Philips MCD177/58 Bedienungsanleitung

MCD177

Quick Start Guide

What’s in the Box?

You should find these items upon opening the box.

Quick Start Guide

Quick Start GuideAV cables (Y/W/R) Remote control with

battery

Power adaptor FM antenna

User Manual

Remove the plastic

protective sheet

MCD177_58_QSG_Eng 10/17/08, 10:421

Tip

See the User Manual for other TV

connection options.

Setting up the TV

Press SOURCE (DISC on the remote control) to select disc source.

Turn on the TV and set it to the correct Video In channel.

Y PB PR

ATo hear the sound of this DVD Player

through your TV, use the audio cables (white/

red, supplied) to connect LINE OUT (L/R)

jacks of the DVD Player to the

corresponding AUDIO IN jacks on the TV.

B To listen to TV through this system, use a

cinch cable (not supplied) to connect AUX

IN jack (3.5mm) to the corresponding

AUDIO OUT jacks on theTV set.

Y PB PR

Connect the speaker cables.

Connect the FM antenna.

Connect the composite video cable (yellow, supplied) to a TV.

Connect the power cords of the system and TV.

Notes for the remote control:

–First, select the source you wish to control by

pressing one of the source select keys on the

remote control (DISC or FM for example).

–Then select the desired function ( 2;, í,

ëfor example).

speaker

(right)

speaker

(left)

FM wire antenna

Power adaptor

MCD177_58_QSG_Eng 10/17/08, 10:422

Setting the clock

Setting DVD menu options

IMPORTANT!

If the progressive scan feature is activated but the connected TV does not support

progressive signals or the video cables are not connected accordingly, see the user manual

for proper progressive scan setup or deactivate the progressive scan feature as below:

1) Turn off your TV progressive scan mode then turn on to interlaced mode.

2) Select “OFF” in PROGRESSIVE menu of the system setup menu to turn off progressive

scan, then press SYSTEM MENU on the remote to exit the system menu.

Tip

See chapters "Preparations" and "System Menu Options" in the User

Manual for detailed descriptions.

– – Audio Setup Page – –

NIGHT MODE

DIGITAL Output

Dolby Digital Setup

Press DISPLAY/CLOCK agian to store the setting.

In standby mode, press and hold DISPLAY/CLOCK. The clock digits flash on

the display panel.

Press TUNING à/ á(or à/ áon the remote control) to set the

hours.

Press í/

ëto set the minutes.

Press PROG to select between 12 hour and 24 hour display.

– – Preference Page – –

Audio

Subtile

Disc Menu

Parental

Password

Divx Subtitle

Default

MCD177_58_QSG_Eng 10/17/08, 10:423

Playing a disc

Programming and tuning to radio stations

Press SOURCE (FM on the remote control) to select tuner source.

Press PROG for more than two seconds to program all available stations in order of

waveband.

Press í/

ëuntil the desired preset station is displayed.

Press OPEN•CLOSE 0to open the disc door and load in a disc, then press

the same button again to close the disc door.

➜Make sure the label side of the disc is facing up.

Playback will start automatically. If not pressÉÅ.

To stop playback, press 9.

Insert the USB device’s USB plug into the socket on the front panel of the main set.

Press SOURCE (or USB on the remote control) once or more to select USB.

Playing a USB mass storage device

With the Hi-Fi system, you can use USB flash memory (USB 2.0 or USB1.1),

USB flash players (USB 2.0 or USB1.1), memory cards (requires an additional card reader to

work with this Hi-Fi system).

Play the USB’s audio files as you do with the albums/tracks on a CD.

Tip

Detailed playback features and additional functions are described in the

accompany owner's manual.

PDCC-JH-0839

CRoyal Philips Electronics N.V. 2008

http://www.philips.com

MCD177_58_QSG_Eng 10/17/08, 10:424
