PEUGEOT 208 Bedienungsanleitung
Handbook
4
Familiarisation
Stop & Start
This system puts the engine temporarily into
standby during stops in the traffic (red lights, traffic
jams, etc...). The engine restarts automatically as
soon as you want to move off. Perfectly suited to
urban use, the Stop & Start system reduces fuel
consumption, exhaust emissions and the noise
level when stationary.
95
Electronic stability programme
This system allows you to maintain the
directional stability of the vehicle, within the
laws of physics.
123
Exterior
Cornering lighting
At low speed this system provides additional
lighting in corners, at junctions, when parking...,
making use of the corresponding front foglamp.
114
.
5
Familiarisation
Temporary puncture repair kit
This kit is a complete system consisting of a
compressor and a sealant cartridge, to allow
the temporary repair of a tyre.
143
Panoramic sunroof
Equipped with configurable light guides, this
large sunroof provides incomparable visibility
and lighting in the passenger compartment.
56
Rear parking sensors
This system provides a warning when
manoeuvring backwards by detecting obstacles
located behind the vehicle.
104
Exterior
6
Familiarisation
Open
A. Unfolding / Folding the key.
B. Unlocking the vehicle.
Remote control key Bonnet
186
1. Opening the fuel filler flap.
2. Opening the fuel filler cap.
3. Hooking the fuel filler cap.
Tank capacity: approximately 50 litres.
A. Interior release lever.
B. Exterior safety catch
C. Bonnet stay.
Other functions...
C. Normal locking of the vehicle
Vehicle location.
44
Fuel tank
183
.
7
Familiarisation
Interior
Electronic gearbox
This gearbox provides driving that
combines a completely automatic mode and
a manual mode.
5-speed
Interior mood lighting
This subdued passenger compartment lighting
improves visibility inside the vehicle in low
lighting conditions. It comprises several lamps,
located below the instrument panel, in the
footwells, in the courtesy lamp and on each
side of the panoramic sunroof.
Dual zone digital air conditioning
After setting the desired level of comfort, the
system then automatically controls this level
according to the ambient conditions.
Audio and communication
systems
These systems benefit from the latest
technology: MP3 compatible audio systems,
USB player, Bluetooth hands-free system,
satellite navigation system with colour screen,
auxiliary inputs, Hi-Fi audio system, ...
85
120
70
271
211
Bluetooth audio system
297
Audio system
Touch screen
6-speed
88
8
Familiarisation
10. Side adjustable air vents.
11. Front side window demisting/defrosting
vent.
12. Instrument panel.
13. Windscreen demisting/defrosting vent.
14. Sunshine sensor.
15. Glove box / Passenger's airbag
deactivation.
16. Passenger's airbag.
17. Multifunction screen / Audio system.
18. Central adjustable air vents.
Instruments and controls
1. Cruise control / speed limiter controls.
2. Steering mounted controls for the touch
screen.
3. Lighting and direction indicator stalk.
4. Wiper / screenwash / trip computer stalk.
5. Bonnet release lever.
6. Steering wheel adjustment control.
7. Driver's airbag.
Horn.
8. Headlamp height adjustment.
9. Switch panel.
19. Central locking and hazard warning
buttons.
20. Heating / air conditioning controls.
21. 12 V accessory socket.
USB port / auxiliary socket.
Additional USB port.
22. Open storage.
Cup holder.
23. Gear lever.
24. Central armrest with storage.
25. Parking brake.
.
9
Familiarisation
10
Familiarisation
Sitting comfortably
Front seats
57
Manual adjustments
1. Head restraint height adjustment.
2. Backrest angle adjustment.
3. Seat cushion height adjustment.
4. Seat forwards-backwards adjustment.
.
11
Familiarisation
Sitting comfortably
Head restraint adjustment
58
1. Release the adjustment mechanism.
2. Adjust for height and reach.
3. Lock the adjustment mechanism.
Steering wheel adjustment
65
For reasons of safety, these operations
must only be carried out with the
vehicle stationary.
Heated seats control
0: off.
1: low.
2: medium.
3: high.
To raise the head restraint, pull it upwards.
To lower it, press the lug Aand down on the
head restraint at the same time.
59
12
Familiarisation
Sitting comfortably
Door mirrors
Adjustment
A. Selection of the mirror.
B. Adjusting the position of the mirror glass.
C. De-selection of the mirror.
63
Other functions...
Folding / Unfolding.
Rear view mirror
Manual day/night type
1. Selecting the "day" position of the rear view
mirror.
2. Rear view mirror adjustment.
Automatic day/night type
64
1. Automatic detection of day/night mode.
2. Rear view mirror adjustment. A. Fastening.
B. Height adjustment (5-door).
Front seat belts
126
