Philio PAN34 Bedienungsanleitung
In Wall Roller shutter controller
PAN34
Introduction
The in-wall Roller Shutter Controller is designed to switch rise/lower roller shutter
connected to its terminals using radio waves, controllers and a push button directly
connected to this Roller Controller.
This in-wall Roller Shutter Controller is a Z-Wave lusTM enabled wireless device fully
compatible with any Z-WaveTM enabled networks. This device is a security enabled Z-
Wave lus product that uses encrypted Z-Wave lus messages to communicate to
other security enabled Z-Wave lus products. Z-WaveTM enabled devices displaying
the Z-WaveTM logo can also be used with this device regardless of the manufacturer.
This product can be operated in any Z-Wave network with other Z-Wave certified
devices from other manufacturer. Within the network it will act as repeater regardless
of vender to increase reliability of the network. Slim design let the Controller can
easily hide itself into the wall box and that will be good for the house decoration.
This device must be used in conjunction with a Security Enabled Z-Wave Controller
in order to fully utilize all functions. Its functionality and supported command classes
is identical when included as a secure and non-secure device.
The new smart relay calibration technology can reduce the inrush current caused by
the load and let the module work perfectly with many kind of Roller Shutter.
This in-wall Roller Shutter Controller is able to detect position of the Shutter by using
the patterned power measuring method, so it can be remote controlled not only fully
up or down, but also can be adjusted to ex. 30% or 50%. And when manual
controlled by push button, the controller also can memorize the position and send the
new shutter position to its controller (ex. I -Gateway).
Safety Precautions and Installation
Avoid installing the unit in storming or raining weather.
Be sure to isolate or switch off power source before installing or maintenance.
Do ensure that the power supply circuit protected by a 16A circuit breaker or
suitable equivalent fuse.
IMPORTANT
Installation must be performed by skilled technicians who are informed about
the standards and technical requirements of the appliance and its proper
1
installation.
Check your local codes as they apply to your situation. If the house wiring is of
aluminum, consult with an electrician about proper wiring methods.
Before proceeding with the installation, TURN OFF THE OWER TO THE
LIGHTING CIRCUIT AT THE CIRCUIT BREAKER OR FUSE BOX TO AVOID
ELECTRICAL SHOCK.
Specification
Operating Voltage 100 -240VAC 50-60Hz
Maximum Load Resistive load 5A max.
Range Minimum 40 m in door 100m outdoor line of sight
Operating Temperature 0°C - 40°C
Humidity Up to 85% max.
Storage Temperature -20°C to 60°C
Location Indoor use only
Frequency Range 868.40MHz; 869.85MHz (EU)
908.40MHz; 916.00MHz (USA/Canada)
920.90 MHz, 921.70 MHz, 923.10 MHz (Taiwan)
RF Maximum ower +10dBm ( eak), -10dBm (Average)
Communication rotocol Z-Wave™
OTA Yes
FCC ID RHH AN34
Dimensions 47.5 x 39 x16 mm
Wire 0.75mm², 18AWG
** Specifications are subject to change and improvement without notice.
Troubleshooting
Sy pto Cause of Failure Reco endation
The AN34 not working
and LED off
1. The AN34 is not
connect to the Main
power
2. The AN34 break
down
1. Check power connections
2. Don’t open up the AN34 and send
it for repair.
The shutter move direction
is reverse
Wrong connection of NC
and NO to the motor
Swap the NC NO connection
AN34 LED light work fine
But can not control
1. No association setting
2. Same frequency
interference
3. S1 or S2 are both
pressed in Two ush
Button switch type,
AN34 would not
accept RF command.
1. Carry out association
2. Wait for a while to re-try
3. Release S1 and S2
2
Fig 1. Assembling Installation and operation
1. ut the in wall AN34 into a wall box and connect the AC power wire L,N to AN34
connector L, N.
2. Connect the wall switch to the AN34 as Fig1
3. To manually switch up and down of the shutter, simply press the external switch S1
or S2. The detail is described in 7-5.
4. AN34 built in meter function and can read the Watt, KWh, V(Voltage), I(Current),
F ( ower Factor) of the load by using Z-Wave command class, user can set a
threshold current to get the warning caused by abnormal operation
5. AN34 have overload protection function and can help to prevent short circuit
caused by load.
DANGER
Danger of electrocution!
All works on the device may be performed only by a qualified and licensed
electrician. Observe national regulations.
Any works introducing changes into the configuration must be always performed with
disconnected voltage.
Choosing a Suitable Location
1. Do not locate the Module facing direct sunlight, humid or dusty place.
2. The suitable ambient temperature for the Module is 0°C~40°C.
3. Do not locate the Module where exists combustible substances or any source of
heat, e.g. fires, radiators, boiler etc.
4. After putting it into use, the body of Module will become a little bit hot of which
phenomenon is normal.
Adding to Z-WaveTM Network
In the front casing, there is an include button with LED indicator below which is used
to carry out inclusion, exclusion, reset.
The table below lists an operation summary of basic Z-Wave functions. lease refer
to the instructions for your Z-WaveTM Certificated rimary Controller to access the
Setup function, and to include/exclude/reset devices.
Function Description LED Indication
No node ID The Z-Wave Controller does not allocate
a node ID to the AN34.
LED 2-second on, 2-second
off
3
Add
(Classic
Inclusion)
1. ut your Z-Wave controller into
inclusion mode by following the
instructions provided by the
controller manufacturer.
One press one flash LED
2. ressing Include button three times
within 2 seconds will enter inclusion
mode.
Smart Start 1. The product has a DSK string. Key
in the first five digits to initiate the
SmartStart process, or scan QR
code.
Ex: DSK: 18112-24021- 48001-
62259-57092-27453-08187-47408
2. SmartStart enabled products can
be added into a Z-Wave™ network
by scanning the Z-Wave™ QR
Code on the product, with a
controller providing SmartStart
inclusion. No further action is
required and the SmartStart product
will be added automatically to the
closest network within 10 minutes of
being switched on.
Notice:
The QR Code can be found on the
device AN34 or in the box.
Remove 1. ut your Z-Wave controller into One press one flash LED
(Exclusion) exclusion mode by following the
instructions provided by the
controller manufacturer.
2. ressing Include button three
times within 2 seconds will enter
exclusion mode.
Node ID has been excluded. LED 0.5s On, 0.5s Off (En-
ter auto inclusion)
Reset 1. ressing Include button three times
within 2 seconds will enter inclusion
mode.
Use this procedure only in
the event that the primary
controller is lost or
otherwise inoperable.
2. Within 1 second, press Include
button again for 5 seconds.
3. IDs are excluded. LED 0.5s On, 0.5s Off (En-
ter auto inclusion)
Adding a node ID allocated by Z-Wave Controller means inclusion. Removing a node ID
allocated by Z-Wave Controller means exclusion.
Failed or success in including/excluding the node ID can be viewed from the Z-Wave
Controller.
LED Indication
There is a LED for identify function in the front case. AN34 support the indicator ID
0x50 (Identify) and roperties ID 0x03, 0x04 and 0x05.
To distinguish what mode the AN34 is in, view from the LED for identification.
State Type LED Indication
Motor No matter up or down, close or open, Led will flash every second
4
activate while Motor activate.
When S1 or S2 close to L, the LED will flash even when the motor
stop by itself, this is to let user know the S1 or S2 still close and not
been release yet.
No node ID Under normal operation, when the AN34 has not been allocated a
node ID, the LED flashes on and off alternately at 2-second
intervals. By pressing S1 S2 or Include button, it will stop flashing
temporarily.
Learning When AN34 is in learning mode, LED flashes on and off
alternately and repeatedly at 0.5 second intervals.
Overload When overload state occurs, the AN34 is disabled and LED
flashes on and off alternately at 0.2 second intervals. AN34 will
send alarm type=8 alarm Level=0xFF to Group1, Overload state
can be cleared by disconnect and reconnect the AN34 to the main
power
Moving Range Calibration
1. It is important to carry out a shutter calibration process before you control the
shutter to move. ress inclusion button over 3 seconds and release before the 6th
second, the roller shutter controller will start the shutter calibration process. The
process is composed of three continue stages. The shutter move to the TO in first
stage, and move to the BOTTOM in second stage, and move to the TO again in
third stage. Then AN34 will know the total range from the BOTTOM to the TO .
2. During the shutter calibration process, any emergencies happen you can press
and release the include button to stop the process.
3. If user found the direction is reverse, this may cause by the wrong connection of
NC and NO to the motor, please exchange NC and NO connection and execute
calibration process again.
4. For safe issue, please select the motor which can stop by itself when go to bottom
end or top end.
Progra ing
1. Basic Co and Class
The AN34 will respond to BASIC and BINARY commands that are part of the
Z-Wave system.
1.1 BASIC_GET
When AN34 receive Basic Get Command, it will send Basic Report Command
to report the position of the shutter. When the report value is 0x00, that mean the
shutter is at the Bottom, if the report value is 0x63 that mean the shutter is at the
Top, any other value between 0x01~0x62 imply Shutter at the position between
top and bottom.
Basic Get Command: [Co and Class Basic, Basic Get]
Basic Report Command：
[Co and Class Basic, Basic Report, Value = 0x00 (BOTTOM)]
[Co and Class Basic, Basic Report, Value = 0x01~0x62 (Between BOT-
5
TOM and TOP)]
[Co and Class Basic, Basic Report, Value = 0x63 (TOP)]
1-2 BASIC_SET
AN34 can accept Basic Set Command which value is either (0x00) Bottom or
Top (0x63) or (0x01-0x62) the position between TO and Bottom. Other value
(0x64-0xFE) is not acceptable.
[Co and Class Basic, Basic Set, Value = 0x63] control the shutter to
the top (0x63)
[Co and Class Basic, Basic Set, Value = 0x00(0)] control the shutter to
the botto (0x00)
[Co and Class Basic, Basic Set, Value = 0xFF] control the shutter to
the ost recent (non-zero) level.
[Co and Class Basic, Basic Set, Value = 0x01-0x62] control the shutter
to the position between botto and top
2. Multilevel Switch Co and Class (Version 3)：
2-1 MULTILEVEL SWITCH SET:
AN34 can accept Multilevel Switch Set Command which value is either (0x00) Bot-
tom or Top (0x63) or (0x01-0x62) the position between TO and Bottom. Other value
(0x64-0xFE) is not acceptable.
[Co and Class Multilevel Switch, Multilevel Switch Set, Value = 0x63]
control the shutter to the top (0x63)
[Co and Class Multilevel Switch, Multilevel Switch Set, Value =
0x00(0)] control the shutter to the bottom(0x00)
[Co and Class Multilevel Switch, Multilevel Switch Set, Value =
0xFF(255)] control the shutter to the the ost recent (non-zero) level.
[Co and Class Multilevel Switch, Multilevel Switch Set, Value = 0x01-
0x62] control the shutter to the position between Bottom and Top.
2-2 MULTILEVEL SWITCH GET:
When AN34 receive Multilevel Switch Get Command, it will send Multilevel Switch
Report Command to report the position of the shutter. When the report value is 0x00,
that mean the shutter is at the Bottom, if the report value is 0x63 that mean the shut-
ter is at the top, any other value between 0x01~0x62 imply shutter at the position be-
tween top and bottom.
Switch Multilevel Get Command：
[Co and Class Multilevel Switch, Multilevel Switch Get]
Multilevel Switch Report Command：
[Co and Class Multilevel Switch, Multilevel Switch Report,
Value = 0x00(BOTTOM)]
[Co and Class Multilevel Switch, Multilevel Switch Report,
Value = 0x01~0x62(Between BOTTOM and TOP)]
6
[Co and Class Multilevel Switch, Multilevel Switch Report,
Value = 0x63 (TOP)]
2-3 MULTILEVEL SWITCH START LEVEL CHANGE:
This is the co and which user can ove the shutter up to the top or down to
the botto .
[Co and Class Multilevel Switch, Multilevel Switch Start Level Change,
Up/Down Value]
2-3.1 Up/Down Bit:
If Up/Down Bit=0x00 Shutter move up
If Up/Down Bit=0x01 Shutter move down
If Up/Down Bit=0x03 no move
[Co and Class Multilevel Switch, Multilevel Switch Start Level Change,
Up/Down=0x00] control the shutter to the top (0x63)
[Co and Class Multilevel Switch, Multilevel Switch Start Level Change,
Up/Down=0x01] control the shutter to the botto (0x00)
[Co and Class Multilevel Switch, Multilevel Switch Start Level Change,
Up/Down=0x03] Don't ove the shutter or stop the oving shutter
ATT. 1. Ignore Start Level、Start Level、Dimming Duration、Inc/Dec、Step size can
not be used.
2. PAN34 can not control the speed of otor.
3. It may have some distance error caused by motor start up time.
4. If user found the error become significant, you may using S1 or S2 move
shutter to the end or remote move shutter to 0% and 100%, and that will
automatically calibrate this error.
2-3.4 MULTILEVEL SWITCH STO LEVEL CHANGE:
When receive Multilevel Switch Stop Level change Command AN34 will stop the
motor.
Z-Wave’s Groups introduction (Maximum 5 nodes)
There is only one group called Lifeline，there is only 5 nodes for Group1 which sup-
port MULTILEVEL_SWITCH_RE ORT、METER_RE ORT_COMMAND_V3、 NOTI-
FICATION_RE ORT and DEVICE_RESET_LOCALLY_NOTIFICATION.
3-1 Device reset locally notification :
When AN34 is reset manually, it will send a DEVICE_RESET_LOCALLY_
NOTIFICATION to the nodes of group 1.
3-2 Report the shutter position ：
Every time when user press S1 or S2 and let shutter to move, AN34 will report the
position status to controller, and at the moving process when change over 10%
AN34 will send Multilevel Switch Report to Group 1 as well.
Multilevel Switch Report：
Ex. Report position at 30%
[Command Class Multilevel Switch， Multilevel Switch Report，Value = 30(%)]
3-3 Meter Co and Class：
7
The Switch will report its (1) instant ower Consumption (Watt) or (2) accumulated
power consumption(KWH) or (3) AC load Voltage (V) or (4) AC load current ( I ) (5)
load power factor ( F) to Z-Wave Controller after receive the Meter Get Command
from Z-Wave Controller.
When the power consumption of load vary over 5%, it will send Meter report to the
nodes of Group as well
3-3.1 Instant Power Consu ption (Watt) of Switch
When receiving Meter Get Command, it will report Meter Report Command to the
node asked.
Meter Get Command: [Co and Class Meter, Meter Get, Scale
=0x02(W)]
Meter Report Command:
[Co and Class Meter，Meter Report，Rate Type = 0x01，Meter
Type =
0x01，Precision = 1，Scale = 0x02，Size = 4，Meter Value(W) ]
Example:
Meter Value 1 = 0x00 (W)
Meter Value 2 = 0x00 (W)
Meter Value 3 = 0x03 (W)
Meter Value 4 = 0xEA (W)
Meter(W) = Meter Value 3 *256 + Meter Value 4 = 100.2W
3-3.2 Accu ulated Power Consu ption (KW/h)
When receiving Meter Get Command, it will report Meter Report Command to
the node asked.
Meter Get Command: [Co and Class Meter, Meter Get, Scale = 0x00
(KW/h)]
Meter Report Command:
[Co and Class Meter，Meter Report，Rate Type = 0x01， Meter
Type
=0x01， Precision = 2，Scale = 0x00，Size = 4，Meter Value (KWh)]
Example:
Scale = 0x00 (KWh)
recision = 2
Size = 4 Bytes (KW/h)
Meter Value 1 = 0x00(KWh)
Meter Value 2 = 0x01(KWh)
Meter Value 3 = 0x38(KWh)
Meter Value 4 = 0xA3(KWh)
Accumulated power consumption (KW/h) = (Meter Value 2*65536) + (Meter Value
3*256) + (Meter Value 4) = 800.35 (KW/h)
3-3.3 AC load Voltage (V)
When receiving Meter Get Command, it will report Meter Report Command to the
node asked.
Meter Get Command: [Co and Class Meter, Meter Get, Scale
=0x04(V)]
8
Meter Report Command:
[Co and Class Meter，Meter Report，Rate Type = 0x01，Meter
Type =
0x01，Precision = 1，Scale = 0x04，Size = 2， Meter Value(V)]
Example:
Scale = 0x04 (V)
recision = 1
Size = 2 (2 Bytes of V)
Meter Value 1 = 0x09(V)
Meter Value 2 = 0x01(V)
AC load Voltage = (Meter Value 1*256) +(Meter Value 2)= 230.5 (V)
3-3.4 AC load current ( I )
When receiving Meter Get Command, it will report Meter Report Command to the
node asked.
Meter Get Command: [Co and Class Meter, Meter Get, Scale
=0x05(I)]
Meter Report Command:
[Co and Class Meter，Meter Report，Rate Type = 0x01，Meter
Type
= 0x01，Precision = 2，Scale = 0x05，Size = 2，Meter Value(I)]
Example:
Scale = 0x05 (I)
recision = 2
Size = 2 (2 Bytes of I)
Meter Value 1 = 0x01(I)
Meter Value 2 = 0x21(I)
AC load current = (Meter Value 1*256) +(Meter Value 2)= 2.89 (A)
3-3.5 load power factor (PF)
When receiving Meter Get Command, it will report Meter Report Command to the
node asked.
Meter Get Command: [Co and Class Meter, Meter Get, Scale
=0x06(PF)]
Meter Report Command:
[Co and Class Meter，Meter Report，Rate Type = 0x01，Meter Type
=
0x01， Precision = 2，Scale = 0x06，Size = 1 Bytes，Meter Value(PF)]
Example:
Scale = 0x06 ( F)
recision = 2
Size = 1 (1 Byte of F)
Meter Value 1 = 0x63( F) (It means that the load power factor is 0.99)
3-3.6 Reset Accu ulated Power Consu ption (KWh)
Whenever re-start counting the accumulated power consumption is needed, you can
use Meter Reset Command to clear it.
Meter Reset Command：[Co and Class Meter, Meter Reset]
9
4. Notification Report Co and：
When AN34 detect Overload, it will send Notification Report to Group1, Notification
_Type = 0x08, Notification State=0x08. When it receive Notification Get command
with Notification Type = 0x08 and the AN34 not in overload status, it will send Notifi-
cation Report, Alarm Type = 0x08, Notification State=0x00.
When AN34 detect an overload power, it will send Notification Report to Group1.
[Command Class Notification, Notification Report, Notification Type = 0x08,
Notification State = 0x08 (Overload)]
[Command Class Notification, Notification Report, Notification Type = 0x08,
Notification State = 0x00 (Normal)]
When in Two ush Button switch type, S1 or S2 are closed and not released to open,
and AN34 receive any control moving command from Z-Wave RF.
5. Z-Wave’s Configuration
Configuration
Para eter
Function Size
(Byte)
Value Unit Default Description
1 Watt
Meter
Report
eriod
2 0 -
0x7FFF
5s 720 0:Disable auto Report
1~0x7FFF: 5s ~45
hour
2 External
switch
mode
1 1-2 2 1: One ush button
2:Two ush button
3 Total 2 0-6000 0.1
Second
00: The time depends
on Moving Range
Calibration
moving
time of
curtain
1~6000: 0.1s~600s
4 Watt
threshold
1 1-5 Watt 1The threshold is a
judgment for motor
running or not
5Watt
differential
1 0-1 1 0: It will not report
Watt when change
over 5%
1: It will report watt
value when the
differential is over
5%
6 Timer
offset for
motor
start
running
2 0-255 0.01
second
50 0-255: 0s ~ 2.55s
50 = 0.5s
5-1 Watt Meter Report Period:
If the setting is configured for 1hour (set value =720), the AN34 will report its instant
power consumption every 1 hour to the node of Group 1. The maximum interval to
report its instant power consumption is 45 hours (5s*32767/3600=45hr). Default
value is 1 hour. If the setting value is 0, the auto report function of meter Watt will be
disabled.
5-2 External switch ode
5-2-1 One ush Button：
When the configuration setting is One ush Button, only S1 input will be valid.
The control moving commands can be accepted in this switch mode while the
shutter is moving. In this switch mode, the inclusion/exclusion/reset function can
also be fulfilled by pressing S1 just like the operation of include button.
10
Inhaltsverzeichnis
Andere Philio Controller Handbücher
