Philips MCD139B/05 Bedienungsanleitung

MCD139B

Quick Start Guide

What’s in the Box?

You should find these items upon opening the box.

PROG

GOTO

VOL

ZOOM

DSC

DBB

SUBTIT LE

Quick Start Guide

Composite Video Cable DIN cable Remote control with one

CR2025 battery loaded

FM wire antenna Quick start guide User manual

MCD139B QSG_12_Eng 2007.5.23, 15:581

Important!

–This set can only be operated after the

supplied DIN cable has been connected.

Tips

–For connecting to a Progressive Scan

TV, refer to the user manual for proper

connections and detailed setup.

Connect the speaker wires of the right speaker and subwoofer to the

left speaker.

Connect the left speaker and the DVD player by using the supplied

DIN cable.

Connect the DVD player to your TV using the supplied composite video

cable.

Connect the VCR or cable/satellite box to the TV system. Connect AUX

IN 1 jacks to the AUDIO OUT jacks on theVCR or cable/satellite box.

Connect the supplied FM wire antenna.

Setting up the TV

Press SOURCE on the set (or DISC on the remote) to select disc source.

Turn on the TV and set it to the correct Video In channel.

ATo listen to TV channels through this system, use the

audio cable (white/red, not supplied) to connect

AUX IN 1 (L/R) jacks to the corresponding AUDIO

OUT jacks on the TV set.

BTo listen to TV channels through this system, use the

audio cable (white/red, not supplied) to connect

AUX IN 1 (L/R) jacks to the HEADPHONE jack on

the TV set.

●Before starting operation, press AUX1/2/TV on

the remote control to select “AUX 1” to activate

the input source.

●See the User Manual for other TV connection options.

AC Power Cord

Connect the AC power cord to the wall socket.

OUT

MCD139B QSG_12_Eng 2007.5.23, 15:582

Tip

See chapters "Getting Started" and "DVD menu operations" in the

User Manual for detailed descriptions.

Setting DVD menu options

IMPORTANT!

If the progressive scan feature is activated but the connectedTV does not support

progressive signals or the video cables are not connected accordingly, see the user

manual for proper progressive scan setup or deactivate the progressive scan

feature as below:

1)Turn off your TV progressive scan mode then turn on to interlaced mode.

2) Select “OFF” in PROGRESSIVE menu of the system setup menu to turn off

progressive scan, then press SYSTEM MENU on the remote to exit the system

menu.

Or To turn off progressive scan, you may also first press OPEN/CLOSE open the

disc door, then press

on the remote control, and press AUDIO on the remote.

Setting the clock

ETUMOIDU

In standby or any source mode, press and hold CLOCK on the remote control.

The clock digits will be lighted on the display.

Press ¡/ ™on the set repeatedly to set the hours.

Press à/ áon the set repeatedly to set the minutes.

VOL

Press CLOCK again to store the setting.

PHILIPS PHILIPS

PHILIPS

MCD139B QSG_12_Eng 2007.5.23, 15:583

Playing a disc

Push OPEN /CLOSEçto open the disc door.

Load in a disc with the label side facing up, then close the disc door.

Playback will start automatically. If not, pressÉÅ.

To stop playback, press 9.

PDCC-JS/JW-0719

CRoyal Philips Electronics N.V. 2007

http://www.philips.com

Tip

Detailed playback features and

additional functions are described in the

accompanied user manual.

Programming and tuning to radio stations

Press SOURCE (or TUNER on the remote) to select tuner source (FM).

Press and hold PROG on the set (or on the remote control) until “ START ” appears on

the display panel. The system starts to program all available stations in order of waveband.

Press ¡/ ™until the desired preset station is displayed.

To s witch on the system,

press STANDBY ONBor

SOURCE on the set, or

DISC,AUX1/2/TV or

TUNER on the remote.

Notes for the remote control:

–First, select the source you wish to

control by pressing one of the source

select keys on the remote control

(DISC or AUX1/2/TV, for example).

–Then select the desired function

(2;, í, ëfor example).

TUNING

MCD139B QSG_12_Eng 2007.5.23, 15:584
