FAN FORCED

HEATER

Model NF15-9BMB

OWNER’S MANUAL

PLEASE READ AND SAVE THESE INSTRUCTIONS

IMPORTANT SAFETY INSTRUCTIONS

WARNING!

When using electrical appliances, basic precautions should

always be followed to reduce the risk of fire, electric shock, and injury to persons,

including the following.

INSTRUCTIONS FOR USE AND CARE

1. Read all instructions before using heater.

2. This heater is hot when in use. To avoid burns, do not let bare skin touch hot

surface. If provided, always use handles when moving this heater. Keep

combustible materials such as furniture, pillows, bedding, papers, clothes and

curtains at least 3 feet (0.9m) from the front of the heater and keep them away

from the sides and rear.

3. Extreme caution is necessary when any heater is used by or near children or

invalids and whenever the heater is left operating and unattended.

4. Always unplug the heater when not in use.

5. Do not operate the heater with a damaged cord or plug, if the heater malfunctions,

has been dropped or damaged in any manner. Return heater to authorized service

facility for examination, electrical or mechanical adjustment, or repair.

6. Do not use the heater outdoors.

7. This heater is not intended for use in bathroom, laundry areas and similar moist

indoor locations. Never locate heater where it may fall into a bathtub or other

water container.

8. Do not run cord under carpeting. Do not cover cord with throw rugs, runners or

the like. Arrange cord away from traffic areas where it can be tripped over.

9. CAUTION :This appliance has a polarized plug (one blade is wider than the

other). To reduce the risk of shock, this plug is intended to fit only one way in

a polarized outlet. If the plug does not fit fully in the outlet, reverse the plug.

If it still does not fit, contact a qualified electrician. DO NOT attempt to

defeat this safety feature. To do so could result in an electric shock hazard.

10. This heater draws 12.5 amps during operation. To prevent overloading a circuit,

do not plug the heater into a circuit that already has other appliances working.

11. CAUTION: It is normal for the plug to feel warm to the touch; however, a

loose fit between the AC outlet (receptacle) and plug may cause overheating

and distortion of the plug. Contact a qualified electrician to replace loose or

worn outlet.

12. To disconnect the heater, first turn controls to the OFF position, then

remove plug from outlet. Never pull by the cord.

13. Do not insert or allow foreign objects to enter any ventilation or exhaust opening

as this may cause an electric shock or fire, or damage the heater.

14. To prevent a possible fire, do not block air intakes or exhaust in any manner. Do

not use on soft surface, like a bed, where openings may become blocked.

15. A heater has hot and arcing or sparking parts inside. Do not use it in the areas

where gasoline, paint, or flammable liquids are used or stored.

16. Use this heater only as described in this manual. Any other use not recommended

by the manufacturer may cause fire, electric shock, or injury to persons.

17. CAUTION: Avoid the use of an extension cord because the extension cord

may overheat and cause a risk of fire. However, if you have to use an

extension cord, the cord shall be No.14 AWG minimum size and rated not

less than 1875 watts.

18. The output of this heater may vary and its temperature may become intense

enough to burn exposed skin. Use of this heater is not recommended for persons

with reduced sensitivity to heat or an inability to react to avoid burns.

SAVE THESE IMPORTANT INSTRUCTIONS FOR

EASYREFERENCE.

ASSEMBLY

This heater is pre-assembled in factory.

ELECTRICAL RATINGS

This product is rated 12.5 amps (1500W) at 120V, 60 Hz.

FEATURES

APower Indicator Light

BPower and Setting Control

Thermo

Oscillation

stat Control

OPERATION

Place the heater on a firm, level surface free from obstructions, and at least 3 ft.

(0.9m) away from any wall or combustible material.

With the Power Switch in the OFF position, plug the heater into a grounded

120V outlet. Always operate the heater in the upright position.

To use the fan only function and no heat needed, please push the Power and Setting

Control switch（B）to FAN( ) position, the fan inside will work and Power

Indicator Light (A) will illustrate.

To turn the heater on, please turn the Power and Setting Control switch (B)

clockwise to the desired position LOW( ) or HIGH( ) , and turn

Thermostat Control (C) to your desired setting from MIN to MAX .

Symbol Function

The heater turns off

FAN

an working only

The heater operates at 900 watts

The heater operates at 1500 watts

For quicker heat up, you can turn the Power and Setting Control switch (B) to

position HIGH( ), and turn the Thermostat Control (C) to MAX

, when

the room reaches a comfortable temperature, slowly turn (C) counter-clockwise

until the Power Indicator Light (A) turns off. This is the point at which the

thermostat setting equals the room temperature and the thermostat will auto

matically turn the heater on to and off to maintain this selected temperature. Then

you can turn (B) to position LOW( ) for energy savin

To turn on the Oscillation feature (D), turn the Oscillation switch “ON”.

Note: If the fan was shut off, either because of by pressing POWER to select OFF,

or the unit was turn off automatically for high room temperature, the oscillation

will be off.

g and prevent overheat.

RESET INSTRUCTIONS

This heater is equipped with an internal High Limit Switch which causes the unit to

stop operating in the event the internal temperature exceeds normal operating

temperatures.

IF THE UNIT SHUTS DOWN

1) TURN THE UNIT OFF

2) UNPLUG UNIT AND WAIT 10 MINUTES

3) PLUG IN AND TURN ON

TROUBLESHOOTING

If your heater fails to operate, please follow these instructions:

Ensure that your circuit breaker or fuse is working properly.

Be sure the heater is plugged in and that the electrical outlet is working properly.

Check for any obstruction. If you find any obstruction, turn the heater off. Unplug

the heater and wait a few minutes for it to cool down. Carefully remove the

obstruction. Plug the heater in and turn it on again by referring to the

OPERATING INSTRUCTIONS

NOTE: IF YOU EXPERIENCE A PROBLEM WITH YOUR HEATER,

PLEASE SEE THE WARRANTY INFORMATION FOR INSTRUCTIONS.

PLEASE DO NOT ATTEMPT TO OPEN OR REPAIR THE HEATER

YOURSELF. DOING SO MAY VOID THE WARRANTY AND COULD

CAUSE DAMAGE OR PERSONAL INJURY. IF THE PROBLEM STILL

PERSISTS, PLEASE CONTACT US BY REFERRING TO THE SERVICE &

SUPPORT INFORMATION ON THE FOLLOWING PAGE.

CLEANING AND STORAGE

We recommend that the heater be cleaned at least once a month and before off-season

storage.

Turn the heater off and unplug it. Allow it to cool down.

Use a dry cloth to clean the external surfaces of the heater.

DO NOT USE WATER, WAX, POLISH ORANY CHEMICALSOLUTION.

Clean your heater using the above-mentioned steps, then pack the heater in its

original container and store it in a cool dry place.

This heater does not disassemble.

The motor is factory lubricated for life, and will require no further lubrication.

SPECIFICATIONS

Model No.: NF15-9BMB

Voltage: 120V, 60Hz

Current: Maximum 12.5 Amps

Tolerances on all specifications: Not exceeded than 105%

PRINTED IN CHINA

SERVICE & SUPPORT

(STAPLE SALES RECEIPT HERE)

NOTE: PROOF OF PURCHASE IS REQUIRED FOR ALL

WARRANTY CLAIMS

THANK YOU FOR PURCHASING THIS ESSENTIAL NEEDS

PRODUCT!

In the event of a warranty claim or if service is required for this heater, please contact us at

the following:

Tel: 866-876-4332

Email us at: [email protected]

For questions or comments, please write to:

PELONIS CUSTOMER SERVICE

1937 North Great Southwest Parkway

Grand Prairie, TX 75050, USA

For your records, staple your sales receipt to this manual and record the following:

DATE OF PURCHASE: ________________________________

_____________

PLACE OF PURCHASE: ________________________________

____________

SERIAL NUMBER: ________________________________

_________________

ONE (1) YEAR LIMITED WARRANTY

•Please read all instructions before attempting to use this product.

•Please return the Warranty Registration card within fifteen (15) days from the date

of purchasing this product.

PELONIS warrants as limited herein to the original purchaser of retail that each new

Pelonis Fan Forced Heater, shall be free of defects in material and workmanship for a

period of one (1) year from the date of original purchase. This one (1) year warranty is

limited to the heating elements, motor, and electric control circuit board.

In the event of malfunctions or failure of your Pelonis Fan Forced Heater, simply deliver or

send the heater, postage prepaid along with PROOF OF PURCHASE, within the warranty

period of one (1) year, to PELONIS. PELONIS reserves the right to inspect the claimed

defective part or parts to determine if the defect or malfunction complaint is covered by this

warranty. PELONIS shall, within sixty (60) days after receipt of the product, at its option,

repair and/or replace the defective part or parts free of charge. This warranty shall only

cover defects arising from normal usage. PELONIS assumes no responsibility whatsoever

if the Fan Forced Heater should fail during the warranty period by reason of:

•Misuse, negligence, physical damage or accidents.

•Lack of maintenance (see instructions for proper maintenance).

•Repair by any unauthorized party during the warranty period.

•Damage caused by connection to an improper input voltage (see specification

label on your heater).

PELONIS makes no further warranties or representations, express or implied except those

contained herein. No representative or dealer is authorized to assume any other liability

regarding the Fan Forced Heater. The duration of the implied warranty granted under State

law, including warranties of merchantability and fitness for particular purpose are limited in

duration should the duration of the express warranty grant it hereunder. PELONIS shall in

no event be liable for direct, indirect, special or consequential damages.

Some states do not allow limitations on how long an implied warranty lasts, and/or the

above limitations or exclusion may not apply to you. This warranty gives you specific legal

rights and you may have other rights which vary from state to state.
