MCD 709

Quick Start Guide

What’s in the Box?

You should find these items upon opening the box.

User Manual

User manual

Remote control with two

AAA batteries

FM and MW antennas

Control Cable Composite Video Cable

Quick Start Guide

Quick start guide

MCD709 QUG_Eng-12 2006.6.8, 15:551

Tips

–See the User Manual for other TV

connection options.

–For connecting to a Progressive Scan

TV, refer to the user manual for proper

connections and detailed setup.

Setting up the TV

Press SOURCE (DISC on the remote) to select disc source.

Turn on the TV and set it to the correctVideo In channel.

Connect the speaker and subwoofer cables.

Connect the MW and FM antennas.

Connect the control cable.

Connect the composite video to a TV.

Connect the power cords of the system and TV.

AC power

FM antenna MW antenna

Speaker

(right)

Speaker

(left)

Subwoofer

MCD709 QUG_Eng-12 2006.6.8, 15:562

Setting the clock

In standby mode, press and hold CLOCK/RDS on the remote.

When the hour digits flash, turn VOLUME-/+ on the system or press VOLUME+/- on the

remote to set the hours.

Press CLOCK/RDS again and the minute digits flash.Then turn VOLUME-/+ on the

system or press VOLUME+/- on the remote to set the minutes.

Press CLOCK/RDS again to confirm the time setting.

Setting DVD menu options

IMPORTANT!

If the progressive scan feature is activated but the connected TV does not support

progressive signals or the cables are not connected accordingly, see the user

manual for proper progressive scan setup or deactivate the progressive scan

feature as below:

1) Turn off your TV progressive scan mode or turn on to interlaced mode.

2) Press SYSTEM on the remote to exit the system menu and then DISC to exit

progressive scan.

Tip

See chapters "Getting Started" and "System Menu Options" in the

User Manual for detailed descriptions.

IMPORTANT!

– To set clock in the Eco Power mode, press and hold ECO POWER/

STANDBY-ON

on the set for 3 seconds or more to switch to normal

standby mode first before proceeding with the procedures below.

MCD709 QUG_Eng-12 2006.6.8, 15:563

Playing a disc

Press OPEN •CLOSEç(çon the remote) to open the disc tray and load in a disc,

then press the same button again to close the disc tray.

Load in a disc with the label side facing up.

Playback will start automatically. If not pressÉÅ.

To stop playback, press PRESET-/9(9on the remote).

Programming and tuning to radio stations

Press SOURCE (TUNER on the remote) to select tuner source.

Press PROG on the remote for more than two seconds to program all available stations in

order of waveband.

Press PRESET+/- (CH +/- (¡/ ™)on the remote) until the desired preset station is

displayed.

PDCC-JS/JW-0623

2005 CKoninklijke Philips Electronics N.V.

http://www.philips.com

Tip

Detailed playback features and

additional functions are described in the

accompany owner's manual.

Notes for remote control:

– First, select the source you wish to control by

pressing one of the source select keys on the

remote control (DISC or TUNER, for example).

–Then select the desired function (

for example).

MCD709 QUG_Eng-12 2006.6.8, 15:564
