EElleeccttrroo--aaccoouussttiicc ccrroossssoovveerr

FFrreeqquueennccyy::

.8 kHz

NNoommiinnaall iimmppeeddaannccee::

8 Ohms

IInnppuutt ccoonnnneeccttiioonnss::

Two 1/4" phone jacks in parallel

EEnncclloossuurree mmaatteerriiaallss aanndd ffiinniisshh::

Trapezoidal, black carpet-

covered enclosure with dado

joined 1/ " MDF (Medium

Density Fiberboard) and a full-

length, black powder-coated

steel grille

DDiimmeennssiioonnss ((HH xx WW xx DD))::

FFrroonntt::

7.75" x 18. 5" x 17.563"

70.49 cm x 43.36 cm x 44.61 cm

RReeaarr::

7.75" x 1 . 5" x 17.563"

70.49 cm x 31.1 cm x 44.61 cm

WWeeiigghhtt::

5 lbs. ( 3.3 kg)

MMoouunnttiinngg oorr ssuussppeennssiioonn::

Die-cast aluminum 1-3/8" pole-

mount cup for stand-mounting

OOppttiioonnaall ssyysstteemm uuppggrraaddeess::

TLS 115X add-on subwoofer

BBuulllleettss::

• Two-way sound

reinforcement enclosure

• Peavey exclusive Sheffield

Pro 1500+ woofer with .5"

voice coil

• 1.4" 14XT titanium diaphragm

compression driver

• Sound Guard IV tweeter

protection

• 500 Watts program/

1000 Watts peak power

handling

• Heavy duty crossover

network for driver protection

and EQ

• Lightweight trapezoidal

enclosure

• 90˚ x 40˚ coverage constant

directivity horn for better off-

axis tonality

• High quality, heavy duty

carpet covering

SSPPEECCIIFFIICCAATTIIOONNSS TTLLSS™™55XX

• Steel handles

• Steel corners

• Rugged dado and rabbet

construction for lightweight-yet-

strong joints

• T-Nut speaker mounting

• Heavy duty, full-length steel grille

• SA-1 die cast aluminum pole

mount

DDeessccrriippttiioonn

The TLS5X is a two-way speaker

system utilizing a 15" Sheffield Pro

1500+ woofer and a 14XT titanium

diaphragm dynamic compression

driver mounted on a 90˚ x 40˚

coverage constant directivity horn.

The lightweight-yet-rugged, carpet-

covered trapezoidal enclosure with

stand-mount cup is portable for live

music, speech sound reinforcement

and playback. A full-length black

powder coated steel grille provides

driver protection and a professional

appearance.

The TLS 5X speaker system is rated

at 500 Watts program power

handling, and the full crossover

network includes high voltage film

caps and Sound Guard™IV tweeter

protection for clear, punchy sound

and excellent long-term reliability.

Two 1/4" phone jack input

connectors make hook-up a breeze.

Broaden your sound reinforcement

experience by utilizing the TLS 115X

subwoofer with the TLS 5X speaker

system.

33 ++ YYEEAARR LLIIMMIITTEEDD WWAARRRRAANNTTYY

NNOOTTEE::For details, refer to the

warranty statement. Copies of

this statement may be obtained

by contacting Peavey Electronics

Corporation, P.O. Box 898,

Meridian, Mississippi 39301- 898.

20 50 100 200 500 1k 2k 5k 10k 20k

Frequency (Hz)

100

110

dB SPL (re 20 Pa)

Amplitude Response (1W 1m On-Axis)

Figure 1

20 50 100 200 500 1k 2k 5k 10k 20k

Frequency (Hz)

100

140

180

300

360

Beamwidth (Degrees)

Beamwidth

Vertical

Horizontal

Figure 2

20 50 100 200 500 1k 2k 5k 10k 20k

Frequency (Hz)

100 Q & Directivity Index

Figure 3

Features and specifications subject to change without notice.

Peavey Electronics Corporation • 711 A Street • Meridian • MS • 39301 (601) 483-5365 • FAX (601) 486-1 78 • www.peavey.com

80305051
