Philips HTS3011 Bedienungsanleitung

3Enjoy

What’s in the box?

Start disc playback

APress çto open the disc tray.

BPlace a disc with the disc label facing up.

CPress çto close the disc tray.

DPlayback starts automatically.

EIf the disc menu appears on the TV, use  

keys or the numeric keypad to select an option in

the menu and press OK to start playback.

FPress to stop playback.

Note When you press ubutton,

playback resumes from where it last stopped.

To start playback from the beginning, you

have to press .

Need help?

User Manual

See the user manual that came with your Philips DVD Home Theatre System.

2008 CKoninklijke Philips N.V.

www.philips.com

Listen to radio

APress RADIO.

The display panel will show “AUTO INSTALL ....

PRESS PLAY”.

BPress u.

All the available radio stations with strong reception

signal will be stored automatically.

Note This feature is only available for the rst time

setup. If you wish to reinstall all the radio stations,

press and hold REPEAT (PROGRAM) until ‘START’

appears on the display panel.

COnce complete, use íë keys or numeric keypad

(0-9) to select a preset radio station.

DTo delete a preset radio station, press and hold x

until “FM/AM/MW X DELETED” appears.

Experience surround sound

APress SURROUND to switch between Multi-

Channel, Stereo sound or Party sound.

BPress SOUND MODE +- to select a preset

digital sound effect.

www.philips.com/welcome

Quick Start Guide

Connect

Set up

Enjoy

HTS3011

Main Unit Remote Control

and 2 batteries

User

Manual

1 centre, 2 front, 2 rear speakers

and subwoofer

FM wire antenna

Composite

video cable

hts3011_98_qsg_eng_final808.indd1 1hts3011_98_qsg_eng_final808.indd1 1 2008-02-21 4:25:44 PM2008-02-21 4:25:44 PM

1Connect

Placement

Proper speakers system placement is important to

ensure optimum sound performance.

FRONT

RIGHT

FRONT

LEFT

CENTER

REAR

RIGHT

REAR

LEFT

SUBWOOFER

APlace the centre speaker above or close to the TV.

BPlace the subwoofer on the floor, at least one metre

away from the TV.

CPlace the front speakers at equal distances from the

TV.

DPlace the rear speakers at the back or beside the

listening position.

Connect the main unit to TV

VIDEOIN

(CVBS)

VIDEO IN

(CVBS)

zUse the supplied composite video cable to connect

the CVBS socket on the main unit to the VIDEO IN

socket on your TV.

Note It is important to connect the main unit

directly to your TV.

2Set up

Connect the speakers and subwoofer

Connect the various coloured plugs from the speakers

and subwoofer to the same coloured sockets at the rear

of the main unit.

Finding the viewing channel

APress STANDBY-ON on the main unit to turn it

on.

BTurn on the TV. Use the TVs remote control to

select the correct viewing channel.

Note To search for the correct viewing channel,

press the Channel Down button on the TVs remote

control repeatedly (or AV, SELECT, °button) until

you see the Video In channel.

Select the display language on the

screen

APress OPTIONS.

The { General Setup } appears.

BPress

.

Press OPTIONS to exit menu

General Setup

Disc Lock

Display Dim

OSD Language

Screen Saver

DivX(R) VOD Code

Sleep

English

Malayu

CUse  keys to select { OSD Language } and press

.

DUse  keys to select a language option in the

menu and press OK to confirm.

EPress OPTIONS to exit.

Note The language set here is only for the menus

that are shown on the TV while operating this Home

Theatre system, not for the DVD disc menu.

There are various setup options (Audio Setup, Video

Setup, Preferences) available on this Home Theatre

System. Refer to the user manual for more information.

Connect the radio antenna and

power cable

Keep the antennas away from the electronic devices to

prevent unwanted interference.

AConnect the FM antenna (supplied) to the inner pin

of the FM 75 socket. (For some models, it has

been connected in the factory.) Extend the wire for

optimum reception.

Bthe power cable from the main unit to the AC

power outlet.

Connect audio output from TV

(optional)

To hear the TV audio through this unit, use a red and

white audio cables (not supplied) to connect the

AUDIO IN-AUX sockets on the main unit to the

AUDIO OUT sockets on your TV.

AUDIO

OUT

AUDIOIN

AUDIO

OUT

AUDIOOUT

Note When watching the TV programs, you can

press AUX repeatedly on the remote control until

‘AUX1’ or ‘AUX2’ is displayed to get the sound output

from the speakers.

Television (rear)

Main Unit (rear)

FM antenna

SUBWOOFER

FRONT

RIGHT

FRONT

LEFT REAR

RIGHT

REAR

LEFT

FRONT CENTER

Main Unit (rear)

Main Unit (Front)

TV (rear)

Main Unit (rear)

hts3011_98_qsg_eng_final808.indd2 2hts3011_98_qsg_eng_final808.indd2 2 2008-02-21 4:25:48 PM2008-02-21 4:25:48 PM
