Philips GoGear SA178 Bedienungsanleitung

user manual

manuel d’utilisation | benutzerhandbuch | manual del usuario

gebruikershandleiding | manuale per l'utente | manual do usuário

användar-handbok

Digital Audio Player

Lecteur audio numérique | Digitaler Audio-Player | Reproductor de audio digital

Digitale audiospeler | Lettore audio digitale | Leitor Áudio Digital

Digital ljudspelare

SA170 COVER 1 8/25/05 12:11 PM Page 1

We hope you enjoy your product

Please visit www.philips.com/support and enter your product name to view:

- FAQ, Frequently Asked Questions

- Latest user manuals

- Latest PC software downloads

- Firmware upgrade files

Since it is possible for you to upgrade your product,

we recommend that you register your product on

www.philips.com/register

so we can inform you as soon as new free upgrades become available.

The model and production numbers can be found on the label close to the USB connector.

About your new product

With your newly purchased product, you can enjoy the following:

- MP3 and WMA playback (see MUSIC MODE section)

- FM radio*** (see RADIO MODE section)

- Recording: FM*** and voice (see MAKING RECORDINGS section)

***FM radio is only available to some regional versions.

Included accessories

Headphones USB cable

Neck-strap CDROM with user manual, drivers,

FAQ, music management softwares

SA170_ENGLISH.qxd 9/2/05 12:19 PM Page 1

Overview of controls and connections

1MIC Microphone

2pHeadphones jack

3HOLD Disable key press

4RESET Restore the player

5Display Dynamically displays menu, options and track information

6J( / )K Rewind / Fast forward; Up / Down to 1 level

2; Power on / off and Play / Pause; confirms a menu setting

Volume + / - Volume control; Scroll; Skip to previous / next

7REC Start or Stop Voice / FM recording***

8A - B Repeat or loop a sequence

9MENU For menu options

0USB slider Push USB connector in / out

!USB USB cable connector

***FM radio is only available to some regional versions.

SA170_ENGLISH.qxd 9/2/05 12:19 PM Page 2

Preparations

Install software

1Insert the supplied CD into your computer's CD-ROM drive.

If the CD does not autorun, please click the .exe file from the root directory of the CD.

2Select your language and follow screen instructions to complete installation of

Windows Media Player and Firmware Manager.

Powering your player

Your player has a built-in USB rechargeable battery. To charge your player, slide the USB connector to

the LOCK position. Connect your player directly to your computer's USB port.

➔A USB connection screen will show as soon as your player is connected.

Charge your player for 4 hours or until the battery icon stops blinking.

Note:You cannot charge your player when your computer is off.

Organize and transfer your music

Your player will appear as a new USB mass storage in Windows Explorer.

You can organize files and transfer music to your device during USB connection.

1Click and highlight one or more music track to transfer between your player and your computer.

2Use drag and drop actions to complete your transfer.

Safely disconnect your device

Exit any active application working with your player. Safely remove your device by clicking

from your task tray.

WINDOWS98SE USERS:There is no icon.

Simply disconnect your device after file transfer completes.

(File transfer completes when stops animating.)

ATTENTION!

WINDOWS 98SE USERS:

To avoid installation problems, DO NOT CONNECT your device to the computer

until AFTER installation completes.

SA170_ENGLISH.qxd 9/2/05 12:19 PM Page 3

Powering on / off

Power on: Press and hold 2; until the PHILIPS splash screen appears.

Power off: Press and hold 2; again until there is no display on the screen.

TIP

Your device automatically powers down if there is no operation and no music played for

the duration defined in SETTINGS > TIME OUT.

✔

Indication of power level

You can see the approximate power level of your batteries on the display.

Battery full Battery two-thirds full

Battery half full Battery low

Battery empty

TIP

When the batteries are nearly empty, the battery low screen blinks.

Your device will power down in less than 60 seconds.

Your device will save all settings and un-finished recordings before it powers down.

✔

SA170_ENGLISH.qxd 9/2/05 12:19 PM Page 4

Root menu

When your device powers up, you will see the Root menu. Otherwise, press and hold MENU to go

to the root menu.

Navigation

Your device has an intuitive menu navigation system to guide you through various settings

and operations. Use +,-,J( ,)K to browse through menus. Press 2; to confirm your selection.

To exit any current mode or play activity, press MENU or the J( key.

Music enter to play your digital music tracks

Radio enter to listen to your radio presets

Recordings enter to play and manage recordings

Folder enter to browse your music tracks or recordings by folders

SA170_ENGLISH.qxd 9/2/05 12:19 PM Page 5

MUSIC mode: Playback (also applicable to playback

of recordings)

From the root menu, select MUSIC to enter the MUSIC library. Your device will play all your music

alphabetically in the music library as you press 2;.

Go to next track Press )K

Go to previous track Press J(

Pause music Press 2; during playback

Forward search Press and hold )K

Backward search Press and hold J(

Volume control + / -

Basic Operation Controls to press

Folder view

1The Folder view will display your music and recordings in alphabetical order.

From the root menu, select FOLDER to enter the folder view.

The FOLDER view will display your music according to how you arrange them in folders

when you transfer by drag and drop.

Folders and tracks will be listed according to alphabetical order.

2Use the +key to go to the previous track or folder.

Use the -key to go to the next track or folder.

Use the )K key to go into a folder.

Use the J( key to go up one folder level.

3Press 2; to select an item.

➔A small pop-up window comes up.

4Select Play to start playing all the tracks from the selected point in the chosen folder.

Select Delete to delete the chosen item.

TIP

You can only delete tracks (but not folders) in the folder view.

✔

SA170_ENGLISH.qxd 9/2/05 12:19 PM Page 6

Advanced features in playback

A-B REPEAT

To repeat or loop a sequence in a track:

1Press A-B at your chosen starting point;

➔appears on the screen.

2Press A-B again at your chosen end point;

➔appears on the screen, and the repeat sequence begins.

PLAY MODES

You can set your device to play music tracks randomly (Shuffle ) and / or

repeatedly (repeat ).

Changing play modes

1Press MENU. Select Play modes.

2Use scroll controls to select the following options.

Off Normal playback

Repeat 1 Play one track repeatedly

Repeat all Play all tracks repeatedly

Shuffle Play all tracks randomly

Shuffle repeat Play all tracks randomly and repeatedly

Repeat folder Play all tracks within folder repeatedly

Shuffle folder Play all tracks within folder randomly

Icon Meaning

SA170_ENGLISH.qxd 9/2/05 12:19 PM Page 7

EQUALIZERS

You can set your device to play music tracks with different EQ (equalizers).

Changing equalizers

1Press MENU. Select EQUALIZER.

2Use scroll controls to select Rock,Funk,Jazz,Classic, Hip Hop, Dance, Custom, or Off.

Custom EQ

The Equalizer custom setting provides 5 adjustable bands: Bass, Low, Mid, High and Treble.

1Press MENU. Select EQUALIZER > Custom.

2Press J( or )K to select your band.

➔Selected band flashes.

3Press +once or more to increase the band setting.

Press -once or more to reduce the band setting.

4The newly set custom eq can be immediately heard if you are playing music

TIP

- The Custom EQ screen times out when there is more than 5 seconds of inactivity.

✔

SA170_ENGLISH.qxd 9/2/05 12:19 PM Page 8

Radio mode***

From the root menu, select RADIO to enter the radio mode.

Manual tune

1From the root menu, select RADIO to enter the radio mode.

2Press MENU. Select Manual Tune. Press 2; to confirm.

3Press J( and )K to search the station or press and hold )K to search for the

next available station.

4Press 2; to save your preset.

Auto tune

1Press MENU. Select Autotune. Press 2; to confirm.

➔Your device will automatically select up to 30 strongest available

stations.

Playing a preset station

1From the root menu, select RADIO to enter the radio mode and tune

to your preferred station.

2Press J( to scroll up or )K to scroll down for your preset.

3The preset will be automatically played.

***FM radio is only available to some regional versions.

SA170_ENGLISH.qxd 9/2/05 12:19 PM Page 9
