Philips HD7761 Bedienungsanleitung

EN User manual 3

DA Brugervejledning 15

DE Benutzerhandbuch 27

FI Käyttöopas 40

FR Mode d’emploi 51

IT Manuale utente 63

KK Қолданушының нұсқасы 75

KO 사용 설명서 87

NL Gebruiksaanwijzing 99

NO Brukerhåndbok 113

RU  Руководствопользователя124

SV Användarhandbok 137

UK  Посібниккористувача 149

S-CN 用户手册 163

HD7761

1 Introduction

2 General description

1 Filter basket

2 Filter basket holder

3 Water level indicator

4 Water reservoir lid

5 Bean container lid

6 Coarseness knob

7 Coffee bean container

8 Lid of coffee bean chute

9 Coffee bean chute ejector

10 Water lling hole

11 Display

A Pre-ground coffee icon

B Number of cups

C Coffee cup icon

D Strength select coffee bean icon

E Strength select button

F Grinder clean button

12 On/off button

13 Glass jug lid

14 Glass jug

15 Cleaning brush

3 Important

Read this user manual carefully before you use the

appliance and save it for future reference.

3.1 Danger

•Never immerse the appliance in water or any

other liquid, nor rinse it under the tap.

3.2 Warning

•Check if the voltage indicated on the bottom

of the appliance corresponds to the local mains

voltage before you connect the appliance.

•If the mains cord is damaged, you must have it

replaced by Philips, a service centre authorised

by Philips or similarly qualied persons in

order to avoid a hazard.

•This appliance can be used by children aged

from 8 years and above and by persons with

reduced physical, sensory or mental capabilities

or lack of experience and knowledge if they

have been given supervision or instruction

concerning use of the appliance in a safe way

and if they understand the hazards involved.

•Cleaning and user maintenance shall not be

made by children unless they are older than

8 and supervised.

•Keep the appliance and its cord out of the

reach of children aged less than 8 years.

•Children should be supervised to ensure that

they do not play with the appliance.

•Do not let the mains cord hang over the

edge of the table or worktop on which the

appliance stands.

•Do not touch the grinding burrs of the

appliance, especially when the appliance is

connected to the mains.

•Keep the packaging materials (plastic bags,

cardboard buffers, etc.) out of the reach of

children, as they are not a toy.

•Do not touch the hot surfaces of the

appliance when it operates.

•This appliance is designed to grind beans and

make coffee. Use it correctly and with care to

avoid scalding by hot water and steam.

•Do not empty the water reservoir by tilting

the appliance, it can damage the appliance.

Only empty the water reservoir by following

the ush instruction.

•Do not use the appliance if the plug, the mains

cord or the appliance itself is damaged.

ENGLISH

4 Beforerstuse

4.1 Flushing the coffeemaker

You need to ush the coffeemaker once before

rst use.

1 Open the water reservoir lid. Fill the water

reservoir with fresh cold water up to the

8-cup indication.

DNote:

Do not put coffee beans or ground coffee in

the coffeemaker.

2 Close the water reservoir lid.

3 Put the jug in the appliance.

4 Press the on/off button.

•The display lights up.

•If a problem occurs that you cannot solve

by means of this user manual, contact the

Consumer Care Centre in your country. If the

problem cannot be solved, take the appliance

to a service centre authorised by Philips for

examination or repair. Do not attempt to

repair the appliance yourself, otherwise your

guarantee becomes invalid.

3.3 Caution

•Do not place the appliance on a hot surface

and prevent the mains cord from coming into

contact with hot surfaces.

•Unplug the appliance if problems occur during

grinding or brewing and before you clean it.

•Do not move the appliance while it is operating.

•The appliance becomes hot during use. Let

the appliance cool down before you store it.

•During brewing, the lower part of the appliance

and the bottom of the jug become hot.

•After you have unpacked the appliance, make

sure it is complete and undamaged. If in doubt,

do not use the appliance but contact the

Consumer Care Centre in your country.

•This appliance is intended for normal

household use only. It is not intended for

use in environments such as staff kitchens

of shops, ofces, farms or other work

environments. Nor is it intended to be used

by clients in hotels, motels, bed and breakfasts

and other residential environments.

3.4Electromagneticelds

(EMF)

This Philips appliance complies with all standards

regarding electromagnetic elds (EMF). If handled

properly and according to the instructions in this

user manual, the appliance is safe to use based on

scientic evidence available today.

5 Using the

coffeemaker

5.1 Filling the water reservoir

1 Open the water reservoir lid and ll the water

reservoir with the required amount of cold water.

When you open the water reservoir lid, there

are indications for 2 to 10 cups on the inside

of the appliance.You can use these indications

to determine how much water to put in the

water reservoir.

DNote:

Do not ll the water reservoir beyond the

10-cup indication.

5.2 Using coffee beans

We advise you to use light roasted coffee beans to

brew the perfect cup of coffee. If you like stronger

coffee you can use dark roasted espresso beans.

BWarning:

Always keep the water reservoir lid closed when

youllthecoffeebeancontainerwithcoffee

beans.Otherwisecoffeebeanscanfallintothe

water reservoir and block up the water inlet.

5 Press the strength select button.

6 Turn the knob to choose the pre-ground

coffee setting.

•The pre-ground coffee icon lights up.

7 Press in the centre of the knob to conrm.

Then press in the centre of the knob again to

start the ushing process.

8 Let the coffeemaker operate until the ushing

process has been completed.

9 Press the on/off button to switch off the

coffeemaker.

10 Empty the jug.

4 Take a paper lter (type 1x4 or no. 4) and fold

the sealed edges to prevent tearing and folding.

Place the paper lter in the lter basket.

5 Close the lter basket holder.

6 Put the jug in the appliance.

7 Turn the coarseness knob to select the

desired type of grind (from ne to coarse).

ETip:

The coarseness knob allows you to choose

between nine different settings.We preselected

3 optimal settings but you can also choose any

setting in between the icons.We advise you to

experiment with the different grind settings to

nd out which setting you prefer.

1 Remove the coffee bean container lid.

2 Fill the coffee bean container with coffee

beans. Make sure there are enough coffee

beans in the container for the amount of

coffee you want to brew.

DNote:

Always make sure the coffee bean container is

at least half full.

BWarning:

Topreventthegrinderfromjamming,donot

use unroasted or caramelised beans as this

may cause damage.

3 To open the lter basket holder, pull at its tab

on the right side of the coffeemaker.

11 Press the strength select button.

•The coffee bean icons start to ash.

12 Turn the knob to select the desired coffee

strength (mild: 1 bean, medium: 2 beans or

strong: 3 beans).

•The display shows the selected coffee strength.

ETip:

We advise you to experiment with

the amount of water to nd out which

strength you prefer. If you select a number

of cups that is higher than the amount of

water, the coffee becomes stronger. If you

select a number of cups that is smaller

than the amount of water, the coffee

becomes weaker.

8 Press the on/off button on the front of the

coffeemaker.

•The number of cups starts to ash.

9 To select the number of cups, turn the knob

until the desired number of cups appears on

the display.

DNote:

Make sure that the number of cups you select

with the 2-10 cups button is consistent with

the amount of water in the water reservoir.

Please keep in mind that the coffeemaker

uses all the water in the water reservoir. If you

select a number of cups that is smaller than

the amount of water, the coffee becomes

weaker than you intended.

10 Press in the centre of the knob to conrm the

number of cups.

ENGLISH

2 To open the lter basket holder, pull at its tab

on the right side of the coffeemaker.

3 Take a paper lter (type 1x4 or no. 4) and fold

the sealed edges to prevent tearing and folding.

Place the paper lter in the lter basket.

4 Put pre-ground coffee in the paper lter.

DNote:

You can adjust the strength of the coffee to

your own personal taste. For a medium-strong

cup of coffee, use one measuring spoon

(approximately 6g) of ground coffee for each

cup (120ml). For stronger coffee, use

1.5 measuring spoons of ground coffee for

each cup of coffee.

5 Close the lter basket holder.

6 Put the jug in the appliance.

13 Press in the centre of the knob to conrm,

Then press in the centre of the knob again to

start the brewing process.

•The grinder grinds the required amount of

coffee beans.

14 Wait until the coffeemaker has stopped

brewing before you remove the jug.

DNote:

After brewing, coffee drips from the lter

basket for several seconds.

15 Press the on/off button to switch off the

coffeemaker.

5.3 Using pre-ground coffee

If you want to use pre-ground coffee instead of

coffee beans, follow the steps below.

1 Open the water reservoir lid and ll the water

reservoir with the required amount of cold water.

11 Wait until the coffeemaker has stopped

brewing before you remove the jug.

DNote:

After brewing, coffee drips from the lter

basket for several seconds.

12 Press the on/off button to switch off the

coffeemaker.

5.4 Drip stop function

The drip stop function enables you to remove

the jug from the coffeemaker before the brewing

process is nished. When you remove the jug, the

drip stop stops the ow of coffee into the jug.

DNote:

The brewing process does not stop when you

remove the jug. If you do not put the jug back

into the appliance within 20 seconds, the lter

basket overows.

6 Cleaning and

maintenance

6.1 Cleaning after every use

BWarning:

Never immerse the appliance in water or any

otherliquid,norrinseitunderthetap.

1 Press the on/off button to switch off the

coffeemaker.

7 Press the on/off button.

•The display lights up.

8 Press the strength select button.

9 Turn the knob to choose the pre-ground

coffee setting.

•The pre-ground coffee icon lights up.

10 Press in the centre of the knob to conrm.

Then press in the centre of the knob again to

start the brewing process.

ENGLISH

3 Take a paper lter (type 1x4 or no. 4) and

fold the sealed edges to prevent tearing and

folding. Place the paper lter in the lter

basket.

4 Close the lter basket holder.

5 Insert the at end of the cleaning brush

handle into the lock of the coffee bean chute

and press it down.

DNote:

If you switch coffee beans and you do not

want the residue of the old beans to affect

the taste of the new coffee beans you can

clean the coffee bean chute quickly by brush

only, continue with step 7. If you want to

clean the coffee bean chute thoroughly, please

continue with step 6.

6 Press and hold the grinder clean button for

4 seconds.

2 Remove the mains plug from the wall socket.

3 Wipe the outside of the coffeemaker with a

damp cloth.

4 Clean the lter basket and the jug in the

dishwasher or with hot water and some

washing-up liquid.

6.2 Cleaning the coffee bean

chute

DNote:

Make sure the coffee bean container is empty

before you start the cleaning procedure.

1 Press the on/off button to switch off the

coffeemaker.

2 To open the lter basket holder, pull at its tab

on the right side of the coffeemaker.

Andere Handbücher für HD7761

Inhaltsverzeichnis

Sprachen:

Andere Philips Kaffeemaschine Handbücher

Philips

Philips SENSEO HD7827 Bedienungsanleitung

Philips

Philips HD7814/60 Bedienungsanleitung

Philips

Philips HD5665/90 Bedienungsanleitung

Philips

Philips CAFE GAIA HD7544/20 Bedienungsanleitung

Philips

Philips HD8327/09 Bedienungsanleitung

Philips

Philips 1200 Series Bedienungsanleitung

Philips

Philips Senseo HD7863/80 Bedienungsanleitung

Philips

Philips HD8752/05 Bedienungsanleitung

Philips

Philips L'OR Barista Bedienungsanleitung

Philips

Philips Cucina HD7502 Bedienungsanleitung

Philips

Philips Essence Bedienungsanleitung

Philips

Philips HD7444 Bedienungsanleitung

Philips

Philips Senseo Viva Cafe HD6569 Bedienungsanleitung

Philips

Philips HD8831/00 Montageanleitung

Philips

Philips HD3002/00 Bedienungsanleitung

Philips

Philips HD7762 Bedienungsanleitung

Philips

Philips HD7762 Bedienungsanleitung

Philips

Philips HD5730/10 Bedienungsanleitung

Philips

Philips HD8856/04 Bedienungsanleitung

Philips

Philips Syntia HD8833 Bedienungsanleitung

Philips

Philips Cafe Essence HD 7605/A Bedienungsanleitung

Philips

Philips HD5120/00 Bedienungsanleitung

Philips

Philips Senseo HD7842 Bedienungsanleitung

Philips

Philips HD5412 Bedienungsanleitung

Beliebte Kaffeemaschine Handbücher anderer Marken

Taurus

Taurus Livorno 6 Bedienungsanleitung

Delta-q

Delta-q QUICK Bedienungsanleitung

Bunn

Bunn LCA-1 Fehlerbehebungshandbuch

Black & Decker

Black & Decker BLACK DECKER HOME DE790 Montageanleitung

Saeco

Saeco Vienna Plus Sup 018M Bedienungsanleitung

DeLonghi

DeLonghi DC300 Bedienungsanleitung

INCAPTO

INCAPTO BXCO1470E Bedienungsanleitung

Bosch

Bosch TASSIMO finesse TAS16B Series Bedienungsanleitung

Exido

Exido 245-072 Bedienungsanleitung

Animo

Animo OptiVend Choco Bedienungsanleitung

Siemens

Siemens TQ505DF Series Bedienungsanleitung

DeLonghi

DeLonghi ECI341 Bedienungsanleitung

Krups

Krups KT406511 Bedienungsanleitung

Cimbali

Cimbali M32 Classic Bedienungsanleitung

Bosch

Bosch TES 515 SERIES Bedienungsanleitung

Tekmatix

Tekmatix TMFM - 65 Bedienungsanleitung

Scarlett

Scarlett SC-CM33005 Bedienungsanleitung

LAVAZZA

LAVAZZA CLASSY PLUS Bedienungsanleitung
