PetSafe®

Big Dog

Spray Bark Control

Operating and Training Guide

Please read this entire guide before beginning.

PBC00-11005

2 Customer Care Center 1-800-732-2677

www.petsafe.net 3

Important Safety Information

Explanation of Attention Words and Symbols used in this guide

This is the safety alert symbol. It is used to alert you to potential personal injury hazards.

Obey all safety messages that follow this symbol to avoid possible injury or death.

WARNING WARNING indicates a hazardous situation which, if not avoided, could

result in death or serious injury.

CAUTION CAUTION, used with the safety alert symbol, indicates a hazardous situation

which, if not avoided, could result in minor or moderate injury.

CAUTION CAUTION, used without the safety alert symbol, indicates a hazardous

situation which, if not avoided, could result in harm to your pet.

WARNING Not for use with aggressive dogs. Do not use this Product if your dog is

aggressive, or if your dog is prone to aggressive behavior. Aggressive dogs

can cause severe injury and even death to their owner and others. If you are unsure whether this

product is appropriate for your dog, please consult your veterinarian or certified trainer.

AEROSOLS:

• Keep out of reach of children.

• Contents of the refill can and the spray collar are under pressure.

• Use only in a well ventilated area. Use only as directed.

• May explode if heated, do not heat. Do not expose to temperatures over 113°F or 45°C.

• Do not burn. Do not dispose of in fire, even when empty.

• Keep out of direct sunlight.

• Do not leave the aerosol can in a vehicle where temperature could exceed 113°F or 45°C.

• Store in a cool location.

• Keep away from sparks or flame. Do not smoke while refilling.

• Do not puncture. Contact of liquid propellant with skin may cause frostbite.

• Do not ingest. In case of accident, seek medical care. If swallowed, call a poison control

center immediately.

CAUTION Do not expose the device to freezing temperatures -32°F or 0°C or to

conditions warmer than 113°F or 45°C. Do not leave the unit in direct sunlight.

Never leave the unit in a car where the device can heat up to high temperatures 113°F or 45°C.

The PetSafe® Big Dog Spray Bark Control is not a toy. Keep it away from the reach of children.

Use it only for its bark stopping purpose.

2 Customer Care Center 1-800-732-2677

www.petsafe.net 3

CAUTION Risk of skin damage. Please read and follow the instructions in this manual.

Proper fit of the collar is important. A collar worn for too long or made too tight on

the pet’s neck may cause skin damage. Ranging from redness to pressure ulcers; this condition

is commonly known as bed sores.

• Avoid leaving the collar on the dog for more than 12 hours per day.

• When possible reposition the collar on the pet’s neck every 1 to 2 hours.

• Check the fit to prevent excessive pressure; follow the instructions in this manual.

• Never connect a lead to the electronic collar; it will cause excessive pressure on the probe.

• When using a separate collar for a lead, don’t put pressure on the electronic collar.

• Wash the dog’s neck area and the probe of the collar weekly with a damp cloth.

• Examine the probe area daily for signs of a rash or a sore.

• If a rash or sore is found, discontinue use of the collar until the skin has healed.

• If the condition persists beyond 48 hours, see your veterinarian.

• For additional information on bed sores and pressure necrosis, please visit our website.

These steps will help keep your pet safe and comfortable. Some pets are sensitive to contact

pressure. You may find after some time that your pet is very tolerant of the collar. If so, you may

relax some of these precautions. It is important to continue daily checks of the probe area. If

redness or sores are found, discontinue use until the skin has fully healed.

The PetSafe® Big Dog Spray Bark Control must be used only on healthy dogs. We recommend

that you take your dog to a veterinarian before using the collar if he is not in good health.

4 Customer Care Center 1-800-732-2677

www.petsafe.net 5

“In a Tuskegee University study of adult shelter dogs wearing the PetSafe® Spray Bark Control

Collar for six 30-minute sessions over two weeks, we detected no long-term adverse effects, and all

dogs dramatically reduced their barking by the second day.”

Dr. Janet Steiss and Dr. Caroline B. Schaffer

Tuskegee University

Thank you for choosing the PetSafe brand. You and your pet deserve a

companionship that includes memorable moments and a shared understanding

together. Our products and training tools promote a lifestyle of protection,

teaching, and love—essentials that inﬂuence memories for a lifetime. If you have

any questions about our products or training your pet, please visit our website at

www.petsafe.net or contact our Customer Care Center at 1-800-732-2677.

To get the most protection out of your warranty, please register your product

within 30 days at www.petsafe.net. By registering and keeping your receipt,

you will enjoy the product’s full warranty and should you ever need to call the

Customer Care Center, we will be able to help you faster. Most importantly,

PetSafe® will never give or sell your valuable information to anyone. Complete

warranty information is available online at www.petsafe.net.

Table of Contents

Components .............................................................................................. 5

Features ..................................................................................................... 5

How the PetSafe® Big Dog Spray Bark Control Works .................................. 5

Key Deﬁnitions .......................................................................................... 6

Fit the Bark Control Collar ......................................................................... 6

Ensure a Proper Spray Pattern .................................................................... 7

To Insert and Remove the Battery ............................................................... 8

Modes of Operation ................................................................................... 8

To Fill and Reﬁll the Spray ......................................................................... 9

What to Expect During Use of the Bark Control Collar ............................... 9

Tips ..........................................................................................................10

Regular Maintenance ................................................................................10

Accessories ...............................................................................................10

Frequently Asked Questions ..................................................................11

Troubleshooting ......................................................................................11

Customer Care International .....................................................................12

FCC .........................................................................................................13

4 Customer Care Center 1-800-732-2677

www.petsafe.net 5

Components

PetSafe® Big Dog

Spray Bark Control

Citronella Spray

PAC19-12069

Operating Guide

Please read this entire guide before beginning.

PBC00-11005

Battery

(PetSafe® RFA-18)

Features

• Patented Perfect Bark™ detection ensures your dog’s bark is the only sound

that will cause the correction

• Adjustable collar for neck sizes up to 28" with the QuickFit™ Buckle

• For dogs 40+ pounds

• Citronella Spray is safe and effective

• Waterproof

• Good/Low battery indicator

• 40 sprays per reﬁll

• Low spray indicator

• On/Off button

How the PetSafe® Big Dog Spray Bark

Control Works

The PetSafe® Big Dog Spray Bark Control senses your dog’s barking. A unique, patented sensor

uses both vibration of the vocal chords and sound sensors (dual-detection) to distinguish each bark

from other external noises. As he barks, he receives a safe but annoying burst of spray. He’ll quickly

learn the association with this stimulation and stop the unwanted behavior. The PetSafe® Big Dog

Spray Bark Control is proven effective in deterring barking when it is worn.

6 Customer Care Center 1-800-732-2677

www.petsafe.net 7

Key Definitions

Spray Nozzle: Where the spray

ejects when your dog’s bark

is detected.

Sound Activated Sensor: Detects

the sound of your dog’s bark.

Refill Port: Where the spray

is reﬁlled.

Yellow LED: Low spray indicator.

Two Color LED: Shows good or

low battery.

On/Off Button: Turns the collar on

and off, and resets the spray counter.

Sensor Probe: Detects the

vibrations of your dog’s bark.

Sound

Activated Sensor Refill Port

Spray Nozzle

On/Off Button

Two Color LED

Yellow LED

Sensor Probe

Note: The Sensor Probe is not adjustable.

Fit the Bark Control Collar

Important: The proper ﬁt and placement of your Bark Control Collar is important for

effective operation.

To assure a proper ﬁt, please follow these steps:

1. Make sure that the Bark Control Collar is turned off.

2. Start with your dog standing comfortably.

3. Place the Bark Control Collar on your dog’s neck close to the ears.

Center the Sensor Probe underneath your dog’s neck, touching the

skin. Make sure the PetSafe® logo in the front of the unit is upright.

Note: It is sometimes necessary to trim the hair around the Sensor Probe to

make sure that contact is consistent.

YES

CAUTION

Do not shave the pet’s neck as this

may increase the risk of skin irritation.

4. The PetSafe® QuickFit™ Collar is designed so you can

quickly attach and remove the Bark Control Collar from

your dog while maintaining the desired ﬁt (A).

a. With the Snap Buckle fastened, thread the

collar through the Metal Buckle (B).

b. Slide the excess collar through the “C” Loop

on top of the Snap Buckle. This will hold the

collar in place.

A B

6 Customer Care Center 1-800-732-2677

www.petsafe.net 7

c. Once the collar ﬁt is determined,

simply use the Snap Buckle to

remove and replace the collar (C).

5. The Bark Control Collar should ﬁt

snugly, yet loose enough to allow one

ﬁnger to ﬁt under the strap. Allow

your dog to wear the collar for several

minutes, then recheck the ﬁt. Check

the ﬁt again as your dog becomes

more comfortable with the Bark

Control Collar (D).

6. Trim the collar as follows:

a. Mark the desired length of the collar with a pen. Allow for growth if your dog is young or

grows a thick winter coat.

b. Remove the Bark Control Collar from your dog and cut off excess.

CAUTION

The Bark Control Collar should not be worn for more than 12 hours

out of every 24-hour period. Leaving the collar on too long could lead

to Skin Irritation. Please refer to page 3 for additional information.

Ensure a Proper Spray Pattern

For the PetSafe® Big Dog Spray Bark Control to perform

properly, the nozzle must be positioned correctly and there

must be a clear path from the Spray Nozzle to your dog’s

snout. Follow these steps:

1. Make sure the PetSafe® logo on the front of the unit is

upright and the Spray Nozzle is angled out and pointing up

towards the dog’s snout.

2. For long-haired dogs, it may be necessary to trim the neck

hairs along the path of the spray. It is important that the

spray reaches the dog’s snout to be effective.

CAUTION

Do not shave the pet’s neck as this

may increase the risk of skin irritation.

3. For optimal performance the spray bark collar should be

reﬁlled before each use.

8 Customer Care Center 1-800-732-2677

www.petsafe.net 9

To Insert and Remove the Battery

Note: Do not install the battery while the Bark Control Collar is on your dog.

A replacement PetSafe® battery (RFA-18) can be found at many retailers. Contact the Customer

Care Center or visit our web site at www.petsafe.net to locate a retailer near you.

Battery Life

Average battery life is 2 to 4 months, depending on how often your dog barks. However, due to

greater use during your dog’s training, your ﬁrst battery may not last as long as replacement batteries.

Modes of Operation

• To activate the unit, press the On/Off Button until the Green LED Light

comes on and release. The Green LED Light will ﬂash once every 5 seconds.

• To turn the unit off, press the On/Off Button and hold until the Red LED

Light ﬂashes.

Note: The Yellow LED Light will ﬂash brieﬂy before the Red LED Light appears.

This indicates the reset sequence.

Function and Response Table

Function LED Light Response

Unit is on Green LED Light ﬂashes once every 5 seconds

Low battery condition Red LED Light ﬂashes 3 times every 5 seconds

Low spray warning Yellow LED Light appears

8 Customer Care Center 1-800-732-2677

www.petsafe.net 9

To Fill and Refill the Spray

• Remove the collar from your dog.

• Turn the unit off.

• Ensure the reﬁll port is clean.

Note: If any dirt or debris enters the reﬁll port when reﬁlling, it could

cause the unit to become clogged and malfunction. Please read the

“Regular Maintenance” section for proper care.

• Hold the spray can upright and ﬁrmly press the nozzle down into

the Reﬁll Port. Hold for 15 seconds and remove.

Note: If spray leaks out, you may need to press harder to complete

the seal.

• Turn the unit on.

• For optimal performance the spray bark collar should be reﬁlled

before each use.

15 seconds

Important: To reset the Spray Counter, press the On/Off Button until the Yellow LED

Light comes on, and release the button. The Green LED Light will resume to 1 ﬂash

every 5 seconds.

Note: It is important that the On/Off Button be released immediately after the Yellow LED Light comes on

or the unit will be turned off.

CAUTION

Do not puncture or incinerate the spray collar or the rell canister. Do

not expose to extreme heat or store at temperatures above 113° F.

Reﬁll canisters are available. Choose from citronella or unscented spray. Contact the Customer

Care Center or visit our web site at www.petsafe.net to locate a retailer near you.

What to Expect During Use of the Bark

Control Collar

Important: Do not leave your dog alone the ﬁrst few times he wears the Bark Control Collar.

Place the Bark Control Collar properly on your dog and wait nearby until he barks. Most dogs will

understand very quickly that the Bark Control Collar is disrupting their urge to bark and will relax

and stop barking. Because the burst of spray from the Bark Control Collar may be surprising or

startling at ﬁrst, some dogs may bark more at the initial correction.

On rare occasions, a dog may get into a bark-spray-bark-spray cycle. If this happens, reassure your

dog with calm, soothing tones. As your dog relaxes, he will understand that if he becomes quiet, he

will not receive any more spray bursts. The small minority of dogs that have this reaction should

only have it the ﬁrst time they wear the Bark Control Collar.

You should notice a reduction in your dog’s barking within the ﬁrst couple of days that he wears

the Bark Control Collar. At this point, it is important to remember the learning process is still not

complete. Dogs will “test” this new learning experience and will increase their attempts to bark.

This usually occurs during the second week a dog wears the Bark Control Collar. If this does occur,

remain consistent and do not alter your use of the Bark Control Collar. You must place the Bark

Control Collar on your dog in every situation when you expect him to be quiet. If your dog is not

wearing the Bark Control Collar, he may resume barking and his learning would suffer a setback.

10 Customer Care Center 1-800-732-2677

www.petsafe.net 11

Tips

• Before playing with your dog, turn the unit off and remove the Bark Control Collar. The activity

may cause your dog to bark, which could lead to him associating the play with the burst of spray.

• The collar must be ﬁlled to maximum capacity before placing it around your dog’s neck.

• Never ﬁll the device while your dog is wearing it because it may damage the Reﬁll Port.

• To ensure that your dog does not make the connection between you and the spray collar, don’t

let him see you prepare the device for the ﬁrst try, or for subsequent use. Keep your dog away

while you prepare the device as well as when you ﬁll it or change the battery.

• It is important that your dog’s hair doesn’t block the Spray Nozzle. Try tying a bandanna

(handkerchief) around your dog’s neck, then place the spray collar over it. If necessary, you may

also consider trimming a little of the long hair around the dog’s neck for better spray effect.

• Remove all other collars with metallic parts or tags. These could create noise that may needlessly

activate the spraying device.

• Avoid letting your dog wear the device with an empty reservoir. Make sure it is always full.

• Turn OFF the device while not in use.

• The PetSafe® Big Dog Spray Bark Control should only be used with pets that are over 6

months of age.

• If your pet is injured or its mobility is otherwise impaired, contact your veterinarian or

professional trainer before use.

• Do not leave your device unattended where your dog could accidentally damage it through chewing.

• Never ﬁll the Spray Bark Control Collar with any substance other than the one provided

by the manufacturer. Using another substance, as well as opening the device, will void the

manufacturer’s warranty.

• Do not attempt to repair the device yourself. This will invalidate the warranty and make repairs

more difﬁcult.

Regular Maintenance

• For comfort, safety, and effectiveness of this product, please ensure that you check the ﬁt of your

pet’s collar frequently.

• The Bark Control Collar should not be worn for more than 12 hours out of every 24-hour

period to prevent irritation. If any skin irritation is observed, discontinue the use of the collar for

a few days. If the condition persists beyond 48 hours, see your veterinarian.

• The spray from the Bark Control Collar may stick to the hair under your dog’s snout. Clean your

dog’s hair weekly with a washcloth and a mild hand soap. Rinse and dry your dog’s neck thoroughly.

• If spray, dirt or debris accumulates on the Bark Control Collar (including the nozzle and reﬁll port),

wipe the Bark Control Collar clean with a damp cloth and dry thoroughly. It is recommended that the

unit be cleaned monthly or as needed to prevent clogging. The need for cleaning will depend on usage.

Accessories

To purchase additional accessories for your PetSafe® Big Dog Spray Bark Control, contact the

Customer Care Center or visit our website at www.petsafe.net to locate a retailer near you.

Inhaltsverzeichnis

Andere Petsafe Tierpflegeprodukte Handbücher

Petsafe

Petsafe DrinkWell Bedienungsanleitung

Petsafe

Petsafe cinch-it Medium Bedienungsanleitung

Petsafe

Petsafe HPA11-10987 Bedienungsanleitung

Petsafe

Petsafe Drinkwell DOGC-AU-17 Bedienungsanleitung

Petsafe

Petsafe Drinkwell PWW17-16560 Bedienungsanleitung

Petsafe

Petsafe Deluxe Ultralight PUL-275 Bedienungsanleitung

Petsafe

Petsafe Do-It-Yourself Dog Kennel Bedienungsanleitung

Petsafe

Petsafe Electronic SmartDoor Bedienungsanleitung

Petsafe

Petsafe PDBDT-300 Bedienungsanleitung

Petsafe

Petsafe VIBRATION PBC00-12789 Einrichtungshandbuch

Petsafe

Petsafe HBC11-14014 Bedienungsanleitung

Petsafe

Petsafe PTY00-14665 Einrichtungshandbuch

Petsafe

Petsafe fountain Bedienungsanleitung

Petsafe

Petsafe ZIG00-15922 Bedienungsanleitung

Petsafe

Petsafe pawz away PWF00-13665 Einrichtungshandbuch

Petsafe

Petsafe Deluxe ST-350-LD Einrichtungshandbuch

Petsafe

Petsafe pcf-275-19 Bedienungsanleitung

Petsafe

Petsafe Pawz Away PWF00-14040 Einrichtungshandbuch

Petsafe

Petsafe YardMax Cordless In-Ground Fence Bedienungsanleitung

Petsafe

Petsafe PPA00-10958 Bedienungsanleitung

Petsafe

Petsafe PDT00-14016 Einrichtungshandbuch

Petsafe

Petsafe PDT00-16030 Bedienungsanleitung

Petsafe

Petsafe PDT20-12471 Bedienungsanleitung

Petsafe

Petsafe PDT00-13410 Einrichtungshandbuch

Beliebte Tierpflegeprodukte Handbücher anderer Marken

Schwinn

Schwinn Rascal Bedienungsanleitung

K&H

K&H Small Animal Bedienungsanleitung

SHOR-LINE

SHOR-LINE 006.3230.00 Bedienungsanleitung

Datamars

Datamars OMNI MAX Bedienungsanleitung

Trixie

Trixie 24444 Bedienungsanleitung

Roverpet

Roverpet 30DDPP Bedienungsanleitung

SportDOG

SportDOG SD-105S-C Bedienungsanleitung

Staywell

Staywell 400 Series Magnetic Bedienungsanleitung

Dogtek

Dogtek Sonic Birdhouse Bedienungsanleitung

Togfit

Togfit Deluxe Trigger Lock Door Gate Bedienungsanleitung

Girafus

Girafus 227PA Bedienungsanleitung

ubbink

ubbink KoiFeeder Solar Bedienungsanleitung

ULTRACOM

ULTRACOM KOIRA-GPS Bedienungsanleitung

CADOCA

CADOCA Deuba 106911 Bedienungsanleitung

Dogtra

Dogtra RR Deluxe Bedienungsanleitung

Carson

Carson CONVERTIBLE PET YARD 2200 Bedienungsanleitung

Creative Cedar Designs

Creative Cedar Designs K-9 Kabin Bedienungsanleitung

PlexiDor

PlexiDor Electronic Pet Door Bedienungsanleitung
