REFRIGERATOR

USER’S MANUAL

PTL 3352

Dear customer,

Thank you for buying a PHILCO brand product. So that your appliance serves you well, please read

all the instructions in this user‘s manual.

EN - 1

02/2013

CONTENTS

PART 1: BEFORE PUTTING INTO OPERATION................................................................................................. 2

• Safety notice.....................................................................................................................................................................................2

• Safety instructions for gas R600a..............................................................................................................................................4

PART 2: DESCRIPTION OF THE APPLIANCE .................................................................................................... 5

PART 3: INSTALLATION.................................................................................................................................... 6

• Transport and unpacking ............................................................................................................................................................6

• Placement..........................................................................................................................................................................................7

• Cleaning before use ......................................................................................................................................................................8

• Electrical connection.....................................................................................................................................................................8

• Procedure for switching the door opening direction........................................................................................................9

PART 4: SETTING THE TEMPERATURE........................................................................................................... 10

PART 5: ARRANGEMENT OF FOOD ............................................................................................................... 11

PART 6: REGULAR MAINTENANCE................................................................................................................ 12

• Cleaning the refrigerator .......................................................................................................................................................... 12

• Changing the light bulb............................................................................................................................................................13

PART 7: WHAT SHOULD I DO WHEN.............................................................................................................. 14

PART 8: INFORMATION SHEET ...................................................................................................................... 15

EN - 2

02/2013

PART 1: BEFORE PUTTING INTO OPERATION

Safety notice

Symbols:

General advice for the optimal operation of the appliance

General dangers

Hot surfaces

Before you put the appliance into operation

• Carefully study the user's manual and installation instructions before installing and using the appliance!

This user's manual includes important information regarding the installation, operation and maintenance

of the appliance. Store the user's manual also for future reference, or for other owners of the appliance

if the appliance is sold.

If the appliance is transported in a horizontal position the oil from the compressor may leak into the

cooling circuit. For this reason, allow the appliance to rest in a vertical position for 12 hours before

turning it on, so that the oil ows back into the compressor.

After unpacking the appliance, carefully inspect that it has in not been damaged in any way. Also

check that the power cord is not damaged. If you discover any defects, turn o the appliance and

contact the vendor or in the case of a damaged power cord contact the service centre. If the appliance

and all its parts are in order, install it according to the instructions in the relevant chapter.

• When installing the appliance in its place, or when moving the appliance, the power cord could be

penetrated or damaged. Check that the power cord is not interfering anywhere.

• Before connecting the appliance to the electricity power source check that the capacity of the system

corresponds to the specications on the appliance's rating label.

• Any kinds of home electric wiring necessary for the connection of the appliance must only be carried out

by a qualied electrician.

If you move the appliance from its usual position, it is necessary to understand, that although you

have disconnected the power cord, the components on the rear side of the appliance may remain very

hot for some time.

This appliance is not designed to be built-in. Do not cover or block the air inow or outow openings.

Insucient ventilation will cause bad operation and damage to the appliance.

Operating the appliance

• Use the appliance only for the purposes for which it has been designed.

• This appliance is designed only for household use, for storing food.

• The temperature inside the refrigerator may rise or fall slightly, and so these appliances are not suitable for

storing products (e.g. medicines), which require a stable temperature.

Do not use any other electric appliances (e.g. heating elements, electric ice cream machines, etc.)

inside the appliance. There is a danger of explosion!

EN - 3

02/2013

Do not place food inside the refrigerator containing ammable propulsion gases (e.g. sprays) and no

explosives, contaminants or volatile substances. There is a danger of explosion!

• Store liquor only with a rmly tightened cap and in a vertical position.

• Do not use the base, drawers, door of the appliance, etc. as a step or as a support. There is a danger of injury

to persons or damage to the appliance.

• Ensure that the plastic parts of the appliance and the door seals are not soiled with oil or grease.The plastic

parts and the seals would then become porous.

We do not recommend placing hot liquids or food inside the refrigerator and lling containers all the

way to the rim.

Do not put fragile, heavy or unstable objects on the refrigerator.

Children in the household

• Never leave packaging and its parts with the children. There is a danger of poisoning or suocation by the

cardboard boxes and plastic sheets!

• This appliance is in no way a toy for children!

• For appliances with door locks: do not leave keys within the reach of children!

• If you will no longer be using the refrigerator, remove the door, seals and store it in a safe place. In this way

you will prevent the danger of children becoming trapped inside the refrigerator.

Maintenance and cleaning

Before you begin with regular or exceptional maintenance, disconnect the appliance's power cord or

turn o the fuse or circuit breaker. Never pull the electric power cord, only pull on the power plug.

General instructions

• This appliance must not be used by persons (including children) with physical, sensory or psychological

impairments or by inexperienced persons, unless properly trained or schooled in the safe use of the

appliance, or unless they have been properly supervised by a person who will be responsible for their

safety. Children should be supervised so as not to play with the appliance.

• This appliance has been tested in accordance with the directives in force in the European Union.

• The tightness of the cooling circuit has been veried.

• This appliance conforms to the relevant safety provisions for electrical appliances in force in the European

Union.

EN - 4

02/2013

Technical safety

The appliance contains a cooling gas, ISOBUTHAN (R600a). Only transport or move the appliance

with the utmost care, prevent excessive impacts and shaking to prevent damaging

the appliance. If the cooling circuit becomes damaged and the cooling gas may be escaping, there is a

risk of an explosion, which may be ignited by a spark or ame. If the appliance shows signs of damage, it must

not be put into operation. In such a case contact the service centre, ventilate the room where the appliance is

located and prevent the spreading of ames or other interference with the appliance.

Safety instructions for gas R600a

Measures in case of an unexpected release

If ventilation is possible, allow the material to evaporate.

Characteristics of the gas

The gas is highly ammable, it is necessary to completely prevent contact with an open ame and hot surfaces.

Because the R600a gas is heavier than air, it may become very concentrated at the level of the ground, where

ventilation is weak.

First aid

Inhalation

Take the aected person from the contaminated area to a warm, well ventilated location. Staying in

a contaminated location for a long time may cause suocation, or potentially loss of consciousness. If

necessary, provide mouth-to-mouth resuscitation and in exceptionally serious situations, under expert

medical supervision, give oxygen.

Contact with the skin

Random contact with the skin will not endanger health, it is better to thoroughly wash the aected area. The

liquid spray or dispersed liquid may cause frost bite, wash the aected area with large amounts of water and

contact a medical doctor.

Contact with the eyes

If eyes have been aected, wash out with large amounts of water, while trying to keep the eyes open, and call

a specialised doctor as soon as possible.

If contact or inhalation of the R600a gas occurs, contact your medical doctor.

EN - 5

02/2013

PART 2: DESCRIPTION OF THE APPLIANCE

1. Temperature control dial

2. Main power switch

3. Refrigerator shelves

4. Cover of the fruit and vegetable drawer

5. Fruit and vegetable drawer

6. Levelling feet

7. Door shelf

8. Hidden handle

NOTE:

The picture is for illustration purposes only, some parts may dier from the nal appliance due

to improvements made to the appliance during its production.

EN - 6

02/2013

PART 3: INSTALLATION

Transport and unpacking

If the appliance is transported in a horizontal position the oil from the compressor may leak into the cooling

circuit. For this reason, allow the appliance to rest in a vertical position for 12 hours before turning it on, so that

the oil ows back into the compressor.

Remove the external packaging, remove the protective plastic lm from the surface of the appliance (if used)

and clean the external parts of the appliance with an agent designed for this purpose. Do not use steel wool or

any coarse agents, which could irreparably damage the surface of the appliance. Carefully remove all papers

and adhesive tape from the appliance, door and other parts packed in polystyrene. Remove documents and

accessories from inside the appliance.

The packaging material is recyclable and is marked with a recycling symbol. For disposal follow the local

regulations. Packaging materials (plastic bags, polystyrene parts, etc.) must be kept out of the reach of children,

because they present a possible source of danger.

Carefully inspect the appliance. If you discover any defects, stop the installation and contact the vendor.

Operating conditions

The proper operation of the appliance, the cooling temperature are guaranteed only when the following

conditions are met:

 The temperature in the room where the appliance is located conforms to the climate class stated on the

appliance's rating label.

 Maximum ambient relative humidity: 90%.

 The appliance must be placed at a sucient distance from heat sources (e.g. baking ovens, central heating,

direct sunlight, etc.).

 The appliance must be located in such a place that it is protected against the eects of weather.

 Regular maintenance is performed according to the instructions in this user's manual.

 The ventilation openings in the cover of the appliance must not be covered by anything.

 Correct installation (e.g. levelling, the capacity of the system correspond to the specications on the rating

label of the appliance.)

Table – Climatic class

Climatic class Ambient temperature

SN +10°C to +32°C

N +16°C to +32°C

ST +16°C to +38°C

T +16°C to +43°C

EN - 7

02/2013

Placement

The location for the placement of the appliance must meet the requirements in the paragraph "Operating

conditions" and must have a stable oor with a load bearing capacity corresponding to the weight of the appliance.

Furthermore you must maintain distances and dimensions of the appliance, so that correct operation

is ensured:

1. Top part at least 20 cm;

2. Rear part at least 10 cm;

3. The wall on the side where the door opens at least 30 cm.

Ventilation requirements

The area behind the appliance must provide for sucient air circulation.

Level the appliance using the adjustable feet, ensure there is a gap between the bottom edge of the appliance

and the ground, so that there is sucient circulation of the cooling air, by which you will ensure the optimal

performance of the cooling circuit.

Check whether any cooling circulation pipes have been damaged during the installation.

 Use the appliance only for the purposes for which it has been designed.

 The appliance must be located on a rigid and even surface.

In this way you will ensure free circulation of the coolant and eective operation of your appliance.

 If possible, place the appliance into a cool, well ventilated and dry room.

 Do not locate the appliance in direct sunlight, or in a room with a high temperature, in the vicinity of any

sources of direct heat, such as heating, an oven, a stove, etc. – this would mean that the compressor would

need to work a lot harder resulting a substantially higher power consumption level.

If it is not possible to prevent the installation in the vicinity of a heat source, we recommend the insertion of an

appropriate insulating board (do not use asbestos) between the appliance and the heat source; or at least to

maintain the following minimum distances:

 From a gas or electric stove 5 cm;

 From a heater or oven, etc. 50 cm;

 From another cooling appliance 2 cm.

Do not place any appliances on the appliance, which release heat on to the appliance, such as microwave

ovens, toasters, etc.

Never cover the ventilation grill. Pull out the power plug by pulling on the plug itself, never pull on the cord

when disconnecting the appliance.

EN - 8

02/2013

Before turning on the appliance allow it to stand in its nal location for 12 hours, the coolant circuit

will stabilise in this way and no operating problems will occur. Before connecting the appliance to the

power grid check that it is perfectly dry inside – especially in the corners.

Danger warning

The coolant may be highly ammable, depending on its composition. The coolant circuit was

hermetically closed and sealed and was tested many times for possible leaks. Any unqualied

tampering with the product may cause a re hazard. Check that there is no mechanical interruption

or eect on the coolant circulation, namely in the accessible parts around the compressor.

Only professionally qualied persons may work on the cooling system.

Cleaning before use

Check that you have removed from the appliance all adhesive tape used to hold accessories . Then clean all the

inside parts using lukewarm water with a neutral cleaning agent, vinegar or sodium carbonate – in this way

you will remove the characteristic odour of new parts – then dry carefully. Do not use detergents or aggressive

agents, which could damage the surfaces.

Electrical connection

Before connecting the power plug to the power socket, check that:

 Your hands are completely dry.

 The voltage and frequency shown on the rating label of the appliance corresponds to that in the home

power grid (permitted tolerance from -6% to +6% for nominal voltage, for use with dierent voltages, use

a voltage changer with the corresponding parameters).

 The cord and the plug are not damaged or caught under heavy objects.

 The power cord is not excessively tensioned, it is not permitted to use an extension cord.

Do not connect the appliance to a voltage rectier (e.g. solar power plant) or use an extension cord.

The appliance must be connected to a working grounding lead. If the power socket of the home

system is not grounded in accordance with the current legal regulations, connect the appliance

after consulting a specialised technician to the grounding lead itself. The manufacturer takes no

responsibility for injuries caused as a result of not following these instructions.

If you do not correctly level the freezer during the installation, the doors may not close shut and seal

properly, which may cause problems with the cooling, ice build up or moisture. Levelling the freezer is

very important.

Level the freezer using the adjustable feet – turn them clockwise to lift the freezer and turn them anticlockwise

to lower the freezer.

Andere Handbücher für PTL 3352

Inhaltsverzeichnis

Sprachen:

Andere Philco Kühlschrank Handbücher

Philco

Philco PCE 3262 NIL Bedienungsanleitung

Philco

Philco PTL 1061 Bedienungsanleitung

Philco

Philco PHK15BM Einrichtungshandbuch

Philco

Philco PX 4011 X Bedienungsanleitung

Philco

Philco PTB 80 F Bedienungsanleitung

Philco

Philco PCN 17732 Bi Bedienungsanleitung

Philco

Philco PX 502 Iceberg Bedienungsanleitung

Philco

Philco PRD-220/4A+ Bedienungsanleitung

Philco

Philco PTL 131 D Bedienungsanleitung

Philco

Philco PC 2252 PL Bedienungsanleitung

Philco

Philco PCE 3181HN/N Bedienungsanleitung

Philco

Philco PX 5161 X Bedienungsanleitung

Philco

Philco PC 32614 Bedienungsanleitung

Philco

Philco PC 455 Adora Bedienungsanleitung

Philco

Philco PRSF-5628X1/WD Bedienungsanleitung

Philco

Philco PT 204 E Bedienungsanleitung

Philco

Philco Philco PRD-233W Bedienungsanleitung

Philco

Philco PTB 117 D Bedienungsanleitung

Philco

Philco PXI 3652 X Bedienungsanleitung

Philco

Philco PC 3122 Montageanleitung

Philco

Philco PTB 1931 Bedienungsanleitung

Philco

Philco PCN 17742 EBI Bedienungsanleitung

Philco

Philco PTL 2352 Bedienungsanleitung

Philco

Philco PBF7320NF Bedienungsanleitung

Beliebte Kühlschrank Handbücher anderer Marken

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Bedienungsanleitung

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Bedienungsanleitung

Sharp

Sharp SJ-BA31IEXW2-EU Bedienungsanleitung

CORBERO

CORBERO CC2300MCW Bedienungsanleitung

KitchenAid

KitchenAid 2205264 Bedienungsanleitung

Stengel

Stengel KU 1101 A++ Bedienungsanleitung

NEFF

NEFF KI181 Series Bedienungsanleitung

Hoshizaki

Hoshizaki Reach-In Bedienungsanleitung

Amana

Amana ASD2524VES00 Bedienungsanleitung

BOMANN

BOMANN KGC 213 Bedienungsanleitung

Danby

Danby DAR044A1SLDD Montageanleitung

Samsung

Samsung RF323TE Bedienungsanleitung

Beko

Beko CSA31022 Bedienungsanleitung

IKEA

IKEA FROSTIG C 185 E Bedienungsanleitung

Electrolux

Electrolux ER 6821 D Bedienungsanleitung

True

True TS-28 Bedienungsanleitung

Frigidaire

Frigidaire FSC23R5DW9 Bedienungsanleitung

Beko

Beko LSP4579W Bedienungsanleitung
