Philips HTS3181X Bedienungsanleitung

www.philips.com/welcome

HTS3181

EN User manual

ES Manual del usuario

PT-BR Manual do Usuário

México

Es necesario que lea cuidadosamente su

instructivo de manejo.

Descriptión:

Modelo:

Alimentacón:

Consumo:

Importador: Philips Mexicana, S.A. de C.V.

Domicilio: Av. La Palma No. 6,

Col. San Fernando, La Herradura

Huixquilucan, Edo de Mexico

C.P. 52784, Mexico

Localidad y Tel.: Tel. 52 69 90 00

Exportador: Philips Electronics HK, Ltd.

País de Origen: China

de Serie:

LEA CUICADOSAMENTE ESTE INSTRUCTIVO

ANTES DE USAR SU APARATO.

AVISO IMPORTANTE

Philips Mexicana, S.A. de C.V. no se hace responsable por daños o desperfectos causados por:

– Maltrato, descuido o mal uso, presencia de insectos o roedores (cucarachas, ratones etc.).

– Cuando el aparato no haya sido operarado de acuerdo con el instructivo del uso, fuera de los

valores nominales y tolerancias de las tensiones (voltaje), frecuencia (ciclaje) de alimentación

elétrica y las características que deben renuir las instalaciones auxiliares.

– Por fenómenos naturales tales como: temblores, inundaciones, incendios, descargas electricas,

rayos etc. o delitos causados por terceros (choques asaltos, riñas, etc.).

Evite o uso prolongado do aparelho

com volume superior a 85 decibéis pois

isto poderá prejudicar a sua audição.

Nível de Exemplos

Decibéis

30 Biblioteca silenciosa,

sussurros leves

40 Sala de estar, refrigerador,

quarto longe do trânsito

50 Trânsito leve, conversação

normal, escritório silencioso

60 Ar condicionado a uma distância

de 6 m, máquina de costura

70 Aspirador de pó, secador de cabelo,

restaurante ruidoso

80 Tráfego médio de cidade, coletor

de lixo, alarme de despertador

a uma distância de 60 cm

OS RUÍDOS ABAIXO PODEM SER PERIGOSOS

EM CASO DE EXPOSIÇÃO CONSTANTE

90 Metrô, motocicleta, tráfego de

caminhão, cortador de grama

100 Caminhão de lixo, serra elétrica,

furadeira pneumática

120 Show de banda de rock em frente

às caixas acústicas, trovão

140 Tiro de arma de fogo, avião a jato

180 Lançamento de foguete

Sistema de cine en casal

HTS3181

110-240V;~50-60 Hz

60W

7 Adjust settings 27

General setup 27

Audio setup 28

Video setup 29

Preferences 30

8 Additional Information 32

Update software 32

Care 32

9 Speciﬁcations 33

10 Troubleshooting 35

11 Glossary 37

Contents

1 Important 4

Safety and important notice 4

Trademark notice 5

2 Your HomeTheater System 6

Feature highlights 6

Product overview 6

3 Connect 9

Place the HomeTheater System 9

Connect video cables 9

Connect speakers and subwoofer 11

Connect radio antenna 11

Connect audio cables/other devices 11

Connect power cord 12

4 Get started 13

Insert the remote control batteries 13

Find the correct viewing channel 14

Select menu display language 14

Turn on Progressive Scan 14

Change speaker settings 15

Select a play source 16

5 Play 17

Play a disc 17

Play video 17

Play music 20

Play photo 21

Play from USB device 23

Play from radio 23

6 Adjust sound 25

Control the volume 25

Select surround sound 25

Select a preset sound 25

Adjust microphone volume level 26

Karaoke settings 26

Turn off vocal (cancel voice) 26

Contents English

This product incorporates copyright

protection technology that is protected

by method claims of certain U.S. patents

and other intellectual property rights

owned by Macrovision Corporation and

other rights owners. Use of this copyright

protection technology must be authorised

by Macrovision Corporation, and is intended

for home and other limited viewing uses only

unless otherwise authorised by Macrovision

Corporation. Reverse engineering or

disassembly is prohibited.

About Progressive Scan

Consumers should note that not all high

deﬁnition television sets are fully compatible

with this product and may cause artifacts to

be displayed in the picture. In case of 525

or 625 progressive scan picture problems,

it is recommended that the user switch the

connection to the ‘standard deﬁnition’ output.

If there are questions regarding our TV set

compatibility with this model 525p and 625p

DVD player, please contact our customer

service center.

1 Important

Safety and important notice

Warning

Risk of overheating! Never install the Home• Theater System in a conﬁned space. Always

leave a space of at least 4 inches around the

Home Theater System for ventilation. Ensure

curtains or other objects never cover the

ventilation slots on the Home Theater System.

Never place the Home Theater System,• remote control or batteries near naked ﬂames

or other heat sources, including direct sunlight.

Only use this Home Theater System indoors.• Keep this Home Theater System away from

water, moisture and liquid-ﬁlled objects.

Never place this Home Theater System on• other electrical equipment.

Keep away from this Home Theater System• during lightning storms.

Where the mains plug or an appliance• coupler is used as the disconnect device,

the disconnect device shall remain readily

operable.

Visible and invisible laser radiation when open.• Avoid exposure to beam.

Recycle notice

This electronic equipment contains a large

number of materials that can be recycled

or reused if disassembled by a specialized

company. If you are disposing of an old

machine, please take it to a recycling center.

Please observe the local regulations regarding

disposal of packaging materials, exhausted

batteries and old equipment.

CLASS 1

LASER PRODUCT

Trademark notice

Manufactured under license from Dolby

Laboratories. Dolby, Pro Logic and the

double-D symbol are trademarks of Dolby

Laboratories.

DivX, DivX Ultra Certiﬁed, and associated

logos are trademarks of DivX, Inc. and are

used under license.

Ofﬁcial DivX® Ultra Certiﬁed product.

Plays all versions of DivX ® video (including

DivX ® 6) with enhanced playback of DivX®

media ﬁles and the DivX® Media Format.

Plays DivX® video with menus, subtitles and

audio tracks.

Windows Media and the Windows logo are

trademarks, or registered trademarks of

Microsoft Corporation in the United States

and/or other countries.

The USB-IF Logos are trademarks of Universal

Serial Bus Implementers Forum, inc.

ENERGY STAR and the ENERGY STAR mark

are registered U.S. marks.

Important English

Region codes

You can play discs with the following region

codes.

DVD region code Countries

Latin America

Product overview

Remote control

a (Standby-On)

Turns on the Home Theater System• or switches to standby mode.

2 Your Home

Theater System

Congratulations on your purchase,and

welcome to Philips!To fully beneﬁt from the

support that Philips offers,register your product

at www.philips.com/welcome.

Feature highlights

Listen to rich uncompressed multi-channel

surround sound

This Home Theater System supports 5.1

channels of uncompressed audio that delivers

a real-to-life sound experience as if you are

listening to it live.

USB direct

Simply plug your USB device into the USB jack

to play your MP3/WMA/JPEG/DivX ﬁles.

Sync the audio output with the video play

Synchronize audio and video by delaying the

audio output if the video signal sent to the TV

is slower than the audio streams.

Screen Fit

View the movie in full screen display on any

TV.

Karaoke scoring function

Karaoke scoring gives a score and a comment

for each performance. Have your singing

performance scored for even more karaoke

fun at home!

k Numeric buttons

Selects an item to play.•

l SUBTITLE

Selects the subtitle language on a• disc.

m VOCAL

Changes the audio channel of a• karaoke disc.

n MIC (VOL +/-)

Increases or decreases microphone• volume.

o REPEAT / PROGRAM

Selects or turns off repeat or shufﬂe• mode.

In radio mode, resets the list of• preset stations: press to manually

reset; press and hold to automatically

reset.

p OK Conﬁrms an entry or selection.•

q BACK

Returns to a previous screen.• For DVD, goes to the title menu.• For VCD version 2.0 or SVCD with• PBC turned on, returns to the menu

during playback.

r / (Previous/Next)

Skips to the previous or next title,• chapter, or track.

s (Mute)

Mutes or restores audio output.•

t VOL +/-

Increases or decreases volume.•

u SOUND

Selects a predeﬁned sound effect.•

v ZOOM

Zooms in or out of the picture.• Fits the picture format to the TV• screen (using zoom function: 1.3X

and 1.6X).

b (Open/Close)

Opens or closes the disc• compartment.

c Source buttons

• AUDIO SOURCE: Selects an audio

input source.

• RADIO: Switches to FM band.

• USB: Switches to the USB source.

• DISC: Switches to the disc source.

d SETUP

Accesses or exits the setup menu.•

e (Navigation buttons)

Navigates through the menus.• Press left and right for fast backward• or forward search.

In radio mode, press up and down to• tune the radio frequency.

In radio mode, press left or right to• start auto search.

f INFO

For discs, displays information about• the current status or the disc.

For slideshows, displays a thumbnail• view of photo ﬁles.

g (Play/Pause)

Starts, pauses or resumes disc play.• In radio mode, automatically tunes• radio stations during ﬁrst-time setup.

h (Stop)

Stops disc play.• In radio mode, erases the current• preset radio station.

i SURR (Surround Sound)

Switches to supported surround• sound or stereo sound.

j AUDIO SYNC

Selects an audio language or channel• on a disc.

Press and hold to access the setting• for audio sync, then press VOL +/- to

set the audio delay time.

Your HomeTheater System English

w KARAOKE

Accesses or exits the karaoke menu.•

Main unit

a (Standby-On)

Turns on the Home Theater System• or switches to standby mode.

b Disc compartment

c (Open/Close)

Opens or closes the disc• compartment.

d (Play/Pause)

Starts, pauses or resumes disc play.• In radio mode, automatically tunes• radio stations during ﬁrst-time setup.

e (Stop)

Stops disc play.• In radio mode, erases the current• preset radio station.

f SOURCE

Selects a media to play or listen to• audio from the connected device.

g Display panel

h VOLUME

Increases or decreases volume.•

i MICConnects a microphone.•

j (USB)

Connects a USB supported device.•

a b cdefgh ij

1 Place this Home Theater System near the

TV.

2 Place the speakers system at normal

listening ear-level and directly parallel to

the listening area.

3 Place the subwoofer at the corner of the

room or at least 3 feet away from the TV.

Tip

To avoid magnetic interference or unwanted• noise, never place this Home Theater System

too close to any radiation devices.

Connect video cables

Connect this HomeTheater System toTV to

view disc play. Select the best video connection

that theTV can support.

Option 1: Connect to the VIDEO jack• (for a standard TV).

Option 2: Connect to the component• video jacks (for a standard TV or

Progressive Scan TV).

Note

You must connect this Home Theater System• directly to a TV.

FRONT

RIGHT

FRONT

LEFT

CENTER

REAR

RIGHT

REAR

LEFT

SUBWOOFER

3 Connect

Make the following connections to use your

HomeTheater System.

Basic connections:

Video• Speakers and subwoofer• Power•

Optional connections:

Radio antenna• Audio• Audio from TV• Audio from cable box/recorder/• game console

Other devices• USB device•

Note

Refer to the type plate at the back or bottom• of the product for identiﬁcation and supply

ratings.

Before you make or change any connections,• ensure that all the devices are disconnected

from the power outlet.

Place the HomeTheater

System

Place the Home Theater System where• it cannot be pushed, pulled over or

knocked down. Do not place it in an

enclosed cabinet.

Be sure that you have full access to the• power cord for easy disconnection of the

Home Theater System from the power

supply.

Connect English

Option 2:Connect to the component

video jack

1 Connect the component video cable

(not supplied) to the Y Pb Pr jacks on

this Home Theater System and the

COMPONENT VIDEO input jacks on the

TV. If a progressive scan TV is used, you• may turn on the progressive scan

mode. (see ‘Get started’ > ‘Turn on

Progressive Scan’).

Note

The component video input jack on the TV• might be labeled as Y Pb/Cb Pr/Cr or YUV.

This type of connection provides good picture• quality.

VIDEO OUT

PrY

PbPr Y

Option 1:Connect to theVideo

(CVBS) jack

1 Connect a composite video cable to

the VIDEO jack on this Home Theater

System and the VIDEO input jack on the

TV.

Note

The video input jack on the TV might be• labeled as A/V IN, VIDEO IN, COMPOSITE or

BASEBAND.

This type of connection provides standard• picture quality.

VIDEO

VIDEO IN

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Philips Heimkinosystem Handbücher

Philips

Philips MCD139/All versions Bedienungsanleitung

Philips

Philips MX999 Bedienungsanleitung

Philips

Philips HTS3562 Bedienungsanleitung

Philips

Philips HTS3251B/F7 Bedienungsanleitung

Philips

Philips HTS6515D/37B Bedienungsanleitung

Philips

Philips HTS3180 Bedienungsanleitung

Philips

Philips HTB5510D Bedienungsanleitung

Philips

Philips LSBS5000 Bedienungsanleitung

Philips

Philips HTS3376 Bedienungsanleitung

Philips

Philips HTS7212/12 Bedienungsanleitung

Philips

Philips HTS3377/12 Bedienungsanleitung

Philips

Philips MCD139BDVD Bedienungsanleitung

Philips

Philips MX2500 Bedienungsanleitung

Philips

Philips HTS3011/98 Bedienungsanleitung

Philips

Philips HTS3377/05 Bedienungsanleitung

Philips

Philips HTD3520 Bedienungsanleitung

Philips

Philips HTS3164/12 Bedienungsanleitung

Philips

Philips MCD196/58 Bedienungsanleitung

Philips

Philips MX990DHT Montage- und Bedienungsanleitung

Philips

Philips HTS3520/05 Bedienungsanleitung

Philips

Philips HTS3156/98 Bedienungsanleitung

Philips

Philips HTS9800W/37B Bedienungsanleitung

Philips

Philips HTS3260/12 Bedienungsanleitung

Philips

Philips Walita HTS3152 Bedienungsanleitung

Beliebte Heimkinosystem Handbücher anderer Marken

Samsung

Samsung HT-ES4200K Bedienungsanleitung

Harman Kardon

Harman Kardon HS 100 Bedienungsanleitung

Samsung

Samsung HT-P10 Bedienungsanleitung

Goodmans

Goodmans GDVD19SWS Bedienungsanleitung

Moxi

Moxi media center Bedienungsanleitung

Samsung

Samsung HT-EM35 Bedienungsanleitung

LG HE903PAW Bedienungsanleitung

Bose

Bose SoundTouch 520 Bedienungsanleitung

Sony

Sony BDV-N990W Bedienungsanleitung

Manta

Manta GK-500 Bedienungsanleitung

Sharp

Sharp SBW800 Bedienungsanleitung

LG LHT799 Bedienungsanleitung

Samsung

Samsung HT-TWZ415 Bedienungsanleitung

Loewe

Loewe REFERENCE 52 SL FHD+ 200 NMP Bedienungsanleitung

Samsung

Samsung AH68-02166R Bedienungsanleitung

RCA

RCA 600-Watt Bedienungsanleitung

Sony

Sony HT-7100DH Bedienungsanleitung

Samsung

Samsung HT-DS630T Bedienungsanleitung
