PRO

MCD 705

Quick Start Guide

What’s in the Box?

You should find these items upon opening the box.

User Manual

Quick Start Guide

Quick start guide

User manual

4XSpeaker stands and wall

brackes with screws

Composite video and audio

cables

(yellow, white, red)

Remote control with two

AAA batteries

FM and MW antennas Control Cable

MCD705 QUG_Eng 2006.3.17, 16:461

Tips

–See the User Manual for otherTV

connection options.

– See the related part in the User

Manual if you want to mount the

speakers on the wall.

–For connecting to a Progressive Scan

TV, refer to the user manual for proper

connections and detailed setup.

WOOFER(4Ω)FRONT(8Ω)REAR(8Ω)

REAR(8Ω)L

FRONT(8Ω)

CENTRE(8Ω)L

Setting up the TV

Press SOURCE (DISC on the remote) to select disc source.

Turn on the TV and set it to the correct Video In channel.

Connect the speaker cables.

Connect the MW and FM antennas.

Connect the control cable.

Connect the composite video and audio cables to a TV.

Connect the power cords of the system and TV.

Front Speaker

(Left)

Center

Speaker

Rear

Speaker (Left)

Rear Speaker

(Right)

Front Speaker

(Right)

Subwoofer

AC power

MCD705 QUG_Eng 2006.3.17, 16:462

Setting the clock

In standby mode, press and hold CLOCK on the remote.

When the hour digits flash, turn VOLUME-/+ on the system or press VOLUME+/- on the

remote to set the hours.

Press CLOCK again and the minute digits flash.Then turn VOLUME-/+ on the system or

press VOLUME+/- on the remote to set the minutes.

Press CLOCK again to confirm the time setting.

Setting DVD menu options

IMPORTANT!

If the progressive scan feature is activated but the connected TV does not support

progressive signals or the cables are not connected accordingly, see the user

manual for proper progressive scan setup or deactivate the progressive scan

feature as below:

1) Turn off your TV progressive scan mode or turn on to interlaced mode.

2) Press SYSTEM on the remote to exit the system menu and then DISC to exit

progressive scan.

Tip

See chapters "Preparations" and "DVD Menu Options" in the User

Manual for detailed descriptions.

DIVX(R) VOD

MCD705 QUG_Eng 2006.3.17, 16:463

Press OPEN •CLOSEç(çon the remote) to open the disc tray and load in a disc,

then press the same button again to close the disc tray.

➜Make sure the label side of the disc is facing up.

Playback will start automatically. If not pressÉÅ.

To stop playback, press PRESET-/9(9on the remote).

Playing a disc

Programming and tuning to radio stations

Press SOURCE (TUNER on the remote) to select tuner source.

Press PROG on the remote for more than two seconds to program all available stations in

order of waveband.

Press PRESET+/- (CH +/- (¡/ ™)on the remote) until the desired preset station is

displayed.

Tip

Detailed playback features and

additional functions are described in the

accompany owner's manual.

PDCC-JS/JW-0535

2005 CKoninklijie Philips Electronics

http://www.philips.com GB

OPEN/CLOSE

Notes for remote control:

–First, select the source you wish to control by

pressing one of the source select keys on the remote

control (DISC orTUNER, for example).

–Then select the desired function (

for

example).

MCD705 QUG_Eng 2006.3.17, 16:474
