Perfect power systems WM.20A01OP Bedienungsanleitung

Perfect Power System

❖Phone: (800)-786-6915

❖FAX no: (800)-246-2346

❖Technical Assistance: service@800pwrsrvc.com

Document No.: 700-MAN, Rev. A

All trademarks and registered trademarks are the property of their respective owners.

Due to continuous product improvement, this document is subject to change without prior notice

Power-Lite Wall Mountable 200-490W

Indoor Lighting Inverter

700-MAN Page 2of 50

Notice of Rights

This document contains proprietary and confidential information of the Perfect Power Systems. No

part of this manual may be reproduced, copied, translated or transmitted, in any form or by any

means, without the prior written permission of the company.

Notice of Liability

Information provided in this manual is intended to be accurate and reliable. However, manufacturer.

assumes no responsibility for its use, nor for any infringement of rights of third parties which may

result from its use. THIS DOCUMENT IS PROVIDED “AS IS” AND ANY EXPRESS OR IMPLIED

WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY

AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL MANUAFACTURER

BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL

DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES;

LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON ANY

THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE

OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS DOCUMENT, EVEN IF ADVISED OF

THE POSSIBILITY OF SUCH DAMAGE.

Trademarks

All trademarks and registered trademarks are the property of their respective owners.

Emergency Lighting Inverter Installation and Operation Manual

Document No.: 700-MAN, Rev. A

September 28, 2023

Table of Contents
700-MAN Page 3of 50

Table of Contents
TABLE OF CONTENTS 3
INTRODUCTION 5
Scope and Audience 5
Safety and Warnings 5
Warranty Registration and Warranty Certificate Request 6
Service 6
CHAPTER 1. SAFETY 7
CHAPTER 2. OVERVIEW 11
2.1 Product Description 12
2.2 Product Features 14
CHAPTER 3. HARDWARE OVERVIEW 17
3.1 Key Components 18
CHAPTER 4. INSTALLATION 20
4.1 Delivery Space Requirements 21
4.2 Site Considerations 22
CHAPTER 5. OPERATION 29
5.1 Starting the Unit 30
5.2 Turning ON the Unit 31
CHAPTER 6. MAINTENANCE 37
6.1 Maintenance 38
6.2 Preventative Maintenance 39
6.3 FRU Replacement 42
CHAPTER 7. TROUBLESHOOTING 43
CHAPTER 8. SPECIFICATIONS 46
APPENDIX A –OPTIONS 48
A.1 Auxiliary Transient Voltage Surge-Suppressor (TVSS) 49

700-MAN Page 4of 50

A.2 Auxiliary Output Circuit Breaker 10 amp (max. 3) 49

A.3 Simple Network Management Protocol 49

A.4 Communication interface, RS232 50

A.5 Floor mount brackets 50

A.6 Remote Status 50

A.7 Facility Interface (Dry Contacts) 50

Introduction

700-MAN Page 5of 50

Introduction

Congratulations on selecting one of the fine products from the leader in power-protection technology. Our wide

product offering includes Uninterruptible Power Systems (UPS), power conditioners, automatic voltage

regulators, and specialty transformers (e.g., computer-grade, medical-grade). Since 1972, the manufacturer has

shipped many of these fine products to discerning customers around the world for use on sensitive equipment

and critical applications.

The Single-Phase Lighting Inverter is a self-contained unit that provides backup power for fluorescent and

incandescent lighting sources such as overhead fixtures and exit signs. If a brownout or power outage occurs,

the inverter provides 90 minutes of lighting power to ensure a safe building evacuation. On line pulse-width

modulation (PWM) handles the switchover from utility power to battery power automatically, without

interruption or manual intervention. Convection cooling allows the inverter to operate virtually silently.

Scope and Audience

This guide is intended to be used as a reference for users responsible for installing, operating, and maintaining

this equipment.

Safety and Warnings

This guide uses the following symbols to draw your attention to certain information

Symbol

Meaning

Description

Note

Notes emphasize or supplement important points of the main text.

Tip

Tips provide helpful information, guidelines, or suggestions for

performing tasks more effectively.

Caution

Cautions indicate that failure to take a specified action could result

in damage to the hardware.

DANGER

The Danger symbol warns users of possible injury or death if

instructions are not followed.

Hazardous

voltage

Hazardous voltage inside. Only authorized personnel may service

this equipment.

Electrostatic

sensitive

Components are Electrostatic Discharge Susceptible (ESDS)

Use a grounded ESD wrist strap.

Introduction

700-MAN Page 6of 50

Warranty Registration and Warranty Certificate Request

Web: www.800pwrsrvc.com under download tab.

Service

If you require assistance, fill out a Service Report Form at www.800pwrsrvc.com, email us at

service@800pwrsrvc.com, or call our 24-hour toll free hot line (800-797-7782). Please have the unit’s SERIAL

NO. from the Start-Up label located on the top right front door for speed assistance.

Serial Number:

KVA/Power Rating:

Input Voltage:

Output Voltage:

Manufacturer Date:

Safety

700-MAN Page 7of 50

Chapter 1. Safety

This chapter contains safety precautions to observe when operating or servicing electrical

equipment. The symbols shown are used extensively throughout this manual. Always heed these

precautions because they are essential to the safe operation and servicing of this product.

Safety

700-MAN Page 8of 50

DANGER: This Equipment is intended to be permanently connected. Only factory-trained

or authorized personnel should attempt to install or repair the unit or its battery system.

Improper installation has proven to be the single most significant cause of start-up

problems. High AC and DC electrical voltages are present throughout the unit(s) and

incorrect installation, or servicing could result in electrocution, fire, explosion, or

equipment failure.

DANGER: Read this manual in its entirety before performing the installation, start-up,

operation, or maintenance of the UPS unit or battery systems. Failure to do so could

result in electrocution, fire, explosion, or equipment failure.

DANGER: All power connections must be completed by a licensed electrician who is

experienced in wiring this type of equipment. Wiring must be installed in accordance with

all applicable national and local electrical codes. Improper wiring may cause damage to

the equipment, injury or death of personnel. Verify that all high and low voltage input

power circuits are de-energized and locked out before installing cables or making any

electrical connections.

DANGER: Exercise extreme care when handling unit and batteries to avoid equipment damage or injury to

personnel. Cabinets weigh several hundred pounds.

DANGER: Test lift and balance the cabinets before moving. Maintain minimum tilt from vertical at all times.

The bottom structure will support the unit only if the forklift forks are completely underneath the unit.

DANGER: Observe all battery safety precautions during installation or service of the unit or

batteries. Even with the battery circuit breaker in the off position, the danger of

electrocution may still be present. The battery power to the unit must be locked and

tagged “off” before performing any service or work on the unit. The battery

manufacturer’s safety information and material safety data sheet are located in a pocket

attached to inside the front door of each unit. Failure to follow those instructions and the

instruction listed above and elsewhere in this manual could result in an explosion, fire,

equipment failure, or electrocution.

Safety

700-MAN Page 9of 50

DANGER: All power to the unit must be locked and tagged "off" before performing any

service or work on the unit. failure to do so could result in electrocution.

DANGER: In case of fire involving electrical equipment, only carbon dioxide fire

extinguishers, or those approved for use on electrical equipment, should be used. Use of

water on fires involving live high voltage electrical circuits could present an electrocution

hazard.

DANGER: Extreme caution is required when performing maintenance. Lethal voltages

exist within the equipment during operation. Observe all warnings and cautions in this

manual. Failure to comply may result in serious injury or death. Obtain qualified service

for this equipment as instructed.

DANGER: Be constantly aware that the unit system contains high DC as well as AC

voltages. With input power off and the battery disconnected, high voltage at the filter

capacitors and power circuits should discharge within 30 seconds. However, power circuit

failures can occur, so you should always assume that high voltage might still exist after

shutdown. Verify that power is off using AC and DC voltmeters before making contact.

DANGER: Some components within the cabinets are not connected to chassis ground. Any

contact between floating circuits and the chassis is a lethal shock hazard.

DANGER: Internal battery strapping must be verified by the customer prior to moving this

unit.

This unit contains non-spillable batteries. Keep the unit upright. Do not stack. Do not tip.

Always follow the battery manufacturer’s safety information, located in a pocket attached

to the inside of the door of your unit, to prevent an accident that could result in injury or

death.

Safety

700-MAN Page 10 of 50

DANGER: Lead-acid batteries contain hazardous materials. Batteries must be handled,

transported, and recycled or discarded in accordance with federal, state, and local

regulations. Because lead is a toxic substance, lead-acid batteries should be recycled

rather than discarded.

Do not dispose of batteries in a fire, the batteries may explode.

Do not open or mutilate the batteries. Released electrolytes are harmful to the skin and

eyes and may be toxic.

A battery can have a high short circuit current and present a risk of electrical shock. The

following precautions should be observed when working on batteries:

1. Remove watches, rings, or other metal objects.

2. Use tools with insulated handles.

3. Wear rubber gloves and boots.

4. Do not lay tools or metal parts on top of batteries.

5. Disconnect charging source prior to connecting or disconnecting battery terminals.

6. Determine whether battery is inadvertently grounded. if so, remove the source of

the ground. Contact with any part of a grounded battery can result in electrical

shock. The likelihood of such shock will be reduced if such grounds are removed

during installation and maintenance.

7. Lead-acid batteries can present a risk of fire because they generate hydrogen gas.

The following procedures should be followed:

Do not smoke when near batteries.

Do not cause flame or spark in battery area.

8. Discharge static electricity from your body before touching batteries by first

touching a grounded surface.
