Philips PSA235/00 Bedienungsanleitung

user manual

manuel d’utilisation | benutzerhandbuch | manual del usuario

gebruikershandleiding | manuale per l'utente | manual do usuário

användar-handbok

Digital Audio Player

Lecteur audio numérique | Digitaler Audio-Player | Reproductor de audio digital

Digitale audiospeler | Lettore audio digitale | Leitor Áudio Digital

Digital ljudspelare

psa235 COVER 1 17/6/05 10:14 Page 1

We hope you enjoy your product.

Please visit www.philips.com/support to view:

- FAQ, Frequently Asked Questions

- Latest user manuals

- Latest PC software downloads

- Firmware upgrade files and Device Manager

Since it is possible for you to upgrade your product,

we recommend that you register your product on

www.philips.com/register

so we can inform you as soon as new free upgrades become available.

The model and production numbers can be found inside the battery compartment.

About your new product

With your newly purchased product, you can enjoy the following:

- MP3 and WMA playback (see MUSIC MODE section)

- FM radio*** (see RADIO MODE section)

- Workout progress tracking

***FM radio is only available to some regional versions. FM radio is currenlty not available in Europe.

Included accessories

Headphones USB cable

1 x AAA Armband

CDROM with user manual, drivers, FAQ, music management softwares

PSA235_ENG.qxd 15/8/05 17:50 Page 1

About Batteries

You can use the following batteries with your device:

- normal batteries type LR03, UM4 or AAA (preferably Philips); or

- alkaline batteries type LR03, UM4 or AAA (preferably Philips); or

- rechargeable batteries type LR03, UM4 or AAA (preferably Philips)

Note: Remove batteries if they are empty or if the player is not going to be used for a long time.

Inserting batteries

Use an appropriately-sized coin to twist

anti-clockwise to unlock the back cover.

Insert a new battery with correct polarity.

(See printed label in battery compartment.)

Match the latches on the cover with the slots

on your device. Twist clockwise gently to

replace the back cover.

TIP

You can also twist open the cover without using a coin.

Grip on the rubber part of the back cover. Without moving your gripping

point, gently twist anti-clockwise to open.

✔

PSA235_ENG.qxd 15/8/05 17:50 Page 2

Powering on / off

Power on: Press and hold 2;.

➔PHILIPS splash screen appears briefly

Power off: Press and hold 2; again.

TIP

Your device automatically powers down if there is no operation and no

music played for 10 minutes. Last playback status / screen will be resumed

at next powering on.

✔

Indication of power level

You can see the approximate power level of your batteries on the display.

Battery full

Battery two-thirds full

Battery half full

Battery low

Battery empty

Note: Rechargeable batteries shows lower voltage levels when compared to alkaline ones.

Batteries contain chemical substances, so they should be disposed of properly.

TIP

When the batteries are nearly empty, the battery low screen blinks and

the beep tone sounds once.

When you hear a double beep, your device will power down.

Your device will save all settings and un-finished tracking before it powers down.

✔

PSA235_ENG.qxd 15/8/05 17:50 Page 3

Front of device

1Talking stopwatch Activates voice feedback telling you "elapsed time"

2Stopwatch Press to start, pause, or reset

3Previous Rewinds / Up 1 level / Skip to previous

4Display Dynamically displays menu, options and track information

5VOL - / Move down Navigate down / volume down in playscreeen

6VIEW To switch between root menu, library and now playing screens

7Next Fast forward / Down to 1 level / Skip to next

8Lock key Disables / enables key lock and ShockLock

92; Power on / off and Play / Pause

0VOL + / Move up Navigate up / volume up in playscreeen

PSA235_ENG.qxd 15/8/05 17:50 Page 4

Back of device

1Battery

2Card slot Mini SD Insert your mini SD* card here for memory expansion

3USB jack

4Back cover Insert a coin here to twist open / close back cover;

connects to arm band

5pAudio jack

*SD card is not by-packed.

PSA235_ENG.qxd 15/8/05 17:50 Page 5

Root menu

When your device powers up, you will see the ROOT MENU.

***FM radio is only available in some regional versions. FM radio is currenlty not available in Europe..

Navigation

Your device has an intuitive menu navigation system to guide you through various

settings and operations. Use 3,4,1,2to browse through menus. Press 2to

confirm your selection.

Music enter to play your digital music tracks

Radio*** enter to listen to your radio presets

Sport enter to view your workout summary

Settings enter to customize settings for your device

TIP

Select Shuffle All to play all your device music in a random way.

Smart Hide is a function to hide some library information. With Smart Hide, you can scroll

faster to the right content by hiding albums and artists which contain songs that are fewer

than a specified number.

Smart Hide 1 will hide all artists and albums that has only 1 track in the library.

Smart Hide 2 will hide all artists and albums that has only 2 or fewer tracks in the library.

Smart Hide 3 will hide all artists and albums that has only 3 or fewer tracks in the library.

Smart Hide 4 will hide all artists and albums that has only 4 or fewer tracks in the library.

✔

PSA235_ENG.qxd 15/8/05 17:50 Page 6

Music mode

We have put some music tracks on your device so that you can jump start your music experience.

You can also transfer your digital music collection from your computer to your device through the

included music management software.

(see GETTING DIGITAL MUSIC ON YOUR DEVICE for more information)

IMPORTANT!

We recommend that you the Sync function in Windows Media Player 10 to

transfer music to your player.

Searching for your desired music

1From the root menu, select MUSIC to enter the music mode. As you enter the music

mode, you can search from the following display options:

2Press 3to scroll up or 4to scroll down for your option.

Press 2for next or 1for previous levels.

3Press 2; to play your selection.

TIP

You can also press and hold 3or 4key to SuperScroll.

An enlarged head letter will show as the tracks scroll

quickly.

Stop pressing when you have arrived at your desired

head letter.

✔

Playlists Playlists

collections

Tracks listed in

play order

All songs Shuffle All

Alphabetically

listed tracks

Alphabetically

listed albums

Artists Alphabetically

listed artists

Alphabetically

listed artists

Genres Alphabetically

listed genres

Tracks listed in

album order

Albums Alphabetically

listed albums

Tracks listed in

album order

Alphabetically

listed albums

Tracks listed in

album order

Note: If your music is missing any ID3 tag information, then your may find empty fields or an indication

stating "No artist found" or "No album found" or "No genres found".

PSA235_ENG.qxd 15/8/05 17:50 Page 7

Playback

The keys: 2; ,0,5,3,7(see drawing on page 4) are multi-funtional. They work according to

how you press them: press or press and hold. During music playback, you can do the following:

Pause music Press 2; during playback

Go to next track Press 7

Go to previous track Press 3

Forward search Press and hold 7

Backward search Press and hold 3

Volume control 0/ 5

Basic Operation Controls to press

Customizing playback

Changing play modes

1From the root menu, select Settings.

2Use scroll controls to select the following options. Press 2; to confirm your selection.

Press 2; to deselect a checked option.

Changing Bass Enhancement

1From the root menu, select Settings > DBB.

2Use scroll controls to select On or Off.

Changing equalizers

1From the root menu, select Settings > EQ.

2Use scroll controls to select Rock,RnB,Electronica,Hip Hop,Classical,Jazz.

Shuffle On Off

Repeat Off On

Shuffle and repeat On On

Normal Off Off

Play mode Shuffle Repeat

PSA235_ENG.qxd 15/8/05 17:50 Page 8

Getting digital music onto your device

Before you can transfer your MP3 and/or WMA collection to your device using Windows Media

Playe, you need to have both Windows Media Player and Philips Device Manager installed on your PC

as follows:

Install Philips Device Manager and Windows Media Player

1Insert the supplied CD into your computer's CD-ROM drive.

If the CD does not autorun, please click the .exe from the root directory of the CD.

2Select your language and follow screen instructions to complete installation of Philips

Philips Device Manager and Windows Media Player.

Connect your device to the computer

1Connect your device to your computer using the supplied USB

cable. A USB connection animation will be shown as soon as your

device is connected.

2You can organize files and transfer music to your device during

USB connection.

Organize and transfer your music using Windows Media Player 10

1Launch Windows Media Player from Windows desktop or Start menu.

2To transfer files from your computer to your device, click Copy to CD or Device / Sync tab.

3In the Items to Copy pane, in the drop-down list, click the playlist, category, or other item that

you want to copy.

4Clear the check boxes next to any files you do not want to copy.

5In the Items on Device pane, in the drop-down list, click the device that you want to copy files

to. i.e. PHILIPS GoGear / PHILIPS device.

6Click the Start Sync button.

Music files may be transferred using Windows Explorer (by drag and drop) to your

device only if they are saved in the following folder: "media"

If your Windows Media Player is open when you connect your device, your device

may not be recognized.

To transfer music files to the mini-SD card, you must format the mini-SD card the frist time

it is inserted to the device, and keep using it with the device. Otherwise, files transferred

cannot be recognized in Windows Media Player or Windows Explorer.

✔

PSA235_ENG.qxd 15/8/05 17:50 Page 9
