Peavey TLM 2X Bedienungsanleitung

FFrreeqquueennccyy rraannggee ((--1100 ddBB,, hhaallff

ssppaaccee))::

52 Hz to 21 Hz

FFrreeqquueennccyy rreessppoonnssee ((±±33 ddBB,, hhaallff

ssppaaccee))::

68 Hz to 17 Hz

SSeennssiittiivviittyy ((11WW//11MM))::

98 dB

PPoowweerr rraattiinngg ((pprrooggrraamm))::

500 Watts

PPoowweerr ccaappaacciittyy ((ppeeaa))::

1000 Watts

MMaaxxiimmuumm SSPPLL::

127 dB

TTrraannssdduucceerr ccoommpplleemmeenntt::

Sheffield®Pro 1200+™12"

premium woofer and 14XT™1.4"

titanium diaphragm dynamic

compression driver on a 90 x

40˚ coverage constant

directivity horn

DDrriivveerr pprrootteeccttiioonn::

Sound Guard™IV for the

compression driver provides

long- and medium-term

overload and overdrive

protection

NNoommiinnaall ccoovveerraaggee ppaatttteerrnn::

90˚ x 40˚

EElleeccttrroo--aaccoouussttiicc ccrroossssoovveerr

ffrreeqquueennccyy::

2.9 Hz

NNoommiinnaall iimmppeeddaannccee::

8 Ohms

IInnppuutt ccoonnnneeccttiioonnss::

Two 1/4" phone jac s in parallel

EEnncclloossuurree mmaatteerriiaallss aanndd ffiinniisshh::

Trapezoidal, blac carpet-

covered enclosure with dado

joined 1/2" MDF (Medium

Density Fiberboard), and a full-

length, blac powder-coated

steel grille

DDiimmeennssiioonnss ((HH xx WW xx DD))::

22.375" x 17.75" x 12.5625"

56.833 cm x 45.085 cm x

31.909 cm

WWeeiigghhtt::

40 lbs. (18.18 g)

MMoouunnttiinngg oorr ssuussppeennssiioonn::

Die-cast aluminum 1-3/8" pole-

mount cup for stand-mounting

FFeeaattuurreess

• Two-way sound reinforcement

monitor enclosure

• 30˚ and 45˚ dual angle

monitoring

• Peavey exclusive Sheffield Pro

1200+ woofer with 2.5" voice

coil

• 1.4" 14XT titanium diaphragm

compression driver

• Sound Guard IV tweeter

protection

• 500 Watt program/1000 Watt

pea power handling

• Heavy duty crossover networ

for driver protection and EQ

• Lightweight trapezoidal

enclosure

• 90˚ x 40˚ coverage constant

directivity horn for better off-

axis tonality

• High quality, heavy duty carpet

covering

• Steel handle

• Rugged dado and rabbet

construction for lightweight-

yet-strong joints

• T-Nut spea er mounting

• Heavy duty, full-length steel

grille

• SA-1 die-cast aluminum pole

mount

SPECIFICATIONS TLM™2X

Features and specifications subject to change without notice.

Peavey Electronics Corporation • 711 A Street • Meridian • MS • 39301 (601) 483-5365 • FAX (601) 486-1278 • www.peavey.com

80305060

20 50 100 200 500 1k 2k 5k 10k 20k

Frequency (Hz)

100

110

dB SPL (re 20 Pa)

Amplitude Response (1W 1m On-Axis)

Figure 1

SPECIFICATIONS TLM™2X

DDeessccrriippttiioonn

The TLM2X is a two-way floor

monitor utilizing a 12" Sheffield®

Pro 1200+™woofer and a 14XT™

titanium diaphragm dynamic

compression driver mounted on a

90˚ x 40˚ coverage constant

directivity horn. The lightweight, yet

rugged, carpet-covered monitor

enclosure with stand-mount cup

facilitates portable use a stage

monitor or in other sound

reinforcement applications.

The dual-angle enclosure provides a

choice of 30˚ and 45˚ monitoring

angles for full monitoring utility. A

full-length, blac powder-coated

steel grille provides driver

protection and a professional

appearance.

The TLM 2X spea er system is rated

at 500 Watts program power

handling, and the full crossover

networ includes high voltage film

capacitors and Sound Guard™IV

tweeter protection for clear, punchy

sound and excellent long-term

reliability. Two 1/4" phone jac

input connectors ma e hoo -up and

daisy-chaining to other monitors a

breeze.

33 ++ 22 YYEEAARR LLIIMMIITTEEDD WWAARRRRAANNTTYY

NNOOTTEE::For details, refer to the

warranty statement. Copies of

this statement may be obtained

by contacting Peavey Electronics

Corporation, P.O. Box 2898,

Meridian, Mississippi 39301-2898.
