Philips AZ1834/79 Bedienungsanleitung

www.philips.com/welcome

AZ1834

EN User manual

1 Important

Safety

a Read these instructions.

b Keep these instructions.

c Heed all warnings.

d Follow all instructions.

e Do not use this apparatus near water.

f Clean only with dry cloth.

g Do not block any ventilation openings. Install in accordance with the

manufacturer’s instructions.

h Do not install near any heat sources such as radiators, heat registers, stoves,

or other apparatus (including ampliﬁers) that produce heat.

i Protect the power cord from being walked on or pinched, particularly at

plugs, convenience receptacles, and the point where they exit from the

apparatus.

j Only use attachments/accessories speciﬁed by the manufacturer.

k Use only with the cart, stand, tripod, bracket, or table speciﬁed by

the manufacturer or sold with the apparatus. When a cart is used,

use caution when moving the cart/apparatus combination to avoid

injury from tip-over.

l Unplug this apparatus during lightning storms or when unused for long

periods of time.

m Refer all servicing to qualiﬁed service personnel. Servicing is required when

the apparatus has been damaged in any way, such as power-supply cord

or plug is damaged, liquid has been spilled or objects have fallen into the

apparatus, the apparatus has been exposed to rain or moisture, does not

operate normally, or has been dropped.

n Battery usage CAUTION – To prevent battery leakage which may result in

bodily injury, property damage, or damage to the unit:

Install all batteries correctly, + and - as marked on the unit.•

Do not mix batteries (old and new or carbon and alkaline, etc.).•

Remove batteries when the unit is not used for a long time.•

o Apparatus shall not be exposed to dripping or splashing.

p Do not place any sources of danger on the apparatus (e.g. liquid ﬁlled

objects, lighted candles).

q This product may contain lead and mercury. Disposal of these materials

may be regulated due to environmental considerations. For disposal or

recycling information, please contact your local authorities or the Electronic

Industries Alliance: www.eiae.org.

r Where the MAINS plug or an appliance coupler is used as the disconnect

device, the disconnect device shall remain readily operable.

Warning

Never remove the casing of this apparatus.•

Never lubricate any part of this apparatus.•

Never place this apparatus on other electrical equipment.•

Keep this apparatus away from direct sunlight, naked ﬂames or heat.•

Never look into the laser beam inside this apparatus.•

Ensure that you always have easy access to the power cord, plug or adaptor to disconnect this•

apparatus from the power.

Notice

Any changes or modiﬁcations made to this device that are not expressly approved

by Philips Consumer Lifestyle may void the user’s authority to operate the

equipment.

Environmental information

All unnecessary packaging has been omitted. We have tried to make the packaging

easy to separate into three materials: cardboard (box), polystyrene foam (buffer)

and polyethylene (bags, protective foam sheet.)

Your system consists of materials which can be recycled and reused if disassembled

by a specialized company. Please observe the local regulations regarding the disposal

of packaging materials, exhausted batteries and old equipment.

Windows Media and the Windows logo are trademarks, or registered

trademarks of Microsoft Corporation in the United States and/or other

countries.

This apparatus includes this label:

2 Your CD Soundmachine

Congratulations on your purchase, and welcome to Philips! To fully beneﬁt from the

support that Philips offers, register your product at www.philips.com/welcome.

Introduction

With this unit, you can enjoy audio from discs, USB devices, external devices, or radio

stations.

The unit supports the following media formats:

What’s in the box

Check and identify the contents of your package:

Main unit•

1 x AC power cord•

1 x MP3 link cable•

Quick start guide•

User manual•

Overview of the main unit

a Source selector

Turn on or off the unit, or select a source.•

Start or pause play.•

/Skip to the previous/next track.•

Search within a track/ disc/USB.•

Stop play or erase a program.•

PROG

Program tracks.•

c Display panel

Show current status.•

d ALBUM +/-

Skip to the previous/next album.•

e USB

Select the USB source.•

f CD

Select the disc source.•

g MODE

Select repeat play or random play.•

h OPEN/CLOSE

Open or close the disc compartment.•

i TUNING

Turn to select radio frequency.•

j VOLUME

Adjust volume.•

Jack for a USB mass storage device.•

AC MAINS~

AUX IN

l FM antenna

Improve FM reception.•

m AUX IN

Audio input jack (3.5mm ) for an external audio device.•

n AC MAINS

Jack for the supplied AC power cord.•

o Battery compartment door

3 Get started

Caution

Use of controls or adjustments or performance of procedures other than herein may result in•

hazardous radiation exposure or other unsafe operation.

Always follow the instructions in this chapter in sequence.

If you contact Philips, you will be asked for the model and serial number of this

apparatus.The model number and serial number are on the bottom of the apparatus.

Write the numbers here:

Model No. __________________________

Serial No. ___________________________

Select power supply

The unit can be operated by AC power or batteries.

AC power

Caution

Risk of product damage! Ensure that the power supply voltage corresponds to the voltage printed•

on the bottom of the unit.

Note

The type plate is located on the bottom of the main unit.•

1 Connect the AC power cable to:

the main unit.•

the wall socket.•

Battery power

Caution

Risk of explosion! Keep batteries away from heat, sunshine or ﬁre. Never discard batteries in ﬁre.•

1 Open the battery compartment on the bottom of the unit.

2 Insert 6 R14/UM2/C Cell batteries (not supplied) with correct polarity (+/-) as

indicated, then close the battery compartment.

3 The unit is ready to operate.

Note

Batteries contain chemical substances, so they should be disposed of properly.•

Turn on

1 Push the source selector to CD/USB/AUX, or FM or MW.

Turn off

1 Push the source selector to OFF.

4 Play

Play disc

1 Push the source selector to CD/USB/AUX.

2 Press CD to select the disc source.

3 Press OPEN/CLOSE to open the disc compartment.

4 Insert a disc with the printed side facing up, then close the disc compartment.

5 Press to start play.

To pause/resume play, press• .

To stop play, press• .

To select another track, press• / .

To select an album, press• ALBUM +/-.

To search within a track, press and hold• / , then release to resume

normal play.

Play from USB

Note

Ensure that the USB device contains playable audio contents for supported formats. (See “USB•

playability information”)

1 Plug the USB device into the socket of the unit.

2 Push the source selector to CD/USB/AUX.

3 Press USB to select the USB source.

4 Press ALBUM +/- to select a folder.

5 Press / to select an audio ﬁle.

6 Press to start play.

To pause/resume play, press• .

To stop play, press• .

To search within an audio ﬁle, press and hold• / , then release to

resume normal play.

5 Play options

Repeat and random play

1 Press MODE repeatedly to select:

[REP] (repeat): the current track is played repeatedly.•

[REP ALL] (repeat all): all tracks are played repeatedly.•

[SHUF] (shufﬂe): all tracks are played randomly.•

2 To return to normal play, press MODE repeatedly until play mode is no longer

displayed.

Tip

Shufﬂe play cannot be selected when you play programmed tracks.•

Program tracks

You can program a maximum of 20 tracks.

1 At CD/USB mode, in the stop position, press PROG to activate the program

mode.

[PROG] (program) is displayed.»

2 For MP3/WMA tracks, press ALBUM +/- to select an album.

3 Press / to select a track number, then press PROG to conﬁrm.

4 Repeat steps 2 to 3 to select and store all tracks to program.

5 Press to play the programmed tracks.

During play, [PROG] (program) is displayed.»

To erase the program, in the stop position, press• .

6 Adjust sound

Adjust volume

1 During play, turn VOLUME to increase/decrease the volume level.

7 Listen to radio

Tune to a radio station

1 Push the source selector to FM or MW.

2 Turn TUNING to tune to a station.

Tip

Position the antenna as far as possible from TV, VCR or other radiation source.•

For optimal reception, fully extend and adjust the position of the antenna.•

8 Listen to an external device

You can also listen to an external audio device through this unit.

1 Push the source selector to CD/USB/AUX.

2 Connect the supplied MP3 link cable to:

the• AUX IN jack (3.5mm) on the back of the unit.

the headphone jack on an external device.•

3 Start to play the device (refer to the device’s user manual).

9 Product information

Note

Product information is subject to change without prior notice.•
