Philips HD8856/05 Bedienungsanleitung

QUICK START GUIDE - 快速使用指南

Before using the machine, please read the instruction manual completely.

Carefully read the safety regulations provided in the instruction manual.

使用机器前，请阅读所附的操作说明。

仔细阅读安全守则。

The manufacturer reserves the right to make changes without prior notice.

制造商保留更改产品功能的权利，恕不另行通知。

Type HD8854 / HD8856 - Cod.15002586 - Rev.01 - del 15-05-10

Type HD8854 / HD8856

ACCESSORIES  附件

Intenza water lter

Intenza水过滤器

Cleaning brush

清洁刷

Descaling solution

除垢液

Brew group lubricant

冲煮头组件润滑油

Power cord

电源线

Water hardness tester

水硬度测试条

Brew group cleaning tablets

冲煮头组件清洁剂

Pre-ground coee measuring scoop

预磨咖啡粉量勺

Milk carafe

牛奶玻璃瓶

Door opening button

开门按钮 Power cord connector

电源线连接器

Power button

电源按钮

Water tank

水罐

Coee bean hopper with lid

咖啡豆加料斗（盖）

Grinder adjustment

磨具调节装置

Control panel

控制面板

Milk carafe connector

牛奶玻璃瓶连接器

Dispensing spout

分配头

Drip tray + grill

废水盘 + 格栅

Pre-ground bypass doser

粉末填充槽

Service door

服务门

SBS dial

SBS旋钮

Hot water/steam wand

热水/蒸汽棒

Full drip tray indicator

废水盘满指示灯

Brew group

冲煮头组件

Used grounds drawer

咖啡渣废物盘 Liquid recovery tray

液体回收盘

Remove the covers. Fill the hopper with

coee beans, then close the covers.

取下盖子，向咖啡豆加料斗中

添加咖啡豆，然后盖上盖子。

Insert the plug into the socket located on the

back of the machine and insert the other end

into a power outlet with suitable current.

把电源线一端插入机器背部电

源插孔，另一端插入可用的电

源接口。

Adjust the dispensing spout and place a cup

beneath it.

调节分配头，然后在其下放置

一个咖啡杯。

Set the power button to the“I”position. Press

the stand-by button to start the machine.

将电源按钮调整到“I”位置。

按待机按钮打开机器。

(Only for beverages with milk) Rotate the

handle clockwise and press on the disen-

gage buttons to allow the lid removal.

（仅适合冲泡牛奶类饮料）。

顺时针旋转控制手柄，按下释

放锁按钮，取下盖子。

Fill the carafe with cold milk. Fill milk to above

the“min”line, but do not exceed the“max”

level indicated on the carafe. Replace the lid.

向玻璃瓶中注入冷牛奶。使牛

奶超过玻璃瓶上指示的MIN最

低刻度线，但不应超过MAX最大

刻度线。

STARTING THE MACHINE  启动机器

Before turning on the machine, make sure that the power button is set to“0”.

开机前，确保电源按钮被设置在“0”位置

Remove the covers. Remove the water tank.

取下盖子，把水罐取下。

Fill the tank with fresh drinking water. Do not ex-

ceed the“max”level indicated on the water tank.

Place the water tank back into the machine.

向水罐中注入新鲜的饮用水。请

勿超过水罐上的MAX最大刻度。

然后将水罐放回机器上。

当牛奶玻璃瓶不打算使用或使用

后，应存放到冰箱中。

When the carafe with milk is not going to

be used, or after using it, store it in the

refrigerator.

Insert the carafe inclined towards the front. The

carafe base should be positioned on the hole

(E) located on the drip tray. Insert the carafe

by turning it towards the base through a round

movement (as shown in the gure), until it is

hooked to the hole (E) located in the drip tray.

The carafe will be naturally back in place.

将玻璃瓶倾斜向前插入。

玻璃瓶底座应置入废水盘的孔（E）

中。

通过向基座方向旋转将玻璃瓶（如图

所示），直到完全卡入到废水盘的孔

（E）中。

玻璃瓶将自动回到原来位置。

1 2 3

45 6

7 8 9

Press the espresso or long espresso button.

Press once for 1 cup and twice for 2 cups.

If you wish to save the quantity of espresso

being brewed, press and hold for 3 seconds.

按意式浓咖啡或淡咖啡按钮。

按1次冲泡1杯咖啡，按2次冲泡

2杯咖啡。

如果您想记忆意式浓咖啡冲泡

量，按住该按钮，持续3秒。

The machine starts grinding the selected

coee quantity.

机器开始研磨所选择的咖啡

量。

Coee brewing can be stopped at any time by

pressing the“STOP”button.

Press“STOP”to save the quantity.

随时按“STOP”按钮，可停止

咖啡冲泡。

按“STOP”按钮，保存数量。

CONTROL PANEL  控制面板

The control panel has been designed to allow an ergonomic use of all machine functions.

控制面板的设计，使机器的所有功能符合人体工程学的使用。

ESPRESSO / COFFEE / LONG COFFEE  浓咖啡 /常规咖啡/谈咖啡

Cappuccino button

卡布其诺按钮

Stand-by button

待机按钮

玻璃瓶清洁循环激活按钮

最佳剂量按钮

Carafe cleaning cycle activation button

Opti-dose button

Function buttons

功能按钮

Espresso button Coee button Programming MENU button

浓咖啡按钮常规咖啡按钮编程菜单按钮

谈咖啡按钮

Long coee brew button

Special beverage button

特别饮料按钮

ESPRESSO

STOP

ESPRESSO

STOP

CAPPUCCINO  卡布其诺

WARNING: DISPENSING MAY BE PRECEDED BY SHORT SPURTS OF HOT WATER AND SCALDING IS POSSIBLE.

在开始冲泡阶段，机器可能会分配出水：烫伤危险！

CAPPUCCINO

PLEASE WAIT …

CAPPUCCINO

PLEASE WAIT …

CAPPUCCINO

STOP

CAPPUCCINO

STOP

CAPPUCCINO

STOP

CAPPUCCINO

STOP

Place a container and rotate the handle

clockwise.

Press the button corresponding to the

desired beverage.

The machine starts brewing: it grounds the

coee and warms up to dispense milk.

At the end remove the cup with the bever-

age and replace the upper part of the milk

carafe.The rinse cycle begins.

(see the manual on page 17).

Milk dispensing begins.This operation can

be stopped by pressing“STOP”.

Once milk has been dispensed, the machine

starts brewing the coffee. This operation can

be stopped by pressing“STOP”.

最后，取走盛有饮料的杯子，

并将牛奶玻璃瓶的上部原件放

回。冲洗循环开始。

（详见本手册第17页）。

开始分配出牛奶。按“STOP”

（停止）按钮可停止此操作。

一旦牛奶分配完成，机器将开

始冲泡咖啡。按“STOP” （停

止）按钮可停止此操作。

放置一容器，并顺时针旋转手

柄。

按所需饮料对应的按钮。机器开始冲泡：研磨咖啡并加

热分配牛奶。

HOT WATER DISPENSING  煲热水

WARNING: DISPENSING MAY BE PRECEDED BY SHORT SPURTS OF HOT WATER AND SCALDING IS POSSIBLE.

警告：分配时会少量的热水喷出，容易烫伤。

STEAM DISPENSING  煲蒸汽

WARNING: DISPENSING MAY BE PRECEDED BY SHORT SPURTS OF HOT WATER AND SCALDING IS POSSIBLE.

警告：分配时会少量的热水喷出，容易烫伤。

HOT MILK

HOT WATER

STEAM

SPECIAL BEVERAGES

HOT MILK

HOT WATER

STEAM

SPECIAL BEVERAGES

Place a container under the hot water wand.

Press the“SPECIAL”button.

在热水棒下放置一容器。

按“SPECIAL”（特别）按钮。

At the end, take the container. Repeat the

process to dispense another dose.

最后，取走容器。重复这一操

作过程，可分配其它剂量。

Select “HOT WATER”by pressing button

() or ( ). Press the“OK”button.

按 ( ) 或 ( ) 按钮选

择“HOT WATER”（热水），

按“OK”（确认）按钮。

Place a container under the steam wand.

Press the“SPECIAL”button.

在蒸汽棒下放置一容器。

按“SPECIAL”（特别）按钮。

Select “STEAM”by pressing button ( ) or

(). Press the“OK”button.

按 ( ) 或 ( ) 按钮选

择“HOT WATER”（热水），

按“OK”（确认）按钮。

Press“STOP”to stop dispensing.

按“STOP”（停止）停止分

配。

HOT WATER

STEAM

SPECIAL BEVERAGES

HOT WATER

STEAM

SPECIAL BEVERAGES

MAINTENANCE DURING OPERATION  操作期间的维护

Operations to be performed with machine turned on when the following messages are displayed:“Empty coee grounds drawer”and/or“Empty drip tray”.

当机器开启状态，显示下列信息时，可以执行操作：“Empty coffee grounds drawer”和/或

“Empty drip tray”。

Press the button and open the service door.

按此按钮，打开服务门。

Remove the drip tray and used grounds

drawer.

取下废水盘和咖啡渣废物盘。

Empty the used grounds drawer and the drip

tray, wash and replace back into machine.

倒空咖啡渣废物盘和废水盘，用

水清洗，然后放回机器上。

GENERAL MACHINE CLEANING  一般机器清洁

The cleaning procedure described below must be carried out at least once a week.

每周必须至少执行一次以下清洁程序.

Take out the water tank and wash it with

fresh water.

取下水罐使用新鲜的饮用水清

洁。

Turn o the machine and unplug it.

关闭机器拔下电源。

Remove the drip tray.

取下废水盘。

Remove the dispensing spout and wash it

under running water.

取下分配头，用水清洗。

Clean the pre-ground bypass doser with a

dry cloth.

用干布清洁粉末填充槽。

Clean the steam wand and the display with

a dry cloth.

用干布清洁蒸汽棒与显示屏。

1 2 3

21 3

4 5 6

MACHINE WARNINGS  机器警告

Message How to Reset the Message 信息如何重设信息

HOPPER DOOR

Close the coee bean hopper lid.

HOPPER DOOR

正确将咖啡豆料斗内盖关/盖

好，以便能制备出饮料。

ADD COFFEE

Fill the coee bean hopper with coee beans.

ADD COFFEE

向咖啡豆加料斗中加入咖啡豆。

INSERT BREW GROUP

Insert the brew group back in place.

INSERT BREW GROUP

将冲煮头组件插入机器。

INSERT COFFEE

GROUNDS DRAWER

Insert the used grounds drawer.

INSERT COFFEE

GROUNDS DRAWER

插入咖啡渣废物盘。

EMPTY COFFEE

GROUNDS DRAWER

Open the service door and empty the liquid

recovery tray, located under the brew group,

and the used grounds drawer.

The used grounds drawer must be emp-

tied only when the machine requires it

and with the machine on.

EMPTY COFFEE

GROUNDS DRAWER

打开服务门，并倒空冲煮头组

件下的液体回收盘和咖啡渣废

物盘。

仅当机器需要倒空并且机器处于

开启状态下，必须倒空咖啡渣废

物盘。

FRONT DOOR

Close the service door.

FRONT DOOR

关闭服务门。

REFILL

WATER TANK

Remove the water tank and rell it with fresh

drinking water.

REFILL

WATER TANK

取下水罐并注入新鲜的可饮用

水。

EMPTY DRIP TRAY

Open the service door and empty the liquid

tray, located under the brew group, and the

used grounds drawer.

EMPTY DRIP TRAY

打开服务门，并倒空冲煮头组

件下的液体回收盘和咖啡渣废

物盘。

TURN CARAFE

INTO

BREWING POSITION

ESC

A beverage with milk has been selected. Press

the“ESC”button to cancel the selection.

TURN CARAFE

INTO

BREWING POSITION

ESC

选定牛奶类饮料。按“ESC”按

钮，取消选择。

TURN CARAFE

INTO

RINSING POSITION

ESC

The carafe rinse function has been selected.

Press the“ESC”button to cancel the selection.

TURN CARAFE

INTO

RINSING POSITION

ESC

玻璃瓶重新功能被选定。

按“ESC”按钮，取消选择。

INSERT CARAFE

ESC

An operation has been selected that requires

dispensing milk from the milk carafe. Press the

“ESC”button to cancel the selection.

INSERT CARAFE

ESC

从牛奶玻璃瓶分配牛奶功能被

选定。按“ESC”按钮，取消选

择。

Perform a descaling cycle on the machine.

Damages caused by failure to descale the

machine are not covered by warranty.

对机器执行除垢循环。因未对机

器除垢所导致的损坏不在本产品

担保责任范围之内。

Flashing red light. Machine in Stand-by.

Press the “ ”button.

闪烁红灯。机器处于待机状态。

按 “ ” 键。

RESTART TO SOLVE

An event has occurred which requires the

machine to restart.Take note of the code (E xx)

shown at the bottom.

Switch o the machine, wait 30 seconds and

then switch it on again. If the problem persists,

contact an authorized service center.

RESTART TO SOLVE

出现事件需要机器重启时。

注意底部的错误代码（E xx）。

关闭机器，等待30秒钟后，然后

重新开启。如果故障一直不能解

决，请联系服务中心。

Dieses Handbuch passt für folgende Modelle

Andere Philips Kaffeemaschine Handbücher

Philips

Philips Cucina HD7502 Bedienungsanleitung

Philips

Philips HD7825/60 Bedienungsanleitung

Philips

Philips Senseo Twist HD7870/60 Bedienungsanleitung

Philips

Philips HD7980/70 Bedienungsanleitung

Philips

Philips HD8825 Bedienungsanleitung

Philips

Philips SENSEO HD7854 Bedienungsanleitung

Philips

Philips HD8829 Bedienungsanleitung

Philips

Philips Grind & Brew HD7761/01 Bedienungsanleitung

Philips

Philips HD7448 Bedienungsanleitung

Philips

Philips HD7853 Bedienungsanleitung

Philips

Philips HD8847 Bedienungsanleitung

Philips

Philips HD7762/00 Bedienungsanleitung

Philips

Philips Senseo HD7858 Bedienungsanleitung

Philips

Philips HD8832/09 Bedienungsanleitung

Philips

Philips Saeco Syntia HD8836 Bedienungsanleitung

Philips

Philips HD5120 Bedienungsanleitung

Philips

Philips Saeco INCANTO HD8913 Bedienungsanleitung

Philips

Philips SENSEO HD7854 Bedienungsanleitung

Philips

Philips Saeco Cafissimo LATTE Bedienungsanleitung

Philips

Philips EP5930 Bedienungsanleitung

Philips

Philips HD7762/00/C Bedienungsanleitung

Philips

Philips HD8827/12 Bedienungsanleitung

Philips

Philips Saeco PICOBARISTO SM3054 Bedienungsanleitung

Philips

Philips Xsmall 2000 Series Bedienungsanleitung

Beliebte Kaffeemaschine Handbücher anderer Marken

Taurus

Taurus Livorno 6 Bedienungsanleitung

Delta-q

Delta-q QUICK Bedienungsanleitung

Bunn

Bunn LCA-1 Fehlerbehebungshandbuch

Black & Decker

Black & Decker BLACK DECKER HOME DE790 Montageanleitung

Saeco

Saeco Vienna Plus Sup 018M Bedienungsanleitung

DeLonghi

DeLonghi DC300 Bedienungsanleitung

INCAPTO

INCAPTO BXCO1470E Bedienungsanleitung

Bosch

Bosch TASSIMO finesse TAS16B Series Bedienungsanleitung

Exido

Exido 245-072 Bedienungsanleitung

Animo

Animo OptiVend Choco Bedienungsanleitung

Siemens

Siemens TQ505DF Series Bedienungsanleitung

DeLonghi

DeLonghi ECI341 Bedienungsanleitung

Krups

Krups KT406511 Bedienungsanleitung

Cimbali

Cimbali M32 Classic Bedienungsanleitung

Bosch

Bosch TES 515 SERIES Bedienungsanleitung

Tekmatix

Tekmatix TMFM - 65 Bedienungsanleitung

Scarlett

Scarlett SC-CM33005 Bedienungsanleitung

LAVAZZA

LAVAZZA CLASSY PLUS Bedienungsanleitung
