Philco PF 1602-5 Bedienungsanleitung

UPRIGHT FREEZER

USER’S MANUAL

PF 1602-5

Dear customer,

Thank you for buying a PHILCO brand product. So that your appliance serves you well, please read

all the instructions in this user's manual.

EN - 1

CONTENTS

PART 1: BEFORE PUTTING INTO OPERATION................................................................................................. 2

PART 2: DESCRIPTION OF THE APPLIANCE .................................................................................................... 8

PART 3: INSTALLATION.................................................................................................................................... 9

• Transport and unpacking ............................................................................................................................................................9

• Operating conditions....................................................................................................................................................................9

• Installation location .................................................................................................................................................................... 10

• Levelling the appliance ............................................................................................................................................................. 10

• Cleaning before use....................................................................................................................................................................11

• Electrical connection.................................................................................................................................................................. 11

• Procedure for switching the door opening direction.....................................................................................................11

PART 4: CONTROLS ........................................................................................................................................ 15

PART 5: CLEANING AND MAINTENANCE...................................................................................................... 17

PART 6: TROUBLESHOOTING ........................................................................................................................ 19

PART 7: INFORMATION SHEET ...................................................................................................................... 21

EN - 2

PART 1: BEFORE PUTTING INTO OPERATION

This appliance is in accordance with the following EU guidelines:

2006/95/EC and 2004/108/EC and 2009/125/EC and EC.643/2009

and 2002/96/EC

Safety and warning information

For your safety and correct usage, before installing and rst using

the appliance, read this user manual carefully, including its hints and

warnings. To avoid unnecessary mistakes and accidents, it is important

to make sure that all people using the appliance are thoroughly familiar

with its operation and safety features. Save these instructions and be

sure that they remain with the appliance if it is moved or sold, so that

a using it throughout its life will be properly informed on its correct

appliance usage and safety notices. For the safety of life and property,

keep the precautions of these user's instructions as the manufacturer is

not responsible for damages caused by omission.

Safety for children and others who are vulnerable people

• This appliance can be used by children aged from 8 years and above

and persons with reduced physical, sensory or mental capabilities or

lack of experience and knowledge if they have been given supervision

or instruction concerning use of the appliance in a safe way and

understand the hazards involved. Children shall not play with the

appliance. Cleaning and user maintenance shall not be made by

children without supervision.

• Keep all packaging away from children as there is risk of suocation.

• If you are discarding the appliance, pull the plug out of the socket, cut

the connection cable (as close to the appliance as you can) and remove

the door to prevent children playing from suering an electric shock or

from closing themselves inside it.

EN - 3

• If this appliance, featuring a magnetic door seals, is to replace an older

appliance having a spring lock (latch) on the door or lid, be sure to

make the spring lock unusable before you discard the old appliance.

This will prevent it from becoming a death trap for a child.

General safety

• WARNING — This appliance is intended to be used in household and

similar applications such as

– sta kitchen areas in shops, oces and other working environments;

– farm houses and by clients in hotels, motels and other residential

type environments; -bed and breakfast type environments;

– catering and similar nonretail applications

• WARNING — Do not store explosive substances such as aerosol cans

with a ammable propellant in this appliance.

• WARNING — If the supply cord is damaged, it must be replaced by the

manufacturer, its service agent or similarly qualied persons in order

to avoid a hazard.

• WARNING — Keep ventilation openings, in the appliance enclosure or

in the built-in structure, clear of obstruction.

• WARNING — Do not use mechanical devices or other means to

accelerate the defrosting process, other than those recommended by

the manufacturer.

• WARNING — Do not damage the refrigerant circuit.

• WARNING — Do not use electrical appliances inside the food

storage compartments of the appliance, unless they are of the type

recommended by the manufacturer.

• WARNING—Therefrigerantand insulationblowinggas areammable.

When disposing of the appliance, do so only at an authorized waste

disposal centre. Do not expose to ame.

EN - 4

Refrigerant

The refrigerant isobutene (R600a) is contained within the refrigerant

circuit of the appliance, a natural gas with a high level of environmental

compatibility, which is nevertheless ammable. During transportation

and installation of the appliance, ensure that none of the components

of the refrigerant circuit becomes damaged. The refrigerant (R600a) is

ammable.

First aid

Inhalation

Take the aected person from the contaminated area to a warm, well

ventilated location. Staying in a contaminated location for a long time

may cause suocation, or potentially lead to a loss of consciousness. If

necessary, provide mouth-to-mouth resuscitation and in exceptionally

serious situations, under expert medical supervision, give oxygen.

Contact with the skin

Random contact with the skin will not endanger health, it is better to

thoroughly wash the aected area. The liquid spray or dispersed liquid

may cause frost bite, rinse the aected area with large amounts of water

and contact a medical doctor.

Contact with the eyes

If eyes have been aected, wash out with large amounts of water, while

trying to keep the eyes open and call a specialised doctor as soon as

possible. If contact or inhalation of the R600a gas occurs, contact your

medical doctor.

EN - 5

Caution: risk of re

If the refrigerant circuit should be damaged:

- Avoid opening ames and sources of ignition.

- Thoroughly ventilate the room in which the appliance is situated.

It is dangerous to alter the specications or modify this product in any

way.

Any damage to the cord may cause a shortcircuit, re, and/or electric

shock.

Electrical safety

1. The power cord must not be lengthened.

2. Make sure that the power plug is not crushed or damaged. A crushed

or damaged power plug may overheat and cause a re.

3. Make sure that you can access the main plug of the appliance.

4. Do not pull the main cable.

5. If the power plug socket is loose, do not insert the power plug. There is

a risk of electric shock or re.

6. You must not operate the appliance without the interior lighting lamp

cover.

7. The fridge is only applied with power supply of single phase alternating

current of 220~240V/50Hz. If uctuation of voltage in the district of

user is so large that the voltage exceeds the above scope, for safety

sake, be sure to apply A.C. Automatic voltage regulator of more than

350W to the fridge. The fridge must employ a special power socket

instead of common one with other electric appliances. Its plug must

match the socket with ground wire.

EN - 6

Daily use

• Do not store ammable gass or liquids in the appliance, There is a risk

of an explosion.

• Do not operate any electrical appliances in the appliance (e.g. electric

ice cream makers, mixers etc.).

• When unplugging always pull the plug from the mains socket, do not

pull on the cable.

• Do not place hot items near the plastic components of this appliance.

• Store pre-packed frozen food in accordance with the frozen food

manufacture's instructions.

• The appliances manufactures storage recommendations should be

strictly adhered to. Refer to relrelevant instructions for storage.

• Do not place carbonated or zzy drinks in the freeze compartment as

it creates pressure on the container, which may cause it to explode,

resulting in damage to the appliance.

• Frozen food can cause frost burns if consumed straight from the freezer

compartment.

• Do not place the appliance in direct sunlight.

• Keep buring candles, lamps and other items with naked ames away

from the appliance so that do not set the appliance on re.

• The appliance is intended for keeping food stu and/or beverages

in normal household as explained in this instruction booklet The

appliance is heavy. Care should be taken when moving it.

• Do not remove nor touch items from the freezer compartment if your

hands are damp/wet, as this could cause skin abrasions or frost/freezer

burns.

• Never use the base, drawers, doors etc. to stand on or as supports.

• Frozen food must not be refrozen once it has been thawed out.

• Do not consume ice popsicles or ice cubes straight from the freezer as

this can cause freezer burn to the mouth and lips.

EN - 7

Care and cleaning

• Before maintenance, switch o the appliance and disconnect the

mains plug from the mains socket.

• Do not clean the appliance with metal objects, steam cleaner, ethereal

oils, organic solvents or abrasive cleansers.

• Do not use sharp objects to remove frost from the appliance. Use

a plastic scraper.

Installation Important!

• For electrical connection carefully, follow the instructions given in this

manual.

• Unpack the appliance and check if there are damages on it. Do not

connect the appliance if it is damaged. Report possible damages

immediately to the place you bought it. In this case retain packing.

• Itisadvisable towaitatleastfourhoursbeforeconnectingtheappliance

to allow the oil to ow back in the compressor.

• Adequate air circulation should be around the appliance, lacking

this leads to overheating. To achieve sucient ventilation, follow the

instructions relevant to installation.

• Wherever possible the back of the product should be against a wall

to avoid touching or catching warm parts (compressor, condenser) to

prevent the risk of a re, follow the instructions relevant to installation.

• The appliance must not be locate close to radiators or cookers.

• Make sure that the mains plug is accessible after the installation of the

appliance.

Service

Any electrical work required to do the servicing of the appliance should

be carried out by qualied electrician or competent person.

This product must be serviced by an authorized Service Center, and only

genuine spare parts must be used.

1) lf the appliance is Frost Free.

2) lf the appliance contains freezer compartment.

EN - 8

PART 2: DESCRIPTION OF THE APPLIANCE

Description of the appliance

1. Control panel

2. Upper drawer

3. Drawers

4. Ice tray (inside)

5. Lower drawer

6. Adjustable feet

7. Door

Control panel

1. 2. 3. 4. 5. 6.

1. Temperature control

2. Disable the sound signal

3. High temperature indicator

4. Power On indicator

5. Super freeze indicator

6. Super freeze button

NOTE:

Due to unceasing modication of our products your refrigerator may be slightly dierent from this

Instruction Manual, but its functions and using methods remain the same.

Inhaltsverzeichnis

Andere Philco Gefrierschrank Handbücher

Philco

Philco PTF 953 FBU Bedienungsanleitung

Philco

Philco PTF 823 Bedienungsanleitung

Philco

Philco PTF 8211 BU Bedienungsanleitung

Philco

Philco PSF 341 Bedienungsanleitung

Philco

Philco PF 1472 Bedienungsanleitung

Philco

Philco PF 186 ENF Bedienungsanleitung

Philco

Philco PUF-100W Bedienungsanleitung

Philco

Philco PCF 418 F JOKER Bedienungsanleitung

Philco

Philco PF 2602 NX Bedienungsanleitung

Philco

Philco PBU1153A Bedienungsanleitung

Philco

Philco PF 1475 ENF Bedienungsanleitung

Philco

Philco PFN 1772 EBI Bedienungsanleitung

Philco

Philco PTF 862 Bedienungsanleitung

Philco

Philco PFC-100 Bedienungsanleitung

Philco

Philco PCF 1002 i Bedienungsanleitung

Philco

Philco PSF 34 E CUBE Bedienungsanleitung

Philco

Philco PF 2252 Bedienungsanleitung

Philco

Philco P-100 Bedienungsanleitung

Philco

Philco PCF 142 F JOKER Bedienungsanleitung

Philco

Philco PCF 246 EFPI Bedienungsanleitung

Philco

Philco GH806SNL- 1 Bedienungsanleitung

Philco

Philco PFN 238 EX JOKER Bedienungsanleitung

Philco

Philco PCF-510X Bedienungsanleitung

Philco

Philco PCF 1432-5 Bedienungsanleitung

Beliebte Gefrierschrank Handbücher anderer Marken

Siemens

Siemens GU..D SERIES Bedienungsanleitung

Omcan

Omcan FR-CN-0155 Bedienungsanleitung

Beko

Beko FNE290E24W Bedienungsanleitung

Electrolux

Electrolux ARCTIS G 8 60 50-6I Bedienungsanleitung

Electrolux

Electrolux EUF2042AOX Bedienungsanleitung

Dometic

Dometic CoolFreeze CFX95DZ Bedienungsanleitung

Electrolux

Electrolux EUF7000W1 Bedienungsanleitung

Polar Electro

Polar Electro CT330 Bedienungsanleitung

MPM

MPM MPM-145-SK Series Bedienungsanleitung

SAF

SAF PRESTOTIG 200AC/DC Kurzanleitung

Zanussi

Zanussi ZFT11407WA Bedienungsanleitung

AEG

AEG A63190GT Bedienungsanleitung

AEG

AEG A81000TNW0 Bedienungsanleitung

Matsui

Matsui MUC50S15E Bedienungsanleitung

NEFF

NEFF G4344X8 Bedienungsanleitung

Frigidaire

Frigidaire FV 1246 H Bedienungsanleitung

Frigidaire

Frigidaire FFC13K1AW Bedienungsanleitung

Electrolux

Electrolux EU 2400C Bedienungsanleitung
