PEUGEOT 307 Bedienungsanleitung

29-09-2003

YOUR 307 AT A GLANCE

Pages

Seats 92 - 101

Steering wheel controls 110 - 116

Instrument dials 28 - 29

Heating, air conditioning 84 - 91

Mirrors 118 - 119

Pages

hecks 143 - 151

Access 106 - 109

hanging a bulb 158 - 160

hanging a wheel 152 - 157

Fuel filler flap 109

Each model may only be fitted with some of the equipment shown, according to its specification and the technical

requirements in the country of first registration of the vehicle.

Estate: model available according to country.

YOUR 307 AT A GLANCE

29-09-2003

YOUR 307 AT A GLANCE

1 - Speaker (tweeter).

2 - Windscreen demisting

vents.

3 - Alarm button.

4 - Multi-function display.

5 - entral locking button.

6 - Hazard warning lights

switch.

7 - Electronic stability control

(ESP/ASR) button.

8 - entral adjustable

heating/ventilation vents

and air flow regulation.

9 - Lights and direction

indicators stalk.

10 - Instrument dials.

11 - Windscreen wash/wipe

stalk.

Trip computer stalk.

12 - Driver's air bag.

Horn.

13 - Radio remote control stalk.

14 - Headlamp height

adjustment.

15 - Electric mirror controls.

Window controls.

Rear window disarming

control.

16 - Steering lock and ignition.

17 - ruise control/speed

limiter** switch.

18 - Steering wheel adjustment

control.

19 - Gear lever.

20 - 12 V accessories socket.

21 - an holder.

22 - oin storage.

Passenger air bag

disarming switch*.

23 - Waste container.

24 - Handbrake.

25 - Rear footwell heating vent.

26 - Side air bags.

27 - Front ashtray.

28 - Heating/air conditioning

controls.

29 - D changer.

30 - RB3, RD3 audio equipment

or RT3 audio/telephone.

31 - Passenger air bag.

32 - Glove box.

33 - Fuse box.

34 - Bonnet opening control.

35 - Side adjustable heating/

ventilation vent and air flow

regulation.

36 - Side window demisting

vent.

* According to destination.

** During the year, according to

engine.

29-09-2003

YOUR 307 AT A GLANCE

29-09-2003

THE KEYS

The keys allow you to switch on

the ignition and to independently

operate the locks on the driver's

door, the fuel filler flap and the

glove box, as well as operate the

passenger air bag disarming

switch.

Central locking

From the driver's door, the keys

allow you to lock, deadlock or

unlock the doors and the boot

and to fold back the exterior mir-

rors.

If one of the doors or the boot is

open, it is impossible to operate

the central locking; a bleep indi-

cates this when locking by

remote control.

The remote control performs

the same functions at a dis-

tance.

The remote control key

Locking

Press button Ato lock the vehicle.

This is confirmed by fixed lighting

of the direction indicators for

approximately two seconds.

Note: in addition to deadlocking,

a long press on button Aauto-

matically closes the windows

and the sunroof.

Vehicles fitted with

deadlocking

Deadlocking renders the

internal and external

door locking controls

inoperative.

Press button Ato deadlock the

vehicle.

This is confirmed by fixed lighting

of the direction indicators for

approximately two seconds.

Note: in addition to deadlocking,

a long press on button Aauto-

matically closes the windows

and the sunroof.

Asecond press on button Ain

the five seconds following dead-

locking, changes deadlocking to

normal locking.

This is confirmed by fixed lighting

of the direction indicators for

approximately two seconds.

Unlocking

Press button Bto unlock the vehi-

cle.

This is confirmed by

rapid flashing of the

direction indicators.

Note: If the vehicle is

locked and unlocking

is then activated inadvertently, the

vehicle will re-lock automatically

unless a door is opened within 30

seconds of unlocking.

STARTING

STOP position:

The ignition is off.

1st notch, Accessories position:

The ignition is off but the acces-

sories can be used.

2nd notch, Running position:

The ignition is on.

Starting position:

Operates the starter.

102

WINDSCREEN WIPERS

Front

2Rapid wipe

(heavy rain).

1Normal wipe

(moderate rain).

AUTO Automatic wipe.

0Off.

Single wipe.

Windscreen wash-wipe: pull the

stalk towards you.

Automatic wipe

In the AUTO position,

the wiper operates auto-

matically and adjusts

its speed to the inten-

sity of the rainfall.

Rear

Off Intermittent Windscreen

wipe wash

YOUR 307 AT A GLANCE

29-09-2003

STEERING WHEEL

STALKS

LIGHTS

Front and rear lights (ring A)

Lights off.

Side lights.

Dipped/Main

beam headlamps.

Automatic

switching on

of lights.

Automatic switching on of lights

To activate or deactivate the

function, place the key in the

accessories position, with the

lights stalk in position 0and

press the end of the stalk for

more than two seconds.

Vehicles fitted with a rear fog

lamp (ring B)

Rear fog lamp (rotation

of the ring forwards).

Vehicles fitted with front fog

lamps and a rear fog lamp

(ring C)

Front fog lamps (first

rotation of the ring for-

wards)

Front fog lamps and

rear fog lamp

(second rotation of

the ring forwards)

To switch off: rotate the

push ring rearwards.

110

112

YOUR 307 AT A GLANCE

29-09-2003

FRONT SEATS

1- Forwards/backwards

adjustment.

2- Access to rear seats

(3 door).

3- Seat back angle adjustment.

4- Driver or passenger seat

height adjustment.

5- Front removable armrest

(5 door).

6- Head restraint height and

angle adjustment.

To raise or lower the head

restraint, pull it forwards,

sliding it at the same time.

Never drive with the

head restraints removed.

7- Storage drawer.

29-09-2003

YOUR 307 AT A GLANCE

REAR SEATS

To fold down the rear left seat (2/3 part) or right seat (1/3 part):

always start with the cushion, never with the seat back (there is a risk of damage):

– Move the seat(s) forward if necessary,

– Tilt the seat cushion 1against the front seat(s),

estate: tilt using the handle.

– heck that the seat belt is in the correct position on the side of the seat back,

– Pull control 2forwards to unlock the seat back 3,

– Place the head restraints in the low position,

– Tilt the seat back 3forwards.

Note: the seat cushion 1can be removed to increase the volume of the load space.

When refitting:

– Fold up the seat back and lock it (the red marker of control 2should no longer be visible at this point),

– Fold back the seat cushion.

Take care not to trap the seat belts.

AIR BAGS

The air bags have been designed

to maximise the safety of the

occupants in the event of serious

collisions. They work in conjunc-

tion with the force limiting seat

belts.

Front air bags

These are folded in the centre of

the steering wheel for the driver

and in the fascia for the front pas-

senger. They are deployed simul-

taneously, except in cases where

the passenger air bag is disarmed.

Precautions regarding

the passenger air bag

☞disarm the air bag if you

install a rear-facing child seat,

☞arm the air bag for an adult

passenger.

Disarming the passenger

air bag*

☞With the ignition off, insert

the key into slot 1and turn the

passenger air bag switch to

the "OFF" position.

As soon as you remove the child

seat, turn the air bag switch to the

"ON" position, to activate the air

bag again.

Disarming check

With the ignition switched

on (2nd notch of the igni-

tion), illumination of this

warning light, accompa-

nied by an audible signal and the

message "Passenger air bag

deactivated" on the multi-func-

tion display, indicates that the

passenger air bag is disarmed

(switch in the "OFF" position).

The warning light remains on

throughout the disarming process.

Side air bags*

and curtain air bags*

The side air bags are incorporat-

ed into the seat backs of the front

seats, on the door side.

The curtain air bags are incorporat-

ed into the door pillars and the top

of the passenger compartment.

They are deployed unilaterally, on

whichever side the collision

occurs.

*According

to country.

YOUR 307 AT A GLANCE

29-09-2003

140 141

YOUR 307 AT A GLANCE

29-09-2003

ELECTRIC WINDOWS

1 - Driver's electric window.

2 - Passenger's electric window.

3 - Rear right electric window.

4 - Rear left electric window.

5 - Disarming the rear window switches.

Safety auto-reverse: When the window is rising and meets

an obstacle, it stops and lowers again.

ELECTRIC MIRRORS

STEERING WHEEL

HEIGHT AND DEPTH

ADJUSTMENT

☞When stationary, pull handle A

to unlock the steering wheel.

☞Adjust the height and depth of

the steering wheel.

☞Lock it by pushing handle Ain

fully.

Manual operation:

☞Press or pull the switch lightly.

The window stops as soon as

the switch is released.

Automatic operation:

☞Press or pull the switch firmly.

One touch completely opens

or closes the window.

117

☞Move switch 6to the right or

left to select the correspond-

ing mirror.

☞Then move button 7in all four

directions to adjust.

☞Move switch 6back to the

centre position.

When the vehicle is parked, the

mirrors can be folded back electri-

cally by pulling switch 6

rearwards or automatically

when locking the vehicle.

118 120

YOUR 307 AT A GLANCE

29-09-2003

REAR PARKING

ASSISTANCE

This system, installed in the rear

bumper, detects any obstacle

(person, vehicle, tree, barrier...)

situated behind the vehicle.

Activation

With the engine running, the sys-

tem is activated when reverse

gear is engaged. A bleep indi-

cates that it is active.

The proximity information is given

by an audible signal, consisting of

bleeps which become faster as

the vehicle approaches the

obstacle.

When the distance between the rear

of the vehicle and the obstacle is

less than thirty centimetres, the

audible signal becomes continuous.

In neutral, the system

becomes inactive again.

CRUISE CONTROL

The cruise control makes it possi-

ble to maintain, at a constant rate,

the vehicle speed programmed by

the driver, irrespective of the pro-

file of the road and without any

action on the accelerator or brake

pedal.

To be stored, the vehicle speed

must be in excess of 25 mph

(40 km/h) (manual gearbox) or

37 mph (60 km/h) (automatic gear-

box), with at least 4th gear

engaged (2nd for the automatic

gearbox).

Activation

☞Place knob 1in the ON position.

You may store a speed.

☞Place knob 1in the OFF posi-

tion to deactivate the system.

139

Storing a speed

When you reach the required

speed, press button 2or 3. The

speed is stored and will be main-

tained automatically.

Note: it is possible to accelerate

temporarily without deactivating

the cruise control.

Deactivating the stored speed

If you wish to deactivate the

stored speed:

☞press button 4or the brake or

clutch pedal.

Recalling the stored speed

Following deactivation, press but-

ton 4. Your vehicle will return to

the last speed stored.

Cancelling the stored speed

☞Place knob 1in the OFF posi-

tion or switch off the ignition.

Do not use the

cruise control on

slippery roads or

in heavy traffic.

135

Andere Handbücher für 307

Inhaltsverzeichnis

Andere PEUGEOT Automobil Handbücher

PEUGEOT

PEUGEOT 308 CC Bedienungsanleitung

PEUGEOT

PEUGEOT 2008 Bedienungsanleitung

PEUGEOT

PEUGEOT 207 Spider Bedienungsanleitung

PEUGEOT

PEUGEOT Partner Origin Bedienungsanleitung

PEUGEOT

PEUGEOT PARTNER 4x4 DANGEL Technisches Datenblatt

PEUGEOT

PEUGEOT 406 Coupe Bedienungsanleitung

PEUGEOT

PEUGEOT 3008 2015 Bedienungsanleitung

PEUGEOT

PEUGEOT 308 Bedienungsanleitung

PEUGEOT

PEUGEOT 206 Bedienungsanleitung

PEUGEOT

PEUGEOT 3008 Bedienungsanleitung

PEUGEOT

PEUGEOT 308 Bedienungsanleitung

PEUGEOT

PEUGEOT 207 CC Bedienungsanleitung

PEUGEOT

PEUGEOT 107 Bedienungsanleitung

PEUGEOT

PEUGEOT 3008 HYbrif4 Bedienungsanleitung

PEUGEOT

PEUGEOT ION Bedienungsanleitung

PEUGEOT

PEUGEOT 508 Bedienungsanleitung

PEUGEOT

PEUGEOT 508 Bedienungsanleitung

PEUGEOT

PEUGEOT 3008 Bedienungsanleitung

PEUGEOT

PEUGEOT 406 Coupe Bedienungsanleitung

PEUGEOT

PEUGEOT 208 Bedienungsanleitung

PEUGEOT

PEUGEOT PARTNER Tepee Bedienungsanleitung

PEUGEOT

PEUGEOT RCZ Bedienungsanleitung

PEUGEOT

PEUGEOT 208 Rally 4 2021 Bedienungsanleitung

PEUGEOT

PEUGEOT 205 Cabriolet Bedienungsanleitung

Beliebte Automobil Handbücher anderer Marken

Toyota

Toyota 2000 Tundra Bedienungsanleitung

CITROËN

CITROËN DS4 DSign Bedienungsanleitung

Lexus

Lexus 2015 CT 200h Bedienungsanleitung

Cadillac

Cadillac CTS 2008 Bedienungsanleitung

Mercedes-Benz

Mercedes-Benz M-class ML 55 AMG Bedienungsanleitung

Porsche

Porsche Boxster S Bedienungsanleitung

GMC

GMC 2010 Savana 1500 Cargo Bedienungsanleitung

KIAM

KIAM SPORTAGE 2014 Stücklistenhandbuch

GMC

GMC 2013 Terrain Montageanleitung

GMC

GMC T-Series 1999 Bedienungsanleitung

Mercury

Mercury 1998 Mystique Bedienungsanleitung

Mercury

Mercury 2007 Mariner Bedienungsanleitung

Mazda

Mazda 2007 Mazdaspeed 3 Leitfaden

Mazda

Mazda 2014 CX-5 Bedienungsanleitung

GMC

GMC Chevrolet Express 2022 Bedienungsanleitung

GMC

GMC 1997 Jimmy Bedienungsanleitung

Chevrolet

Chevrolet 2012 Malibu Bedienungsanleitung

Cadillac

Cadillac 2010 Escalade Bedienungsanleitung
