Philips 32HFL2839T/12 Kurzanleitung

For technical support:

https://philipshtv.supportsystem.com

Studio Range - xxHFL2839

Software upgrade - and Instant Initial Cloning

procedure

v1.0

For technical support:

https://philipshtv.supportsystem.com

1. Software upgrade

1.1 Virgin mode

When the installation wizard is displayed, it is possible to directly upgrade the software

from the TV. To be able to upgrade you need to have a USB stick plugged in with a valid

software before starting the TV.

A valid software version to be recognized by the tv should be named

VES161HE_upgrade.bin into the root of a usb device. The software file called

VES161HE_upgrade.bin for your xxHFL2839 product is delivered into the package next

to this manual. Please follow below steps:

1. Copy the VES161HE_upgrade.bin file in the root directory of a formatted USB

device and connect the usb device to the usb input of the tv

2. If a valid software is found on the USB stick, you can upgrade the software by

pressing the RED button on the guest remote control.

3. After the software is loaded successfully, the TV will go to standby mode, program

the software in the TV while the red LED is flashing on the TV and boot up again

with the installation wizard when finished.

4. Remove the usb device

5. Done

For technical support:

https://philipshtv.supportsystem.com

1.2 Tv in on-state

A valid software version to be recognized by the tv should be named

VES161HE_upgrade.bin into the root of a usb device. The software file called

VES161HE_upgrade.bin for your xxHFL2839 product is delivered into the package next

to this manual. Please follow below steps:

1. Copy the VES161HE_upgrade.bin file in the root directory of a formatted USB

stick and connect the usb device to the usb input of the tv.

2. Press the following combination on the remote control `home1505`

3. A popup will now appear to request if the tv can proceed with the upgrade,

confirm with YES.

4. A progress bar will now appear, when finished the tv will restart automatically.

5. Remove the usb device

6. Done

Note: All software versions for all TV platforms can be accessed at any time at

www.philips.com/support

For technical support:

https://philipshtv.supportsystem.com

2. Instant initial cloning

Instant initial cloning allows you to copy all TV channels and settings without going

through the installation wizard. After creating a `masterclone file` on one `master tv`,

configuring the channel installation and all settings to be applied, instant initial cloning

can be done as follows:

1. Copy the masterclone file out of the master tv on a formatted usb device. This can

be done into the professional menu (319753mute) selecting `copy to usb`

2. On all other tv`s, during the first step of the installation wizard, (language

selection) insert the USB flash drive into the usb side connector.

3. Press the GREEN button on the remote and TV set will display the folder view of

the USB flash drive.

4. Select the folder which contains the cloning data which needs to be applied. After

selecting the folder press OK to start the upgrade process.

5. TV will display the OSD message the cloning data was uploaded and TV will reset.

6. When the process is complete, the TV will restart and display the switch ON

channel.

7. Remove the usb device, the tv is now configured with the new

settings/channellist.

8. Done

For technical support:

https://philipshtv.supportsystem.com

IMPORTANT: There is a difference in channel table xml naming (file after export)

between sw version v45.12 and v45.12.3. Loading the file into a higher or lower sw

version, you will have to change the naming accordingly.

Channel table naming to be used with sw v45.12: channelTable.xml:

Channel table naming to be used with sw v45.12.3: channelTable-00001.xml:

PASSWORD TO UNZIP THE SOFTWARE FILE:

2017-170224
